Dahua Technology DH-LDH Series User manual

DH-LDH32-TAI200
DH-LDH43-TAI200
DH-LDH49-TAI200
DH-LDH55-TAI200
LCD Digital Signage
User Manual

DH-LDHxx-TAI200
ii
Safety Instructions
Safety precautions and maintenance
WARNING: Use of controls, adjustments or procedures other than those specied in this documentation may result in exposure to
shock, electrical hazards and/or mechanical hazards.
Read and follow these instructions when connecting and using your display:
Operation:
• Keepthedisplayoutofdirectsunlightandawayfromstovesoranyotherheatsources.
• Removeanyobjectthatcouldfallintoventilationholesorpreventpropercoolingofthedisplay’selectronics.
• Donotblocktheventilationholesonthecabinet.
• Whenpositioningthedisplay,makesurethepowerplugandoutletareeasilyaccessible.
• Whenturningoffthedisplaybydetachingthepowercord,wait6secondsbeforere-attachingthepowercordfornormaloperation.
• EnsuretheuseofanapprovedpowercordprovidedbyDHatalltimes.Ifyourpowercordismissing,pleasecontactyourlocalservicecenter.
• Donotsubjectthedisplaytoseverevibrationorhighimpactconditionsduringoperation.
• Donotknockordropthedisplayduringoperationortransportation.
Maintenance:
• Toprotectyourdisplayfrompossibledamage,donotputexcessivepressureontheLCDpanel.Whenmovingyourdisplay,grasptheframetolift;do
notliftthedisplaybyplacingyourhandorngersontheLCDpanel.
• Unplugthedisplayifyouarenotgoingtouseitforanextensiveperiodoftime.
• Unplugthedisplayifyouneedtocleanitwithaslightlydampcloth.Thescreenmaybewipedwithadryclothwhenthepowerisoff.However,never
useorganicsolvent,suchas,alcohol,orammonia-basedliquidstocleanyourdisplay.
• Toavoidtheriskofshockorpermanentdamagetotheset,donotexposethedisplaytodust,rain,wateroranexcessivelymoistenvironment.
• Ifyourdisplaybecomeswet,wipeitwithdryclothassoonaspossible.
• Ifaforeignsubstanceorwatergetsinyourdisplay,turnthepoweroffimmediatelyanddisconnectthepowercord.Thenremovetheforeignsubstance
orwater,andsendtheunittothemaintenancecenter.
• Donotstoreorusethedisplayinlocationsexposedtoheat,directsunlightorextremecold.
• Inordertomaintainthebestperformanceofyourdisplayandensurealongerlifetime,westronglyrecommendusingthedisplayinalocationthatfalls
withinthefollowingtemperatureandhumidityranges.
-Temperature:0-40°C32-104°F
-Humidity:20-80%RH
IMPORTANT:Alwaysactivateamovingscreensaverprogramwhenyouleaveyourdisplayunattended.Alwaysactivateaperiodicscreenrefresh
applicationiftheunitwilldisplayunchangingstaticcontent.Uninterrupteddisplayofstillorstaticimagesoveranextendedperiodmaycause“burnin”,
alsoknownas“after-imaging”or“ghostimaging”,onyourscreen.Thisisawell-knownphenomenoninLCDpaneltechnology.Inmostcases,the“burned
in”or“after-imaging”or“ghostimaging”willdisappeargraduallyoveraperiodoftimeafterthepowerhasbeenswitchedoff.
WARNING:Severe“burn-in”or“after-image”or“ghostimage”symptomswillnotdisappearandcannotberepaired.Thisisalsonotcoveredunderthe
termsofyourwarranty.
Service:
• Thecasingcovershouldbeopenedonlybyqualiedservicepersonnel.
• Ifthereisanyneedforrepairorintegration,pleasecontactyourlocalservicecenter.
• Donotleaveyourdisplayunderdirectsunlight.
Ifyourdisplaydoesnotoperatenormally,havingfollowedtheinstructionssetoutinthisdocument,pleasecontactatechnicianoryour
localservicecenter.

DH-LDHxx-TAI200
iii
Read and follow these instructions when connecting and using your display:
• Unplugthedisplayifyouarenotgoingtouseitforanextensiveperiodoftime.
• Unplugthedisplayifyouneedtocleanitwithaslightlydampcloth.Thescreenmanybewipedwithadryclothwhenthepoweris
off.However,neverusealcohol,solventsorammonia-basedliquids.
• Consultaservicetechnicianifthedisplaydoesnotoperatenormallywhenyouhavefollowedtheinstructionsinthismanual.
• Thecasingcovershouldbeopenedonlybyqualiedservicepersonnel.
• Keepthedisplayoutofdirectsunlightandawayfromstovesoranyotherheatsources.
• Removeanyobjectthatcouldfallintotheventsorpreventpropercoolingofthedisplay’selectronics.
• Donotblocktheventilationholesonthecabinet.
• Keepthedisplaydry.Toavoidelectricshock,donotexposeittorainorexcessivemoisture.
• WhenturningoffthedisplaybydetachingthepowercableorDCpowercord,waitfor6secondsbeforere-attachingthepower
cableorDCpowercordfornormaloperation..
• Toavoidtheriskofshockorpermanentdamagetothesetdonotexposethedisplaytorainorexcessivemoisture.
• Whenpositioningthedisplay,makesurethepowerplugandoutletareeasilyaccessible.
• IMPORTANT:Alwaysactivateascreensaverprogramduringyourapplication.Ifastillimageinhighcontrastremainsonthe
screenforanextendedperiodoftime,itmayleavean‘after-image’or‘ghostimage’onthefrontofthescreen.Thisisawell-known
phenomenonthatiscausedbytheshortcomingsinherentinLCDtechnology.Inmostcasestheafterimagewilldisappeargradually
overaperiodoftimeafterthepowerhasbeenswitchedoff.Beawarethattheafter-imagesymptomcannotberepairedandisnot
coveredunderwarranty.
CE Declaration of Conformity
ThisdevicecomplieswiththerequirementssetoutintheCouncilDirectiveontheApproximationoftheLawsoftheMemberStatesrelatingto
ElectromagneticCompatibility(2014/30/EU),Low-voltageDirective(2014/35/EU),RoHSdirective(2011/65/EU)andRadioEquipmentDirective(2014/53/
EU).
ThisproducthasbeentestedandfoundtocomplywiththeharmonizedstandardsforInformationTechnologyEquipment,theseharmonizedstandards
publishedunderDirectivesofOfcialJournaloftheEuropeanUnion.
Warning:
ThisequipmentiscompliantwithClassAofEN55032/CISPR32.Inaresidentialenvironmentthisequipmentmaycauseradiointerference.
ESD Warnings
Whenuserclosetothemonitormaycausetheequipmentdischargeandreboottothedisplayofmainmenu.
Federal Communications Commission (FCC) Notice (U.S. Only)
NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigitaldevice,pursuanttopart15ofthe
FCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferencewhentheequipmentisoperated
inacommercialenvironment.Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalledandusedin
accordancewiththeinstructionmanual,maycauseharmfulinterferencetoradiocommunications.Operationofthisequipmentina
residentialareaislikelytocauseharmfulinterferenceinwhichcasetheuserwillberequiredtocorrecttheinterferenceathisown
expense.
Changesormodicationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser’sauthoritytooperatethe
equipment.
UseonlyanRFshieldedcablethatwassuppliedwiththedisplaywhenconnectingthisdisplaytoacomputerdevice.
Topreventdamagewhichmayresultinreorshockhazard,donotexposethisappliancetorainorexcessivemoisture.
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)Thisdevicemaynotcauseharmful
interference,and(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.

DH-LDHxx-TAI200
iv
Europe – EU Declaration of Conformity
ThisdevicecomplieswiththeessentialrequirementsoftheRadioEquipmentDirective(2014/53/EU).Thefollowingtestmethodshavebeenappliedin
ordertoprovepresumptionofconformitywiththeessentialrequirementsoftheRadioEquipmentDirective(2014/53/EU):
-EN60950-1
SafetyofInformationTechnologyEquipment
-EN62311
Assessmentofelectronicandelectricalequipmentrelatedtohumanexposurerestrictionsforelectromagneticelds(0Hz-300GHz)
-EN300328(For802.11b/g/n)
ElectromagneticcompatibilityandRadiospectrumMatters(ERM);WidebandTransmissionsystems;Datatransmissionequipmentoperatinginthe2,4
GHzISMbandandusingspreadspectrummodulationtechniques;HarmonizedENcoveringessentialrequirementsunderarticle3.2oftheR&TTE
Directive
-EN301489-17
ElectromagneticcompatibilityandRadiospectrumMatters(ERM);ElectroMagneticCompatibility(EMC)standardforradioequipmentandservices;Part
17:Specicconditionsfor2,4GHzwidebandtransmissionsystemsand5GHzhighperformanceRLANequipment
-EN301489-1
ElectromagneticcompatibilityandRadioSpectrumMatters(ERM);ElectroMagneticCompatibility(EMC)standardforradioequipmentandservices;Part1:
Commontechnicalrequirements
Canada:
IndustryCanadastatement:
ThisdevicecomplieswithRSS-247oftheIndustryCanadaRules.Operationissubjecttothefollowingtwoconditions:(1)Thisdevicemaynotcause
harmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.
CedispositifestconformeàlanormeCNR-247d'IndustrieCanadaapplicableauxappareilsradioexemptsdelicence.Sonfonctionnementestsujetaux
deuxconditionssuivantes:(1)ledispositifnedoitpasproduiredebrouillagepréjudiciable,et(2)cedispositifdoitacceptertoutbrouillagereçu,ycompris
unbrouillagesusceptibledeprovoquerunfonctionnementin
Electric, Magnetic and Electromagnetic Fields (“EMF”)
1. Wemanufactureandsellmanyproductstargetedatconsumers,which,likeanyelectronicapparatus,ingeneralhavetheabilitytoemitandreceive
electromagneticsignals.
2. OneofourleadingBusinessPrinciplesistotakeallnecessaryhealthandsafetymeasuresforourproducts,tocomplywithallapplicablelegal
requirementsandtostaywellwithintheEMFstandardsapplicableatthetimeofproducingtheproducts.
3. Wearecommittedtodevelop,produceandmarketproductsthatcausenoadversehealtheffects.
4. Weconrmthatifitsproductsarehandledproperlyfortheirintendeduse,theyaresafetouseaccordingtoscienticevidenceavailabletoday.
5. WeplayanactiveroleinthedevelopmentofinternationalEMFandsafetystandards,enablingustoanticipatefurtherdevelopmentsinstandardization
forearlyintegrationinitsproducts.

DH-LDHxx-TAI200
v
Information for U.K. only
(A)
(B)
WARNING - THIS APPLIANCE MUST BE EARTHED.
Important:
Thisapparatusissuppliedwithanapprovedmoulded13Aplug.Tochangeafuseinthistypeofplug
proceedasfollows:+
1. Removefusecoverandfuse.
2. FitnewfusewhichshouldbeaBS13625A,A.S.T.A.orBSIapprovedtype.
3. Retthefusecover.
Ifthettedplugisnotsuitableforyoursocketoutlets,itshouldbecutoffandanappropriate3-pin
plugttedinitsplace.
Ifthemainsplugcontainsafuse,thisshouldhaveavalueof5A.Ifaplugwithoutafuseisused,thefuse
atthedistributionboardshouldnotbegreaterthan5A.
NOTE: Theseveredplugmustbedestroyedtoavoidapossibleshockhazardshoulditbeinserted
intoa13Asocketelsewhere.
How to connect a plug
Thewiresinthemainsleadarecolouredinaccordancewiththefollowingcode:
BLUE-“NEUTRAL”(“N”)
BROWN-“LIVE”(“L”)
GREEN&YELLOW-“EARTH”(“E”)
1. TheGREEN&YELLOWwiremustbeconnectedtotheterminalintheplugwhichismarkedwith
theletter“E”orbytheEarthsymbolorcolouredGREENorGREEN&YELLOW.
2. TheBLUEwiremustbeconnectedtotheterminalwhichismarkedwiththeletter“N”orcoloured
BLACK.
3. TheBROWNwiremustbeconnectedtotheterminalwhichmarkedwiththeletter“L”or
colouredRED.
Beforereplacingtheplugcover,makecertainthatthecordgripisclampedoverthesheathofthelead
-notsimplyoverthethreewires.
North Europe (Nordic Countries) Information
Placering/Ventilation
VARNING:
FÖRSÄKRADIGOMATTHUVUDBRYTAREOCHUTTAGÄRLÄTÅTKOMLIGA,NÄRDUSTÄLLERDINUTRUSTNINGPÅPLATS.
Placering/Ventilation
ADVARSEL:
SØRGVEDPLACERINGENFOR,ATNETLEDNINGENSSTIKOGSTIKKONTAKTERNEMTTILGÆNGELIGE.
Paikka/Ilmankierto
VAROITUS:
SIJOITALAITESITEN,ETTÄVERKKOJOHTOVOIDAANTARVITTAESSAHELPOSTIIRROTTAAPISTORASIASTA.
Plassering/Ventilasjon
ADVARSEL:
NÅRDETTEUTSTYRETPLASSERES,MÅDUPASSEPÅATKONTAKTENEFORSTØMTILFØRSELERLETTEÅNÅ.

DH-LDHxx-TAI200
vi
End-of-Life Disposal
YournewPublicInformationDisplaycontainsmaterialsthatcanberecycledandreused.Specializedcompaniescanrecycleyourproducttoincreasethe
amountofreusablematerialsandtominimizetheamounttobedisposedof.
PleasendoutaboutthelocalregulationsonhowtodisposeofyourolddisplayfromyourlocalDHdealer.
(For customers in Canada and U.S.A.)
Thisproductmaycontainleadand/ormercury.Disposeofinaccordancetolocal-stateandfederalregulations.Foradditionalinformationonrecycling
contactwww.eia.org(ConsumerEducationInitiative)
Waste Electrical and Electronic Equipment-WEEE
Attention users in European Union private households
Thismarkingontheproductoronitspackagingillustratesthat,underEuropeanDirective2012/19/EUgoverningusedelectricaland
electronicappliances,thisproductmaynotbedisposedofwithnormalhouseholdwaste.Youareresponsiblefordisposalofthis
equipmentthroughadesignatedwasteelectricalandelectronicequipmentcollection.Todeterminethelocationsfordroppingoffsuch
wasteelectricalandelectronic,contactyourlocalgovernmentofce,thewastedisposalorganizationthatservesyourhouseholdorthe
storeatwhichyoupurchasedtheproduct.
Attention users in United States:
PleasedisposeofaccordingtoallLocal,StateandFederalLaws.Forthedisposalorrecyclinginformation,contact:www.mygreenelectronics.comorwww.
eiae.org.
End of Life Directives-Recycling
YournewPublicInformationDisplaycontainsseveralmaterialsthatcanberecycledfornewusers.
PleasedisposeofaccordingtoallLocal,State,andFederallaws
Batteries
ForEU:Thecrossed-outwheeledbinimpliesthatusedbatteriesshouldnotbeputtothegeneralhouseholdwaste!Thereisa
separatecollectionsystemforusedbatteries,toallowpropertreatmentandrecyclinginaccordancewithlegislation.
Pleasecontactyourlocalauthorityfordetailsonthecollectionandrecyclingschemes.
ForSwitzerland:Theusedbatteryistobereturnedtothesellingpoint.
Forothernon-EUcountries:Pleasecontactyourlocalauthorityforcorrectmethodofdisposaloftheusedbattery.
According to EU directive 2006/66/EC, the battery can’t be disposed improperly. The battery shall be separated
to collect by local service.
Após o uso, as pilhas
deverão ser entregues ao
estabelecimento comercial ou
e/ou baterias
rede de assistência técnica
autorizada.

DH-LDHxx-TAI200
vii
Table Of Contents
1. Unpacking and Installation.......................................................1
1.1. Unpacking.........................................................................................1
1.2. PackageContents........................................................................1
1.3. InstallationNotes.........................................................................1
1.4. InstallingandRemovingTableStands(optional)........2
1.5. MountingonaWall....................................................................3
1.5.1. VESAGrid....................................................................3
1.6. MountinginPortraitPosition................................................4
2. Parts and Functions...................................................................5
2.1. ControlPanel.................................................................................5
2.2. Input/OutputTerminals.............................................................6
2.3. RemoteControl...........................................................................7
2.3.1. Insertingthebatteriesintheremote
control.............................................................................9
2.3.2. Handlingtheremotecontrol.............................9
2.3.3. Operatingrangeoftheremotecontrol......9
3. Connecting External Equipment.......................................... 10
3.1. ConnectingExternalEquipment(DVD/VCR/
VCD)...............................................................................................10
3.1.1. UsingHDMI/VGAvideoinput.......................10
3.2. ConnectingaPC.......................................................................10
3.2.1. UsingHDMI/VGAinput....................................10
4. Basic Operations..................................................................... 11
4.1. BootingUpandShuttingDown.......................................11
4.2. InitializingSignage......................................................................11
4.3. LogginginSystem.....................................................................11
4.4. OperatingQuickToolBar....................................................11
4.5. ConguringDate&Time.....................................................12
4.6. DisplayingPrograms................................................................12
5. Conguring System Settings................................................. 16
5.1. ConguringVisual&AudioParameters.......................16
5.2. SelectingInputSource...........................................................17
5.3. SelectingSystemLanguage..................................................17
6. System Maintenance............................................................... 17
6.1. MaintenanceRequirements................................................17
6.2. ModifyingPassword.................................................................17
6.3. RebootingYourSignage.........................................................17
6.4. ConguringAutoRebootTime........................................18
6.5. UpgradingSystem....................................................................18
6.6. RestoringYourSignagetoFactorySettings................18
7. Input Mode............................................................................... 18
8. leaning and Troubleshooting................................................. 19
8.1. Cleaning..........................................................................................19
8.2. Troubleshooting.........................................................................20
9. Technical Specications ......................................................... 21

DH-LDHxx-TAI200
1
1. Unpacking and Installation
1.1. Unpacking
• Thisproductispackedinacarton,togetherwiththestandardaccessories.
• Anyotheroptionalaccessorieswillbepackedseparately.
• Duetothesizeandweightofthisdisplayitisrecommendedfortwopeopletomoveit.
• Afteropeningthecarton,ensurethatthecontentsarecompleteandingoodcondition.
1.2. Package Contents
Pleaseverifythatyoureceivedthefollowingitemswithyourpackagecontent:
• LCDdisplay
• Remotecontrol
• Powercord(1.8m)
• Logo
• HDMICable(1.8m)
• UserManual
*The supplied power cord varies depending on destination.
Power Cord(1.8m)
User Manual
Remote Control
HDMI Cable(1.8m) Logo
DH-LDH32-MAI200
DH-LDH43-MAI200
DH-LDH49-MAI200
DH-LDH55-MAI200
LCD Monitor
User Manual

*Differencesaccordingtoregions.
Displaydesignandaccessoriesmaydifferfromthoseillustratedabove.
NOTES:
• Forallotherregions,applyapowercordthatconformstotheACvoltageofthepowersocketandhasbeenapprovedbyandcomplieswiththe
safetyregulationsoftheparticularcountry(TypeH05VV-F,2Gor3G,0.75or1mm2shouldbeused).
• Youmightliketosavethepackageboxandpackingmaterialforshippingthedisplay.
1.3. Installation Notes
• Duetothehighpowerconsumption,alwaysusetheplugexclusivelydesignedforthisproduct.Ifanextendedlineisrequired,pleaseconsultyour
serviceagent.
• Theproductshouldbeinstalledonaatsurfacetoavoidtipping.Thedistancebetweenthebackoftheproductandthewallshouldbemaintained
forproperventilation.Avoidinstallingtheproductinthekitchen,bathroomoranyotherplaceswithhighhumiditysoasnottoshortentheservicelife
oftheelectroniccomponents.
• Theproductcannormallyoperateonlyunder3000minaltitude.Ininstallationsataltitudesabove3000m,someabnormalitiesmaybeexperienced.

DH-LDHxx-TAI200
2
1.4. Installing and Removing Table Stands (optional)
To install table stands:
Step 1- Put on the table
Layaprotectivesheetonthetable,whickwaswrappedarroundthedisplaywhenitwaspackaged,beneachthescreensurfacesoasnottoscratch
thescreenface.
Step 2- Fix the tube to the display (by using M6xL41 screws)
Pleaserefertothefollowingdrawingtoknowthepositionofscrews.
Step 3- Set up the stand (by using thumb)
M6xL41 screws
Table stand
Longer portions face the front
Thumb screws
Thumb screws
To remove table stands:
1. Poweroffthedisplay.
2. Spreadaprotectivesheetonaatsurface.
3. Placethedisplayface-downontheprotectivesheet.
4. Removescrewsusingascrewdriverandplacetheminasafeplaceforreuse.

DH-LDHxx-TAI200
3
1.5. Mounting on a Wall
Tomountthisdisplaytoawall,youwillhavetoobtainastandardwall-mountingkit(commerciallyavailable).Werecommendusingamountinginterface
thatcomplieswithTUV-GSand/orUL1678standard.
Protective Sheet
Table
VESA Grid
1. Layaprotectivesheetonatable,whichwaswrappedaroundthedisplaywhenitwaspackaged,beneaththescreensurfacesoasnottoscratchthe
screenface.
2. Ensureyouhaveallaccessoriesformountingthisdisplay(wallmount,ceilingmount,tablestand,etc).
3. Followtheinstructionsthatcomewiththebasemountingkit.Failuretofollowcorrectmountingprocedurescouldresultindamagetotheequipment
orinjurytotheuserorinstaller.Productwarrantydoesnotcoverdamagecausedbyimproperinstallation.
4. Forthewall-mountingkit,useM6mountingscrews(havingalength10mmlongerthanthethicknessofthemountingbracket)andtightenthem
securely.
1.5.1. VESA Grid
DH-LDH32-TAI200 200(H)x200(V)mm
DH-LDH43-TAI200 400(H)x400(V)mm
DH-LDH49-TAI200 400(H)x400(V)mm
DH-LDH55-TAI200 400(H)x400(V)mm
Caution:
Topreventthedisplayfromfalling:
• Forwallorceilinginstallation,werecommendinstallingthedisplaywithmetalbracketswhicharecommerciallyavailable.Fordetailedinstallation
instructions,refertotheguidereceivedwiththerespectivebracket.
• Tolessentheprobabilityofinjuryanddamageresultingfromfallofthedisplayincaseofearthquakeorothernaturaldisaster,besuretoconsultthe
bracketmanufacturerforinstallationlocation.
Ventilation Requirements for enclosure locating
Toallowheattodisperse,leavespacebetweensurroundingobjectsasshowninthe
diagrambelow.

100 mm 100 mm
100 mm
100 mm

DH-LDHxx-TAI200
4
1.6. Mounting in Portrait Position
Thisdisplaycanbeinstalledinportraitposition.
1. Removethetablestand,ifattached.
2. Rotate90degreescounter-clockwise.
90
90
NOTE: Wheninstallingthedisplayonawall,pleaseconsultaprofessionaltechnicianforproperinstallation.Weacceptnoliabilityforinstallationsnot
performedbyaprofessionaltechnician.

DH-LDHxx-TAI200
5
2. Parts and Functions
2.1. Control Panel
1
1Remote control sensor and power status indicator
• Receivescommandsignalsfromtheremotecontrol.
• Indicatestheoperatingstatusofthedisplay:
-Lightsgreenwhenthedisplayisturnedon
-Lightsgreenwhenthedisplayisinstandbymode
-Lightsoffwhenthemainpowerofthedisplayisturnedoff
• Pulldownthelenstohavebetterremotecontrolperformance
andeasytoobservethelightinformationofpowerstatus.
• Pushupthelensbeforemountingthedisplayforvideowall
application.
• Pull/Pushthelensuntilhearingtheclicksound.

DH-LDHxx-TAI200
6
2.2. Input/Output Terminals
8
9
1 32 5
4
7
6
RS232
IN HDMI 1
MICRO SD
USB 2.0
USB 3.0
RS232
SD
HDMI USBUSB
RJ45
VGA
1AC IN
ACpowerinputfromthewalloutlet.
2RS232 IN
RS232controlsignalinput.
3HDMI
HDMIsignalinput.
4/ 5USB PORT
ConnectyourUSBstoragedevice.
6RJ-45
Networkinterface.
7SD
ConnectyourSDCARD.
8VGA IN
VGAinput.
9SECURITY LOCK
Usedforsecurityandtheftprevention.

DH-LDHxx-TAI200
7
2.3. Remote Control
Fordevicesofspeciedmodels,youcanuseremotecontrolstooperate
them.Therearetwokindsofremotecontrols.Refertooneofthem
accordingtotheremotecontrolyouhavereceived.SeeAppendixgure1-1
Appendixgure1-1Remotecontrolappearance
Appendix table 1-1 Buttons description
Operation Item Buttons Needed
Turning on/off device Press .
Turn on/off device
screen Hold forthreeseconds.
Adjusting volume • Volumeup:Press andpressright
arrowbutton.
• Volumedown:Press andpressleft
arrowbutton.
Typing password to log 1.Whenyoundthescreenislocked,youcan
useyourremotecontroltotypethepassword.
Press onyourremotecontrol.
The“Login”interfaceisdisplayed.
2.Operatearrowkeysandmovepointerto
passwordbox,andtypepassword.
3.MovepointertoDoneonvirtualkeyboard.
4.MovepointertoOKandpress on
yourremotecontroltologinthedevice.
Returning to the
previous interface PressEscor .
Returning to the main
menu Press
Representing the
frequently used tool bar Press ,operatetheleft/rightarrowkeysto
selectafunctionyouwant.
Note: In the HDMI/VGA signal, only the key work.

DH-LDHxx-TAI200
8
Remote control use
-5m
-30°
When using a remote control, let the remote control lens down,
and then press it close to the monitor, and point to the remote
sensor. Ensure that the sight between the remote control and
the monitor is not obstructed by furniture, walls, or other objects.
Working indicator light
(The shape of the product will vary between the models, please
take the actual machine as the standard!)
Open monitor
·Please insert the power cord into the AC power outlet.

DH-LDHxx-TAI200
9
2.3.1. Inserting the batteries in the remote control
Theremotecontrolispoweredbytwo1.5VAAAbatteries.
Toinstallorreplacebatteries:
1. Pressandthenslidethecovertoopenit.
2. Alignthebatteriesaccordingtothe(+)and(–)indicationsinsidethe
batterycompartment.
3. Replacethecover.
Caution:
Theincorrectuseofbatteriescanresultinleaksorbursting.Besuretofollowtheseinstructions:
• Place“AAA”batteriesmatchingthe(+)and(–)signsoneachbatterytothe(+)and(–)signsofthebatterycompartment.
• Donotmixbatterytypes.
• Donotcombinenewbatterieswithusedones.Itcausesshorterlifeorleakageofbatteries.
• Removethedeadbatteriesimmediatelytopreventthemfromliquidleakinginthebatterycompartment.Don’ttouchexposedbatteryacid,asitcan
damageyourskin.
NOTE: Ifyoudonotintendtousetheremotecontrolforalongperiod,removethebatteries.
2.3.2. Handling the remote control
• Donotsubjecttostrongshock.
• Donotallowwaterorotherliquidtosplashtheremotecontrol.Iftheremotecontrolgetswet,wipeitdryimmediately.
• Avoidexposuretoheatandsteam.
• Otherthantoinstallthebatteries,donotopentheremotecontrol.
2.3.3. Operating range of the remote control
Pointthetopoftheremotecontroltowardthedisplay’sremotecontrolsensorwhen
pressingabutton.
Usetheremotecontrolwithinadistanceoflessthan2m/6.5ftfromthedisplay’ssensor,
andahorizontalandverticalangleoflessthan30degrees.
NOTE: Theremotecontrolmaynotfunctionproperlywhentheremotecontrol
sensoronthedisplayisunderdirectsunlightorstrongillumination,orwhen
thereisanobstacleinthepathofsignaltransmission.
30 30


DH-LDHxx-TAI200
10
3. Connecting External Equipment
3.1. Connecting External Equipment (DVD/VCR/VCD)
3.1.1. Using HDMI/VGA video input
DVD / VCR / VCD
HDMI Output
[HDMI Input]
RS232
SD
HDMI USB
USB
RJ45
[VGA Input ]
VGA
Output
3.2. Connecting a PC
3.2.1. Using HDMI/VGA input
[HDMI Input]
RS232
SD
HDMI
USBUSB
RJ45
PC
HDMI Output
[VGA Input ]
VGA
Output

DH-LDHxx-TAI200
11
4. Basic Operations
The Signage’s operation system is developed based on the Android
OS. You can connect the Signage to the online platform of information
release & management. Then you can use the platform to release
a multi-media program to the Signage, turn on/off the Signage and
reboot the Signage. You can implement the operations such as local
release, app management and system setting.
4.1. Booting Up and Shutting Down
• BeforebootinguptheSignage,checkifinputvoltagematchesrated
voltageoftheDevice.
• Refertointernationalstandardtoofferthepowerinput(power
inputthatiswithstablepowervalueandlessinterference)toensure
thedeviceworksstablyandprolongitsservicelife.
• TobootuptheSignage:Plugthepowerlineintoasocket.
• Toshutdown:Unplugtheline.
4.2. Initializing Signage
When you are opening the Signage for the rst time or you have
allowed your system to be restored the factory settings, you need to
initialize the Signage. Only after that can you operate and congure
your Signage.
Step 1 Plug the Signage’s power line into a socket.
The Signage boots up and the Device Initialization interface is
displayed. See Figure 4-1.
Figure 4-1The device initialization interface
Step 2 Type your password and type it again to conrm it.
Step 3 Click Done on your virtual keyboard.
Click Conrm on the Device Initialization interface.
Initialization begins. After that, the main menu is displayed. See Figure
4-2.
Figure 4-2 Main menu
4.3. Logging in System
The system will be locked automatically under each of the following
conditions:
• PlugtheSignage’spowerlineintoasocket(orturnontheSignage
withyourremotecontrol).
• Donotoperatethedeviceforthetimeyouhaveset.
• Lockthescreenmanually.
You need to type your password to unlock the system.
Step 1 Click any position on the screen.
The Login interface is displayed. See Figure 4-3.
Figure 4-3 The login interface
Login
Please enter password
OK
Step 2 Type your password.
Step 3 Click Save.
The main menu or the interface before the system is locked is
displayed.
4.4. Operating Quick Tool Bar
Move your pointer to the bottom of any an interface to display the
quick tool bar. See Figure 4-4 and Table 4-1 for details.
Figure 4-4 Quick tool bar

DH-LDHxx-TAI200
12
Table 4-1 Description of quick tool bar
Icon Description
Click this icon to adjust the backlight value.
Click this icon to select an input source from “Local”、
“HDMI”or “VGA”
Click this icon to enter the quick play interface.
Click this icon to lock your Signage.
Click this icon to disconnect your USB from the Signage.
4.5. Configuring Date & Time
You can set date and time for your device. Remember to select a
correct time zone based on where the device lies.
Step 1 In the main menu, select Settings > Date & Time.
The Date & Time interface is displayed. See Figure 4-5.
Figure 4-5 The date & time interface
Step 2 Set date, time and time zone. You can also enable the 24-
hour display format here.
Your settings will take effect at once.
4.6. Displaying Programs
Connect the Signage to the platform and then you use the platform
to send programs to your Signage. Or, you can insert a USB drive
into the Signage and operate the Signage to play the videos &
pictures in the USB.
4.6.1 Displaying Programs from Platform
4.6.1.1 Procedure
Figure 4-6 Procedure
Table 4-2 Procedure description
No. Description No. Description
1 Logging in 2 Connecting Signage to
network
3 Connecting Signage to
platform
4 Receiving programs
from platform
4.6.1.2 Connecting Signage to Network
4.6.1.2.1 Connecting Signage to Network
Connect your device to network by Ethernet, WLAN, 4G or Virtual
Private Network (VPN).
After your Signage is networked, it can be used as a hotspot for other
devices.
Step 1 In main menu, select Settings > Network Setting.
The Network Setting interface is displayed. See Figure 4-7.
Figure 4-7 The network setting interface
Step 2 Select and congure the network type you want to use. See
Table 4-3 for details.
Table 4-3 Network types description
Network
Type
Description
Ethernet ConnectyourSignagetonetworkbyEthernetand
therearetwokindsofmethodsforyoutogiveanIP
toyourSignage.
• DHCP:WhenthereisaDHCPserverinthe
network,afterselectingtheDHCPoption,the
SignageautomaticallyobtainsIPaddressfromthe
DHCPserver.
• Static IP: After selecting Static IP, respectively click
IP ADDRESS, DEFAULT GATEWAY or NETMASK,
and enter the IP address, default gateway and net
mask according to the network plan.
WLAN ConnectyourSignagetonetworkbyWi-Fi.
Click toturnonWi-First.Then,toconnect
yourSignagetonetwork,youcan:
• ClickagivenWi-Fi,typeitspasswordandclick
Connect.
• OryoucanaddaWi-Fimanually:click to
displaytheAddNetworkinterface.Thentype
NetworkSSIDandselectSecurityfromNone,
WEP,WPA/WPA2PSKand802.1xEAP.ClickSave
tonishconguration
4G Youcanconnecta4Gmobilenetworkcardtoyour
deviceandselectDataEnabledtonallygetyour
devicenetworked.
VPN ConnectyourdevicetoVPN.Thenyourdevicecan
getprogramsfromVPN.

DH-LDHxx-TAI200
13
4.6.1.2.2 Conguring Whitelist
Congure the IP that are allowed to access the Signage, and only IP
addresses in the whitelist can access the Signage. This is to enhance
data security.
Step 1 In main menu, click Settings > Network Setting > Whitelist.
The Whitelist interface is displayed.
Step 2 Click to enable whitelist and make it take effect
ofcially.
Step 3 Add an IP address to your whitelist.
1) Click .
The Add Whitelist interface is displayed. See Figure 4-8.
Figure 4-8 The add whitelist interface
2) Type an IP address.
3) Click Conrm.
The IP address you have added is displayed.
Repeat Step 3 to add multiple IP addresses to your whitelist.
4.6.1.3 Connecting Signage to platform
Connect the Signage to the platform. Then you can use the platform to
send programs.
To use the platform to send programs, stop playing programs from the
USB drive rst.
Preparation
• YourSignageandtheplatformhavebeenconnectedtoeachother.
ToconnectSignagetonetwork,see“4.6.1.2.1ConnectingSignageto
Network.”
• Ensuretheplatform’sIPaddresshasbeenaddedtoyourwhitelistif
youhaveenabledit.Tocongurewhitelist,see“4.6.1.2.2Conguring
Whitelist.”
Procedure
Step 1 In main menu, click Network Release.
The Platform Address interface is displayed. See Figure 4-9.
Figure 4-9 The platform address interface
Step 2 Type the platform’s IP address or domain name.
Step 3 Click OK.
Step 4 Receive programs from the platform.
4.6.2 Displaying Programs from USB Drive
4.6.2.1 Releasing Programs by General Templates
4.6.2.1.1 Quick Play
Use the given templates to quickly release information.
Preparation
You have inserted your USB into the Signage. You need to previously
prepare images or videos in your USB and you must save them under
a le named after “USBPLAY.”
Procedure
Step 1 In the main menu, select Local Release > General > Quick
Play.
The Quick Play interface is displayed. See Figure 4-10.
Figure 4-10 The quick play interface
Step 2 Select a template.
The system will display images & videos information according to their
layout in the template. And, an image is displayed for 10 seconds by
default and a video to the end.
4.6.2.1.2 Customized Play
Dene your own templates to release information.
Step 1 In the main menu, select Local Release > General >
Customized Play.
The Customized Play interface is displayed. See Figure 4-11.
