NOTE
Installing the Wall Mount Plate
This monitor meets the specifications for the wall
mount plate or other compatible devices.
1Place the screen face down. To protect the
screen from scratches, cover the surface with a
soft cloth.
2Place the wall mount plate onto the monitor
and align it with the screw holes.
3Tighten the four screws to fix the plate to the
monitor using a screwdriver.
Installing on the Wall
Install the monitor at least 100 mm away from the
wall and leave about 100 mm of space at each
side of the monitor to ensure sufficient ventilation.
Detailed installation instructions can be obtained
from your local retail store. Alternatively, please
refer to the manual for how to install and set up a
tilting wall mounting bracket.
1If you use screws longer than the standard
length, it may damage the inside of the
product.
2A non-VESA standard screw may damage
the product and cause the monitor to fall.
LG Electronics is not liable for any accidents
relating to the use of non-standard screws.
Wall Mount (A x B) 100 x 100
Screw specifications M4 x L10
Number of screws
required
4
Wall Mount Plate
(Optional)
RW120
yThe wall mount plate is sold separately.
yFor more information on installation, refer to
the wall mount plate's installation guide.
yBe careful not to apply too much force while
mounting the wall mount plate as it may
cause damage to the screen.
To install the monitor to a wall, attach a wall
mounting bracket (optional) to the back of the
monitor.
Make sure that the wall mounting bracket is se-
curely fixed to the monitor and to the wall.
100 mm
100 mm
100 mm
100 mm 100 mm
