To Our Valued Customer:
Congratulations on your purchase of the very latest in Dacor * products! Our unique combination of features, style and
performance make us The Life of the Kitchen =, and a great addition to your home.
In order to familiarize yourself with the controls, functions, and full potential of your new Distinctive Appliance, we
suggest that you thoroughly read this use and care manual, beginning with the Important Safety Instructions
section.
All Dacor appliances are designed and manufactured with quality and pride, while working within the framework of our
company value. Should you ever experience a problem with your product, please first check the Before You Call for
Service section of this manual for guidance. It provides useful suggestions and remedies prior to calling for service.
Valuable customer input helps us to continuously improve our products and services, so please feel free to contact
our Customer Service Team for assistance with any of your product support needs.
Dacor Customer Service Team
1440 Bridge Gate Drive
Diamond Bar, CA 91765
Telephone:
Fax:
Hours of Operation:
Web Site:
[phone]
[phone]
Monday through Friday
6:00 A.M. to 5:00 P.M. Pacific Time
www.Dacor.com
Thank you for choosing Dacor for your home. We are a company built by families for families and we are dedicated
to serving yours. We are confident that your new Dacor product will deliver a high level of performance and
enjoyment for many years to come.
Sincerely,
The Dacor Customer Service Team
© 2007 Dacor, all rights resen,_,_

INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE
APPLIANCE.
CUSTOMER: READ THIS USE AND CARE MANUAL COMPLETELY
BEFORE USING THIS APPLIANCE. SAVE IT FOR FUTURE REFER-
ENCE. IT CONTAINS IMPORTANT USE AND CARE INFORMATION.
KEEPYOUR SALES RECEIPT OR CANCELED CHECK IN A SAFE
PLACE. PROOF OF ORIGINAL PURCHASE DATE IS REQUIRED FOR
WARRANTY SERVICE.
If you have any questions, call:
Dacor Customer Service Team
1 [phone] (U.S.A. and Canada)
Monday -- Friday 6:00 A.M.to 5:00 P.M.Pacific Time
Web site: www.Dacor.com
Have the complete model and serial number for your
appliance available. The numbers are found on the appli-
ance data plate, located inside the grill, below the control
panel. Open the door to expose the grill. On double ovens,
the plate is located behind the top grill. Write these num-
bers below for future reference.
Important Information About
Safety Instructions
The Important Safety Instructions and warnings in
this manual cannot cover all possible problems and condi-
tions that can occur. Use common sense and caution when
installing, maintaining or operating this appliance.
Always contact the Dacor Customer Service Team about
problems or conditions that you don't understand.
Safety Symbols and Labels
Model Number
Serial Number
Date of Purchase
View data plate
For service and warranty information see page 31.
Since Dacor continuously improves the quality and perfor-
mance of our products, we may need to make changes to
the appliance without updating this manual.
DANGER
store or USe c0mbustible,f!ammab!e0r exp!osivevapors and
liquids (such asgasoline)nside or in the vicinity ofthis or any
otherappliancelKeep itemsthatcould explode, suchas aerosol
cans away fromthe burnersand oven,Do notstore flammable or
explosive materials inadjacent cabinetsor areas.
WARNING
WARNING. NEVERcover any slots, holesor passages!n the
oven bottomor cover an entirerackwith matenalssuch as
. : ....
aluminumfoil. Doingsoblocks a!rflow throughthe oven and
may cause carbon monoxide poisoning.Aluminumfoil linings
may also trap heat; causing a fire hazard.
READ AND SAVE THESE INSTRUCTIONS
1

General Safety Precautions
To reduce the risk of fire, electric shock, serious injury or death when using your oven, follow basic safety precautions,
including the following:
WARNING
•If you receive a damaged product,immediately contact
your dealer or builder.Do not install or usea damaged
appliance.
• Makesure that the oven has been properlyinstalled
and grounded by a qualified installer accordingto the
accompanying installationinstructions. Have the installer
show you the locationof the fuse orjunction box so that
you know where and howto turn off powerto the oven.
• Do notinstall, repair or replaceany part of theoven unless
specifically recommendedin the literature accompanying
it.A qualified servicetechnicianshould performall other
service.
• Beforeperformingany type ofservice, make sure that
the electrical powerto the oven is turned off at the circuit
breakeror fuse box.
• Only usethe ovenfor cooking tasks expectedof a home
appliance as outlinedin this manual. This oven is not
intendedfor commercial use.
• DONOT TOUCHTHE SURFACESOF THE OVEN
DURINGOR IMMEDIATELYAFTERUSE.
•Makesure individuals who usethe ovenare able to operate
it properly.
• Never allowanyone, includingchildren tosit, stand or climb
on any partof the oven includingthe door.Doing so may
cause tipping, damage, serious injuryor death
• Do notleave childrenalone or unattended inthe area
around the oven. Do notallow childrento playwith the
controls, pull on the handle(s)or touch other parts of the
oven.
• Do notstore itemsof interest to childrenabovethe oven.
Children could be burned or injuredwhile climbing on the
appliance.
• Do nottamper with the controls.
• To preventthe unit from tippingforward and to provide
a stable installation, make surethe oven issecured to
the cabinet according to the accompanyinginstallation
instructions.
•Do notheat unopenedfood containerssuch as baby food
jars and cans Pressurebuild up may cause the container
to burst and cause injury.
• Do notuse water on greasefires.A violent steamexplosion
may result.Smother any flameswith a lid, cookiesheet
or flat tray. Use bakingsoda or a foam extinguisherto
extinguishflaming grease. Be careful to avoid getting
burned.
WARNING
•Keep flammableitems, such as paper,cardboard, plastic
and cloth awayfrom and out of the oven. Do not allow pot
holdersto touch hotsurfaces.
• Do notwear loose or hangingapparel while usingthe oven.
Donot allow clothing to come intocontact with the interior
ofthe oven and surroundingareas during and immediately
after use.
• Do notuse towels or bulky cloth as pot holders.
• Do not usethe ovenfor storage.
• Cleanand maintainthe oven regularly as instructed in this
manual. Keepthe entireoven free of greasethat could
catchfire.
• Do nottouch the outside surfaces ofthe ovenduringthe
self-cleancycle. They will be hot.
• Use cookwareonly for its intendedpurpose. Checkthe
manufacturer'srecommendationsbefore useto determine
if a utensil is suitable for useon in an oven. Certain types
of glass,ceramic and earthenware are not suitable for use
in the oven. Personalinjuryor damage may result from the
improperuse of cookware.
• Exercisecaution when opening the oven door.Let hot air or
steamescape before lookingor reaching inside.
• Use extremecaution ifadding water tofood in the oven.
The steam can cause serious burnsor scalds.
• Use only dry pot holderswhen removingfood and
cookwarefrom the oven. Wet pot holderscan causesteam
burns.
• Foryour safety,do not usethe oven to cookwithout the
convectionfilter(s) installed.When the filter is not installed,
the spinningfan bladesat the back of theoven are
exposed.
•Do notallow food to sit in the ovenfor morethan one hour
beforeor after cooking. Eatingspoiledfood can result in
food poisoning.
• Do not leavemetal objects, such as aluminumfoil, the meat
probe or cookie sheets on the bottomof the oven. Do not
allowthe broil elements onthe ceiling of the oven chamber
to be covered up. Do not linethe ovenwith aluminum foil or
other materials.Doing so may cause the oven or the items
in it to overheat, creating a fire hazardor causing property
damage.
• Non-stickcoatings when heated,can be harmful to birds.
Removebirdsto a separate, well-ventilatedroom during
cooking.
2

Model Identification
• The oven comes in three widths, 27 inches, 30 inches •
and 36 inches wide.
The oven also available in single and double oven
models.
Some double oven models are available with convec-
tion cooking in both the upper and lower oven cham-
bers. Other double ovens are equipped for convection
cooking in only the upper oven chamber.
Control Panel
Single
Oven
Style varies
Control Panel
Double
Oven
Style varies
Control Panel - Single Oven
_ _ _ _ _ _:_i!:7_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!_!
Control Panel - Double Oven with Convection Upper Oven Only
Control Panel -Double Oven with Upper and Lower Convection Oven
3

Partsof the Oven
[] Control Panel Your oven's control panel consists of keys and a display. Use the control panel to
control all the oven's features (sometimes called modes.)
[] Air Intake/Exhaust The oven draws air in through the intake slots to cool its internal parts. The air
Slots comes out through the exhaust slot at the bottom of the oven. Do not block or
cover the air intake or exhaust slots.
[] Meat Probe Connector When you use the meat probe, insert the skewer into the meat and plug the other
end into this connector. See the Using the Meat Probe section on page 17 for
proper operation. On double ovens, only the upper oven is equipped with a meat
probe connector.
[] Oven Lights There are two oven lights inside the oven chamber so that you can easily see the
food inside. Press the light key on the control panel to turn them on. The bulbs are
12 volt, 20 watt, halogen.
[] Rack Supports There are six sets of rack supports inside each oven chamber. They support the
adjustable oven racks. They are numbered from the bottom up.
[] Door Gasket The door gasket prevents heat from escaping when the door is closed.
[] Self-Clean Latch The self-clean latch automatically locks the oven door during the self-clean cycle.
The door latches for your safety. There are very high temperatures inside the oven
during the self-dean cycle.
[] Broil Elements The broil elements are located on the ceiling of the oven chamber. On some
models, they are hidden behind a glass panel. They are the source of top heat.
[] Convection Fan* The convection fan blows heated air into the oven chamber during the convection
cooking process. The convection filter covers it.
[] Convection Element* The convection element heats the air that is blown into the oven chamber by the
convection fan during the convection cooking process. The convection filter covers
it.
[] Convection Filter* The convection filter covers the convection fan. It helps prevent the transfer of
taste from one food to another when you are cooking a whole meal. It also keeps
the oven cleaner and covers the moving fan blades for safety purposes.
[] Oven Rack Your oven comes with one GlJdeRackTM oven rack and a set of standard racks. The
total number of racks depends on the model.
[] Bake Elements Hidden below the glass panel on the floor of the oven chamber are the bake ele-
ments. They are the source of bottom heat.
Some double ovens are not equipped for convection cooking in the lower oven. These models do not have a convec-
tion fan, element and filter in the bottom oven chamber.
4

JI
II
III
5

Control Panel Layout
[] START Key When you use the various features (or modes) on your oven, select the cook-
ing mode first, then press the START key. Also, use the START key to start the
timers.
[] Cooking Mode Keypad
[] CANCEL •SECURE Key
Select the type of cooking you want to perform by pressing one of the cook-
ing mode keys. Also includes the SELF-CLEAN and PROBE keys, and on double
ovens, the PROOF key. Double ovens have two cooking mode keypads, one for the
upper oven and one for the lower.
Use this key to turn off your oven. This key sets all temperature settings back to
zero and turns off any features (except the timer) that are currently in use. It also
activates the lock-out feature. On double ovens, there is a CANCEL • SECURE key
for each oven.
[] Display The control panel display provides various types of information about the oven,
including the current time (once the clock is set), the current cook settings and the
cooking temperature. See below for the symbols that appear on the display
[] Number Keypad When you want to set the temperature, cook time or the time, use the number
keypad.
[] Delay Timed Cooking Use these keys to set the oven to turn on or off automatically at a later time. On
Keys double ovens, there is a set of delay timed cooking keys for each oven. See page
15 for instructions.
[] TIMER Keys Use the TIMER 1 and TIMER 2 keys to time an event. The two timers operate
separately from each other. You can use them even if the oven is not in use. They
do not turn the oven on or off. See page 15 for instructions.
[] CLOCK Key Use this key to set the clock.
[] Light Key Located on the number keypad. If you need to turn the oven lights on or off, press
the light key.
[] Sabbath Key (#) Use this key to start Sabbath mode. See page 20 for details.
Display Symbols
Convection Bake Broil Roast 80 Meat Door Lock Timer Self-Clean
Probe (self-clean)
Q Q
Timer Numbers
6

Control Panel - Single Oven
Control Panel - Double Oven with Convection Upper Oven Only
Control Panel - Double Oven with Upper and Lower Convection Oven
7

Control Panel Settings
Setting the Time
To set the time:
,
,
Press the CLOCK key. The colon between the minutes
and seconds on the time display will begin to flash.
Enter the current time on the number keypad before
the colons stops flashing. For example: For 12:08,
press 1-2-0-8 on the keypad. Pressing the # key
changes the AM-PM indicator.
3. Press START.
IMPORTANT
of thetimers is in use or ifselFclean or Sabbath modeis
activel
•After a powerfailure, the time on the display may flash,
indicatingthat the time may n0t becorrect
!
•After pressing theclock key,you mustenter the time and
pressSTART soon afte_ard, If you wait longer than six
24/12 Hour Clock (Military Time)
The oven is set to 12-hour (non-military) time at the fac-
tory. 24 hour time is also known as military time.
1:36 PM = 13:36 military time.
If you want to switch the clock to 24 hour
time or switch from military back to regular
time:
1. Press and hold the clock key for six seconds. The
display will indicate the mode the clock is currently set
to, 12 Hr or 24 Hr.
2. Press the #key to change the clock mode. To leave
the setting as is, do not touch any keys.
3. Press CANCEL • SECURE to return to the main dis-
play. If you have set the clock to 24 hour time, the
keypad will allow you to enter military time when set-
ting the clock.
Setting the Temperature Scale
The control panel allows you to select the temperature
scale (Fahrenheit or Celsius) it uses to display the cooking
temperature. The oven is preset at the factory to Fahren-
heit.
To change the temperature scale:
1. Press and hold the BROIL key (under UPPER OVEN
on double ovens) for six seconds.
2. The display will indicate the temperature scale the
control panel is currently set to, "F" or "C".
3. Press the # key to change the temperature scale. To
leave the setting as is, do not touch any keys.
4. Press CANCEL • SECURE. The control panel will go
back to the regular clock display, set to the new tem-
perature scale.
Before Your Cook...
•When you use your oven to bake or roast, it preheats
automatically. The preheat cycle rapidly brings the
oven chamber up to the proper cooking temperature.
It takes several minutes to preheat the oven. Preheat
time depends on the temperature settings. The time
may be longer depending on the type of electrical
supply in your community. There is no preheat cycle
for any of the broil modes.
• After you pull food out of the oven, it will continue to
cook. This process is called "carry-over." The larger
the portion of food, the longer it will cook. It is best to
let the meat rest after it comes out of the oven for 10
to 15 minutes before carving. Doing so will allow the
meat to retain its juices and make it easier to carve.
• Dacor recommends turning the oven on for one hour
at 500°F to burn off any residual oils used during the
manufacturing process. Any of these oils left on the
inner parts can cause an undesirable smell the first
few times the oven is used.
8
