DAEWOO ELECTRONICS RN-325PW User manual

S/M No. : FR06300010
✔ Caution :
In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS Corp.
Mar. 2004
http : //svc.dwe.co.kr
Service Manual
Refrigerator
MODEL : RN-325PW
DESPIECE

Serves manual
60CM Freezer Fridge
Model:DD2-40
4 Trouble shooting guide
5 Exploded view
6 Parts list
Contents
1 Cover
2 The cooling system
3 The electrical diagram

The cooling system

The electrical diagram

No Problem Possible Cause What To Do
Not plugged in. Plug in
Is the circuit breaker tripped or blown fuse?
Put on the home circuit breaker or change
the new fuse.
Is the refrigerator temperature control setted at
“off”?
Set the temperature control knob at "4".
Is the refrigerator control dialed set to correct
location?
Set it to a colder temperature.
Is the refrigerator placed in direct sunlight or
closely a heat source?
Move the refrigerator to proper location.
Is the door closed completely? Close the door completely.
Is the door opened too frequently or too long? Open the door less often,
Does the door gasket seal properly? Make the gasket sealing properly.
Is the refrigerator overloaded? Load less food into it.
Is the refrigerator control dialed set to correct
location?
Set it to a warmer temperature.
Is the ambient temperature too low?
Hot-pipe is installed in two sides of
refrigerator.That makes refrigerator's
temperture lowquckly and save the power
Normal state.
Condensation can occur when you leave the
door open for a long time.
Normal state.
5 Vibrations The refrigerator is not level and firm. Place the refrigerator in a level location.
Water bubbling comes from the refrigerant
circulating of the refrigerator.
Normal state.
Contraction and expansion of the insulation
inside the walls may cause popping and
cracking.
Normal state.
Is the refrigerator unstable or touching the
wall?
Keep the refrigerator leaving the wall.
Is the refrigerator not level? Adjust the refrigerator leveling.
Were the doors not properly installed? Assure the doors installed propertly.
Is the door gasket dirty and distortion? Cleaning and flatting the door gasket.
Has the home circuit breaker or fuse tripped?
Put on the home circuit breaker or change
the new fuse.
Is the refrigerator's door close completely? Assure the door close completely.
Is the ambient temperature too high?
Is the temperature controller in freezer
chamber or in refrigerator chamber is set at
“strong” position
Sets it at a right position.
Too much food is loaded into the refrigerator
and insufficient spaces for airflow.
Load less food into the refrigerator.
Operating for all long
time.
9
Trouble shooting guide
1
The refrigerator does
not get cold at all.
2
The refrigerator does
not get cold enough.
3
The food in the
refrigerator is frozen
8
The lamp does not
work.
4
Two sides of the
cabinet are hot:
condensation occurs.
6
The refrigerator is
noisy.
7
The door can not
close properly.

The door were not closed completely or the
gasket not sealing enough.
Close the doors completely or make the
gasket sealing enough.
Open the door too frequently. Decrease the open-door times.
Operating for all long
time.
9

Exploded view

No. Parts code Description of Spare Part Quantity
(UNIT)
220014867 Top front decorative cover 1
320014868 Decorative front 1
420014866 Right door hinge cover 1
53031400182 Upper Hinge Assembly 1
620050016 Door Switch 1
73050400021 LED light 1
820014203 Lamp Cover 1
920061367 Thermostat 1
10 20015505 Thermostat Knob 1
12 10023171 Upper Door 1
13 20014875 Upper Door Gasket 1
14 20122050412 Upper rack (ice blue) 3
15 20122050413 Lower Rack (ice blue) 1
17 20014437 Wire box 1
18 20060086 Drier filter (for R600a) 1
20 20012807 Drain pan 1
21 20014438 Base of wire box 1
22 20060046 Connecting tube (short) 1
23 20061718 Process tube 2
24 20120090230 Compressor 1
25 20050009 Connecting wire of compressor 1
26 20050008 Earthing wire of compressor 1
27 20120080130 Compressor Base Support 1
28 20050242 Power supply cord plug 1
29 20014877 Inner Door Gasket 1
30 20014876 Lower Door Gasket 1
31 10023172 Lower Door 1
32 20122030357 Lower Drawer (ice blue) 1
33 20122030358 Middle Drawer (ice blue) 2
34 20014361 Long adjustable Foot 1
35 20010123 Long adjustable foot 1
36 20021538 Lower Door Hinge Assembly 1
37 20016937 Left Position Block 1
38 20122990591 Shelf breaker 2
39 20016938 Right Position Block 1
40 20017709 Decorative breaker 1
41 20023116 Middle Door Hinge 1
42 20122040261 Crisper drawer(ice blue) 1
43 20120030099 Cover of Crisper Box 1
44 20012230 Cushion for Door Hinge 1
45 20120020165 Shelf of refrigerator chamber 3
46 20061201 Evaperator of freezer 1
47 20061267 Bottom Evaperator of freezer 1
48 20010068 Right limit block of door 1
49 20010371 Left limit block of door 1
50 20010021 Lower door right aid-closer 1
51 20010384 Lower door left aid-closer 1
52 3070101586 Carton 1
Totally Quantity:
(RN-325PW)
Total Amount:
