Daewoo electricals AVS1449 User manual

1
LED Bluetooth Party Speaker
AVS1449
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
LED Bluetooth Party Speaker
AVS1449
User Manual

2
LED Bluetooth Party Speaker
AVS1449
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
•Read and familiarise yourself with all operating instructions before
using this Speaker.
•Before using your Speaker, visually check that the unit is intact and has
not suffered any transit damage.
•Always use this appliance on a solid, level, non-flammable surface.
•Ensure that there is clearance of at least 100mm (4 Inches) minimum
around the Speaker for sufficient ventilation.
•Ensure that any ventilation openings are not covered with items, such
as newspapers, table-cloths, curtains, etc.
•No naked flame sources, such as lighted candles, should be placed on
the Speaker.
•Do not position the Speaker close to sources of heat such as radiators,
heaters, other electronic equipment, etc.
•The Speaker shall not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on the
apparatus.
•Do not immerse the Speaker or its charging cable in water or any other
liquids.
•Do not leave the Speaker unattended during use.
•Do not leave the Speaker unattended whilst connected to a USB
supply.
•Close supervision is required when using this Speaker near children.
•Never leave this Speaker within reach of children.
•This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
•Children of less than 3 years should be kept away unless continuously
supervised.
•It is imperative to unplug the USB supply after the Speaker has been

3
LED Bluetooth Party Speaker
AVS1449
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
used, before it is cleaned and whilst being repaired.
•Unplug after each use.
•Repairs to electrical appliances should only be performed by qualified
personnel. Improper repairs may place the user at serious risk.
•Do not operate this appliance after a malfunction or after being
dropped or damaged in any way.
•Do not allow the charging cable to hang over sharp edges or come in
contact with hot surfaces.
•Do not run the charging cable under carpets, rugs, etc.
•This product is intended for household use only and should not be used
for industrial purposes.
•Do not use any accessories or attachments with this product other than
those supplied or recommended by supplier.
•Do not use this product for anything other than its intended use.
•Do not push objects into any openings as damage to the product
and/or electric shock may occur.

4
LED Bluetooth Party Speaker
AVS1449
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts –Top Panel
1. Handle
2. DC 5V in –Charging Socket.
3. Power On/Off Switch
4. Micro SD/TF Card Player
5. LED Display
6. USB Memory Stick Player
7. 3.5mm AUX input Jack socket.
8. 6.25mm (quarter Inch) Microphone input Jack
socket.
9. Briefly press to Skip back to the previous
track, press and hold to reverse search a track
in USB and SD/TF card mode.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
10. Briefly press to Skip forwards to
the next track, press and hold to
forward search a track in USB and
SD/TF card mode.
11. Press to Play or Pause tracks.
12. Volume Control.
13. Repeat.
14. LED (mode).
15. MODE –press to select Bluetooth,
AUX input, USB memory stick, SD/TF
Card or FM Radio mode.
16. LED Indicator
16

5
LED Bluetooth Party Speaker
AVS1449
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts –Speaker Front & Accessories
Before the first time you use your Party Speaker
Please read these operating instructions thoroughly and keep them in a safe place for future
reference.
Remove all packing materials and discard responsibly.
Charging the internal Battery
Before use, please ensure that the internal rechargeable battery is fully charged as follows:
1. Insert the DC Plug (22) of the USB Charging Cable (20) into the DC 5V in
Charging Socket (2) on the top panel of the speaker to charge the internal
battery.
2. Insert the USB plug (21) of the USB Charging Cable (20) into a suitable
USB charger rated at 2 amp minimum.
3. The LED Indicator (16) will light red to show the internal battery is
charging. Once the battery is fully charged (after approximately 6 hours),
the LED Indicator (16) will go out showing that the internal battery is fully
charged and the USB Charging Cable (20) can be removed.
NB the speaker can be used normally during charging. Also, once fully
charged, the speaker will operate for up to 3 hours on its internal battery.
During use, if the speaker gives a beep tone, this indicates the internal battery is low on
charge and will need recharging. Follow the procedure above to recharge the battery.
Using the Bluetooth Mode
1. Switch on the speaker by pressing the Power On/Off switch (3) on the
top panel (arrowed right).
2. The LED Display (2) on the top panel will flash the word ‘blue’ to indicate
that it is ready to pair with an external Bluetooth device as below:
17. Loudspeaker(s)
18. LED Lighting Effect(s)
19. 3.5mm Jack to Jack lead (a 3.5mm Jack to
Jack Lead is supplied but an appropriate
lead maybe required to suit the external
equipment used.)
20. USB Charging Cable
21. USB Plug
22. DC Plug
17
18
19
20
17
21
18
22

6
LED Bluetooth Party Speaker
AVS1449
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3Enable the Bluetooth mode on your Phone, Tablet or other Bluetooth compatible
device and set it to search.
4. Select ‘AVS1449’ from the search results found by your device which will now pair with
the speaker. Once your device has paired the speaker will chime once to confirm it is
has paired and the word ‘BLUE’ on the LED Display (2) will stop flashing and the
speaker is ready to play.
5. Enable the music player on your Phone, Tablet or other device you are
using.
6. Press the Play/Pause button (11) to start and stop (pause) the
connected device playing.
7. Briefly press the skip forwards (10) and skip back buttons (9)
to change the track being played.
8. Alternatively use your devices controls in the usual manner.
9. Rotate the Volume Control (12) control (right) clockwise and
anticlockwise to increase and decrease the volume level.
Using the FM Radio
1. Press the Mode button (15) until the FM radio is shown on the LED display (5) as below:
2. Press the Play/Pause button (11) to make the FM radio scan the airwaves. As the radio
scans, each station picked up will automatically be stored into the radio presets.
3. Once the radio has finished scanning the radio will default to preset 1, to change the radio
preset, briefly press the skip forwards (10) and skip back buttons (9) to change the
radio station being played.
4. Rotate the Volume Control (12) control clockwise and anticlockwise to increase and
decrease the volume level.
Using the AUX Input
The AUX Input allows a direct wired connection of an external audio
device (such as a mobile phone, mp3 player, etc.) via a 3.5mm jack socket
input on the top panel.
1. Insert the 3.5mm jack to jack lead (19) into the 3.5mm AUX input Jack
socket (7) on the top panel (arrowed top right).
2. Connect the other end of the 3.5mm jack to jack lead* (19) to your
external device.
3. Press the Mode button on the top panel (15) to enter the aux in mode.
The LED Display (2) on the top panel (arrowed bottom right) will show
the word ‘AUX’.
4. Rotate the Volume Control (12) control clockwise and anticlockwise to
increase and decrease the volume level.
5. Use your devices controls in the usual manner whilst playing music
back through the speaker.
*A different lead may be required if the supplied cable is not compatible with your device.

7
LED Bluetooth Party Speaker
AVS1449
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using the Microphone input
Playing Music from a USB Memory Stick
1. Insert a USB Memory Stick (pre-loaded with audio tracks –Mp3, WAV, files etc.) into
the USB memory stick player (6) on the top panel. NB the USB port supports USB 2.0
and up to 32GB capacity max.
2. The tracks on the memory stick will begin to play automatically.
3. Press the Play/Pause button (11) to play and pause the memory stick. Press the
Play/Pause button (11) again to resume playing the memory stick.
4. Briefly press the skip forwards (10) and skip back buttons (9) to change the
track being played, press and hold to search a track.
5. Rotate the Volume Control (12) control (right) clockwise and anticlockwise to increase
and decrease the volume level.
NB the speaker will default to Aux mode after the USB memory stick has been removed.
Playing Music from a Micro SD/TF Card
1. Insert a Micro SD/TF card (pre-loaded with audio tracks –Mp3, WAV, files etc.) into
the Micro SD/TF Card Player (4) on the rear panel. NB the Micro SD/TF card player
supports cards up to 32GB capacity max.
2. The tracks on the card will begin to play automatically.
3. Briefly press the skip forwards (10) and skip back buttons (9) to change the
track being played, press and hold to search a track.
4. Rotate the Volume Control (12) control (right) clockwise and anticlockwise to
increase and decrease the volume level.
NB the speaker will default to Aux mode after the Micro SD/TF card has been removed.
TWS (True Wireless Stereo) mode
TWS mode enables two speakers to be used together producing stereo sound whilst using
them in Bluetooth mode, follow the below steps to pair the two speakers together using
Bluetooth:
1. Press and hold the Play/Pause (TWS) button (11) on both speakers for three seconds
and the two speakers will automatically pair together.
2. Connect to the speakers via Bluetooth as described in ‘Using Bluetooth Mode’ above.
3. Enable the music player on your Phone, Tablet or other device you are using.
4. Briefly press the Play/Pause button (11) on either speaker to start and stop (pause) the
connected device playing.
NB True Wireless Stereo pairing is only available in Bluetooth mode.
Care and Use of your Speaker
•Always disconnect the Speaker from the USB supply before cleaning.
•Clean outside of the Speaker with a clean damp cloth. Never clean with harsh or abrasive
cleaners.
•Do not submerge the Speaker or its charging cable in water or any other liquids.
Insert a Microphone (not supplied) equipped with a 0.25”
(6.35mm) Jack plug into the Microphone Input Jack Socket
(8) in order to sing along with your favourite tracks.

8
LED Bluetooth Party Speaker
AVS1449
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Specification
Waste batteries should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice.
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice.
Model Number
AVS1449
Power Supply/Charger
DC 5V @2A
Audio output power
2x 8W RMS
Speaker Units
2x 6.5” Full Range Drivers
Unpacked Weight
Approx. 3.3 Kgs
Dimensions (Approx.)
533mm (h) x 250mm (w) x 222mm (d) Approx.
Operation temperature
0°C to + 40°C
Built in Battery type
3.7V Li-ion, 3600 mAh
Bluetooth Frequency Range
2402 - 2480MHz
Bluetooth Transmission power
≦-3.325dBm
FM Frequency Range
88 - 108 MHz
This product conforms to Radio Equipment Directive 2014/53/EU

9
LED Bluetooth Party Speaker
AVS1449
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
GUARANTEE
This product is guaranteed for twenty-four months from the date of original
purchase. If any defect should occur due to faulty materials or workmanship, please
return it to the store it was purchased from.
You will need to have your receipt of purchase to hand. The guarantee is subject to
the following provisions:
• It is only valid within the boundaries of the country of purchase.
• The product must be correctly installed and operated in accordance with the
instructions contained in the User Manual.
• The product must be used solely for domestic purposes.
• The guarantee will berendered invalid if the product is re-sold or has been
damaged by inexpert repair.
• The manufacturer disclaims any liability for incidental or consequential damages.
• The guarantee is in addition to, anddoes not diminish, your statutory or legal
rights.
Daewoo Electricals is a registered trademark.
Produced and imported under licence by ESG Ltd
Manchester M3 1JS www.esgltd.com
