Daema RCG-118ER User manual

TITLES PAGE NO
GENERAL SAFETY PRECAUTIONS 1-2
PART IDENTIFICATION 3
SPECIFICATIONS 4
OPERATION INSTRUCTION 4-6
CARE AND CLEANING 6-7
Thank you for choosing DAEMA“Vacuum Cleaner, RCG-118ER”.
CONTENTS

For household use only!
When using your vacuum, basic safety precautions should always be observed, including
the following.
1. Do not leave vacuum cleaner unattended when it is plugged in. Unplug from outlet when
not in use and before pulling filters out.
2. To reduce the risk of electric shock-do not use outdoors or on wet surfaces.
3. Do not allow children to use as a toy. Close attention is necessary when used near
children.
4. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
5. Do not use with damaged cord or plug. Do not use vacuum cleaner if it has been
dropped, damaged, left outdoor, or dropped into water. Return appliance to the
appliance customer service for examination repair or adjustment.
6. Do not pull or carry by cord. Do not use cord as a handle. Close a door on cord, or pull
cord around sharp edges or corners. Do not run appliance over cord. Keep cord away
from heated surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
8. Do not handle plug or vacuum cleaner with wet hands. Dot not use outdoors or on wet
surfaces.
9. Do not put any objects into openings. Do not use with any openings blocked and do not
restrict airflow. Keep all opening free of dust, lint, hair, and anything that may reduce
airflow.
10. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving
parts.
11. Do not pick up hard or sharp objects such as glass nails, screws, coins, etc.
12. Do not pick up hot coals, cigarette, matches or any hot, smoking, or burning objects.
13. Do not use without filters in place.
14. Turn off all controls before plugging or unplugging vacuum cleaner.
15. Use extra care when vacuuming on stairs.
16. Do not pick up flammable or combustible materials (lighter fluid, gasoline, etc.) or use in
the presence of explosive liquids or vapour.
17. Do not pick up toxic material (chlorine bleach, ammonia, drain cleaner, etc.)
18. Do not in an enclosed space filled with vapours given off by oil based paints, paint
thinner, moth proofing, flammable dust, or other explosive or toxic vapours.
19. Always unplug this appliance before connecting or disconnecting vacuum hose. Do not
allow plug to whip when rewinding.
20. Use only on dry, indoor surfaces.
21. Do not use for any purpose other than described in this user’s guide.
22. Store your appliance indoor in a cool, dry area.
23. Keep your work area well dry.
24. Do not immerse the hand vacuum into water or other liquids.
25. Keep end of hose, wands and other openings away from your face and body.
26. Do not use the cleaner to clean your pets or any animal.
27. Keep the head (eyes, ear, mouth, etc.) away from the openings, when the cleaner is
working or plugging.
GENERAL SAFETY PRECAUTIONS

WARNING:
Important:
If the suction opening of the unit, the hose or the tube is blocked, switch off the vacuum
clearer and remove the blocking substance before you start the unit again.
1. Do not operate the vacuum cleaner too close to heater or radiators.
2. Before inserting the power plug into the wall outlet, make sure that your hands are dry.
3. Before you start the unit, make sure to remove large or sharp objects that might damage
the dust tank and hose.
4. When pulling out the power plug from the wall outlet, pull the plug not the power cord.
5. Do not use without all filters in place.
6. When using, if you learn of squeak from the cleaner, it must be suction appears to be
reduced, so you must stop (make sure the cleaner is not plugging), then clean the all air
filter.
Note:
If the supply cord is damaged, it must be replaced by manufacture, service agent or similarly
qualified person in order to avoid a hazard.
WARNING:
Hold the plug when rewinding the cord. Do not allow the cord to whip when rewinding.

Accessories
PART IDENTIFICATION
A. Floor Brush
B. Extension Tube
C. Hose
D. Manual Air Regulator
E. Hose Head
F. Cord Winder Button
G. Power Regulator
H. On/Off Switch
I. Dust Bag full Indicator
J. Clip To Open Dust Bag
Compartment
K. Handle
L. Dust Bag Compartment
Cover
M. Wheels
N. Plug Housing
O. Outlet filter Cover
P. Outer filer
Q. Motor Filter
R. Dust Bag
Crevice Tool With
Dusting Brush

Note:
Always remove the power plug from the wall outlet before assembling or removing
accessories.
1. Attaching the Flexible Hose into the vacuum connect the flexible hose into the air intake
duct, push in until you hear a “click”, indicating it is in its locked position.
2. Fitting the tube to the curved wand/hose extension. Push the tube into the curved
wand/hose extension.
3. Fitting the Floor Brush to the tube. Push the tube into the floor brush. Adjust the tube to
the desired length.
Model
RCG-118ER
Rated Voltage
220-240V~
Frequency
50/60Hz
Rated Wattage
1800W
SPECIFICATIONS
OPERATION INSTRUCTION

Variable suction control
Note:
Once all attachments are in place, unwind a sufficient length of cable and insert the plug
into the wall outlet. A yellow mark on the power cord shows the ideal cable length. Do not
pull the power cord beyond the red mark.
1. Insert the power plug into the wall outlet.
2. Press the power on/off button located the unit to turn the vacuum cleaner “on”.
3. To rewind the power cord, press the cord rewind button with one hand and guide the
power cord with the other hand to ensure that it does not whip causing damage or injury.
4. To adjust the suction, slide the speed control button on the suction hand to control the
suction power of the vacuum cleaner.
Motor thermostat (Optional)
Important:
This motor is equipped with a motor protective thermostat. If for some reason the vacuum
cleaner should overheat, the thermostat will automatically turn the unit off. Should this occur
unplug the vacuum cleaner from the wall outlet and turn off switch, change dust bag and
clean filters. Allow the unit to cool for approximately 1 hour. To restart,plug into wall outlet
and turn switch back on.
Change dust bag.
1.Open the front cover 2.Change dust bag
Rewind Button
On/off Button
Speed Control

Carry and move away the cleaner:
Note:
This cleaner have a special feature for handle. There is a handle on the top. In addition,
another carry-handle is in front. You can use it to conveniently carry the cleaner when the
cleaner is in vertical
Removing & cleaning pre-motor filter and air outlet filter
Warning:
Always unplug the unit from electrical outlet before getting out the dust barrel.
A. Pre-motor filter
Open the front cover Clean or change filter
CARE AND CLEANING
Pre-motor
filter
Front Handle
Top Handle

B. Air outlet filter
1. Press the air outlet grid knob to open
2. Take out the air outlet filter for clean and change.
Please note:
The sponge filter material in the cleaner will became dusty over time. This is normal and will
not affect the performance of the filter. If the sponge filter is so dusty that suction does not
return to 100%, then we suggest that the filter be removed then rinsed under the faucet and
allowed to dry for 24 hours by airing not near the fire or some high temperature objects
before refitting into the vacuum. This should be done once six months or when suction
appears to be reduced obviously.
Important:
Please note that there is a safety switch inside the vacuum to prevent the unit from being run
with high vacuum rate. If the vacuum is too high, the safety switch will be turned on. In this
case, it can mannish the vacuum rate and protect the motor from being broken.
Note:
The suction hole must be open, free of any obstructions at all times. Otherwise, the motor
will overheat and could become damaged.
Important:
All filters should be checked regularly for signs of damage, preferably after each cleaning
task. The filters must be replaced immediately if they become damaged. Always disconnect
the vacuum from the electrical outlet when checking the filters.
