Daewoo DTQ - 20D5FS User manual

Service Manual
Color Television
CHASSIS :CN-220B/C
Model :DTQ - 20D5FS / FSP
DTQ - 20D5FC
S/M No. : CN220NTEF0R1
OCT.2001
DAEWOO ELECTRONICS CO.,LTD
http ://svc.dwe.co.kr
MODEL
ITEM DTQ-20D5FS DTQ-20D5FSP 20D5FC
TV STANDARD NTSC-M
POWER INPUT 120V 60HZ 220V 60HZ
POWER CONSUMPTION 84W
TUNING SYSTEM Frequency Synthesizer (FS) Tuning System
TUNING RANGES
VHF : 2 ~ 13 (12)
UHF : 14 ~ 69 (56)
A~W, A- 5 ~ A-1, W + 1 ~ W + 84
SOUND OUTPUT 5W + 5W
SPEAKER 8 ohm 5W x 2EA
ANTENNA INPUT
IMPEDANCE 75 ohm Unbalanced
AUXILIARY INPUT
TERMINAL
Front : Video, Audio, Earphone
Rear: Video, Audio, (R,L)
INTERMEDIATE
FREQUENCIES
Picture IF Carrier Frequency : 45.75 MHZ
Sound IF Carrier Frequency : 41.25 MHZ
Color Sub-Carrer Frequency : 3.579545 MHZ
REMOTE CONTROL R - 40
SPECIAL FUNCTIONS
AV only PIP
ICONMENU TYPE
STEREO / SAP
3 - Language OSD
with Caption
SPECIFICATIONS
120V 60HZ
DTQ - 20D4AS / ASP
DTQ - 20D4SSF / SSSP
✔Caution:In this Service Manual, some parts can be changed for improving, their performance
without notice in the parts list.So,if you need the latest parts information, please refer
to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)

1
TABLE OF CONTENTS
SAFETY INSTRUCTION .................................................................................................................. 2
SPECIFICATIONS ............................................................................................................................ 3
CIRCUIT BLOCK DIAGRAM ........................................................................................................... 5
ALIGNMENT INSTRUCTION ........................................................................................................... 6
Your Remote Control ........................................................................................................................ 6
Service Mode Adjustment ................................................................................................................. 7
Assembly Adjustment ....................................................................................................................... 8
SCHEMATIC DIAGRAM .................................................................................................................. 12
EXPLODED VIEW ............................................................................................................................ 12
PRINTED CIRCUIT BOARD ............................................................................................................ 13
SERVICE PARTS LIST .................................................................................................................... 14
The Different Parts List ..................................................................................................................... 21
APPENDIX (“ Appendix is provided only by internet [http://svc.dwe.co.kr] ”)
IC DESCRIPTION ........................................................................................................................... 1
Trouble Shooting Guide ............................................................................................................... 11
1. No Power .................................................................................................................................... 11
2. No Picture ................................................................................................................................... 12
3. No Sound .................................................................................................................................... 13
4. CH Don’t Stop ............................................................................................................................. 14
5. No Color ..................................................................................................................................... 15
6. No Vertical Deflection ................................................................................................................. 15
7. No On-Screen Display ................................................................................................................ 16
8. Remote Control Does not Operate ............................................................................................. 16

2
SAFETY INSTRUCTION
WARNING : Only competent service personnel may carry out work involving the testing or repair of this equipment
1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards, the high
voltage must not exceed the specified limit. The nominal value of the high voltage of this receiver is 22-23 kV (14”) or
24-26 kV (20” - 21”) at max beam current. The high voltage must not, under any circumstances, exceed 27.5 kV (14”,
20”), 29KV (21”). Each time a receiver requires servicing, the high voltage should be checked. It is important to use an
accurate and reliable high voltage meter.
2. The only source of X-RAY Radiation in this TV receiver is the picture tube. For continued X-RAY RADIATION
protection, the replacement tube must be exactly the same type tube as specified in the parts list.
X-RAY RADIATION PRECAUTION
1. Potentials of high voltage are present when this receiver is operating. Operation of the receiver outside the cabinet or
with the back cover removed involves a shock hazard from the receiver.
1)Servicing should not be attempted by anyone who is not thoroughly familiar with the precautions necessary when
working on high voltage equipment.
2)Discharge the high potential of the picture tube before handling the tube. The picture tube is highly evacuated and if
broken, glass fragments will be violently expelled.
2. If any Fuse in this TV receiver is blown, replace it with the FUSE specified in the Replacement Parts List.
3. When replacing a high wattage resistor (oxide metal film resistor) in circuit board, keep the resistor body 10 mm away
from the circuit board.
4. Keep wires away from high voltage or high temperature components.
5. This receiver must operate under AC 230 volts, 5O Hz. NEVER connect to a DC supply of any other voltage or
frequency.
SAFETY PRECAUTION
Many electrical and mechanical parts in this equipment have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the X-RAY RADIATION protection afforded by them cannot necessarily be
obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these spe-
cial safety characteristics are identified in this manual and its supplements, electrical components having such features are
identified by designated symbol on the parts list. Before replacing any of these components, read the parts list in this manual
carefully. The use of substitutes replacement parts which do not have the same safety characteristics as specified in the parts
list may create X-RAY Radiation.
PRODUCT SAFETY NOTICE

3
SPECIFICATIONS
CN-220B Chassis
MODEL
ITEM
DTQ-20D5FS
DTQ-20D5FSP
DTQ-20D4SSSP
TV STANDARD NTSC-M
POWER INPUT 120V 60HZ 220V 60HZ 120V 60HZ 220V 60HZ
POWER CONSUMPTION 84W
TUNING SYSTEM Frequency Synthesizer (FS) Tuning System
TUNING RANGES
VHF : 2 ~ 13 (12)
UHF : 14 ~ 69 (56)
A~W, A- 5 ~ A-1, W + 1 ~ W + 84
SOUND OUTPUT 5W + 5W
SPEAKER 8 ohm 5W x 2EA
ANTENNA INPUT IMPED-
ANCE 75 ohm Unbalanced
AUXILIARY INPUT TERMI-
NAL
Front : Video, Audio, Earphone
Rear: Video, Audio, (R,L)
INTERMEDIATE FREQUEN-
CIES
Picture IF Carrier Frequency : 45.75 MHZ
Sound IF Carrier Frequency : 41.25 MHZ
Color Sub-Carrer Frequency : 3.579545 MHZ
REMOTE CONTROL R - 40
SPECIAL FUNCTIONS
AV only PIP ICON MENU TYPE
STEREO / SAP
3 -Language OSD
with Caption
DTQ-20D5FC
ICON MENU TYPE
STEREO / SAP
3 -Language OSD
with Caption

4
SPECIFICATIONS
CN-220C Chassis
MODEL
ITEM DTQ-20D4AS DTQ-20D4ASP
TV STANDARD NTST-M
POWER INPUT 120V 60HZ 220V 60HZ 90-260V 60HZ
POWER CONSUMPTION 84W
TUNING SYSTEM Frequency Synthesizer (FS) Tuning System
TUNING RANGES
TV VHF(L) : CH 2 ~ CH 6
UHF(H) : CH 7 ~ CH 13
UHF : CH 14 ~ CH 69
CATV VHF(L) : 5A, A, B, A-5 - A-1
CH 2 - CH 6
VHF(H) : C - W + 11
CH 7 - CH 13
UHF : W + 12 - W + 84
SOUND OUTPUT 5W + 5W
SPEAKER 8 ohm 5W x 2EA
ANTENNA INPUT IMPEDANCE 75 ohm Unbalanced
AUXILIARY INPUT TERMINAL Front : Video, Audio, Earphone
Rear: Video, Audio, (R,L)
INTERMEDIATE FREQUEN-
CIES
Picture IF Carrier Frequency : 45.75 MHZ
Sound IF Carrier Frequency : 41.25 MHZ
Color Sub-Carrer Frequency : 3.579545 MHZ
REMOTE CONTROL R - 40
SPECIAL FUNCTIONS
1) ICON MENU TYPE
2) 3-Language OSD
3) WITH CAPTION
4) CH LABEL
DTQ-20D4ASP

5
CIRCUIT BLOCK DIAGRAM
VA H V
L R
SCL SDA
(1)
(2)
OSDRGB
(1)
(2)
TUNER DT5
-NF20F
u
-
COM IC
LC8632
40
SCL SDA
SOUND
SCL
SOUND
SDA
MAIN
IC
DCT814B
SCL
SDA RGB
SOUNDIC MSP3430G SCL SDA
Scre
en
FouseH.
V
.
FBT
HEATER
POWERIC 2SK2564
EEPROM IR SW1~ SW5
SAW FILTER
VIDEO
AMP
TDA
6
103Q
10V 28V
SOUND AMP TDA7266
IFDET. OUT TRAP
BPF
5V 9V
5V
X-RAY
SMPSTRANS
TSM-3541A5
DPM001T1(110V),
DP001T1A(
220V)
14V
5V
33V
VERTICAL LA784
1
HOR.OUTPUT 2
SD2499
DEFLECTION YOKE
OCP
26V 14V
9V 5V
EARPHONE
A/V IN 2
RF
220
V
PIP
IC
SDA9388 CVS SCL RGB SDA
A/V IN 1

6
ALIGNMENT INSTRUCTIONS
Your Remote Control
1. POWER
Use this button to turn your TV on or off.
2. 0 - 9
Use these buttons to change channels.
3. MUTE
Use to turn the TV’ s sound on and off.
4. DISPLAY
Use this buttons to display the channel
number and status.
5. CH
Use these buttons to change channels on your
TV, or select items in the menu system.
6. VOL
Use these buttons to change your TV’ s volume,
to activate selections in the menu system, or to
change audio and video settings.
7. TV/VIDEO
Use this button to select main picture source.
8. MTS
Use this button to select one mode of Mono,
Stereo or SAP.
9. PREVIOUS
Use this button to return previous channel you were
watching.
10. PIP
Use this button to turn PIP on/off.
11. STILL
Use this button to still PIP source.
12. SWAP
Use this button to exchange PIP source and main
source.
13. SCREEN
Use this button to change the size of the picture
(from normal 4:3 to WIDE, ZOOM, and the original
4:3 in turn).
14. POSITION
Use this button to change position of pip on your TV.
15. INPUT
Use this button to select PIP source (TV/VIDEO).
CH
TV/VIDEO PREVIOUS
STILLPIP
SCREEN POSITION
MENU
MUTE
123
456
78
0
9
1
2
3
5
6
7
5
4
8
11
12
11
15
14
13
10
7
POWER
DISPLAY
VOLVOL
CH
MTS
SWAP
INPUT
6

7
SERVICE MODE ADJUSTMENTS
Follow the steps below whenever service adjustment is required. See Table- A and Table- B to determine if
service adjustments are required.
1) How to enter the service mode using the user remote control.
· Turn the set on.
· Direct the remote control to the reception window of TV.
· Push buttons of remote control in sequence as follows.
1 MUTE DISPL AY MUTE
· Then, the screen will appear as follows.
· Using the channel up or channel down button, select the item you wish to adjust.
(The color of selected item turns into the red.)
· Press the volume up or down button to enter in the service mode you wish to adjust.
2) How to memorize the adjusted values in the service mode.
· Must press DISPLAY button the state which the screen is displaying each of service menus
after all adjustments are completed each of all service menu.
Table-A : Adjust the values of service mode when a part is replaced.
PART
REPLACED
ADJUSTMENT NOTES
NECESSARY UNNECESSARY
I701
(U-COM) OData is stored in I703.
I101
(MAIN) O
I703
(EEPROM) O
Initial setting values are written from I701.
Adjusting Items
CRT OAdjust items related to picture tube only.(White Balance adjustment)
S2 SCRN
S5 IFC
S6 GEO
S8 W/B
S9 DP
S12 FACT
S7 PTRN NORMAL
S5 RFAGCD
S6 H.PHASE/V.POSI/V.SIZE
S8 RD/BD/RB/GB/BB
S9 Subbrightness
ALIGNMENT INSTRUCTIONS

8
ALIGNMENT INSTRUCTIONS
Table-B
* indicates the items with different settings each of sets
ASSEMBLY ADJUSTMENTS
1) SCREEN ADJUSTMENT (S2)
· Enter the service mode and select service adjustment S2.
· You cna see the one horizontal line on the screen.
· Adjust the Screen Control Volume (located on FBT) so that the horizontal line onscreen may be
disappeared.
· Press the volume up or down button to exit in the screen adjustment mode.
MODE ADJUSTMENT ITEMS DATA REMARKS
INITIAL RANGE
S2 Screen Adjustment --
S5
Auto RF AGC --
Video Level (VIDEOL) 70 ~ 7 Must be set to 7
RF AGC Delay (RFAGCD) *0 ~ 63 Align RF AGC threshold
FM Level (FM.LEV) 80 ~ 31 Must be set to 20
AGC Point 3.75 -Select AGC reference voltage
A/D VALUE --
S6
Horizontal Phase(H.PHASE) *0 ~ 31 Align sync to flyback pulse, using internal cross pattern(S7)
Vertical Position (V.POSI) *0 ~ 63 Align vertical DC bias, using internal cross pattern(S7)
Vertical Size (V.SIZE) *0 ~ 127 Align vertical amplitude, using internal cross pattern(S7)
NO SD POWER OFF YES -Automatically turn off in 15min for no received signal.
Vertical S-Correction (V SC) 00 ~ 31 Must be set to 6
Vertical Linearity (V LIN) 20 0 ~ 31 Must be set to 16
S7
Internal Black --Display internal BLACK pattern
Internal 100% White --Display internal 100% WHITE
Internal 60% White --Display internal 60% WHITE
Internal Cross Pattern --Display internal CROSS pattern
S8
Red Drive (RD) *0 ~ 127 Align RED OUT AC level
Green Drive (GD) 10 0 ~ 15 Must be set to 10
Blue Drive (BD) *0 ~ 127 Align BLUE OUT AC level
Red Bias (RB) *0 ~ 255 Align RED OUT DC level
Green Bias (GB) *0 ~ 255 Align GREEN OUT DC level
Blue Bias (BB) *0 ~ 255 Align BLUE OUT DC level
S9
Subbrightness *0 ~ 127 Align common RGB DC level
Contrast 10 0 ~ 27
Tint 27 0 ~ 27
Color 15 0 ~ 27
S12 Forwarding Mode -Factory Initialization
IN THE SCREEN ADJUSTMENT MODE, DONT PRESS OTHER BUTTONS EXCEPT VOLUME UP OR DOWN BUTTON.
NOTE

9
2) FOCUS ADJUSTMENT
· Turn in a local station and adjust the Focus Control knob (located on FBT) for best picture
details at high light condition.
3) RF AGC DELAY ADJUSTMENT (S5)
· Receive a good local channel.
· Enter the service mode and select service adjustment S5.
· You can see the OSD as shown in below.
· Select RFAGCD item, press the volume up or down button until noise or beat in picture disappears.
· Press the DISPLAY button to memorize the data.
4) GEOMETRIC ADJUSTMENTS (S6)
· Enter the service mode and select service adjustment S7.
· Whenever you select the “ S7”using the volume up or down button, the screen is changing like this.
· Using the volume up or down button, select internal cross pattern.
· Select service adjustment S6
· You can see the OSD as shown in below.
4-1. Horizontal Position Adjustment
· Select H.PHASE item, adjust H.PHASE data value to obtain proper horizontal centering of the
internal cross pattern at the left and right of the screen.
4-2. Vertical Position Adjustment
· Select V.POSI item, adjust V.POSI data value to center the raster properly on thescreen.
ALIGNMENT INSTRUCTIONS
IF CONTROL
AUTO RFAGC START
VIDEOL 7
RFAGCD 10
FM.LEV 8
AGC POINT 3.75
A/D VALUE : 8DH
MOVE ADJUST RECALL : SET
GEOMETRY
H. PHASE20
V. POSI 29
V. SIZE 70
NO SD POWER OFF YES
VSC 0
VLIN 20
MOVE ADJUST RECALL : SET
NORMAL BLACK WHITE100 WHITE60 CROSS

10
ALIGNMENT INSTRUCTIONS
4-3. Vertical Size Adjustment
· Select “V.SIZE”item, adjust “ V.SIZE”data value to proper vertical size as follows.
5) WHITE BALANCE ADJUSTMENT(S8)
· Receive a good local channel.
· Enter the service mode and select service adjustment S8.
· You can see the OSD as shown in below.
· Using volume up or volume down, adjust service adjustment data of RD/GD/BD and RB/GB/BB until a good gray
scale with normal whites is obtained.ALIGNMENT INSTRUCTIONS
· Press the DISPLAY button to memorize the data.
6) DIGITAL PRESET(D.P) ADJUSTMENTS(S9)
SUBBRIGHTNESS ADJUSTMENT
· Receive a good local channel.
· Enter the service mode and select service adjustment S9.
· You can see the OSD as shoown in below.
RD 58
GD 10
BD 65
RB 105
GB 160
BB 100
MOVE ADJUST RECALL : SET
D.P.
SUB BRIGHTNESS 64
CONTRAST 10
TINT 27
COLOR 15
MOVE ADJUST RECALL : SET

11
ALIGNMENT INSTRUCTIONS
· Select Subbrightness item, adjust Subbrightness data value to obtain normal brightness level.
· Press the DISPLAY button to memorize the data.
CONTRAST
· Fixed value = 10
TINT
· Fixed value = 27
COLOR
· Fixed value = 15
7) FACTORY OUTGOING MODE (S12 : FACT)
· If you select the S12, then the set becomes factory outgoing status.
· You can see the OSD “outgoing OK”

12
EXPLODED VIEW
20 19
EPS 20D51PAD
4858193401
LDPE T0.03X1300X1000
1
BAG PE
4858211800
DW-3
1
CARTON BOX
4858055200
150 ART P/E FILM(C/TV)1SPEC PLATE
4855415800
HIPS BK
4852155601 4856214902
30X190 BK2
SCREW CRT FIXING AS
30X80 BK
2SCREW CRT FIXING AS
4856013300
PVC T1.0
4857618000
TT2 WAS 3X12 MFZN BK
SCREW TAPPTIE
TT2 WAS 3X12 MFZN BK
2
SCREW TAPPTIE
7128301212
CUAU+ABS BK
1
MARK BRAND
4855617500
20 19
18
14-3
14-2
17
16
15
14
10-1
10
10-1
9-1
9-1
4-1
9
8
7
5
10
6
14-1
13
12
9
PC BK
1
4856013302
2 1
CR T2.0
4856215402
1 5 TT2 TRS 4X14 MFZN BK
7172401412
4 1 1 14945801+5541201
4851915401
HIPS BK
4854945801
1 1 11 1 1 2 8
7128301212
1HIPS BK
4852073601
HIPS BK
4852326511
1SWPA PIE 0.5
4856716000
ABS BK 2326511+4856401+6716000 PMMA MILKY EGI T0.5
18
17
16-1
4855313101 4855541201 4852067101 4854856401 4852539601
16-1
16
15
14-3
14-2 14-1
14
13 12 11
10
9-1
9
8 7 6 5
4-1
4 3 2
1
COVER BACK SCREW TAPPTITE RUBBER CRT BUTTON CTRL BUTTON DECO SENSOR INSU PLATE SPEAKER MASK FRONT DECO COVER PANEL FRONT PANEL SPRING BUTTON POWER GRILL
11
4
3
2
1
MATERIAL REMARKS
MAIN PCB
PART NAME Q'tyPART CODENo

13
A48JLL91x50 M16
DC-20SF
CN-220C
58G0000146
4856013302
PTMPMSJ801
PTSPPWJ776
1
DEGAUSING COIL
15
3FELT T0.7 L=200CLOTH BLACK
4857817611
12
2
98
SPEAKER
3
PCSMOG
1 1EGI T0.5
GRILL R
4852539800
EGI T0.5
GRILL L
4852539700
1
1
1 4
ABSBK
SWRM
4 4
SPECIALSCREW
4856016100
1 1
30X190 BK
4856013302
150ART P/EFILM
4855415800
4
1
4
CR T2.0
4856214902
1
1
1
11
1 1
T2STRS4X14MFZN
67122401411 8
T2STRS3X12MFZN
7128301211
A1050P-H24 T2.0
4855615900
1
SWPAPIE 0.5
4856716000
ABSBK
HIPS BK
HIPS BK
4854945901 4852156201 4852067101
4854856601
4852326601
18 17
19
18 17
16
15 14 13
12
11
10
9 8 7 6
5
4
2
1-1
1
CRT
WASHERRUBBER
SPECPLATE
COVER BACK
MAIN PCBASSY
SCREWTAPPING SCREWTAPPING
BUTTON
MASK FRONT
MARK BRAND
SPRING
BUTTONPOWER
PANEL CTRL
16
14
13
11
10
7
6
5
3
2
MATERIAL REMARKS
SCREW CRT FIXING AS.
PART NAME Q'tyPART CODE
No
EXPLODED VIEW

14
PRINTED CIRCUIT BOARD

15
SERVICE PARTS LIST
LOC PART NAME PART DESCRIPTION QTY REMARK
ZZ100TRANSMITTER REMOCONR-40C03 10000
ZZ110ACCESSORY AS DTQ-20D5FS 10000
10 BATTERY R03/NN 20000
20 ANT ROD S3BW216B (L=600 MM) 10000
30 TRANS ANT MATCHING IMT-06 10000
M821 BAG INSTRUCTION L.D.P.E T0.05X250X400 10000
ZZ120COVER BACK AS DTQ-20D5FS 10000
M211 COVER BACK HIPS BK 10000
M541 SPEC PLATE 150ART P/E FILM (C/TV) 10000
M781 CLOTH BLACK FELT 200X20X0.7 20000
M782 CLOTH BLACK FELT 300X20X0.7 20000
ZZ130PACKING AS DTQ-20D5FS 10000
M801 BOX CARTON DW-3 10000
M811 PAD EPS 20D5 10000
M821 BAG P.E L.D.P.E T0.03X1300X1000 10000
ZZ131COIL DEGAUSSING DC-2030 10000
ZZ132CRT GROUND NET 2001S-1015-1P 10000
ZZ140CABINET AS DTQ-20D5FS 10000
CRT1 CRT AS NTSC 20" ITC CRT AS 10000
V01 COIL DY ODY-M2050 10000
V02 PAINT LOCK 3B-1401B 10
V03 TAPE CLOTH 19X30 BEIGE 1700
V04 BOND SILICON RTV 122 CARTRIDGE 10
V05 MAGNET CP NY-225 (MINI NECK) 10000
V06 RUBBER WEDGE HMR 28 SR (|0X54) 30000
V901 CRT BARE A48JLL40X(W) 10000
CRT1AWASHER RUBBER CR T2.0 40000
CRT1BSCREW CRT FIXING 30X80 BK 20000
CRT1CSCREW CRT FIXING 30X190 BK 20000
M191 BUTTON CTRL 4945802+5541201 10000
M192 PANEL FRONT AS 2326511+4856401+6716000 10000
M192ASCREW TAPPTITE TT2 WAS 3X12 MFZN BK 20000
M201ASCREW TAPPTITE TT2 TRS 4X14 MFZN BK 50000
M531 DECO COVER PC BK 10000
M561 MARK BRAND CU AU+ABS BK 10000
M681 TIE CABLE NYLON66 DA100 10000
M761 INSU PLATE PVC T1.0 20000
M761ASCREW TAPPTITE TT2 WAS 3X12 MFZN BK 40000
M781 CLOTH BLACK CLOTH T0.7 L=200 20000
SP01ASCREW TAPPTITE TT2 WAS 3X12 MFZN BK 20000
SP02ASCREW TAPPTITE TT2 WAS 3X12 MFZN BK 20000
ZZ200MASK FRONT AS DTQ-20D5FS 10000
M201 MASK FRONT HIPS BK 10000
M251 GRILL EGI T0.8 20000
ZZ210SPEAKER AS DTQ-20D5FS 10000
PA601CONNECTOR YH025-04+35098+ULW=400 10000
SP01 SPEAKER 7.5W 8 OHM 95BF03LC 10000
SP02 SPEAKER 7.5W 8 OHM 95BF03LC 10000
ZZ290PCB MAIN MANUAL AS DTQ-20D5FS 10000
C403 C CERA 500V B 0.01MF K 10000
C404 C MYLAR 1.6KV BUP 7000PF J 10000
C406 C MYLAR 200V EU 0.39MF J 10000
C801 C LINE ACROSS WORLD AC250V 0.1UF M R.4710000
C804 C ELECTRO 200V LHS 330MF 10000
C805 C MYLAR 1KV BCP 4700PF J 10000
C880 C CERA AC U/C/V AC400V 2200PF 10000
D703 LED KLR114L 10000
D801 DIODE BRIDGE D2SB80 10000
R
is a recommendable part for stock.
is safety component, so it must be used the same component.
Caution
D807 DIODE RGP30J 10000
F801 FUSE GLASS TUBE UL/CSA TL 4A 125V MF51 10000
I301 HEAT SINK ASS`Y 1LA7841--- + 7174300811 10000
I301 IC VERTICAL LA7841 10000
I301A HEAT SINK AL EX DG 10000
I301B SCREW TAPPTITE TT2 RND 3X8 MFZN 10000
I401 IC REGULATOR KIA7805API 10000
I501 IC CHROMA DCT814B 10000
I601 HEAT SINK ASS`Y 1TDA7266-- + 7174301011 10000
I601 IC AUDIO TDA7266 10000
I601A HEAT SINK AL EX BK 10000
I601B SCREW TAPPTITE TT2 RND 3X10 MFZN 10000
I602 IC AUDIO MSP3430G-P0-A4 10000
I701 IC MICOM DW863240V-GM1(5P34) 10000
I703 IC AT24C16-10PC 10000
I801 MODULE POWER DPM001T1 10000
I901 HEAT SINK ASS`Y 1TDA6103Q- + 7174300811 10000
I901 IC VIDEO TDA6103Q 10000
I901A HEAT SINK A1050P-H24 T2.0 10000
I901B SCREW TAPPTITE TT2 RND 3X8 MFZN 10000
IL701 IC PREAMP TS0P1238WI1 10000
JA02 JACK PIN BOARD YS-JB9711 10000
JA03 JACK PIN BOARD PH-JB-9614A 10000
JA05 JACK PIN BOARD PH-JB-9614A 10000
L111 COIL CHOKE TRF-9225 (0.55UH) 10000
L401 COIL H-LINEARITY L-102 (102UH) 10000
L501 COIL VCO TRF-V008 10000
L801 FILTER LINE LF-24A2 10000
M352 HOLDER LED P.P 10000
P401 CONN WAFER YFW500-05 10000
P501ACONNECTOR BIC-08T-25T+C-20T+ULW=40010000
PWC1CORD POWER ASS`Y 4859903711+ 4857417700 10000
PW000CORD POWER SPT-2#18AWG 2.1MM W/
TERMI 10000
PW001TERM CLAMP PT-01-T3 20000
Q402 HEAT SINK ASS`Y T2SD2499-- + 7174301011 10000
Q402 TR 2SD2499 10000
Q402AHEAT SINK AL T1.0 10000
Q402BSCREW TAPPTITE TT2 RND 3X10 MFZN 10000
Q402CWASHER SPCC 10000
Q801 HEAT SINK ASS`Y T2SK2564-- + 7174300811 10000
Q801 FET 2SK2564 10000
Q801AHEAT SINK AL EX B/K 10000
Q801BSCREW TAPPTITE TT2 RND 3X8 MFZN 10000
R801 R CEMENT 7W 2.2 0HM J 15MM 4P 10000
R883 POSISTOR ECPAC7R0M140 10000
RLY1 SW RELAY DQ5D1-O(M)/GJ-SS-105LM 10000
RS801VARISTOR SVC471D14A 10000
SCT1 SOCKET CRT PCS633A 10000
SF101FILTER SAW TSF5241P 10000
SW701SW TACT KPT-1112 1C-1P 10000
T401 TRANS DRIVE HD-15D 10000
T402 FBT FSA37012M 10000
T801 TRANS SMPS TSM-3541A5 10000
U102 TUNER VARACTOR DT5-NF20F 10000
X201 CRYSTAL QUARTZ HC-49/U 27.0MHZ 30PPM 10000
X651 CRYSTAL QUARTZ HC-49/U 18.43200MHZ 30PPM 10000
X701 CRYSTAL QUARTZ C-001R 32.768000KHZ 20PPM 10000
LOC PART NAME PART DESCRIPTION QTY REMARK
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
✔ Caution:In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)

16
Z501 FILTER CERA TPS-4.5MB TRAP (TAPPING) 10000
ZZ200PCB CHIP MOUNT B AS DTQ-20D5FS 10000
CC151C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC152C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC153C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC154C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC155C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC202C CHIP CERA 50V CH 20PF J 2012 10000
CC203C CHIP CERA 50V CH 20PF J 2012 10000
CC204C CHIP CERA 50V CH 820PF J 2012 10000
CC205C CHIP CERA 50V CH 180PF J 2012 10000
CC206C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC207C CHIP CERA 50V X7R 0.1MF K 2012 10000
CC208C CHIP CERA 50V X7R 0.1MF K 2012 10000
CC209C CHIP CERA 50V X7R 0.1MF K 2012 10000
CC210C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC212C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC213C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC214C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC215C CHIP CERA 50V X7R 0.1MF K 2012 10000
CC217C CHIP CERA Y5V 50V 0.47MF Z 2012 10000
CC220C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC501C CHIP CERA 50V CH 47PF J 2012 10000
CC502C CHIP CERA 50V CH 20PF J 2012 10000
CC528C CHIP CERA 50V X7R 1000PF K 2012 10000
CC551C CHIP CERA 50V CH 100PF J 2012 10000
CC552C CHIP CERA 50V CH 100PF J 2012 10000
CC556C CHIP CERA 50V CH 8PF D 2012 10000
CC560C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC562C CHIP CERA 50V CH 18PF J 2012 10000
CC567C CHIP CERA 50V CH 180PF J 2012 10000
CC568C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC569C CHIP CERA 50V Y5V 0.1MF Z 2012 10000
CC570C CHIP CERA 50V Y5V 0.1MF Z 2012 10000
CC571C CHIP CERA 50V Y5V 0.1MF Z 2012 10000
CC573C CHIP CERA 50V Y5V 0.1MF Z 2012 10000
CC575C CHIP CERA 50V X7R 1000PF K 2012 10000
CC580C CHIP CERA 50V X7R 1500PF K 2012 10000
CC605C CHIP CERA 50V X7R 0.1MF K 2012 10000
CC650C CHIP CERA 50V Y5V 0.1MF Z 2012 10000
CC651C CHIP CERA 50V X7R 4700PF K 2012 10000
CC652C CHIP CERA 50V X7R 4700PF K 2012 10000
CC653C CHIP CERA 50V Y5V 0.1MF Z 2012 10000
CC654C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC655C CHIP CERA 50V CH 4PF C 2012 10000
CC656C CHIP CERA 50V CH 4PF C 2012 10000
CC661C CHIP CERA 50V Y5V 0.1MF Z 2012 10000
CC663C CHIP CERA 50V Y5V 0.1MF Z 2012 10000
CC665C CHIP CERA 50V Y5V 0.1MF Z 2012 10000
CC666C CHIP CERA 50V X7R 470PF K 2012 10000
CC667C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC669C CHIP CERA 50V X7R 470PF K 2012 10000
CC670C CHIP CERA 50V X7R 470PF K 2012 10000
CC671C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC752C CHIP CERA 50V CH 18PF J 2012 10000
CC753C CHIP CERA 50V CH 18PF J 2012 10000
CC754C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC755C CHIP CERA 50V X7R 0.01MF K 2012 10000
LOC PART NAME PART DESCRIPTION QTY REMARK
SERVICE PARTS LIST
CC756C CHIP CERA 50V CH 220PF J 2012 10000
CC757C CHIP CERA 50V X7R 0.033MF K 2012 10000
CC758C CHIP CERA 50V CH 100PF J 2012 10000
CC759C CHIP CERA 50V CH 100PF J 2012 10000
CC760C CHIP CERA 50V CH 100PF J 2012 10000
CC761C CHIP CERA 50V X7R 0.1MF K 2012 10000
CC768C CHIP CERA 50V CH 100PF J 2012 10000
CC780C CHIP CERA 50V X7R 0.01MF K 2012 10000
CC900C CHIP CERA 50V X7R 1000PF K 2012 10000
CCA01C CHIP CERA 50V X7R 1000PF K 2012 10000
CCA13C CHIP CERA 50V X7R 1000PF K 2012 10000
CCA14C CHIP CERA 50V X7R 1000PF K 2012 10000
I201 IC CHIP PIP SDA9388X 10000
JC210R CHIP 1/10 0 OHM 2012 10000
JC301R CHIP 1/10 0 OHM 2012 10000
JC401R CHIP 1/10 0 OHM 2012 10000
JC502R CHIP 1/10 0 OHM 2012 10000
JC504R CHIP 1/10 0 OHM 2012 10000
JC507R CHIP 1/10 0 OHM 2012 10000
JC510R CHIP 1/10 0 OHM 2012 10000
JC604R CHIP 1/10 0 OHM 2012 10000
JC680R CHIP 1/10 0 OHM 2012 10000
JCA01R CHIP 1/10 0 OHM 2012 10000
JCA03R CHIP 1/10 0 OHM 2012 10000
RC105R CHIP 1/10 15K OHM J 2012 10000
RC150R CHIP 1/10 15K OHM J 2012 10000
RC151R CHIP 1/10 100K OHM J 2012 10000
RC154R CHIP 1/10 47K OHM J 2012 10000
RC156R CHIP 1/10 47K OHM J 2012 10000
RC165R CHIP 1/10 4.7K OHM J 2012 10000
RC202R CHIP 1/10 4.7K OHM J 2012 10000
RC203R CHIP 1/10 1K OHM J 2012 10000
RC204R CHIP 1/10 3.9K OHM J 2012 10000
RC205R CHIP 1/10 47K OHM J 2012 10000
RC206R CHIP 1/10 1K OHM J 2012 10000
RC207R CHIP 1/10 47K OHM J 2012 10000
RC208R CHIP 1/10 1K OHM J 2012 10000
RC209R CHIP 1/10 1K OHM J 2012 10000
RC210R CHIP 1/10 0 OHM 2012 10000
RC211R CHIP 1/10 100 OHM J 2012 10000
RC212R CHIP 1/10 330 OHM J 2012 10000
RC213R CHIP 1/10 330 OHM J 2012 10000
RC216R CHIP 1/10 1K OHM J 2012 10000
RC219R CHIP 1/10 75 OHM J 2012 10000
RC220R CHIP 1/10 0 OHM 2012 10000
RC351R CHIP 1/10 6.8K OHM J 2012 10000
RC359R CHIP 1/10 27K OHM J 2012 10000
RC360R CHIP 1/10 33K OHM J 2012 10000
RC361R CHIP 1/10 2.2K OHM J 2012 10000
RC362R CHIP 1/10 11K OHM J 2012 10000
RC405R CHIP 1/10 1K OHM J 2012 10000
RC426R CHIP 1/10 3.3K OHM J 2012 10000
RC453R CHIP 1/10 10K OHM J 2012 10000
RC454R CHIP 1/10 1K OHM J 2012 10000
RC455R CHIP 1/10 330 OHM J 2012 10000
RC501R CHIP 1/10 1K OHM J 2012 10000
RC503R CHIP 1/10 5.6K OHM J 2012 10000
RC508R CHIP 1/10 1K OHM J 2012 10000
LOC PART NAME PART DESCRIPTION QTY REMARK
R

17
RC509R CHIP 1/10 1K OHM J 2012 10000
RC510R CHIP 1/10 390 OHM J 2012 10000
RC525R CHIP 1/10 1K OHM J 2012 10000
RC526R CHIP 1/10 1.3K OHM J 2012 10000
RC530R CHIP 1/10 560 OHM J 2012 10000
RC531R CHIP 1/10 560 OHM J 2012 10000
RC533R CHIP 1/10 39 OHM J 2012 10000
RC554R CHIP 1/10 1K OHM J 2012 10000
RC555R CHIP 1/10 820K OHM J 2012 10000
RC557R CHIP 1/10 1.8K OHM J 2012 10000
RC558R CHIP 1/10 1K OHM J 2012 10000
RC559R CHIP 1/10 330 OHM J 2012 10000
RC561R CHIP 1/10 330 OHM J 2012 10000
RC562R CHIP 1/10 820K OHM J 2012 10000
RC565R CHIP 1/10 12K OHM J 2012 10000
RC566R CHIP 1/10 12K OHM J 2012 10000
RC567R CHIP 1/10 10K OHM J 2012 10000
RC568R CHIP 1/10 4.7K OHM F 2012 10000
RC569R CHIP 1/10 1.5K OHM J 2012 10000
RC570R CHIP 1/10 10K OHM J 2012 10000
RC571R CHIP 1/10 2.7K OHM J 2012 10000
RC572R CHIP 1/10 22K OHM J 2012 10000
RC573R CHIP 1/10 1K OHM J 2012 10000
RC580R CHIP 1/10 330 OHM J 2012 10000
RC581R CHIP 1/10 330 OHM J 2012 10000
RC582R CHIP 1/10 330 OHM J 2012 10000
RC601R CHIP 1/10 1K OHM J 2012 10000
RC602R CHIP 1/10 1K OHM J 2012 10000
RC603R CHIP 1/10 8.2K OHM J 2012 10000
RC604R CHIP 1/10 8.2K OHM J 2012 10000
RC651R CHIP 1/10 1K OHM J 2012 10000
RC652R CHIP 1/10 1K OHM J 2012 10000
RC653R CHIP 1/10 100 OHM J 2012 10000
RC661R CHIP 1/10 5.1K OHM J 2012 10000
RC662R CHIP 1/10 510 OHM J 2012 10000
RC665R CHIP 1/10 10K OHM J 2012 10000
RC701R CHIP 1/10 39 OHM J 2012 10000
RC703R CHIP 1/10 100 OHM J 2012 10000
RC704R CHIP 1/10 1K OHM J 2012 10000
RC705R CHIP 1/10 4.7K OHM J 2012 10000
RC706R CHIP 1/10 4.7K OHM J 2012 10000
RC707R CHIP 1/10 1K OHM J 2012 10000
RC708R CHIP 1/10 4.7K OHM J 2012 10000
RC709R CHIP 1/10 1.5K OHM J 2012 10000
RC712R CHIP 1/10 47K OHM J 2012 10000
RC731R CHIP 1/10 10K OHM J 2012 10000
RC732R CHIP 1/10 1K OHM J 2012 10000
RC733R CHIP 1/10 1K OHM J 2012 10000
RC734R CHIP 1/10 1K OHM J 2012 10000
RC735R CHIP 1/10 1K OHM J 2012 10000
RC736R CHIP 1/10 10K OHM J 2012 10000
RC737R CHIP 1/10 10K OHM J 2012 10000
RC738R CHIP 1/10 470 OHM J 2012 10000
RC743R CHIP 1/10 1K OHM J 2012 10000
RC744R CHIP 1/10 1K OHM J 2012 10000
RC746R CHIP 1/10 2.2K OHM J 2012 10000
RC747R CHIP 1/10 3.9K OHM J 2012 10000
RC750R CHIP 1/10 4.7K OHM J 2012 10000
LOC PART NAME PART DESCRIPTION QTY REMARK
SERVICE PARTS LIST
RC751R CHIP 1/10 470 OHM J 2012 10000
RC752R CHIP 1/10 470 OHM J 2012 10000
RC755R CHIP 1/10 4.7K OHM J 2012 10000
RC756R CHIP 1/10 4.7K OHM J 2012 10000
RC758R CHIP 1/10 4.7K OHM J 2012 10000
RC759R CHIP 1/10 4.7K OHM J 2012 10000
RC760R CHIP 1/10 10K OHM J 2012 10000
RC763R CHIP 1/10 200 OHM J 2012 10000
RC776R CHIP 1/10 4.7K OHM J 2012 10000
RC780R CHIP 1/10 100 OHM J 2012 10000
RC781R CHIP 1/10 1K OHM J 2012 10000
RC782R CHIP 1/10 330 OHM J 2012 10000
RC784R CHIP 1/10 510K OHM J 2012 10000
RC785R CHIP 1/10 100 OHM J 2012 10000
RC786R CHIP 1/10 1K OHM J 2012 10000
RC787R CHIP 1/10 4.7K OHM J 2012 10000
RC788R CHIP 1/10 4.7K OHM J 2012 10000
RC789R CHIP 1/10 1K OHM J 2012 10000
RC791R CHIP 1/10 1K OHM J 2012 10000
RC792R CHIP 1/10 1K OHM J 2012 10000
RC793R CHIP 1/10 1K OHM J 2012 10000
RC794R CHIP 1/10 1K OHM J 2012 10000
RC795R CHIP 1/10 10K OHM J 2012 10000
RC796R CHIP 1/10 470 OHM J 2012 10000
RC797R CHIP 1/10 10K OHM J 2012 10000
RC798R CHIP 1/10 1K OHM J 2012 10000
RC799R CHIP 1/10 10K OHM J 2012 10000
RC913R CHIP 1/10 2.7K OHM J 2012 10000
RC914R CHIP 1/10 3K OHM J 2012 10000
RC915R CHIP 1/10 2.7K OHM J 2012 10000
RC923R CHIP 1/10 2.2K OHM J 2012 10000
RC924R CHIP 1/10 2.2K OHM J 2012 10000
RC925R CHIP 1/10 2.2K OHM J 2012 10000
RCA10R CHIP 1/10 220K OHM J 2012 10000
RCA11R CHIP 1/10 100 OHM J 2012 10000
RCA12R CHIP 1/10 100 OHM J 2012 10000
RCA13R CHIP 1/10 220K OHM J 2012 10000
RCA14R CHIP 1/10 910KOHM J 2012 10000
RCA16R CHIP 1/10 47K OHM J 2012 10000
RCA17R CHIP 1/10 47K OHM J 2012 10000
RCA18R CHIP 1/10 47K OHM J 2012 10000
RCA19R CHIP 1/10 1K OHM J 2012 10000
RCA20R CHIP 1/10 20K OHM J 2012 10000
RCV03R CHIP 1/10 75 OHM J 2012 10000
RCV04R CHIP 1/10 100 OHM J 2012 10000
RCV05R CHIP 1/10 47 OHM J 2012 10000
RCV06R CHIP 1/10 51 OHM J 2012 10000
RCV10R CHIP 1/10 2.4K OHM J 2012 10000
RCV11R CHIP 1/10 1K OHM J 2012 10000
RCV12R CHIP 1/10 10 OHM J 2012 10000
ZZ200PCB MAIN (RHU) AS DTQ-20D5FS 10000
C105 C ELECTRO 16V RSS 470MF (10X12.5)TP 10000
C310 C ELECTRO 25V RSS 1000MF (13X20) TP 10000
C410 C ELECTRO 250V RSS 10MF (10X20) TP 10000
C414 C ELECTRO 35V RSS 470MF (10X20) TP 10000
C415 C ELECTRO 16V RSS 1000MF (10X20) TP 10000
C510 C ELECTRO 16V RSS 470MF (10X12.5)TP 10000
C514 C ELECTRO 16V RSS 470MF (10X12.5)TP 10000
LOC PART NAME PART DESCRIPTION QTY REMARK

18
C670 C ELECTRO 16V RSS 470MF (10X12.5)TP 10000
C681 C ELECTRO 25V RUS 2200MF (16X25) TP 10000
C812 C ELECTRO 16V RSS 1000MF (10X20) TP 10000
C813 C CERA SEMI 2KV BL(N) 470PF K (T) 10000
C814 C ELECTRO 160V RSS 100MF (16X25) TP 10000
C820 C ELECTRO 160V RSS 100MF (16X25) TP 10000
C832 C CERA SEMI 2KV BL(N) 470PF K (T) 10000
C888 C CERA 2KV B 470PF K (TAPPING) 10000
C889 C ELECTRO 16V RUS 1000MF (10X20) TP 10000
C965 C CERA 2KV B 1000PF K (TAPPING) 10000
L800 COIL DELAY LINE RS208 10000
ZZ200PCB MAIN M-10 AS DTQ-20D5FS 10000
10 TAPE MASKING 6.2X500 1200
E01 EYE LET BSR T0.2 (R1.6) 10000
E02 EYE LET BSR T0.2 (R1.6) 10000
E04 EYE LET BSR T0.2 (R2.3) 10000
E05 EYE LET BSR T0.2 (R2.3) 10000
E06 EYE LET BSR T0.2 (R1.6) 10000
E07 EYE LET BSR T0.2 (R1.6) 10000
E08 EYE LET BSR T0.2 (R1.6) 10000
E09 EYE LET BSR T0.2 (R1.6) 10000
E10 EYE LET BSR T0.2 (R2.3) 10000
E11 EYE LET BSR T0.2 (R2.3) 10000
E12 EYE LET BSR T0.2 (R2.3) 10000
E13 EYE LET BSR T0.2 (R2.3) 10000
E14 EYE LET BSR T0.2 (R2.3) 10000
E15 EYE LET BSR T0.2 (R1.6) 10000
E17 EYE LET BSR T0.2 (R2.3) 10000
E18 EYE LET BSR T0.2 (R2.3) 10000
E19 EYE LET BSR T0.2 (R2.3) 10000
E20 EYE LET BSR T0.2 (R2.3) 10000
E22 EYE LET BSR T0.2 (R2.3) 10000
E23 EYE LET BSR T0.2 (R1.6) 10000
E24 EYE LET BSR T0.2 (R1.6) 10000
E25 EYE LET BSR T0.2 (R1.6) 10000
E26 EYE LET BSR T0.2 (R1.6) 10000
E27 EYE LET BSR T0.2 (R1.6) 10000
E29 EYE LET BSR T0.2 (R2.3) 10000
E30 EYE LET BSR T0.2 (R1.6) 10000
E31 EYE LET BSR T0.2 (R1.6) 10000
E32 EYE LET BSR T0.2 (R1.6) 10000
E33 EYE LET BSR T0.2 (R2.3) 10000
E34 EYE LET BSR T0.2 (R2.3) 10000
E35 EYE LET BSR T0.2 (R2.3) 10000
P601 CONN WAFER YW025-04 (STICK) 10000
P801ATERM PIN DA-IB0214(D2.3/DY PIN) 10000
P801BTERM PIN DA-IB0214(D2.3/DY PIN) 10000
R303 R M-OXIDE FILM 1W 1.2 OHM J (TAPPING) 10000
R403 R M-OXIDE FILM 2W 5.6K OHM J SMALL 10000
R414 R M-OXIDE FILM 2W 2.2 OHM J SMALL 10000
R804 R M-OXIDE FILM 2W 0.27 OHM J SMALL 10000
R814 R M-OXIDE FILM 2W 0.82 OHM J SMALL 10000
ZZ200PCB MAIN RADIAL AS DTQ-20D5FS 10000
C101 C ELECTRO 50V RSS 1MF (5X11) TP 10000
C102 C ELECTRO 16V RSS 100MF (6.3X11) TP 10000
C103 C ELECTRO 50V RSS 3.3MF (5X11) TP 10000
C104 C MYLAR 50V EU 0.033MF J (TP) 10000
C106 C ELECTRO 50V RSS 1MF (5X11) TP 10000
LOC PART NAME PART DESCRIPTION QTY REMARK
SERVICE PARTS LIST
C107 C ELECTRO 50V RSS 0.22MF (5X11) TP 10000
C201 C ELECTRO 16V RSS 220MF (8X11.5) TP 10000
C202 C ELECTRO 50V RSS 10MF (5X11) TP 10000
C203 C ELECTRO 50V RSS 1MF (5X11) TP 10000
C220 C ELECTRO 50V RSS 2.2MF (5X11) TP 10000
C221 C ELECTRO 50V RSS 2.2MF (5X11) TP 10000
C301 C MYLAR 50V EU 0.01MF J (TP) 10000
C302 C ELECTRO 50V RSS 4.7MF (5X11) TP 10000
C303 C ELECTRO 50V RSS 10MF (5X11) TP 10000
C305 C ELECTRO 50V RSS 100MF (8X11.5) TP 10000
C307 C CERA 500V SL 10PF D (TAPPING) 10000
C308 C MYLAR 50V EU 0.1MF J (TP) 10000
C311 C ELECTRO 50V RT 2.2MF (6.3X11) TP 10000
C401 C CERA 500V B 1000PF K (TAPPING) 10000
C405 C ELECTRO 160V RSS 1MF (6.3X11) TP 10000
C411 C ELECTRO 50V RSS 10MF (5X11) TP 10000
C412 C CERA 500V B 1000PF K (TAPPING) 10000
C413 C CERA 500V B 1000PF K (TAPPING) 10000
C416 C CERA 500V B 1000PF K (TAPPING) 10000
C417 C CERA 500V B 1000PF K (TAPPING) 10000
C418 C MYLAR 100V 0.1MF J (TP) 10000
C420 C ELECTRO 50V RSS 0.33MF (5X11) TP 10000
C451 C ELECTRO 16V RSS 100MF (6.3X11) TP 10000
C452 C ELECTRO 16V RSS 220MF (8X11.5) TP 10000
C501 C MYLAR 50V MEU 1MF J 10000
C502 C ELECTRO 16V RSS 330MF (8X11.5) TP 10000
C507 C MYLAR 50V EU 0.22MF J (TP) 10000
C508 C MYLAR 50V EU 0.22MF J (TP) 10000
C509 C ELECTRO 50V RSS 1MF (5X11) TP 10000
C511 C MYLAR 50V EU 0.033MF J (TP) 10000
C512 C ELECTRO 50V RSS 0.1MF (5X11) TP 10000
C513 C ELECTRO 50V RSS 1MF (5X11) TP 10000
C516 C ELECTRO 50V RSS 2.2MF (5X11) TP 10000
C517 C MYLAR 50V 0.047MF J (TP) 10000
C518 C ELECTRO 50V RSS 0.47MF (5X11) TP 10000
C519 C ELECTRO 50V RSS 0.47MF (5X11) TP 10000
C520 C ELECTRO 50V RSS 1MF (5X11) TP 10000
C525 C ELECTRO 50V RSS 1MF (5X11) TP 10000
C551 C ELECTRO 50V RSS 0.47MF (5X11) TP 10000
C651 C MYLAR 50V EU 0.1MF J (TP) 10000
C652 C ELECTRO 16V RSS 47MF (5X11) TP 10000
C654 C ELECTRO 16V RSS 100MF (6.3X11) TP 10000
C655 C ELECTRO 50V RSS 3.3MF (5X11) TP 10000
C658 C ELECTRO 50V RSS 10MF (5X11) TP 10000
C659 C ELECTRO 50V RSS 10MF (5X11) TP 10000
C660 C ELECTRO 50V RSS 10MF (5X11) TP 10000
C662 C ELECTRO 50V RSS 3.3MF (5X11) TP 10000
C666 C ELECTRO 50V RSS 10MF (5X11) TP 10000
C669 C ELECTRO 25V RSS 100MF (6.3X11) TP 10000
C682 C MYLAR 50V EU 0.22MF J (TP) 10000
C683 C ELECTRO 50V RSS 1MF (5X11) TP 10000
C684 C MYLAR 50V EU 0.22MF J (TP) 10000
C685 C ELECTRO 25V RSS 47MF (5X11) TP 10000
C686 C ELECTRO 25V RSS 47MF (5X11) TP 10000
C701 C ELECTRO 25V RSS 47MF (5X11) TP 10000
C702 C ELECTRO 16V RSS 220MF (8X11.5) TP 10000
C703 C ELECTRO 50V RSS 1MF (5X11) TP 10000
C704 C ELECTRO 50V RSS 2.2MF (5X11) TP 10000
LOC PART NAME PART DESCRIPTION QTY REMARK
R
R
R
R
R
