Daewoo FREE GLIDE SDA1592 User manual

1
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
•Read and familiarise yourself with all operating
instructions before using this Steam Iron.
•Before plugging your steam iron into the mains, visually
check that the steam iron is intact and has not suffered
any transit damage.
•Check that the voltage indicated on the data plate
corresponds with that of the local network before
connecting the appliance to the mains power supply.
•Close supervision is required when using this appliance
near children.
•Never leave this appliance within reach of children.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory
and mental capabilities or lack of experience or
knowledge if they have been given supervision or
instruction concerning use if the appliance in a safe way
and understand the hazards involved.

3
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
•Keep the appliance and its cord out of reach of children
aged less than 8 years.
•DO NOT leave the appliance unattended during use.
•DO NOT leave the appliance unattended whilst
connected to the mains supply.
•Always use this appliance on a solid, level, non-
flammable surface.
•DO NOT use this appliance outdoors.
•It is imperative to unplug the power cord after the
appliance has been used, before it is cleaned and whilst
being repaired.
•If the power cable is damaged, it should only be replaced
by suitable qualified personnel in order to avoid a hazard.
•Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place user
at serious risk.
•DO NOT operate this appliance with a damaged plug or
cord, after a malfunction or after being dropped or
damaged in any way.
•Regular, periodic checks should be carried out on the
mains cable to ensure no damage is evident. Should there
be any signs of damage the appliance should not be used.
•DO NOT allow the mains cable to hang over sharp edges
or come in contact with hot surfaces.
•DO NOT run the mains cable under carpets, rugs, etc.
•Allow the unit to cool before storage.
•Never place the appliance near to flammable material or
high pressure containers.
•This appliance is intended for household use only and

4
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
should not be used for industrial purposes.
•DO NOT use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
•DO NOT immerse the appliance, base or its cord in water
or any other liquids.
•DO NOT use this appliance for anything other than its
intended use.
•DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
•Ensure appliance is situated in an open area, do not allow
it to come in contact with or place beneath cupboards,
curtains, wall coverings, clothing or other flammable
materials.
•Unplug after each use. Grasp the plug, not the cord.
•DO NOT cover this appliance.
•CAUTION: The soleplate of the steam iron will get hot
during use.
THIS APPLIANCE MUST BE EARTHED

5
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and not sent to
landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or visit www.recycle-more.co.uk, enter your
postcode to find out your nearest recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.

6
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before the First Use of Your Steam Iron
1. Remove all packing materials, including the plastic protective cover from the
soleplate and discard responsibly.
2. Ensure all parts are present (if applicable) see Description of Parts above.
3. Wipe the soleplate of the steam iron using a soft, clean damp cloth and dry
thoroughly. DO NOT immerse the steam iron in water or any other liquid.
Whilst using the steam iron for the first time, a little smoke or odour may be
emitted, this is normal and will soon pass.
1. Steam Trigger
2. Spray Button
3. Steam Adjustment Button
4. Tank Filling Spout (Under Cover)
5. Water Tank Max Fill Level
6. Spray Outlet
7. Mains Cable
8. Unlock Button
9. Indicator Light
10. Temperature Dial
11. Soleplate
12. Measuring Cup
1
2
3
4
5
6
7
9
10
11
12
8

7
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Setting up Your Steam Iron
1. Do not insert the mains plug into the mains socket.
2. Place the steam iron on a solid, level, and heat
resistant surface at a comfortable height for the
user.
3. Fill the water tank of the steam iron using the
Measuring Cup (12) through Tank Filling
Spout (4) with cold water as shown left.
4. Ensuring water does not exceed the Water Tank
Max Fill Level (5) on the surface of the steam iron in
upright position.
To keep the base smooth and scratch free do not run the iron over metal
objects such as zips, buttons etc.
If your area has hard water it is advisable to use only distilled or demineralised
water.
Disconnect the iron from the mains after use and allow to cool before pouring
out any remaining water.
Do not store the iron with water in the water tank.
WARNING! Do not use chemically de-limed or perfumed water.

8
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Setting the Temperature
1. Refer to the ironing instructions on the garment to be ironed.
2. If the garment doesn’t have any ironing instructions but you know the type of
fabric used in the garment, follow the chart below.
3. Fabrics with special finishes should be ironed at the lowest temperature
setting.
4. With mixed fibres always select the lowest applicable temperature.
5. Group items with similar fibres together, as the iron heats up faster than it
cools, start ironing clothes requiring the lowest temperature first.
6. Set the Temperature Dial (10) to the setting according to the guide below:
Using your Steam Iron
1. Fill the Iron as described in the Setting up Your Steam Iron
section.
2. Place the Iron in the upright position on a stable surface,
then plug the Iron into the mains supply.
3. Set the Steam Adjustment Button (3) to ‘0’ position as
shown right in Fig(a).
4. Set the Temperature Dial (10) as described in the Setting
the Temperature section.
5. The Indicator Light (9) will then stay Red indicated that the
Iron is heating up.
6. Once the Indicator Light (9) turns off indicated that the iron
has reached the temperature and is ready to iron.
During any breaks whilst ironing, always ensure that the iron is placed in the
upright position on a stable surface.
Temperature Dial (10) Position
Garment Type
● Position (Low temperature)
Nylon, Silk or Synthetics
●● Position (Medium temperature)
Wool or Mixtures
●●● Position (High temperature)
Cotton or Linen
Fig(a)

9
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Steam Ironing
1. Set the Temperature Dial (10) to MAX. Steam Ironing is only possible at MAX
temperature, otherwise the water will leak from the soleplate.
2. The Indicator Light (9) will then stay Red indicating that the Iron is heating up.
3. Once the Indicator Light (9) turns off indicates that the iron has reached the
temperature and is ready to iron.
4. Set the steam output on the Steam Adjustment Button (3) as shown below
and position the iron horizontally.
5. After few seconds, the steam will be generated from the soleplate.
During any breaks whilst steam ironing, always set the steam output to “0”
and place the iron in the upright position.
Do not press the Steam Trigger (1) button otherwise the water will leak from
the soleplate.
The steam can only emit when the iron is placed horizontally.
Spray Function
1. Press the Spray Button (2) to use the Spray Function.
Steam Burst Function
1. Set the Steam Adjustment Button (3) to ‘0’ position.
2. Press the Steam Trigger (1) button to use the Steam Burst Function.
Spray Button (2)
Steam Trigger (1)
No steam
Low steam
High steam
Steam Adjustment
Button (3)
Steam Adjustment
Button (3)

10
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using the Cordless Feature
Once the desired temperature has been reached,
press the Unlock Button (8) to detach the base
with the cable then you can use the iron freely.
Self-Cleaning Function
Your iron will give the best ironing results and last longest if you apply the Self-
Cleaning once a month, or more depending upon the usage.
1. Fill the water tank to half with water.
2. Position the iron in the upright position on a stable surface.
3. Plug the Iron into the mains supply.
4. Turn the Temperature Dial (10) to MAX.
5. Allow the iron to heat up until the Indicator Light (9) turns off.
6. Unplug the iron from the mains power supply.
7. Keep the iron horizontally over the sink.
8. Set and hold the Steam Adjustment Button (3) to
SELF CLEAN position as shown right, boiling water
and steam will then emit from the soleplate after
few seconds.
9. Move the iron forwards and backwards
until the water tank is empty.
10. Release the Steam Adjustment Button (3) then it will go back to ‘0’.
11. Plug the Iron into the mains supply.
12. Turn the Temperature Dial (10) to MAX, then let the iron heat up again. The
remaining water inside the steam chamber will now vaporize through the
soleplate.
During this process of dry steaming, it is recommended to use it over an old
piece of cloth.

11
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Anti-Calc Function
The anti-calc function can remove the limescale and impurities from the water. It
is recommended this is performed regularly to prolong the efficiency of the steam
iron by following the steps below:
1. Make sure the steam iron is unplugged from the mains power supply and has
fully cooled.
2. Fill the water cup with 3/4 full, add descaling solution until water tank is to
MAX (follow instruction on descaling solution).
3. Leave the solution in the water tank for 15 minutes, shaking occasionally, and
then empty it.
4. Repeat steps 2 and 3 until the iron is descaled.
5. Fill the tank with fresh water to rinse and empty.
Care and Storage
•Before carrying out any cleaning or maintenance, ensure that the steam iron is
unplugged from the mains power supply and has fully cooled.
•Wipe the soleplate with a soft damp cloth and dry thoroughly, after pouring off
any remaining water. The body of the iron can also be wiped down with a soft
damp cloth, do not use harsh or abrasive cleaning products.
•Empty the iron immediately after each use. Do not store the iron with water in
it.
Not emptying the water will damage the iron.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician. Never use a mains plug with the fuse cover missing.
If you need to remove the plug –DISCONNECT FROM THE MAINS –and then cut it
off the mains lead and immediately dispose of it safely. Never attempt to reuse
the plug or insert it into a socket outlet as there is a danger of electric shock.
Technical Data
Model No.
SDA1592
Rated Voltage
230V~ 50/60Hz
Rated Power
2200W
Protection Class
I (This Appliance must be Earthed)
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.

12
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
Unit not powering
up.
Mains plug not in
socket.
Check that the mains plug is
inserted into the socket and is
switched on.
Temperature dial is
not set to the correct
setting.
Rotate the Temperature dial
clockwise to the required heat
setting.
Fuse has blown in the
mains plug.
Check by substitution.
Unit does not
steam.
The water tank may be
empty.
Unplug the iron and fill as per
the instructions.
White substance is
appearing around
spray outlet and
soleplate.
Calcium deposits.
Use distilled or demineralised
water

13
2200W Cordless Steam Iron
Model No. SDA1592
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must becorrectly installed and operated in accordance with the
requirements contained in the instruction manual.
• The product must beused solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
