INSTRUCTION MANUAL
DWD-FD1411
Washing Machine Instruction Manual
CONTENTS Page
A NOTE TO YOU
Thank you for buying a DAEWOO appliance.
DAEWOO washing machines are easy to use, save time, and help you manage your home better.
This manual contains valuable information about how to operate and maintain your machine properly and safely.
Please read it carefully.
"Economic wash system
Using artificial intelligence, the washer uses minimum energy and
water by selecting optimal water level and washing time.
"Low noise system
The washing machine minimises the washing and spinning noises
by sensing the amount of laundry.
"Child-Lock
The Child-Lock system has been used to prevent children from pressing any buttons to change
the programme during operation.
PARTS AND FEATURES.................................................................................................................2
WASHING MACHINE SAFETY........................................................................................................3
INSTALLATION INSTRUCTIONS....................................................................................................4
INLET HOSE CONNECTION...........................................................................................................5
ELECTRICAL REQUIREMENTS .....................................................................................................6
OPERATING YOUR WASHING MACHINE.....................................................................................7
THE FUNCTIONS OF THE CONTROL PANEL...............................................................................9
WASHING PROCEDURE AND PROGRAME SELECTION ..........................................................10
MAINTENANCE .............................................................................................................................19
HOW TO CLEAN THE FILTER......................................................................................................20
REMOVING STAINS......................................................................................................................21
TROUBLE SHOOTING ..................................................................................................................22
SPECIFICATION............................................................................................................................23

2
PARTS AND FEATURES
The parts and features of your washer are illustrated on the page.
Become familiar with all parts and features before using your washer.
Accessories
NOTE
The drawings in the book may vary from your model model.
They are designed to show the different features of all models covered by this book,
therefore your model may not include all the features that are available.
Hose drain Inlet hose Manual Cap holder
ADJUSTABLE LEGS
CONTROL PANEL
DOOR
DETERGENT COMPARTMENT
INLET HOSE
PUMP COVER
POWER CORD
HOSE DRAIN

3
Save these instructions
Your safety is important to us.
To reduce the risk of fire, electrical shock, or injury when using your machine adhere to the
following basic precautions.
Understanding your responsibilities
• Do not use chlorine bleach and ammonia or acid(such as vinegar or rust remover) in the same
wash. Hazardous fumes can form.
• Unplug power supply cord before attempting to service your machine.
• Do not wash fibreglass material.
Small particles can stick to fabrics washed in subsequent loads and cause skin irritation.
• Do not spray water on the control panel of the washer.
It could cause fire or an electric shock.
• In case of the dual valve model, with only the cold water inlet valve, connected and the water
temperature selected as hot or warm, there may be water leakage from unconnected water inlet
valve.
• This appliance must be earthed.
• Flammable fluids (dry-cleaning solvents, etc)
should not be used or stored in or near your
machine.
Do not add flammable fluids to your wash.
These substances give off vapours that can
create a fire hazard or explosion.
• Do not attempt to open the machine door
after a cycle has started.
• Do not tamper with the controls.
• The appliance is not intended for use by
young children or without supervision.
• If the supply cord is damaged, it must be
replaced by the manufacturer, or its service
agent or a similarly qualified person in order
to avoid a hazard.
• If the appliance is connected to the power
supply via an extension lead, it should not
be positioned where it could be splashed by,
or susceptible to, water.
Please ...
• Have only a qualified person install, repair,
or replace parts on washer.
• Ensure your washing machine is regularly
maintained/serviced.
• Position your washing machine where it will
be protected from the weather and keep
it where the temperature will not fall below
freezing.
• Do not install your machine at a place of
extremely high humidity. It could cause an
electric shock or a short circuit.
• Your washing machine must be connected to
the correct outlet, electrical supply, water
supply, and drain supply.
WASHING MACHINE SAFETY
Read all instructions before using your machine

4
Removing transit bolts
1. Before operating the washer, remove the
transit bolts(3ea) along with the rubber.
• If the bolts are not removed, it may cause
heavy vibration, noise and malfunction.
2. Unscrew the 3 bolts with the 10mm hex
wrench or spanner or cross-tip screwdriver.
Keep the 3 bolts for a later time.
• When the appliance is transported, transit
bolts will be re-used.
3. Close the holes with the cap holders supplied.
Location of washer
• Check location where the machine will be installed. Make sure you have everything necessary
for correct installation.
• Do not place or store your washing machine below 0°C (32°F) to avoid any damage from
freezing.
• Never place/store laundry products on top of the machine.
• Install the washer on the horizontal solid floor.
If the washer is installed on an uneven floor, it could make
considerable noise, vibrate severely and cause a malfunction. If the
machine is not level, adjust the legs up or down for horizontal
installation.
• Ventilation openings must not be obstructed by carpeting when the
machine is installed on a carpeted floor.
• Leave some space (right & left : 2cm, rear : 10cm).
• In case of built-in installation, the distance between top of the washer and bottom of upper plate
should be at least 3mm.
INSTALLATION INSTRUCTIONS
Laundry
Tub
Washer
approx.
2cm
Drain Hose

5
The machine should be connected to the water mains using the the new hose sets supplied.
NEVER reuse old hoses.
If using only one water tap or if there is only one water inlet valve, connect the inlet hose to the
cold water inlet valve.
Caution: Be careful not to confuse hot water inlet and cold water inlet.
For Ordinary Tap
For Screw-Shaped Tap
INLET HOSE CONNECTION
1Pull down the collar of the
inlet hose to separate it
from the water tap
adapter.
2Loosen the four screws
properly in order to fit into
water tap.
3Fit the water tap adapter
into the water tap and
tighten the four screws
evenly while pushing up
the adapter so that the
rubber packing can stick
to the water tap tightly.
4Remove the tape, and
screw tightly connector B
into connector A.
5Connect the inlet hose to
the water tap adapter by
pulling down the collar of
the hose end.
6Connect the inlet hose
adapter of the hose to the
water inlet of the washer
by turning it clockwise
until it is tight.
• Please check the rubber
packing is present inside the
inlet hose adapter of the hose.
1Connect the inlet hose to
the water tap by screwing
the connector tightly.
2Connect the connector-
inlet supplied if
necessary.
3Connect the inlet hose
adapter to the water inlet
of the machine and turn it
until tight.
*Check the packing in the inlet
TAPE
Raccorclement B
Raccorclement A
Connector
Connector
Rubber
Packing
Hose
Connector Rubber
Packing
Hose
Connector
inlet
Connector

6
ELECTRICAL REQUIREMENTS
• An electrical earth is required on this machine
• If it does not fit the outlet, have a proper outlet
installed by a qualified electrician.
• Don’t earth to a gas pipe.
• Don’t change the power supply cord plug.
• Check with a qualified electrician if you are not
sure the machine is properly earthed.
WARNING
Recommended earthing method
Electrical shock hazard : Failure to follow these instructions could result in
death or serious injury.
For your personal safety, this machine must be earthed.
It is fitted with a supply lead (A) attached to an earthed plug (B). To prevent
electric shock occurring, this machine must be plugged into the relevant
earthed power socket (C). It is the personal responsibility and obligation of
the customer to ensure that this is in place before the washing machine is
installed.
C
B
A
Drain system
• Never forget to install drain hose before operating your machine.
• Open the packing box, and there is a drain hose inside the drum.
• Connect the drain hose to the drain outlet at the back side of the machine.
•
The top of the washing machine must be at least 60cm high but no higher than 100cm from floor
level.
• When installing the drain hose to tub(sink), secure it tightly with string or a plastic strap.
• Proper securing of the drain hose will protect the floor from flooding.
• When the drain hose is too long, do not force it back into the machine as this will cause
excessive noise.
Level adjustment
1If the washer is installed on an
unsuitable floor, it could make
considerable noise, vibrate and
cause a malfunction.

7
OPERATING YOUR WASHING MACHINE
2Adjust the level of the washing machine using the adjustable legs.
• Please check if there is any gap between the
four adjustable legs and the floor.
• Turn the adjustable legs. adjust the level of the
machine and make sure that is stable.
• Adjust the fixing nuts tightly so that the washer
maintains the adjustment.
3Make it sure that the washing machine does not move when
you press down the four corners of the washer's top plate.
adjustable leg
Fixing Nut
NOTE
There should be no instability of the machine when
all the adjustable legs have been correctly balanced.
To obtain the best washing results, you must operate your machine properly.
This section gives you this important information.
• Close zippers, snaps, and hooks to avoid
snagging other items.
Remove pin, buckles, and other hard
objects to avoid scratching the machine
interior.
• Empty pockets and pull them inside out.
• Turn down cuffs and turn synthetic garments
inside out to avoid damaging the fibres.
• Tie strings and sashes to avoid tangling.
• Treat spots and stains.
(See “Removing stains” on page 21)
Preparing clothes for washing

8
• For best cleaning and wrinkle-free results, put clothes
into the machine loosely so that they move easily in
the water.
• Load machine properly and select correct load size
setting.
Overloading and selecting a setting too small for the
wash load can :
- Cause poor cleaning
- Increase wrinkling
- Create excessive lint
- Wear out items faster (because of damage to fibres)
• Mix large and small items in each load. Load evenly to
maintain washer balance.
An unbalanced load can make the washer vibrate
during spin.
• Reduce wash time when using a small load size
setting. Loads with only a few small items needs less
wash time.
• Use a large load size setting to reduce wrinkling with
permanent press clothes and some synthetic
garments. These items should have more room to
move in the water than heavy items. (towels, jeans)
Loading
1Detergent compartment 2Adding fabric softener
• If desired, pour liquid fabric softener into the
dispenser using the amount recommended
by the manufacturers.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing of the
fabric softener which could stain clothes.
• Do not open the detergent case when water
is supplied.
• Avoid pouring fabric softener directly on the
clothes.
3Please use only the powder detergent for the front loader washing machine.
• Please use the proper amount of detergent in conformity with the instruction of the detergent
manufacturer.
• A use of a large amount of detergent more than the recommended amount can cause many
soapsuds and the overload to the motor. In addition to, this will deteriorate the washing and rinse
performance.
Adding detergent
• Separate heavily soiled items from lightly soiled ones, even if they would normally be washed together.
• Separate dark colours from light colours, colourfast items from non-colourfast items.
Sorting
Soil (Heavy, Normal, Light) Separate clothes according to amount of soil.
Colour (White, Lights, Darks) Separate white clothes from coloured clothes.
Lint (Lint producers, Collectors) Wash lint producers and lint collectors separately.
Main wash Pre wash
Fabric softener

9
Press this switch to turn the power on or off.
Operation and temporary stop is repeated as it is pressed.
When you want to change program in operating;
press the “Start/Hold” button #Select the program that you want to change #press the
“Start/Hold” button again.
You can select the course you want, and each lamp is turned on when that course is selected.
For the more detailed information, please refer to the page 11~18.
It can be used to adjust temperature of water according to types of the load to be washed.
As the button is pressed, temperature of water is selected by
Cold #30˚C #40˚C #60˚C #95˚C
By pressing the spin button, the spin speed can be chosen.
Rinse Hold •
Is selected by pressing the spin button repeatedly. This function leaves clothes
in the machine; suspended in the water after a rinse without entering into spin.
• To proceed through to a drain or spin, after the Rinse Hold function is
completed, use spin button.
Spin only • If you want only spin, you can operate spin only. (See page 18.)
Crease Care • If you want to prevent crease, select this button with spin speed.
Rinse+ • Is used to add a rinse, which may assist in removing traces of detergent residue.
• By selecting Rinse+ function, the rinse time and the rinse water are increased.
Pre-Wash • The washer operates one additional wash and spin before the main wash.
• If the laundry is heavily soiled, Pre-Wash course is effective.
• Pre-Wash is available in Cotton and Synthetic programs.
All courses have pre-set washing times, but Time Save decreases it to 10 minutes.
Each time this button is pressed the watch icon is repeated on and off. When it is on, the Time
Save function is set. Time Save is available in Cotton, Eco and Synthetic programs.
It can be used to pre-engage time for wash.
Use this function when you want to protect any accident occurring from handling of washer by a child.
During an operation of washer, press ‘Time Save’ and ‘Time Delay’ buttons simultaneously.
In Child Lock mode, no button functions except Power button.
In Child Lock mode, press ‘Time Save’ and ‘Time Delay’ buttons simultaneously like setting Child
Lock and Child Lock is cancelled.
To change to the desirde program, while in Child Lock mode;
1. Press both the Time save and Time delay buttons together once again.
2. Press the Start/Hold button.
3. Select the desired program and press the
Start/Hold button again.
THE FUNCTIONS OF THE CONTROL PANEL
* The Child Lock will be cancelled when power is off.
Change
the desired
program

10
1. COTTON IS AUTOMATICALLY SELECTED WHEN THE POWER BUTTON IS PRESSED.
• Press the Power button to start.
• Press the Start/Hold button
• Initial cycle:
- Programme : Cotton
- Wash : main wash
- Rinse : 3 times
- Spin : 800 rpm
- Water temperature : 40˚C
WASHING PROCEDURE AND PROGRAMME SELECTION
2. MANUAL SELECTION
• Press the Power button to start
• Select the cycle you want by turning the programme dial and pressing each button.
• Press the Start/Hold button.
3. TIME DELAYED WASHING
• A washing cycle may be programmed to finish up to 12 hours later.
For example, should you wish to delay the wash so that it will finish in eight hours' time:
- Press the Time Delay Button
* Each pressing of the button advances time delay by one hour.
• Now the timer is set.
• If you want to check the selected programme, press the “Start/Hold” button again.
• Preparing washing before starting “Time Delay”;
- Load laundry and close the door
- Place the detergent and fabric softener in the detergent compartment.
• To cancel the time delay, press the Power button.
ajust to "8"
select the
program
or manual

11
4. FUNCTION
• Recommended programmes according to the laundry type
• Pre Wash : If the laundry is heavily soiled, “Pre Wash” program is recommended.
Pre Wash is available in Cotton and Synthetic programmes.
• Rinse+ : Used to introduce an additional rinse, which may assist in removing traces of detergent residue.
• Eco : By selecting Eco function, the water temperature is lowered and washing time is increased.
So you can economise your consumption of heating energy.
Fabric
Type
First check if laundry is machine
washable.(white cotton, linen
towel and sheets..)
Colourfast garments
(shirts, night dresses, pyjamas..)
and lightly soiled white cottons
(underwear..)
60˚C
(95˚C)
Pre Wash
Rinse+
Crease Care Rating
40˚C
(COLD,
30°C, 60°C)
Pre Wash
Rinse+
Crease Care Rating
Laundry type is the same as
Cotton. 60˚CPre Wash
Rinse+
Crease Care Rating
Proper
Temp. Option Maximum Load
Programme
Cotton
Eco
Polyamide, Acrylic, Polyester 40˚C (COLD,
30°C, 60°C)
Pre Wash
Rinse+
Crease Care
Less than
1.5kg
Synthetic
Delicate laundry easily
damaged
(silk, curtains..)
Cold
(30°C, 40°C) Rinse+ Crease Care Less than 1.0kg
Delicate
Machine washable woollens
with pure new wool only. Cold (30°C, 40°C) Rinse+ Crease Care Less than 1.0kg
Wool
“Hand wash” marked delicate
and wool laundry Cold (30˚C) Rinse+ Crease Care Less than 1.0kg
Hand Wash
Coloured laundry which
is lightly soiled. 30˚C (Cold, 40˚C) Rinse+ Crease Care Less than 1.0kg
Quick 30

12
* COTTON PROGRAMME
Note
• If you want to change the setting during operation, press the Start/Hold button to hold the operation
and press the button you want.
• ‘COLD’, ‘30’, ‘40’, ‘60’ and ‘95’ ˚C washing temperatures are selectable with the cotton programme.
• ‘Prewash’, ‘Rinse+’, and ‘Crease Care’ wash options are selectable with this programme.
Caution!
• If you select washing temperature ‘95’ ˚C, some cold water is supplied before the drain of main wash.
This is to protect the user from the hazard of burn injury by lowering the temperature of hot wash
water instead of directly draining it. Therefore this is not a malfuction.
(Be careful with the draining water, since it can be still hot although the temperature is lowered.)
Put the laundry in to the drum.
Then close the door.
• In the detergent compartment, put the powder into the main wash and pre-wash
sections. Softener should be be poured into the middle section of the compartment
and be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with detergent.
Press the Power button.
•
The LED shows only ‘---’ and all Program Lights turn on.
Select the ‘Cotton’ programme using the programme selection dial.
• (If you press the Start/Hold button after pressing the power button without selecting
a programme, the ‘Cotton’ program is selected as default program.
• Water temperature ‘40’ ˚C, spin ‘800’ rpm and rinse ‘3’ times are selected
automatically.
• If you want to change the water temperature, spin velocity or add wash options
(Rinse+, Crease Care), press each button.
Press Start/Hold button.
• The washing machine will start operating by locking the door and supplying water.
1
2
3
4

13
* ECO PROGRAM
Put the laundry in the drum.
Then close the door.
• In the detergent compartment, put the powder into the main wash and pre-wash
sections. Softener should be poured into the middle section of the compartment and
be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
•
The LED shows only ‘---’ and all Program Lights turn on.
Select the ‘Eco’ programme using the programme selection dial.
• Water temperature ‘60’ ˚C, spin ‘800’ rpm and rinse ‘3’ times are selected
automatically.
• If you want to change the spin velocity or add wash options (Rinse+, Crease Care),
press each button.
Press Start/Hold button.
• The washing machine will start operating by locking the door and supplying
1
2
3
4
Note
• If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
• Only ‘60’ ˚C washing temperature is selectable with the Eco programme.
• Only ‘Rinse+’ and ‘Crease Care’ of all wash options are selectable with this programme.

14
* SYNTHETIC PROGRAM
Put the laundry in the drum.
Then close the door.
• In the detergent compartment, put the powder into the main wash and pre-wash
sections. Softener should be poured into the middle section of the compartment and
be below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
•
The LED shows only ‘---’ and all Program Lights turn on.
Select the ‘Synthetic’ programme using the programme selection dial.
• Water temperature ‘40’ ˚C, spin ‘800’ rpm and rinse ‘3’ times are selected
automatically.
• If you want to change the water temperature, the spin velocity or add wash options
(Prewash, Rinse+, Crease Care), press each button.
Press Start/Hold button.
• The washing machine will start operating by locking the door and supplying water.
1
2
3
4
Note
• If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
• Only ‘30’, ‘40’ and ‘60’ ˚C washing temperatures are selectable with the Synthetic programme.
• 1400rpm of spin velocity is NOT selectable with Synthetic program
• ‘Prewash’, ‘Rinse+’, and ‘Crease Care’ wash options are selectable with this programme.
• The appropriate amount of laundry for Synthetic program is below 1.5kg.

15
* DELICATE PROGRAM
Put the laundry in the drum.
Then close the door.
• In the detergent compartment, put the powder into the main wash section.
Softener should be poured into the middle section of the compartment and be
below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
•
The LED shows only ‘---’ and all Program Lights turn on.
Select the ‘Delicate’ programme using the programme selection dial.
• Water temperature ‘Cold’, spin ‘400’ rpm and rinse ‘2’ times are selected
automatically.
• If you want to change the spin velocity or add wash options (Rinse+, Crease Care),
press each button.
Press Start/Hold button.
• The washing machine will start operating by locking the door and supplying water.
1
2
3
4
Note
• If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
• Only ‘Cold’, ‘30’°C and ‘40’°C washing temperature is selectable with the Delicate programe.
• Only 'Rinse+' and 'Crease Care' wash options are selectable with this option but 1000rpm and 1400rpm of
spin velocity is NOT selectable with Delicate program.
• The appropriate amount of laundry for Delicate program is below 1.0kg.

16
* WOOL PROGRAM
Put the laundry in the drum.
Then close the door.
• In the detergent compartment, put the powder into the main wash section.
Softener should be poured into the middle section of the compartment and be
below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
•
The LED shows only ‘---’ and all Program Lights turn on.
Select the ‘Wool’ programme using the programme selection dial.
• Water
temperature ‘Cold’, spin ‘400’ rpm and rinse ‘2’ times are selected
automatically.
• If you want to change the spin velocity or add wash options (Rinse+, Crease Care),
press each button.
Press Start/Hold button.
• The washing machine will start operating by locking the door and supplying water.
1
2
3
4
Note
• If you want to change the setting during operation, press the Start/Hold button to hold the operation
and press the button you want.
• Only the ‘Cold’, ‘30’°C and ‘40’°C water temperature is available with the Wool programme.
• 1000rpm and 1400rpm of spin velocity is NOT selectable with the Wool programme in order to
protect the clothing from damage.
• Only ‘Rinse+’ and ‘Crease Care’ wash options are selectable with this programme.
• The appropriate amount of laundry for the Wool programme is below 1.0kg.
• Use only special detergent for wool.
(Do not use more than the recommended amount of detergent for woollens as this may lead to too
much lather in the wash.)

17
* HAND WASH
Put the laundry in the drum.
Then close the door.
• In the detergent compartment, put the powder into the main wash section.
Softener should be poured into the middle section of the compartment and be
below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
•
The LED shows only ‘---’ and all Program Lights turn on.
Select the ‘Hand Wash’ programme using the programme selection dial.
• Water temperature ‘Cold’, spin ‘400’ rpm and rinse ‘3’ times are selected
automatically.
• If you want to change the water temperature, spin velocity or add wash options
(Rinse+, Crease Care), press each button.
Press Start/Hold button.
• The washing machine will start operating by locking the door and supplying water.
1
2
3
4
Note
• If you want to change the setting during operation, press the Start/Hold button to hold the operation
and press the button you want.
• Only ‘Cold’ and ‘30’ ˚C washing temperatures are available with the 'Hand Wash' programme.
• 1000rpm and 1400rpm of spin velocity is NOT selectable with this programme.
• Only ‘Rinse+’ and ‘Crease Care’ wash options may be chosen with this programme.
• Use Hand Wash programme for the laundry that is marked ‘Hand wash’ in the care label.

18
* QUICK 30
* SPIN ONLY
Put the laundry in the drum. Then close the door.
Press the Power button.
• The LED shows only “--” and all Program Lights turn on.
Select the spin speed by pressing Spin button.
Press the Start/Pause button.
• The washing machine will start operating by locking the door.
1
2
3
4
Put the laundry in the drum.
Then close the door.
• In the detergent compartment, put the powder into the main wash section.
Softener should be poured into the middle section of the compartment and be
below the ‘MAX’ level.
• Put detergent into the pre wash compartment only if you want to add prewash.
• When you want to use bleach, put it into the main wash compartment with
detergent.
Press the Power button.
•
The LED shows only ‘---’ and all Program Lights turn on.
Select the ‘Quick’ programme using the programme selection dial.
• Water temperature ‘30’ ˚C, spin ‘800’ rpm and rinse ‘2’ times are selected
automatically.
• If you want to change the water temperature, spin velocity or add wash options
(Rinse+, Crease Care), press each button.
Press Start/Hold button.
• The washing machine will start operating by locking the door and supplying
1
2
3
4
Note
• If you want to change the setting during operation, press the Start/Hold button to hold the operation and
press the button you want.
• Only ‘Cold’, ‘30’ ˚C and ‘40’ ˚C washing temperatures are available with the Quick 30 programme.
• Only ‘Rinse+’ and ‘Crease Care’ wash options are may be chosen with this programme.

19
MAINTENANCE
Proper care of your washing machine can extend its life. This section explains how to care for
your machine properly and safely.
Cleaning your machine
Winter storage or moving care
Install and store your machine where it will not be subject to freezing temperatures as any water left
n hoses, etc. may damage it.
If you wish to store/move your machine during freezing weather, please take note of the following:
Non-use or vacation care
Operate your washing machine only when you are at home.
If you are on vacation or your machine is not being used for an extended period of time, you
should:
• Unplug the power supply cord or turn off eletrical power to the washer.
• Disconnect the water supply.
This helps avoid accidental flooding (due to a water pressure surge) while you are away.
Wipe up detergent, bleach, and other spills with
a soft, damp cloth or sponge as they occur.
Occasionally wipe the outside of the washer to
keep its it looking like new.
Clean interior with 250ml of chlorine bleach
mixed with 500ml of detergent.
Run washer through a complete cycle.
Repeat this process if necessary.
Exterior Interior
• Disconnect from mains.
• Disconnect and drain water inlet hoses.
• Run the washing machine on a drain and
spin setting (see page 10) for 1 minute.
• Unplug the power supply cord.
• Flush water pipes and hoses.
• Reconnect water inlet hoses.
• Reconnect to water supply.
• Reconnect power supply cord.
To winterize washer To use washer again
Check all pockets for sharp or metal objects eg. keys,
pins, clips, money, etc. as they may damage the interior of
your machine.
If any such items are found please do not rest/leave them
on top of the machine.

20
HOW TO CLEAN THE FILTER
Cleaning the water inlet filter
• Clean the filter when water leaks from the water inlet.
Cleaning the drain filter
• This drain filter is used to screen foreign bodies such as threads, coins, pins, buttons etc..
• If the drain filter is not cleaned regularly (after every ten washes), drainage problems could arise.
CAUTION : Be careful when draining if the water is hot.
Cleaning the detergent case
*After a while detergent and fabric softeners leave a deposit in the drawer:
- It should be cleaned from time to time with a jet of running water.
- If necessary it can be removed completely from the machine by pressing the catch downwards
and by pulling it out.
- To facilitate cleaning, the upper part of the fabric softener compartment can be removed.
*Detergent can also accumulate inside the recess which should be
cleaned occasionally with a brush.
*Once you have finished cleaning, replace the case and run a rinse
cycle without laundry.
1Pull the power
plug out before
cleaning it.
2Turn off the water
supply to the
washer and
separate the inlet
hose.
3Pull the inlet filter
out. 4Remove the dirt from the inlet filter
with a brush.
1. Open the lower cover(1) by
using a coin. Remove the cap
hose(2) to pull out the hose.
2. Unplug the cap hose(2), allowing
the water to flow out. At this time
use a vessel to prevent water
flowing on to the floor. When water
does not flow any more, turn the
pump filter(3) open to the left.
3. Remove any foreign material
from the pump filter(3). After
cleaning, turn the pump filter
clockwise and insert the cap
hose(2) to the original place.
Close the lower cover.
1
100
23
2
3
