1
TWS Bluetooth Speakers
AVS1406, AVS1431 & AVS1432
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
TWS Bluetooth Speakers
User Manual
Available in black, blue and grey colours

2
TWS Bluetooth Speakers
AVS1406, AVS1431 & AVS1432
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed. These instructions should be saved for future reference:
•Read and familiarise yourself with all operating instructions before
using these Speakers.
•Before plugging your units into the mains, visually check that the unit
is intact and has not suffered any transit damage.
•Check that the voltage indicated on the data plate corresponds with
that of the local network before connecting the appliance to the
mains power supply.
•Always use this appliance on a solid, level, non-flammable surface.
•Ensure that there is clearance of at least 100mm (4 Inches) minimum
around the Speakers for sufficient ventilation.
•Ensure that the ventilation openings are not covered with items, such
as newspapers, table-cloths, curtains, etc.
•No naked flame sources, such as lighted candles, should be placed on
the Speakers.
•Do not position the Speakers close to sources of heat such as
radiators, heaters, other electronic equipment, etc.
•The Speakers shall not be exposed to dripping or splashing and that
no objects filled with liquids, such as vases, shall be placed on the
apparatus.
•Do not immerse the Speakers in water or any other liquids.
•Do not leave the Speakers unattended during use.
•Do not leave the Speakers unattended whilst connected to a USB
supply.
•Close supervision is required when using these Speakers near
children.
•Never leave these Speakers within reach of children.
•This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
•Children of less than 3 years should be kept away unless continuously
supervised.
•Do not use these Speakers outdoors.

3
TWS Bluetooth Speakers
AVS1406, AVS1431 & AVS1432
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•It is imperative to unplug the power supply after the Speakers have
been used, before they are cleaned and whilst being repaired.
•Repairs to electrical appliances should only be performed by qualified
personnel. Improper repairs may place the user at serious risk.
•Do not operate these appliances after a malfunction or after being
dropped or damaged in any way.
•Do not allow the USB cable to hang over sharp edges or come in
contact with hot surfaces.
•Do not run the USB charging cable under carpets, rugs, etc.
•This product is intended for household use only and should not be
used for industrial purposes.
•Do not use any accessories or attachments with this product other
than those supplied or recommended by supplier.
•Do not use this product for anything other than its intended use.
•Do not push objects into any openings as damage to the product
and/or electric shock may occur.

4
TWS Bluetooth Speakers
AVS1406, AVS1431 & AVS1432
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts –Front Panel Controls
Description of Parts –Rear Panel
Before the first time you use your TWS Speaker
Please read these operating instructions thoroughly and keep them in a safe place for
future reference.
Remove all packing materials and discard responsibly.
1. –Press to power up, power off and Bluetooth pair the speakers.
2. ▬–Press to skip to the previous next track or press and hold to decrease the volume.
3. +–Press to skip forwards to the next track or press and hold to increase the volume.
4. –Press to Play/Pause/Phone the track you are playing.
5. LED Indicator.
6. MICRO SD –Micro SD/TF Card
Player
7. AUX –External 3.5mm input.
8. USB –USB Memory Stick Port.
9. Micro USB DC Port
10.USB Charging Cable
11.Micro USB Plug.
12.3.5mm Jack to Jack Lead.
7
8
9
1
6
2
3
4
5
10
11
12

5
TWS Bluetooth Speakers
AVS1406, AVS1431 & AVS1432
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Charging the internal Battery
Before use, please ensure that the internal rechargeable batteries are fully charged as follows:
1. Insert the Micro USB Plug (11) of the USB Charging Cable (10) into the Micro USB DC
Port (9) on rear panel of the Speaker to charge the internal battery.
2. Insert the large USB plug on the other end of the USB Charging Cable (10) into a suitable
USB charger rated at 5 volts 1 amp minimum.
3. The LED Indicator (5) will light red to show the internal battery is charging. Once the
battery is fully charged, the LED Indicator (5) will go out showing that the internal battery
is fully charged and the USB Charging Cable (10) can be removed.
NB the Speaker can be used normally during charging.
Operating Instructions
Using the Bluetooth Mode
1. Press and hold the Power button (1) on the front Panel for three seconds to power up
the speaker.
2. The LED Indicator (5) will quickly flash blue.
3. Enable the Bluetooth mode on your Phone, Tablet or other Bluetooth compatible device
and set it to search.
4. Select ‘AVS1406’ from the search results found by your device which will now pair with
the speaker. Once the device has paired with the speaker the LED Indicator (5) will light
steady blue and the speaker will chime.
5. Enable the music player on your Phone, Tablet or other device you are using.
6. Press the Play/Pause/Phone button (4) to start and stop (pause) the connected device
playing.
7. Use the Skip Back ▬(2) and Skip Forward + buttons (3) to change the track being played.
8. Press and hold the Skip Back ▬(2) and Skip Forward + buttons (3) to decrease and
increase the volume level.
9. Alternatively use your devices controls in the usual manner.
NB the LED Indicator (5) will flash slowly whist music is playing.
Using the AUX/LINE Input
The AUX/LINE Input allows a direct wired connection of an external audio device (such as a
mobile phone, music player, etc.) via a 3.5mm jack socket input on the rear Panel.
1. Press and hold the Power button (1) on the front Panel for three seconds to power up
the speaker.
2. Insert a 3.5mm jack to jack lead (12) into the AUX socket (7) on the rear panel of the
Speaker.
3. The speaker will automatically detect the lead and switch to AUX mode.
4. Insert the other end of the lead into the device you are playing from.
5. Press and hold the Skip Back ▬(2) and Skip Forward + buttons (3) to decrease and
increase the volume level.
Playing Music from a USB Memory Stick
1. Press and hold the Power button (1) on the front Panel for three seconds to power up
the speaker.
2. Insert a USB Memory Stick (pre-loaded with audio tracks –Mp3, WAV, files etc.) into the
USB memory stick port (8) on the rear panel. NB the USB port supports USB 2.0 and up
to 32GB capacity max.
3. The tracks on the memory stick will begin to play automatically.

6
TWS Bluetooth Speakers
AVS1406, AVS1431 & AVS1432
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
4. Press the Play/Pause/Phone button (4) to start and stop (pause) the USB memory
stick.
5. Use the Skip Back ▬(2) and Skip Forward + buttons (3) to step through the tracks on the
memory stick.
6. Press and hold the Skip Back ▬(2) and Skip Forward + buttons (3) to decrease and
increase the volume level.
Playing Music from a Micro SD/TF Card
1. Press and hold the Power button (1) on the front Panel for three seconds to power up
the speaker.
2. Insert a Micro SD or TF card (pre-loaded with audio tracks –Mp3, WAV, files etc.) into the
MICRO SD/TF Player (6) on the rear panel. NB the Micro SD/TF card player supports cards
up to 32GB capacity max.
3. The tracks on the card will begin to play automatically.
4. Press the Play/Pause/Phone button (4) to start and stop (pause) the SD/TF card player.
5. Use the Skip Back ▬(2) and Skip Forward + buttons (3) to step through the tracks on the
memory card.
6. Press and hold the Skip Back ▬(2) and Skip Forward + buttons (3) to decrease and increase
the volume level.
Handling Telephone Calls
Answering a Call
1. A call coming in will mute (cut) the music you are listening to and the speaker will make a
ringing sound.
2. Press the Play/Pause/Phone button (4) to answer the call.
3. Press and hold down the Skip Forward + button (3) to increase the call volume level.*
4. Press and hold down the Skip Back ▬button (2) to decrease the call volume level.
5. Press the Play/Pause/Phone button (4) again to end the call.
6. The callers voice will be heard through the speaker and your voice will be picked up by the
built in Microphone.
Rejecting a Call
1. A call coming in will mute (cut) the music you are listening to.
2. Press and hold the Play/Pause/Phone button (4) for two seconds to reject the call.
Redialling the Last Call Made
1. Briefly press the Play/Pause/Phone button (4) twice to redial the last number you called.
2. Briefly press the Play/Pause/Phone button (4) once to end the call.
*A beeping tone will be heard warning when the maximum volume setting has been reached.
TWS (True Wireless Stereo) mode
TWS mode enables two fabric speakers to be used together producing stereo sound whilst
using them in Bluetooth mode, follow the below steps to pair the two speakers together using
Bluetooth:
1. Take both speakers and press and hold the Power buttons (1) on both speakers for
three seconds to power up the speakers.

7
TWS Bluetooth Speakers
AVS1406, AVS1431 & AVS1432
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2. Press and hold the Play/Pause/Phone button (4) on both speakers for three seconds
and the two speakers will automatically pair together.
3. Connect to the speakers via Bluetooth as described in ‘Using Bluetooth Mode’ above.
4. Enable the music player on your Phone, Tablet or other device you are using.
5. Briefly press the Play/Pause/Phone button (4) on either speaker to start and stop
(pause) the connected device playing.
6. Use the Skip Back ▬(2) and Skip Forward + buttons (3) on either speaker to change the
track being played.
7. Press and hold the Skip Back ▬(2) and Skip Forward + buttons (3) on either speaker to
decrease and increase the volume level.
8. Alternatively use your devices controls in the usual manner.
NB True Wireless Stereo pairing is only available in Bluetooth mode.
Care and Use of your Speakers
•Always disconnect the Speakers from the USB charging supply before cleaning.
•Clean outside of the Speakers with a clean damp cloth. Never clean with harsh or abrasive
cleaners.
•Do not submerge the Speakers in water or any other liquids.
Technical Specification
Waste batteries should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice.
Model Number
AVS1406, AVS1431 and AVS1432
Power Supply/Charger
DC 5V @1A
Total audio output power
5W
Speaker size and rating
52mm 4Ω 5W
Audio Frequency Response
100Hz –20KHz
Aux input sensitivity
300mV
Unpacked Weight
Approx. 320gs
Dimensions (Approx.)
Approx. 88mm (dia.) x 107mm (h)
Operation temperature
0°C to + 40°C
Built in Battery type
Lithium Ion, 1200 mAh 3.7V
Bluetooth Frequency Range
2402 - 2480MHz
Bluetooth Transmission power
≦-3.325dBm
This product conforms to Radio Equipment Directive 2014/53/EU

8
TWS Bluetooth Speakers
AVS1406, AVS1431 & AVS1432
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
GUARANTEE
This product is guaranteed for twenty-four months from the date of original
purchase. If any defect should occur due to faulty materials or workmanship, please
return it to the store it was purchased from.
You will need to have your receipt of purchase to hand. The guarantee is subject to
the following provisions:
• It is only valid within the boundaries of the country of purchase.
• The product must be correctly installed and operated in accordance with the
instructions contained in the User Manual.
• The product must be used solely for domestic purposes.
• The guarantee will berendered invalid if the product is re-sold or has been
damaged by inexpert repair.
• The manufacturer disclaims any liability for incidental or consequential damages.
• The guarantee is in addition to, anddoes not diminish, your statutory or legal
rights.
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
Daewoo Electricals is a registered trademark.
Produced and imported under licence by ESG Ltd
Manchester M3 1JS www.esgltd.com
