Surveillance Kit NVR504
User manual

What’s in the Box

Introduce the NVR
•Wireless Camera
S/
N
Item
Description
1
Antenna
interface
Install antenna
2
Setscrew
Fixed bracket
3
Knob
Adjust the camera angle
5
Power
Supply
12VDC power supply.
•Wirele
ss

NVR

Installation
•Install wireless camera
Steps:
(1) Drill mounting holes, push in screws and fasten the screws.
(2) Connect Power adapter to socket.
(3) Loosen the setscrew and knob,adjust the camera angle
according to your surveillance need,then fasten the screws
•Install wireless NVR
If your product came with a hard drive, please skip this step.
Steps:
1. Install the hard disk with a cross screwdriver
(1) Unfastening the screws on the rear panel,and side panel.
(2) Remove the cover from the NVR.
(3) Connect
thedata

cable and power cable to HDD.
(4) Fasten the screws on the bottom to fix the HDD.
(5) Re-install the cover of the NVR and fasten screws.
2. Cable Connection
(1) Connect mouse to USB interface.
(2) Connect to monitor by HDMI cable or VGA cable.
(3) Connect to internet by network cable via router(or switch).
(4) Connect to 12VDC adapter and turn on power,the Power
indicator would turn red
Notes:
In order to guarantee the video quality, IPC antenna should try to
keep in parallel or tangent with NVR antenna. Because the signal
of surrounding antenna is much stronger ,but much weaker if
antenna endpoints back off direction.
.
| English

Local Operation
Step 1: Startup
Check the power supply is plugged into an electrical outlet. Then
the power LED should red,and the video will automatic display on
the monitor,after several minutes.
Step 2: Login
（1）click right mouse button, log-in menu pops up.
（2）Enter the correct password, default password is admin.
Note: Please modify the user password before using the product
to protect your privacy.
Password modification: " Main menu →The system menu →
Account →Modify Pwd →Enter the old password: (admin) →Set
a new password →Save "to change passwords.
Step 3: Format the hard disk
Only NVR can record after format hard disk.
(1) Right click to login and enter “Main menu→System→HDD
manager”.
(2) Select the hard disk,and click “Format Disk” button .
(3) The hard disk status would turn on “in use”.It’ll display” ” on
each live view channel,and start record.

Password can be composed of numbers, characters, operators
and dots, *, #, and the length cannot exceed 12 characters.
pls attention: If you forget your password. You can click to retrieve
the password, the system will automatically generate a random
number, send the random code to the customer service of the
supplier, and request a new login password, as shown in the
following figure:
General settings
You can set the system time, date format, time zone, language
selection, resolution, auto logout time, daylight saving time, IPC
time synchronization, and start wizard. The interface is as shown
in the figure below, after the operation is completed, left click the
next button.

Hard disk settings
It can display the list of currently existing hard disks, including
model, capacity, usage, status, and format status. If you need to
format the hard disk, you can first select the corresponding hard
disk, and then click the format button. After a while, the selected
hard disk can be formatted, and the format status of the hard disk
will also be displayed as "formatted". The operation interface is as
shown in the figure below. After the operation is completed, click
Finish after the settings are completed to complete all the above
settings.
App Installation
Do not scan the QR Code displayed on the screen but the one
below.
Alternatively, you can directly download the Daewoo Home
Connect app.

Add camera
Add or replace wireless camera,please fellow the steps below.
a) Wait 1.5minutes for camera start up.
b) Enter ”Main menu (right-click the main interface→Pair IPC”,
delete camera which status is " not connected" in the Channel
list.
c) Click ”Pair” button,and pop-up a window,"Pairing,pus and hold
IPC button ".
d) Push the pair button in IPC within 5 seconds.
e) It mean pair successfully when dispaly "connected" in status
column.
Camera removal
On the IPC pairing interface, select the camera to be deleted and
click the 【Delete】button, a prompt box will pop up: Are you
sure you want to delete? After deletion, you need to re-pair, click
the 【OK】button to complete the device deletion operation. As
shown below:

Image settings
Function description: Set the image parameters of IPC device
channels: brightness, contrast, hue, saturation, sharpness, image
quality, video format, horizontal and vertical flip, backlight
compensation, defogging, digital wide dynamic, wide dynamic
intensity.
1、I Right-click the main interface of the system, select 【IPC
Config】in the pop-up right-click menu, and the image setting
interface opens by default;
2、The user adjusts the camera image parameters according to
his needs, click 【Apply】, and then click the 【OK】button to
save the user modified parameters.
Advanced settings
Function description: IPC equipment motion detection and
humanoid recognition switch, sensitivity adjustment and area
setting.
Operation steps: On the IPC configuration interface. Click the 【
Advanced】heading to enter the advanced settings interface.
You can manually turn on or off the motion detection and
humanoid recognition functions, adjust the sensitivity level, and
set the motion detection and humanoid recognition areas. As
shown below:

System settings
System settings main menu: general settings, preview settings,
recording plan, recording backup, network configuration, storage
management, user management, alarm function, exception
handling, restore default, upgrade system The interface is shown
below:
General settings
【System Time】Set the current system date & time of the hard
disk recorder
【Date Format】Choose the format of the date display
【Time Zone】Choose your time zone
【Language】Support multiple languages
【Resolution】The default resolution is 1280x1024, 1024x768,
1280x720, 1440x900, 1920x1080
【Auto Logout(m)】Can set the menu standby time 0-60, 0 is not
set standby time;
【DST】Check the checkbox before daylight saving time to set
the start time and end time of daylight saving time.
【IPC Sync. Time】You can check to enable the IPC time
synchronization function, or you can uncheck to turn off the IPC
time synchronization function.
Operation steps: Use the mouse to click the option to be
modified, switch or manually input the value to be modified, and
click the 【Save】button to take effect.

Record Mode
Set NVR recording plan parameters.
【CAM】Select the corresponding channel number to set the
channel, for all channel settings, select the full
【Prerecorded(s)】Record 1-30 seconds before the recording
action state occurs (the length of time may vary due to the size of
the stream);
【Delay(s)】After the recording action setting starts, the recording
will be delayed for a period of time;
【Audio coding】The mark indicates that the recording is
enabled, and the audio encoding of the recording is enabled.
【Mode Brush】
Timed Record: perform ordinary recording within the set time
period
Moving Record: record the motion detection alarm period within
the set time period
Not Record: no video will be recorded within the set time period.
【Copy】Reproduce the recording settings of one channel to
other channels.
【Restore】Restore recording settings to system default.

Storage management
Function description: Configure and manage the hard disk in the
device. The current hard disk information is displayed in the menu,
including the number of connected hard disks, access interfaces,
status, and total capacity. The hard disk can be formatted. During
operation, select the operation hard disk and click the right
function button to execute.
User Management
Function description: User management mainly includes: Add
User, Delete User, Modify User, Modify Pwd.

【Add User】To add a new user, you can set a new user name
and password. And permissions configuration.
【Delete User】Delete redundant users. By default, reserved
users are not allowed to delete.
【Modify User】Modify the attributes of existing users, the
default administrator user cannot be modified;
【Modify Pwd】Modify the user account password, the
password can be set to 1-12 digits.

Alarm function
【CAM】Select the corresponding channel number to set the
channel, and set all channels in a unified way.
【Period】The device will trigger the motion detection alarm
signal within the set time range
【Show Message】On the NVR preview screen, a dialog box for
prompting alarm information will pop up;
【Buzzer】When the alarm occurs, the device emits two long
beeps
You can configure an email to receive email alerts
Motion Detect：
【CAM】Select the corresponding channel number to set the
channel, and set all channels in a unified way.
【Period】The device will trigger the motion detection alarm
signal within the set time range
【Delay(s)】When the video is lost, it means that when the
alarm is over, the alarm will stop for an extended period of time,
ranging from 10 to 300 seconds;
【Show Message】On the NVR preview screen, a dialog box
for prompting alarm information will pop up;
【Buzzer】When the alarm occurs, the device emits two long
beeps.
【Record Channel】Select the channel to set the motion
detection area；

Video playback
Function description: Play back the video files in the hard disk.
You can enter the video playback interface through the shortcut
menu of the right mouse button and click the 【Video Playback】
option, as shown in the following figure:
1.Time and date : Select the time and date. The date with a white
border is the current system date; the date with a red background
indicates that there is a recording on the current date
2.Full HD : Select sub-stream playback/mainstream playback.
3. Time selection : Choose a good time and date, you can
search for a specific time recording
4.Channel selection : Select the specified channel to record.
3. Full screen mode : Mouse click all full screen to enter the full-
screen playback interface
4. File backup : Jump to the backup interface for the backup
operation. Click the button to pop up Figure 3.5, you can follow the
instructions below. Note: Before backing up files, you need to
install a storage device that is sufficient to hold the stored files; the
backup is terminated midway, and files that have been copied to
the storage device can be played back independently.
7. Play ratio : Display the speed multiple of fast or slow
playback.
8. Stop playback : Video recording stops playing.

PTZ control
Function description: Use the NVR to control the camera pan/tilt
rotation, zoom, preset position, cruise and other operations.
Operation premise:
Before users control the IP camera or PTZ, please make sure that
the camera supports PTZ control function and the network with the
NVR has been connected normally.
Steps:
1. Right-click on the main interface and select PTZ control in the
shortcut menu to enter the PTZ control interface. As shown below:
2. Support PTZ direction control, zoom, focus, iris adjustment,
preset call, you can enter the sub-menu to set the cruise path, run
cruise.
CELLPHONE REMOTE MONITOR
Step 1: Install the app
1.From your phone, download the free DAEWOO Home Connect
app from the App store or Google Play
2. Launch the application
3.Create an account
4.Connect and create a “house”

Step2: Add device
Tap “+” button in the main interface view to open the device
adding view. Then Select autosearch. It will auto connect to
device.
Step 3:Live view
Tap the online device icon in the device list, the channel’s video
will be connected and display automatically.

Informations
Default Admin password
admin
Log out
If you need to log out the user during use,
you can right-click the shortcut menu,
choose to shut down the system, and click
logout to complete.
The user needs to re-enter the user name
and password when logging out of the
system and operating again.
Reboot
If you need to restart the machine during
use, you can right-click the shortcut menu,
choose to shut down the system and click
restart to complete.
Shut Down
If users need to shut down the system
during use, they can right-click the shortcut
menu, choose to shut down the system,
click to shut down the system to complete.
