Single-Port Long Reach Ethernet over Coaxial Extender User’s Manual
Dahua Single-Port Long Reach Ethernet over Coaxial
Extender User’s Manual
V1.0.3
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

Single-Port Long Reach Ethernet over Coaxial Extender User’s Manual
Important Safeguards and Warnings
Attention:
Please read the following safeguards and warnings carefully before using the product in order to avoid
damages and losses.
Note
Do not expose the device to lampblack, steam or dust. Otherwise it may cause fire or electric shock.
Do not install the device at position exposed to sunlight or in high temperature. Temperature rise in
device may cause fire.
Do not expose the device to humid environment. Otherwise it may cause fire.
The device must be installed on solid and flat surface in order to guarantee safety under load and
earthquake. Otherwise, it may cause device to fall off or turnover.
Do not place the device on carpet or quilt.
Do not block air vent of the device or ventilation around the device. Otherwise, temperature in
device will rise and may cause fire.
Do not place any object on the device.
Do not disassemble the device without professional instruction.
Warning:
Please use battery properly to avoid fire, explosion and other dangers.
Please replace used battery with battery of the same type.
Do not use power line other than the one specified. Please use it properly. Otherwise, it may cause
fire or electric shock.
Special Announcement:
This manual is for reference only.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks are the properties of their respective owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website for more information.
The function of the ITE being investigated to IEC 60950-1 is considered not likely to require
connection to an Ethernet network with outside plant routing, including campus environment.
The installation instructions clearly state that the ITE is to be connected only to PoE networks
without routing to the outside plant.

Single-Port Long Reach Ethernet over Coaxial Extender User’s Manual
Table of Contents
1Product Overview............................................................................................. - 1 -
1.1 Product Introduction .........................................................................................................- 1 -
1.2 Product Features..............................................................................................................- 1 -
1.3 Typical Application............................................................................................................- 1 -
2Device Structure............................................................................................... - 2 -
2.1 Device Panel ....................................................................................................................- 2 -
3Installation Guide ............................................................................................. - 3 -
3.1 Device Installation ............................................................................................................- 3 -
4Appendix 1 PoE Power Supply Specifications (RG59 Coaxial Cable)......... - 4 -

Single-Port Long Reach Ethernet over Coaxial Extender User’s Manual
- 1 -
1 Product Overview
1.1 Product Introduction
Single-Port Long Reach Ethernet over Coaxial Extender is a type of converter from RJ45 to
BNC port, which supports long range power supply transmission via coaxial cable. It provides one BNC
coaxial port and one RJ45 port.
The product is equipped with two transmission modes which are 100Mbps and 10Mbps. It can be
modified according to the transmission distance.
1.2 Product Features
Supports IEEE802.3，IEEE802.3u and IEEE802.3X standards.
Supports IEEE802.3af and IEEE802.3at power supply standards.
Port: 1*RJ45 10/100Mbps, 1*BNC.
Supports RG59 coaxial cable: 400m/100Mbps, 1000m/10Mbps.
Supports MDI/MDIX self-adaption.
Supports long range power supply transmission via coaxial cable.
Operating temperature: -30~65℃.
1.3 Typical Application
The product is divided into transmitter (DH-LR1002-1ET) and receiver (DH-LR1002-1EC), which can be
used together with EoC passive converter (LR1002). It owns three types of networking schemes,
which is shown in Figure 1-1. ePoE switch or ePoE IPC means the specific switch or IPC with the
function of long distance.
Figure 1-1

Single-Port Long Reach Ethernet over Coaxial Extender User’s Manual
- 2 -
2 Device Structure
2.1 Device Panel
The device panel is shown in Figure 2-1 (DH-LR1002-1ET) and Figure 2-2 (DH-LR1002-1EC).
Figure 2-1
Figure 2-2
Please refer to Table 2-1 for more details.
SN
Name
Note
1
PoE OUT
PoE output port
2
PoE IN
PoE input port
3
Link
BNC port Link indicator light
E100: On for 3 seconds, off for 1 second
E10: On for 1 second, off for 1 second
4
PWR
Power indicator light
5
Long Reach
Coaxial cable port
Table 2-1

Single-Port Long Reach Ethernet over Coaxial Extender User’s Manual
- 3 -
3 Installation Guide
3.1 Device Installation
Single-Port Long Reach Ethernet over Coaxial Extender supports two installation modes. It can be
installed into the junction box or it can support DIN rail mount.
Please refer to Figure 3-1 for the installation inside junction box.
Figure 3-1
Please refer to Figure 3-2 for DIN rail mount.
Figure 3-2

Single-Port Long Reach Ethernet over Coaxial Extender User’s Manual
- 4 -
4 Appendix 1 PoE Power Supply Specifications (RG59
Coaxial Cable)
Cable Length
(m)
Communication
Bandwidth (Mbps)
PoE Max Load
Capacity (W)
Network Operating
Mode
100
100
21
E100
200
100
15
E100
300
100
11
E100
400
100
9
E100
500
10
7
E10
800
10
5
E10
1000
10
4
E10
ePoE switch supply voltage 48V.
RG-59, max. DC resistance < 5Ω/100m.
Caution: The load capacity can be applied to networking scheme 3. Cable length means
the total wire length from switch to transmitter (including network cable and coaxial cable).
It can use max. 2m network cable to connection transmitter to IPC.
100
100
25.5
E100
200
100
24
E100
300
100
19
E100
400
100
16
E100
500
10
13
E10
800
10
8
E10
1000
10
6
E10
ePoE switch supply voltage 53V.
RG-59, max. DC resistance < 5Ω/100m.
Caution: The load capacity can be applied to networking scheme 3. Cable length means
the total wire length from switch to transmitter (including network cable and coaxial cable).
It can use max. 2m network cable to connection transmitter to IPC.
Note
This user’s manual is for reference only.
Slight difference may be found in user interface.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks are the properties of their respective owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website for more information.
