USER'S MANUAL

DABS1010

Belt sander

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

INDEX

.GENERAL SAFETY RULES ...................................................................................................................... 3

.SPECIFIC SAFETY RULES ...................................................................................................................... 4

.FEATURES ............................................................................................................................................... 4

.ASSEMBLY ............................................................................................................................................... 5

.OPERATION ............................................................................................................................................. 6

.MAINTENANCE ....................................................................................................................................... 7

.TECHNICAL SPECIFICATIONS ............................................................................................................... 8

8. EXPLODED VIEW

.....,............................................................................................................................. 9

WARRANTY ............................................................................................................................................... 11

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

6543

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

Fig.1

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

Fig.2

Fig. 4

Fig.3

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

Fig. 5 Fig. 6

Fig. 7

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

Fig. 9

Fig. 8

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

Fig. 10 Fig. 11

1 1

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

8. EXPLODED VIEW

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

1. The belt cover (x1)

2. Belt - 102×L031 (x1)

3. The middle cover (x1)

4. Cross slotted self tapping screw - ST4×14 (x12)

5. The interface of dust (x1)

6. Small pulley (x1)

7. Flat mat - ø12×ø8×0.5 (x4)

8. Bafe plate of dust (x1)

9. The left casing (x1)

10. Power cord (x1)

11. Sheath (x1)

12. Carbon brush - R24+5 (x2)

13. Brush (x2)

14. Brush cover (x2)

15. Reset spring (x1)

16. Flip (x1)

17. The axis of rotation (x1)

18. Locknut - M6 (x1)

19. Flat mat - ø13×ø6×1 (x5)

20. Before the handle (x1)

21. The screw - M6 (x1)

22. Front handle wrench (x1)

23. Half-round self-tapping screw - ST5×50 (x2)

24. The stator (x1)

25. Bearing - 608RZ (x3)

26. Creepage retaining ring (x1)

27. The rotor (x1)

28. Speed switches (x1)

29. Wind circle (x1)

30. Line pressing board (x1)

31. Switch (x1)

32. Capacitance - 0.22uf (x1)

33. Inductance - (x1)

34. Right casing (x1)

35. Cross slotted self tapping screw - ST4×16 (x12)

36. Nameplate decorative cover (x1)

37. Half-round self-tapping screw - ST3×10 (x3)

38. Nameplate (x1)

39. Abrasive belt - 76×533 (x1)

40. Cross head self tapping screw - ST4×40 (x4)

41. Front axle (x4)

42. Needle roller bearing (x1)

43. The front wheel (x1)

44. Fixed pin (split pin) (x1)

45. The front wheel rack (x1)

46. Adjust the spring (x1)

47. Flat mat - ø10×ø5×0.8 (x1)

48. Clamping spring (shaft clamping) - ø8 (x2)

49. Adjusting knob (x1)

50. The rivet - ø6×15 (x1)

51. Front wheel frame wrench (x1)

52. Plastic stent (x1)

53. Front wheel rest spring (x1)

54. Iron plate (x1)

55. Bearing - 626RZ (x1)

56. The rear wheel (x1)

57. Bowl gasket ø21×ø10 (x1)

58. Copper set of ø16×ø10×9 (x1)

59. After the shaft (x1)

60. Cylindrical pin (x1)

61. Ceramic chip (x2)

62. Stand (x1)

63. Flat mat - ø16×ø8×0.5 (x1)

64. Big gear (x1)

65. Bearing - 606Z (x1)

66. Pinion (x1)

67. Bearing - 627RZ (x1)

68. The pulley (x1)

69. Nut - M6 (x1)

70. Dust bag (x1)

WARRANTY DOES NOT COVER

GUARANTEE

The warranty period starts from the date of sale of the products and covers 2 years for all power products.

During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer

workmanship admitted fault are removed. The guarantee comes into force only when warranty card and cutting coupons are

properly lled. The product is accepted for repair in its pure form and full completeness.

• Mechanical damage (cracks, chips, etc.) and damage

caused by exposure to aggressive media, foreign objects

inside the unit and air vents, as well as for damage occurred

as a result of improper storage (corrosion of metal parts);

• Failures caused by overloading or product misuse, use of

the product for other purposes. A sure sign of overload

products is melting or discoloration of parts due to the high

temperature, simultaneous failure of two or more nodes,

teaser on the surfaces of the cylinder and the piston or

destruction of piston rings. Also, the warranty does not

cover failure of the automatic voltage regulator due to

incorrect operation;

• Failure caused by clogging of the fuel and cooling

systems;

• Wearing parts (carbon brushes, belts, rubber seals, oil

seals, shock absorbers, springs, clutches, spark plugs,

mufers, nozzles, pulleys, guide rollers, cables, recoil

starter, chucks, collets, removable batteries, lters and

safety elements, grease, removable devices, equipment,

knives, drills, etc.);

• Electrical cables with mechanical and thermal damage;

• Product opened or repaired by a non-authorized service

center.

• Prevention, care products (cleaning, washing, lubrication,

etc.), installation and conguration of the product;

• Natural wear products (production share);

• Failures caused by using the product for the needs related

to business activities;

• If the warranty card is empty or missing seal (stamp) of the

Seller;

• The absence of the holder's signature on the warranty card.

WARRANTY CARD

Product

Model

Company

Date

of sale

Product

Model

Company

Date

of sale

Product

Model

Company

Date

of sale

The product is in good conditions and fully complete. Read and agree the terms of the warranty.

Product model

Serial number

Username

Date of sale

Company

Client's signature

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

www.daewoopowerproducts.com

Manufactured under license of Daewoo International Corporation, Korea

and excessive sparking seen through the ventilation slots. When the carbon brushes have worn

down to approximately 4-5mm, they will require replacing.

Caution! Make sure that the sander is isolated from the mains power supply before tting acces-

sories, maintenance and adjustment if in doubt consult a qualied electrician.

Place the sander on a workbench and using a screwdriver remove the carbon brush housing cover

(See 1 of Fig.10).

Remove the carbon brush from the brush housing and replace it with a new one. Slide the new

carbon brush (See 1of Fig.11) into the brush housing. Repeat this procedure for the other carbon

brush. Then replace the carbon brush housing cover.

NOTE: carbon brushes must be replaced in pairs.

7. TECHNICAL SPECIFICATIONS

Power: 1010 W

Belt size: 76x533 mm

Belt no load speed: 120-380 rpm

Maneuver the sanding belt off the rollers.

NOTE: The Sanding belt has directional arrows printed on the inside of the belt (See 1 of Fig.8)

Sanding belts come in different grades i.e. rough through to smooth. Select the grade according to

the material operated on.

Locate the sanding belt on the rollers (See Fig.9)Make sure the sanding belt does not touch the

sides of the casing and that the arrows, printed on the inside of the sanding belt point in the direc-

tion of travel. Release the tension lever.

NOTE: Caution is required as the lever is under spring tension. Make sure the lever closes fully. With

the new sanding belt tted it must be checked to ensure that it is running centrally on the rollers

(see section Centralizing the sanding belt).

6. MAINTENANCE

WARNING: Always ensure that the tool is switched off and the plug is removed from the power point

before making any adjustments or maintenance procedures.

Keep the tools air vents unclogged and clean at all times.

1. Regularly check to see if any dust or foreign matter has entered the grills near the motor and

around the trigger switch. Use a soft brush to remove any accumulated dust. Wear safety glasses to

protect your eyes whilst cleaning.

2. Re-lubricate all moving parts at regular intervals.

3. If the body of the sander needs cleaning, wipe it with a soft damp cloth. A mild detergent can be

used but nothing like alcohol, petrol or other cleaning agent.Never use caustic agents to clean

plastic parts.

CAUTION! Water must never come into contact with the sander.

4. During use, the carbon brushes will wear down and will be indicated by a possible loss of power

4. ASSEMBLY

Fitting the dust collection bag

This machine is tted with a dust extraction outlet and collection bag. We recommend that this

facility is used at all times, as well as using an approved face mask. Fit the dust collection bag onto

the dust extraction outlet (See 1 of Fig.2).

Switching on and off

Connect the plug to the power supply. To start the machine ,squeeze the ON/OFF trigger switch; to

stop the machine, release the ON/OFF trigger switch. (See 1 of Fig.3).

WARNING! The sander is designed for dry sanding only and under no circumstances should it be

used for wet sanding.

Lock-on button

This machine is tted with a lock-on button.When the on/off switch is depressed ,press lock-on

button to get continuous operation without depressing the on/off switch (See 1 of Fig. 4).

Centralizing the sanding belt

Check that the sanding belt is running centrally before using. Centralizing the belt is necessary to

stop the belt running off the rollers. Turn the machine with the belt facing the operator (See Fig.5).

Start the sander and observe how the sanding belt is running. If the sanding belt is seen to move

along the rollers in either direction, it will require centralizing before use.

Turn the centralizing knob (See 1 of Fig.6) either clockwise or anti-clockwise to adjust the belt

tracking until the sanding belt is running centrally. Run the Sander for a short time. If the belt is still

not running centrally, use the centralizing knob to ne adjust the position of the sanding belt.

5. OPERATION

Using the belt sander

Hold the machine with both hands and assume a balanced posture. Press the ON/OFF trigger

switch and allow the motor to reach full speed. Hold the machine parallel to the work piece. Gently

bring belt contact with the work piece.

CAUTION! The sander may initially snatch forwards. Resist the forwards motion and allow the

sander to move forwards at a gradual pace. Do not use excessive, downward pressure, this may

cause the belt to snap. Keep the sander moving forwards at an even pace. Failure to do this will

result in an uneven nish. When the operation nished, lift the sander clear of the workpiece and

release the ON/OFF trigger switch. Wait until the belt has stopped rotating before putting the sander

down on workbench. Failure to do this will result in the machine running forwards.

Replacing the sanding belts

Locate the belt tension lever (See 1 of Fig.7) and pull outwards. Take care as the lever is under

tension and may spring back to the closed position. Continue pulling the lever outwards until it locks

in the position shown in Fig. 7.

WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may

result in electric shock, re and/or serious personal injury.

1. GENERAL SAFETY RULES

SAVE THESE INSTRUCTIONS

Work area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres such as in the presence of ammable

liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes.

3. Keep bystanders, children and visitors away while operating a power tool. Distraction can cause

you to lose control.

Electrical safety

1. Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators.

There is an increased risk of electric shock if your body is grounded.

2. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the

risk of electric shock.

3. Do not abuse the cord. Never use the cord to carry the tool or pull the plug

from an outlet. Keep the cord away from heat, oil, sharp edges or moving parts. Replace the dama-

ged cords immediately if you found one. The damaged cords will increase the risk of electric shock.

4. When operating a power tool outside, use an outdoor extension cord which marked “W-A” or “W”.

These cords are rated for outdoor use, so it can reduce the risk of electric shock.

Personal safety

1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not

use the tool while tired or under the inuence of drugs, alcohol, or medication. A moment of inatten-

tion while operating power tools may result in serious personal injury.

2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing,

and gloves away from the moving parts. Because loose clothes, jewelry, and long hair can be

caught in the moving parts.

3. Avoid accidental starting. Be sure switch is off before plugging in. Carrying tools with your nger

on the switch or plugging in tools that have the switch on will invite accidents.

4. Remove adjusting keys or wrenches before turning the tool on. A wrench or a key that is left

attached to a rotating part of the tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance

enable better control of the tool in unexpected situations.

6. Use safety equipment. Always wear eye protection.Dust mask, non-skid safety shoes, hard hat, or

hearing protection must be used for appropriate conditions. Ordinary eye or sun glasses are NOT

eye protection.

Tool use and care

1. Use clamps or other practical way to secure and support the work piece to a stable platform.

Holding the work piece by hand or against your body is unstable and may lead to loss of control.

2. Do not force tool. Use the correct tool for your application. The correct tool will do the job better

and safer at the rate for which it is designed.

3. Do not use tool if the switch can not turn on or off. Any tool that cannot be controlled with the

switch is dangerous and must be repaired before use.

4. Disconnect the plug from the power source before making any adjustment, changing accessories, or

storing the tool. Such preventive safety measures can reduce the risk of starting the tool accidentally.

5. Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the

hands of untrained users.

6. Maintain tools with care. Keep the cutting tools sharp and clean. Properly maintained tools with

sharp cutting edges are less likely to bind and are easier to control.

7. Check for misalignment or binding of moving parts, breakage of parts and any other condition

that may affect the tools operation. If damaged, have the tool serviced before using. Many accidents

are caused by poorly maintained tools.

8. Use only accessories that are recommended by the manufacturer for your model. Accessories

that may be suitable for one tool, may become hazardous when used on another tool.

Service

1. Tool service must be performed only by qualied repair personnel. Service or maintenance perfor-

med by unqualied personnel could result in a risk of injury.

2. When servicing a tool, use only identical replacement parts. Follow instructions in the maintenan-

ce section of this manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

2. SPECIFIC SAFETY RULES

1. Make sure that the foreign objects such as nails and screws have been removed from the work

before commencing sanding.

2. Rags,cloths,cord,string and the likeshould never be left around the work area.

3. Always switch off before the sander is put down.

4. Do not force the sander. Let the tool work at a reasonable speed.Overloading will occur if too

much pressure is applied and the motor slows resulting in inefcient sanding and may damage the

sander motor.

5. When an extension cable is required, be sure that it has the right ampere rating for the tool and is

in safe electrical condition.

6. Fully unwind cable drum extension to avoid potential overheating.

7. Do not touch the moving sanding belt.

8. Worn, torn or heavily clogged sanding belts can not be continuely use.

9. Always connect the dust bag or use dust extraction system when sanding wood.

3. FEATURES

Before using the tool, make yourself familize with all the features (See Fig.1):

1. Front handle

2. Belt centralizing adjuster

3. Carbon brush housing

4. Drive belt cover

5. Dust extraction outlet

6. On/Off trigger switch

7. Rear handle

8. Lock-on button

Table of contents

Other Daewoo Sander manuals

Daewoo

Daewoo DALOS18-1 User manual

Daewoo

Daewoo DABS 950 User manual

Daewoo

Daewoo DADS750-C User manual

Daewoo

Daewoo DACP1400 User manual

Popular Sander manuals by other brands

Milwaukee

Milwaukee 6006 Service parts list

SuperMax

SuperMax 19-38 DRUM SANDER owner's manual

MaxPro PROFESSIONAL

MaxPro PROFESSIONAL MPPO1200 manual

Hitachi Koki

Hitachi Koki SV 8SA Handling instructions

Wen

Wen 6508 manual

Draper

Draper Stormforce SFAS50 instructions

EINHELL

EINHELL BT-OS 150 operating instructions

DeWalt

DeWalt dwe6411 instruction manual

Parkside

Parkside PBS 600 B1 Translation of the original instructions

P.I.T.

P.I.T. PP0180-C1 Operation manual

VONROC

VONROC PM507AC Original instructions

Sumake

Sumake ST-AP1063H Original instructions

Metabo

Metabo W 850-100 Original instructions

Top Craft

Top Craft TTS-280 user manual

Makita

Makita BO4553 instruction manual

PRETUL

PRETUL PULA-P manual

Makita

Makita BO5012K parts manual

Stanley

Stanley SSS310 Original instruction

Daewoo DABS1010 User manual

Popular Sander manuals by other brands
