Daewoo RFS-26A Series User manual

RFS-26A..
Code : MRF701-11

Disposal of Used Electrical &
Electronic Equipment
The meaning of the symbol on the product, its
accessory or packaging indicates that this product
shall not be treated as household waste. Please,
dispose of this equipment at your applicable
collection point for the recycling of electrical &
electronic equipments waste.
In the European Union and Other European countries there
are separate collection systems for used electrical and
electronic product. By ensuring the correct disposal of this
product, you will help prevent potential
hazards to the environment and to human health, which
could otherwise be caused by unsuitable waste handling of
this product. The recycling of materials will help conserve
natural resources.
Please do not therefore dispose of your old electrical and
electronic equipment with your household waste.
For more detailed information about recycling of this
product, please contact your local city office or your
household waste disposal service.
RoHS (Directive 2002/95/EC) Compliant
This product is environmentally sound and
sustainable free from Pb, Cd, Cr+6, Hg, PBBs
and PBDEs restricted in accordance with the
Directive.
Refrigerant Information
(R-134a Models Only)
OBSERVE AMBIENT TEMPERATURE
This refrigerator is designed to operate in ambient
temperature specified by its category, which is marked on
the rating plate
NOTE
Internal temperature may be affected by such factors as
the location of the refrigerator, ambient temperature and
frequency of the door opening.
Refrigerant R-134a
Charge 0.190kg
Global Warming Potential 1300
Contains fluorinated greenhouse gases covered by the
Kyoto Protocol and is hermetically sealed.
Foam blown with fluorinated greenhouse gases.
Climatic category Ambient temperature from...to
SN + 10to + 32
N + 16to + 32
ST + 16to + 38
T + 16to + 43
Contents
Be sure to keep for safety ·······································1~2
Installation Guide·················································2
Control Panel ······················································3
Temperature Control ············································4
How to use Interior Parts ······································5
How to use the Dispenser ··································· ·6
How to use the Automatic Icemaker·························6
Care & Cleaning ···············································7~8
Before You Call for Service... ·······························8~9
Something strange?
Don't worry. Here is the answer ····························10
Installation Preparation ···········································11
If the refrigerator can not pass through a door
during installation, follow these steps ·····················11
Refrigerator Leveling &
Door Adjustment (if needed.) ···································12
Water Filter ························································14
How to install Water Line···································14 ~ 15

Be sure to keep for safety!
Read these safety instructions thoroughly and carefully
before using. Please keep this user guide on hand for
future reference.
Indicates the possibility of danger of
death or serious injury.
Indicates the possibility of risk of personal
injury or material damage.
Other Signs
DO NOT remove or disassemble!
Be sure to unplug from outlet/mains!
NO. DO NOT...
Be sure to keep and follow!
Caution
1. If the supply cord becomes damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
2. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
WARNING
Never let the power cord be crushed
by the refrigerator itself or other (heavy)
objects.
Never bend power cord excessively.
If the cord is damaged or peeled, it can be a
cause of fire and electric shock.
Do not plug several appliances into the
same wall outlet.
It can be a cause of overheating and/or fire.
Use an exclusive grounding receptacle for
the refrigerator.
Never hold the power cord or plug with wet
hands.
There is a risk of electric shock.
Never use a damaged power cord or plug,
or loose main socket.
There is a risk of fire, electric shock or
serious injury.
Be sure to ground. Check if your wall outlet
is grounded (earthed).
There is a risk of electric shock hazards.
Never unplug by pulling only the power cord
wire. Always grip the plug firmly.
Let the cord from the plug outlet be
directed downwards.
If it is directed up, the cord near the plug is
bent and can be damaged, which can
cause an electric shock or fire.
Do not install the refrigerator on a wet
floor or in a place with excessive humidity and
moisture.
Electric insulation gets weakened,
resulting in a risk of electric shock
hazards.
Never let the power cord touch or pass over
heating appliances.
Power cord can be damaged, resulting in a
risk of electric shock hazards.
Check if plug is loose from the wall outlet.
Electric insulation gets weakened,
resulting in a risk of electric shock
hazards.
Never pour or spray water into the
refrigerator (both interior and exterior).
Electric insulation gets weakened, resulting
in a risk of electric shock hazards.
Do not place containers with water or
liquid on top of refrigerator.
Water can spill into the refrigerator
and can cause electric shock hazards or
damage.
Do not let children hang on the refrigerator
doors.
Refrigerator can fall and harm them.
1

Do not move or remove compartment
shelves/pockets while foods and
containers are on them.
Hard containers (of glass, metal etc.) can
fall to hurt you and can break glass shelf
and interior parts.
Never repair, disassemble or amend the
refrigerator on your own.
There is a risk of personal injury or damage
to the refrigerator. It is recommended that
any service be carried out by a qualified
person.
Never store any flammable gas or liquid
in the refrigerator.
Never use flammable gas, benzene, thinners,
gasoline, spray etc. near the refrigerator.
There is a risk of fire, explosion and
personal injury or damage.
If a gas leak is found near the refrigerator
or in the kitchen, ventilate it immediately
without touching the power plug or
refrigerator.
Do not store medicine, academic research
samples which require strict temperature
control in the refrigerator.
Never insert fingers or hands into the bottom
of the refrigerator, especially into the bottom
back.
You can be hurt by sharp metal edges or can
receive an electric shock.
Do not change fuse or LED lamp on your own.
Call the service agent to change them.
When you find the power cord damaged or
cut, call the service agent immediately.
When you get rid of your old refrigerator, be
sure to remove the door packings first.
Children can be entrapped and suffocated in
an abandoned refrigerator.
CAUTION
Be sure to unplug the refrigerator when it is
not going to be used for a long time.
Never touch foods and containers
especially of metal with wet hands in the
freezer compartment.
You can be hurt by chilblains or cold burns.
Never eat any decayed or deteriorated food at all.
Foods stored too long in the refrigerator can
deteriorate and become decayed.
Never place bottles and containers of glass
in the freezer compartment.
Glass containers and bottles can break
and hurt you.
When moving the refrigerator (horizontally
or tilted), more than 2 persons are required
to hold it.
(One to hold top back handles, the other to hold
the bottom holder. )
If other parts are held instead, it is very
dangerous and likely to slip.
Be sure to turn up the wheel first before
moving the refrigerator.
The wheels can damage or scratch the floor.
If you are moving it for a long distance, never
forget to fasten the interior parts tightly with tapes.
Otherwise, the parts can collide and
break each other.
Installation Guide
↜Read these safety instructions carefully before use and
follow precautions for your safety.
Precautions in installation and
power connection
¥To prevent fire, electric shock or leakage
⇡Never install the refrigerator on a wet, watery floor or
where water can gather easily.
⇢Check the following before power connection.
Connect power plug only to a grounded wall socket
(an earthed mains).
Do not plug refrigerator power together with other
appliances to the same socket.
⇣Do not use an adapter plug or an extension cord.
2

3
⇤Do not let the power cord be crushed by other
(heavy) objects.
 If you hear a strange noise, strong chemical odour
or find smoke etc. from the refrigerator after the
power is plugged in, pull out the plug immediately
and call the service agent.
 Wait about 5 minutes before you plug-in again in
order to prevent any damage to the compressor and
electrical devices of refrigerator.
 Wait 2~3 hours until the inside gets cold enough after
the first power plug-in, then store foods inside.
(There can be some smell of plastic parts on initial
operation of the refrigerator after plugging in.
The smell fades away as the refrigerator works and
doors are opened and closed.)
Precautions in use
¥To prevent personal injury, fire, electric shock etc. read
this user guide carefully before use and keep it at
hand for any reference.
¥Accessories
Control Panel
1. FRZ.SET button
Selection button for freezer compartment
temperature.
2. QUICK ICE button : Quick ice cube production
on/off switch.
3. Water dispenser button
4. Crushed ice dispenser button
5. Ice cube dispenser button
6. Alarm/Lock button
Switching the warning signal off/
switching panel lock on/off
Lock button for control panel
Press button for more than 3 seconds to
activate and prevent settings from being
unintentionally changed.
To release the button, press for longer than 3
seconds. The display goes out.
7. REF.SET button : Selection button for refrigerator
compartment temperature.
8. LIGHT/FILTER button
1) Button for dispenser light on.
2) Button for filter exchange or reset.
After exchanging or to reset press the button
for 3 seconds.
9. Symbols on the display panel
Quick ice
Appears when the “quick ice” function is on.
Light
Appears when the water dispenser light is on.
Water filter Filter exchange display
After 6 months of first power input, the icon will
flicker. When the appliance is turned off,
the water filter symbol is reset.
Panel lock
Appears when the panel lock is on
Interior lights of the refrigerator turn off when the doors are open for more than 20 minutes.
In case either the freezer or refrigerator door is left open for more than a minute, door alarm rings for 5 minutes with
1 minute intervals.
Display off function
- 1 minute after no buttons or doors are operated by customer, all the display LED turns off.
- Under the LED off status, it returns to normal display mode when customers operate buttons or doors.
Alarm function
- The door warning signal sounds if one of the doors is open for more than one minute,
or the temperature inside the appliance is too high.
- The warning rings with 1 minute intervals and the “alarm” will blink on the display.
- To switch off the warning signal, close the door if a door is open, and press “ alarm/lock” button.
Note

Temperature Control
↜When this refrigerator is first plugged in, the temperature
mode is set to [Middle].
Freezer Compartment
Push the FRZ.SET button and the setting temperature
changes as the figure shows.
>>> Sequential Temperature Change <<<
When you want faster freezing, push the FRZ.SET button,
until 'Super' LED turns on. Just push the button again to
release.
Refrigerator Compartment
Push the REF.SET button and the setting temperature
changes as the figure shows.
>>> Sequential Temperature Change <<<
When you want faster freezing, push the REF.SET button,
until 'Super' LED turns on. Just push the button again to
release.
Temperature indicator convert function
(Fahrenheit ƧCelsius)
Press “alarm/lock” button to enter locked mode.
Under the locked mode, press and hold “quick
ice” button for 15 seconds until the temperature
unit switches.
Caution
Food in the refrigerator can be frozen if the ambient
temperature of the refrigerator is below 5°c.
4
Faster Freezing...
Faster Cooling or Refrigeration
Note

5
How to use the interior parts
⇡
⇢
⇤
⇧
⇩
⇨
⇪
⇫
⇣
⇥
1. Door storage compartment
for storing butter and cheese.
2. Door storage compartment
for storing refrigerating food of
small size.
3. Door storage compartment
for storing refrigerating food.
4. Door storage compartment
for storing refrigerating food.
5. Ice maker/Ice storage bin
for making and storing ice.
6. Water filter
7. Adjustable glass shelf
for storing common food.
8. Small glass shelf
for storing common food.
9. Vegetable case
10. Wide case
11. Freezer case
12. Freezer drawer
13. Control and display panel
13-1. Water dispenser
13-2. Ice dispenser
14. Egg case
15. Ice storage case
⇬
⇦
⇯
⇭
⇮
⇡
⇣
⇩
13-1
13-2

Caution
  Do not touch or hold food with wet hands
(food container) in the freezer compartment
óThere is a risk of chilblains (cold burns).
 Do not store medicine, academic research
samples etc. in the refrigerator.
Do not store vegetables in the chilled room, for
they can be frozen.
Food Storage Tips
Wash food before storing.
Divide and separate food into
smaller pieces.
Place watery food or food
with a lot of moisture in front
shelves (close to door side).
If they are placed close to the
cold air spout, they can be
frozen.
Warm or hot food should be
cooled down enough before
storing to reduce power
consumption and to enhance
refrigeration performance.
Be careful in storing tropical fruits
such as bananas, pineapples and
tomatoes, as they can easily
deteriorate in lower temperatures.
Keep enough space between
the foods. If too tight or too close,
cold air circulation is hindered, resulting
in poor refrigeration.
Never forget to cover or wrap
food to prevent odours.
How to use the Dispenser
Hold an appropriate container under the ice and water
dispenser.
Keep ‘WATER’, ‘ICE CUBE’, or ‘CRUSHED ICE’ button
pressed until the desired amount of water/ice is in the
container.
Caution
Avoid using thin fragile cups or crystal glasses when
taking ice cubes.
For your safety, never insert your fingers or other tools
into the dispenser outlet.
If you find the ices discolored, stop using the dispenser
and call the service agent.
How to use the Automatic
Icemaker
About 8 ice cubes (14~16 times a day) are made at one
time. If the ice storage case is full, ice making stops.
It is normal for the icemaker to make banging sounds
when the ice cubes are falling into the ice storage case.
To prevent bad odour or smell, regularly clean the
ice cube's storage case.
If the amount of ice in the storage case is not sufficient,
the ice may not be dispensed. Wait a day or so to make
more ice.
If the ice does not dispense easily, ensure the dispenser
outlet is not blocked.
In case the ice maker doesn’t work
If the ice cubes get stuck and not
dispensed
Pull out the ice storage case and separate
any ice cubes that may have stuck together.
If the amount of water which is supplied to the icemaker
needs adjusting, call for the service agent.
In case of power failure
The ice cubes in the storage case may melt to flow down
to the ice dispenser.
If many hours of power failure is predicted, pull out the
storage case, remove the icecubes in it and replace it
back when power resumes.
6
WATER ICE CUBE / CRUSHED ICE

7
Care & Cleaning
⇡Water Dispenser
Remove the strainer and clean the water collecting
tray with a sponge or absorbent cloth.
⇢Ice cubes storage Case
 Removing: Press the release button and remove the
ice cube container.
 Cleaning: Empty the ice cube container and clean
with lukewarm water. Thoroughly dry the container
and screw the conveyor to prevent new ice cubes
from sticking.
 Replacing: Push the ice cube container all the way
back onto the supports until it locks into position.
If the container cannot be pushed all the way back,
rotate the swirl coil a quarter turn and insert again.
⇣Freezer & Refrigerator Bins
Hold both ends and pull up.
⇤Refrigerator Shelves
Lift up and pull the shelf, unhook and then remove
the shelf. You can replace it at varying heights.
To place taller items such as tall
bottles, you can remove the small
glass shelf and place it in the holder
under the icemaker.
Be sure to
unplug first
⇡
⇤
⇢
⇥
⇧
⇦
⇣

⇥Vegetable case & Wide case
Pull out the cases as far as possible. Lift up the front
of the cases and pull them out.
Insert the cases into the rail and
push towards the back.
⇦Freezer case
Pull out the case as far as possible. Pull out the clips
on both sides and lift up the front of the freezer case.
⇧Freezer drawer
Lift the freezer drawer up and out.
How to Clean
Interior Parts
Use cloth with water and mild detergent to clean.
Back (Machine section)
Remove dust on the grill with a vacuum cleaner
at least once a year.
Caution
Never use petrol, benzene,
thinners, scouring pads or harsh
abrasives, for they can damage
the surfaces.
Disconnecting the ice maker
Make sure to shut off the water supply to the
appliance a few hours before disconnecting the
ice maker.
If ice cubes will not be dispensed for more than 1 week (such
as due to vacation), temporarily disconnect the ice cube
maker to prevent the ice cubes from freezing together.
1. Press the release button and remove the ice cube
container.
2. Switch the on/off switch behind the ice cube container off
(0) − the ice maker is deactivated.
3. Empty and clean out the ice cube container.
4. Push the ice cube container all the way back onto the
supports until it locks into position.
Reactivating the ice maker:
 Switch the on/off switch behind the ice cube container on
(1) − the ice maker is activated.
8
Note

Before You Call for Service...
Please check the following troubleshooting tips before you call
for service!
Problem
It never gets cold inside.
Freezing & refrigerating is
not so good.
Checkup Point
⇡Is the refrigerator unplugged?
⇢Is the temperature set to [Low Mode]?
⇣Is the refrigerator under direct sunlight or is a
heat appliance placed near it?
⇤Is the space between the refrigerator back and the
wall too close?
Action
⇡Plug in the refrigerator.
⇢Set the temperature mode to Middle or High.
⇣Move to a place where there is no direct
sunlight, no heat appliances around.
⇤Keep sufficient space (more than 5cm)
between the back of the refrigerator and the wall.
Problem
Foods in the
refrigerator get frozen.
Checkup Point
⇡Is temperature set to [High]?
⇢Is the room temperature too low?
⇣Is food with moisture stored close to the cold air
spout?
Action
⇡Set the temperature to [Middle] or [Low].
⇢Food can be frozen if ambient temperature is below 5.
Move to a place where the temperature is over 5.
⇣Place food with moisture on the shelves close to the
doors.
Problem
Strange sounds from
the refrigerator.
Checkup Point
⇡Is the floor beneath the refrigerator uneven?
⇢Is the space between refrigerator back and the wall too
close?
⇣Do any objects or other stuff touch the refrigerator?
Action
⇡Move the refrigerator to a level and even floor.
⇢Keep sufficient space.
⇣Remove any object which touches the refrigerator.
Problem
Odour or unpleasant
smell from the inside.
Checkup Point
⇡Is the food stored uncovered or unwrapped?
⇢Are the shelves and pockets stained with food stuff?
⇣Is the food stored too long?
Action
⇡Be sure to cover and wrap the food.
⇢Clean them regularly. Once smell gets soaked into those
parts, it is not easy to remove.
⇣Do not store food for too long. A refrigerator is neither a
perfect nor a permanent food keeper.
9

Something strange ?
Don’t worry. Here is the
answer.
Front and side of refrigerator feels
warm or hot.
Pipes (refrigerant vessel) are placed beneath the
surface to prevent moisture forming on it.
Heat
Door
is
sticky
Strange
Sound
Frost
& Dew
Explanation
Case
Doors do not open easily.
It sounds like water is flowing from
the refrigerator.
When you close the door and then open again
immediately, the door is not easy to open
because warm air rushes in and creates
the pressure difference.
In this case wait for a minute, then it will open
easily.
When the compressor starts to run or stop,
refrigerant which makes the inside cold flowing in
the pipes can make such a sound.
Defrosted water can also make such a sound.
(This refrigerator adopts an automatic defrosting
system.)
Cracking or clicking sounds.
Inside parts shrink and/or expand due to
temperature change --- When the inside gets
cold or when the door is open, such sounds can
be made.
Humming or buzzing sounds.
Dew or frost on the wall and/or
food container surface in the
freezer and refrigerator
compartment.
Dew on the cabinet surface.
Compressor or fans for cold air circulation can
make such working sound. (If the refrigerator is
not level, the sound can be louder.)
If it is highly humid around the refrigerator,
moisture in the air sticks to the surface to form
dew.
Frost and/or dew can be made in the following
cases;
High temperature and/or high humidity around
the refrigerator.
When doors are open too long.
Food with much moisture are stored uncovered
or unwrapped.
You can see the same appearance when cold
water is poured in a glass cup and dew is
forming on the surface of it.
10

11
Installation Preparation
Check if the refrigerator can pass a
doorway or enter a door first.
Dimensions (including Door Handles)
(Width*Depth*Height) 910mm x 895mm x 1772mm
Find a suitable place to install
Sufficient space from the back of the refrigerator to the wall
for free air ventilation.
Avoid direct sunlight.
Once the installation place is ready, follow
the installation instructions.
If the surrounding temperature of refrigerator
is low (below 5), food can be frozen or the
refrigerator can function abnormally.
If the refrigerator can not
pass through a door
during installation, follow
these steps.
This instruction manual refers to several models. The real
features are model dependent.
Caution
Risk of electric shock! Before removing top hinge cover:
hShut off the water supply to the appliance.
hUnplug the appliance or switch off the fuse.
Removing left refrigerator door
Unscrew top hinge cover with a screw driver and
remove the hinge cover.
Unscrew the earth and disconnect the harness wires
and water tube.
Turn top hinge fastener counterclockwise and remove
the top hinge. (After the hinge is removed, the door can
fall down forward. Be careful!)
Note
1
2
3

12
Removing right refrigerator door
1. Turn top hinge fastener counterclockwise and remove
the top hinge. (After the hinge is removed the door can
fall down forward. Be careful!)
2. Lift up the door and remove it. (The same as step 4,
step 5 in removing the left refrigerator door.)
Removing freezer door
Open freezer door as far as possible, pull up freezer
case and freezer drawer.
Push locks (on both sides) and pull the freezer door
forward and remove.
Replacing refrigerator doors
- Replace the left door, right door, then replace the top
hinge cover.
- Replacing steps are the reverse of the steps of removing
the doors.
Replacing freezer door
Align the end of rails (both sides) with supporter of
freezer drawer rail.
Fully push and close freezer door, check the locking of
the rail with the lock of supporter.
Open the freezer as far as possible, assemble one
gear rail in supporter of rail gear.
Push and assemble another gear rail on opposite side
of the rail.
Refrigerator Leveling &
Door Adjustment
(If needed)
The refrigerator must be level in order to maintain optimal
performance and desirable front appearance.
(If the floor beneath the refrigerator is uneven, the freezer
and refrigerator doors look unbalanced.)
Leveling and door adjustment
Leveling the appliance.
Remove the front cover, if it is attached.
Use a hexagonal wrench to align the front of the
appliance.
Adjusting a refrigerator door
If the height of the refrigerator doors is uneven, turn the
screw nut on the lower hinge to adjust the refrigerator door.
- To raise a refrigerator door turn the screw counterclockwise.
- To lower a refrigerator door turn the screw clockwise.
1
2
1
2
3
4
1
2

13
Aligning the refrigerator doors
Caution
Risk of electric shock! Before removing top hinge cover
1. Shut off the water supply to the appliance.
2. Unplug the appliance or switch off the fuse.
If the refrigerator doors are not properly aligned.
Unscrew the top hinge cover and raise the panel
Do not disconnect any harness wire or water tube!
Loosen the fastener counterclockwise, move the hinge
sideway to adjust the refrigerator door.
Do not remove the fastener!
Tighten the fastener and replace the top hinge cover.
Adjusting the freezer drawer
If the freezer drawer is not even.
1. Loosen the two side fasteners.
Do not remove the fasteners!
2. Use the top fastener to adjust the freezer drawer.
3. If level of freezer drawer is proper, tighten the two side
fasteners.
Front Cover
After installation and/or door leveling, fasten front cover with
screws. (Remove the screws on the front bottom panel first.
Click and screw the cover.)
Caution
The front of refrigerator needs to be just a little
higher than the back for easy door closing, but if
the wheel is raised too much for door balance,
i.e. the front of refrigerator is much higher than
the back, it can be difficult to open the door.
Installing the handles
- After installation and/or door leveling, install the handles.
- All the handles are identical.
Insert refrigerator door handles into guide, the direction
of set screw being to the center of the appliance.
Fasten the set screw with the L- wrench (supplied).
Insert freezer door handles into guide,
the direction of set screw being to downward.
Fasten the set screw with the L- wrench (supplied).
1
2
3
1
2

Foldaway door bar (mullion bar)
- When closing the left refrigerator door, the mullion bar
folds behind the right refrigerator door, forming a seal
between the refrigerator doors.
- When opening the left refrigerator door, the mullion bar
folds back to the left door automatically.
(mullion bar folds back O) (mullion bar folds away X)
- The mullion bar may become damaged if you attempt to
close the left refrigerator door with mullion bar folded out.
When closing the left refrigerator door, make sure the
mullion bar is folded back.
Water filter
1. Disconnect the water supply to the
appliance.
2. Remove the locking cap for
installing the filter.
(The ice and water dispenser can
also be used without a water filter,
in which case the locking cap must
be used.)
3. Carefully turn the filter clockwise.
4. Change the filter at least once
every 6 months.
A new filter can be obtained from aftersales services.
Caution
Wipe with cloth if droplets fall when
exchanging a filter. Draw water from the water
dispenser for 5 minutes before use. This will
remove air from the water system.
Information concerning the water filter
- After use, the water system is subject to low pressure.
Proceed with caution when removing the filter.
- Flush the water system if the appliance has not been in
use for a long period of time, or if the ice/water has an
unpleasant taste or smell. To do this, dispense water
through the water dispenser for several minutes.
If the unpleasant taste or smell remains, replace the filter.
- Protect from frost, remove the filter cartridge if you expect
the temperature to drop below freezing.
- If pressure surges could occur in the water pipe, do not
install the water filter without a suitable surge eliminator.
Contact an installation expert if you are not sure whether
pressure surges could occur in the water pipe.
- After installing a new filter:
Discard any ice produced in the first 24 hours after
switching on.
- If no ice has been removed for a long period of time,
empty the ice box and discard any ice produced over the
next 24 hours.
How to install water line
1. The water pressure should be 2.0 ~ 8.8kgf/cm²
(1.96~8.62 Bar) or more to run the automatic icemaker.
Check your tap water pressure; if a cup of 180cc is
full within 10 seconds, the pressure is OK.
2. When installing the water tubes, ensure they are not
close to any hot surfaces.
3. The water filter only filters water; it does not eliminate
any bacteria or microbes.
4. If the water pressure is not high enough to run the
icemaker, call the local plumber to get an additional
water pressure pump.
5. If the water pressure exceeds 8.8kgf/cm² (8.62 Bar), a
pressure reducing valve must be installed.
6. The filter life depends on the amount of use. We
recommend you to replace the filter at least once every
6 months.
7. After installation of refrigerator and water line system,
select [WATER] on your control panel and press it for
2~3 minutes to supply water into the water tank and
dispense water.
8. Use plumbers thread sealing tape on every connection
of pipes/tubes to ensure there is no water leaks.
9. The water tube should be connected to the cold water
line.
14

WATER SUPPLY KIT
Connecting the water line to the refrigerator.
(Necessary parts are available at local service agents.)
1. Connect water line to the compression fitting.
- If you are using copper tubing (not supplied), slip the
compression nut (not supplied) and ferrule (not supplied)
on copper tubing.
- If you are using plastic tubing (not supplied), insert the
molded ending of the plastic tubing into the compression
fitting.
2. Tighten the compression nut onto the compression
fitting.
3. Turn the water on and check for any leakage.
15
