Daewoo DMR - 08SO User manual

Service Manual
Refrigerator
http : //svc.dwe.co.kr Mar 2002
DAEWOO ELECTRONICS CO., LTD.
S/M No. : DMR0811001
DMR - 08SO
DMR - 08SN
DMR - 08SE
DMR - 08D
DMR - 11S
DMR - 11D
MODEL :

1
1. SPECIFICATION
Division Contents CONTENTS Remark
Freezer(L)
Refrigerator(L)
Usable Capacity
TOTAL(L)
W(mm)
D(mm)
Products
H(mm)
Net Weight Products Weight(Kg)
Cooling System Fan Cooling Type
Defrosting Control Automatic On and Off
Compressor type HEL18YH-1
Gas Charge Volume(gr) 150 R-134a
Cooling
Control
System
Temp. Controlling Method F-Control Type
Rated Voltage 127V/60Hz
Rated Power Consumption of Motor 120V/7.2W
Rated Power Consumption of Heating System 120V/148W
Electric
Characteristics
Power Consumption
76
218
294
650
635
1650
1.Quality Contents

2
2. NAME OF PARTS
1.DMR-11S

3
Name of Parts
2.DMR-11D

4
3. AIR FLOW DIAGRAM
Freezer door pocket
Do not put in ice cream or frozen
Food to store for a long term.
Open and shutting the door can rise
Up the temperature
Cold air absorbing duct
Do not place food in front of the duct
Because it is the entrance of the cold air
Refrigerator door pocket
Temperature is high even if the
Pocket is in the middle.
When storing margarine or cheese
Of one or two weeks, make use of
the refrigerator shelf.
Crisper
Suitable in storing fruits or vegetable.
Wraping can prevent then from dryness
B
C
Freezing Room
Do not put in any bottle
such as beer or beverage
because it can be frozen to
break.
Refrigerator Room
This model is multi-flow
type which flows ou
t
cold air from each shel
f
space. The hot air afte
r
making the refrigerato
r
cool flows into cooling
system through the low
temperature.
Do not put in food having much moisture at the middle par
t
of each shelf space(“A”,”B” and ”C” part).
It can be frozen owing to the low temperature
A
B

5
4. REFRIGRANT CYCLE DIAGRAM

6
5. DIAGRAM
1) Wiring Diagram

8
Diagram
2)Practic Wiring Diagram

Diagram
3) Mechanical Room Piping and Assembly

9
6. Characteristics of Electric Parts
1) COMPRESSOR
2) RELAY
3) RUNNING CAPACITY
4) TEMP FUSE
5) DEFROSTING TIMER
DMR-11S/11D Remarks
Type
No. HEL18YH-1
Starting
Method RSCR
Rated Voltage 127V/60Hz
Main Core Resistance 2.76A
Aux.Cor Resistance 6.28A
DMR-11S/11D Remarks
Ty pe No. 308NHBYY-52
Resistance Value 6.8Ω
Max. Voltage 200V
PTC
Max. Current 10A
O.L Operating Current 2.18A, 90
DMR-11S/11D Remarks
Rated Voltage 200V
Rated capacitance 12㎌
DMR-11S/11D Remarks
Rated Voltage 250V
Rated Current 10A
Operating Temperature 77
Model DMR-11S/11D Remarks
Type Name TMDEY11UA1
Time 12H02M

Characteristics of Electric Parts
6) FAN MOTOR
7) GALSS HEATER
8) R LAMP
9) BI-METAL (Defrosting bi-metal)
10) F-THERMOSTAT
DMR-11S/11D Remarks
Type Name
PFN-C359-2A
B-359-4
ON:-10, OFF:-16
11) Door S/W
DMR-11S/11D Remarks
DSD-4 (125V, 0.5A)
(250V,0.25A)
2Button 3Pin
DMR-11S/11D Remarks
Type Name IS-23211DWBFF-3
Type Shaded Pole Induction Motor
Rated Voltage 127V, 60Hz
Input Power 7.2W
Number of Pole 2Poles
Revolution 2,650rpm
DMR-11S/11D Remarks
Rated Power 120V, 148W
Remarks
Type Name 125V, 15W
DMR-11S/11D Remarks
Type Name PB308L,IB308L
Returning Temperature ON:-4, OFF:9
Rated Power
Rated Power

7. EXPLODED VIEW AND PARTS LIST
11
1. Exploded view

12
8.PARTS LIST
DMR-08SO
/SN/SE/D DMR-11S DMR-11D
3010041200 0
3010801200 0 0
3017001100 0
3017001200 0 0
1-2 3016100500 ACCUMULATOR SAS Erasure
1-3 4016N03280 CLAMP CABLE 0 0 0
1-4 3018100201 BI-METAL AS 0 0 0
1-5 4017290590 FIXTURE FUSE TEMP 0 0 0
1-6 400EL21313 FUSE TEMP AS 0 0 0
1-7 3017001600 PAD EVA 0 0 0
3010045400 0
3010047900 0 0
2 4010G01123 BOLT SPECIAL 0 0 0
3010305600 0
3010305400 0 0
4 3010100201 ABSORBER COMP 0 0 0
5 4019H09030 WASHER COMP 0 0 0
6 30521234U0 COMPRESSOR 0 0 0 HEL18YH-1
7 3018120200 SWITCH P RELAY AS 0 0 0
8 7112401211 SCREW TAPPING 0 0 0
9 3011108510 CASE VAPORI 0 0 0
14 3016401500 CAPACITOR RUNNING 0 0 0 CHANGE
15 7112401211 SCREW TAPPING 0 0 0
16 4017Z40192 ADJ FOOT AS 0 0 0
17 7650602011 BOLT HEX 0 0 0
18 3012901900 HINGE *U AS 0 0 0
19 3018100400 SWITCH DOOR 0 0 0
20 3012900610 HINGE *M AS 0 0 0
21 3016002300 SCREW SPECIAL 0 0 0
22 3012900900 HINGE *T AS 0 0 0
23 7650602011 BOLT HEX 0 0 0
24 3010908900 CAP *T HINGE 0 0 0
25 3010903200 CAP SCREW 0 0 0
26 3010047200 ASSY FAN MOTR 0 0 0
1-8 ASSY D HTR
3 BASE COMP AS
REMARKS
1 ASSY CAB URT
1-1 EVAPORATOR SAS
NO PART CODE PART NAME
MODEL

13
PARTS LIST
DMR-08SO
/SN/SE/D DMR-11S DMR-11D REMARKSNO PART CODE PART NAME
MODEL
27 7112401611 SCREW TAPPING 0 0 0
3013319400 0 CHANGE
3013320000 0 0 CHANGE
3018902900 0
3018912600 0 0
3016903900 0
3016903600 0 0 CHANGE
31 3011105500 BOXICE 0 0 0
32 4010G56011 CASE ICING 0 0 0
33 3013403000 GUIDE F CONTROL 0 0 0 CHANGE
34 4017G31152 KNOB DAMP 0 0 0 CHANGE
35 3018107900 TIMER DEFROST 0 0 0 CHANGE
36 3018302301 HARNESS M/F DUCT*I 0 0 0 CHANGE
37 7112401411 SCREW TAPPING 0 0 0 CHANGE
38 3018302301 THERMOSTAT 0 0 0 CHANGE
39 7112401211 SCREW TAPPING 0 0 0 CHANGE
40 3011457600 COVER TIMER 0 0 0 CHANGE
41 4017G31041 KNOB C/S 0 0 0 CHANGE
42 3017901500 LAMP SOCKET AS 0 0 0 CHANGE
43 3013630800 LAMP R 0 0 0 CHANGE
44 7112401411 SCREW TAPPING 0 0 0 CHANGE
45 3015506300 WINDOW R 0 0 0 CHANGE
46 3013339000 INSU M/F DUCT 0 0 0 CHANGE
47 3011901000 FILTER DEOD 0 0 0 CHANGE
48 3016911100 COVER M/F DUCT 0 0 0 CHANGE
51 3017823500 SHELF F 0 NEW(1EA)
52 3017823600 SHELF R 0 NEW(2EA)
53 3011601300 DECORATOR F SHELF Erasure
54 3017806500 SHELF GLASS 0
55 3011105301 CASE VEGETB 0 NEW
56 3017805900 SHELF F 0 0
57 3017806000 SHELF R 0 0
3017806500 SHELF GLASS 0
3011413600 COVER VEGETB 0 0
59 3011108600 CASE VEGETB 0 0 0
30 DUCT RETURN
58
28 INSULATOR F LUVR AS
29 LOUVER F

14
PARTS LIST
DMR-08SO
/SN/SE/D DMR-11S DMR-11D REMARKSNO PART CODE PART NAME
MODEL
3010041360 0 NEW
3010040860 0 0 NEW
61 4010G38214 STOPPER DR 0 0 0
62 7112401411 SCREW TAPPING 0 0 0
3012308600 0 NEW
3012308300 0 0 NEW
64 3019014500 POCKET F *T 0 NEW(2EA)
65 3019005200 POCKET F *T 0 0 NEW
66 3019005300 POCKET F *U 0 0 NEW(2EA)
3010041460 0 NEW
3010040960 0 0 NEW
68 4010G38023 BUSHING R DR 0 0 0
69 4010G38034 STOPPER R DR 0 0 0
70 7640501211 BOLT EX 0 0 0
3012308500 0 NEW
3012308400 0 0 NEW
3011454900 0 NEW
3011448500 0 0 NEW
3011164500 0 NEW(2EA)
3011164000 0 0 NEW(2EA)
3011164400 0 NEW(4EA)
3011161400 0 0 NEW(4EA)
3019014700 0 NEW
3019005400 0 0 NEW
76 3019014600 POCKET F *U 0 NEW
77 3012510800 GUIDE POCKET 0 0 0 NEW
78 3017822700 SHELF F 0 NEW
79 3011164300 CASE ICE AS 0 NEW
80 3011162800 CASE CHILD 0 NEW
81 3012510000 GUIDE CHILD *L 0 NEW
82 3012510100 GUIDE CHILD *R 0 NEW
83 3011734700 DOOR CHILD 0 NEW
POCKET JUMBO75
73 CASE EGG
74 CASE DAIRY
GASKET R AS71
72 COVER DAIRY
63 GASKET F AS
67 ASSY R DR URT
60 ASSY F DR URT
