Dacor ECS Technical manual

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 1.1
27”, 30”, 36” Wide, Single,
Classic Wall Ovens
ECS, MCS, & PCS
CUTOUT DIMENSIONS
Models “A” Cutout Height “B” Cutout Width “C” Min. Cabinet Width Oven Overlays
27” 27 3/8” (695mm) 25 1/2” (648mm) 27” (686mm)
3/4” (19mm) Each Side; 15/16” (24mm) Top;
1/16” (1mm) Bottom
30” 28 1/2” (724mm) 30” (762mm)
36” 27 3/4” (705mm) 34 1/2” (876mm) 36” (914mm)
“C”
“A”
“B”
1“ (25mm) Min.
Clear to Top of
Door for Heat
Exhaust
Alternate
Electrical
Location
Recommended
Electrical
Location
Alternate
Electrical
Location
1“ (25mm) Min.
2
33
1
36”
(914mm)
typ.
2 1/2”
(64mm)
to finished
Countertop
“A”
“B”
1“ (25mm) Min.
to Combustible Floor
4“ Typical Toe Kick
Alternate
Electrical
Location
Recommended
Electrical
Location
1 1/2”
(38mm)
Typical Counter
33
2
1
CUTOUT DIMENSIONS
INSTALLED UNDER-COUNTER
NOTES:
1. 24” (610mm) minimum interior cabinet depth.
Back of cabinet may need to be removed.
2. 3/4” (19mm) support platform (flush with cutout).
3. 1/8” (3mm) minimum clearance to adjacent cabinet
doors/drawers.
4. Not approved in a stack configuration.
5. See the Combination Installation (CI) Section if
installing with a microwave, cooktop, or downdraft.
091605 1/2

PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: [phone]
Specifications are subject to change without notice.
See installation instructions for additional details. 1.2
27”, 30”, 36” Wide, Single,
Classic Wall Ovens
ECS, MCS, & PCS
Models
Dedicated Circuit
Required
Total
Connected Load
Approximate
Shipping
Weight
27” 208/240VAC,
4-wire,
60Hz, 30A
(Breaker)
208VAC,
5.2kW (25A)/
240VAC,
5.2kW (22A)
240 lbs.
30”
36”
240VAC,
4-wire,
60Hz, 30A
(Breaker)
240VAC,
7.0kW (29A) 290 lbs.
OVEN HANDLE DIMENSIONS
TOP VIEW
OVERALL DIMENSIONS
Models
“A” Oven Width “B” Overall Height “C” Recess
Width
27” 27” (686mm) 28 3/8” (721mm) 6 3/16” (157mm)
30” 30” (762mm)
36” 36” (914mm) 28 1/8” (714mm) 8 3/16” (208mm)
23 7/8"
(606mm)
“B”
1"
(25mm)
8"
(203mm)
“C”
"A"
5 1/4"
(133mm)
60" (1524mm)
Flexible conduit
Rotating
elbow
3 5/8"
(92mm) 1"
(25mm)
EPICURE™
1"
(25mm)
MILLENNIA™
2 3/8"
(60mm)
PREFERENCE™
24"
(610mm)
21"
(533mm)
Oven
cabinet
top view
Open door
Back of
control panel/
oven door
081705 2/2
