VTOB108
Installation Step
Step 1. Install metal bracket into the groove on wall. At spot 1 fasten screw (ST3×18 Cross
recessed countersunk head tail tapping screws --- galvanizing white), and fix metal
bracket on wall. See Figure 1
Step 2. Align the device on metal bracket according to screw hole. At spot 2 fasten screw (M3×8
Cross recessed countersunk head tail machine screws --- galvanizing white), and fix
device on metal bracket. See Figure 2
Figure 1 Figure 2
