Dahua EEC300D8-N1 User manual

Data Collection Station
Quick Start Guide
V1.0.1

I
Foreword
Safety Instructions
The following categorized signal words with defined meaning might appear in the manual.
Signal Words Meaning
DANGER
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, lower performance, or unpredictable
result.
TIPS Provides methods to help you solve a problem or save you time.
NOTE
Provides additional information as the emphasis and supplement to
the text.
Revision History
Version Revision Content Release Time
V1.0.1 Updated "1.1 Introduction." May 2021
V1.0.0 First release. March 2021

II
Important Safeguards and Warnings
This chapter describes the contents covering proper handling of the Data Collection Station
(hereafter refer to as “the Station”), hazard prevention, and prevention of property damage. Read
these contents carefully before using the Station, comply with them when using, and keep the
manual well for future reference.
Operation Requirement
●Do not place or install the Station in a place exposed to sunlight or near the heat source.
●Keep the Station away from dampness, dust or soot.
●Keep the Station installed horizontally on the stable place to prevent it from falling.
●Do not drop or splash liquid onto the Station, and make sure that there is no object filled with
liquid on the Station to prevent liquid from flowing into the Station.
●Install the Station in a well-ventilated place, and do not block the ventilation of the Scanner.
●Operate the Station within the rated range of power input and output.
●Do not disassemble the Station.
●Transport, use and store the Station under the allowed humidity and temperature conditions.
Electrical Safety
●Always replace with the same type of batteries.
●Use the recommended power cables in the region and conform to the rated power specification.
●Use the power adapter provided with the Station; otherwise, it might result in people injury and
device damage.
●The power source shall conform to the requirement of the Safety Extra Low Voltage (SELV)
standard, and supply power with rated voltage which conforms to Limited Power Source
requirement according to IEC60950-1. Please note that the power supply requirement is subject
to the device label.
●Connect the Station (I-type structure) to the power socket with protective earthing.
●The appliance coupler is a disconnection device. When using the coupler, keep the angle for easy
operation.

III
Table of Contents
Foreword............................................................................................................................................................ I
Important Safeguards and Warnings.............................................................................................................. II
1 Overview........................................................................................................................................................ 1
Introduction................................................................................................................................................................................. 11.1
Product Appearance................................................................................................................................................................. 21.2
1.2.1 Control Module.............................................................................................................................................................. 2
1.2.2 Appearance of Data Collection Modules............................................................................................................. 4
Description of Buttons ............................................................................................................................................................. 51.3
Power on........................................................................................................................................................................................ 61.4
Device Connection.................................................................................................................................................................... 61.5
1.5.1 Connecting Control Module and Data Collection Module ........................................................................... 6
1.5.2 Connecting Body Camera and Data Collection Module ................................................................................ 6
2 HDD Installation .......................................................................................................................................... 10
3 Configuration and Operation ..................................................................................................................... 13
File Management .....................................................................................................................................................................143.1
3.1.1 File Collection...............................................................................................................................................................14
3.1.2 Viewing Files .................................................................................................................................................................14
User ...............................................................................................................................................................................................143.2
3.2.1 User Management......................................................................................................................................................14
3.2.2 Adding Enforcer...........................................................................................................................................................16
3.2.3 Resetting Password....................................................................................................................................................16
Cybersecurity Recommendations ............................................................................................. 18Appendix 1

1
1Overview
Introduction1.1
Working with body camera, the Station can acquire the data of body cameras and charge them. The
Station can auto recognize and connect the connected body camera through the USB port. Working
with Portable Mobile Center Platform, the Station can authorize the body camera, auto acquire the
electronic evidence (video, audio, and snapshot). The Station contains control module and data
collection module. One control module can support 4 data collection modules at most. It is featured
with:
Recharge and collect data from maximum 32 body cameras at the same time
Automatically or manually upgrade body cameras.
Automatically create archive and then save the collected electronic data.
Automatically upload the evidence to FTP or Portable Mobile Center Platform.
Automatically synchronize time.
When there are more than 1 data collection modules, the Station will collect data from the body
camera in the fixed docks of each data collection module in priority.
You can search, edit, transcode, play back, view, delete and manage all the data in the Station.

2
Product Appearance1.2
1.2.1 Control Module
Front panel and rear panelFigure 1-1

3
Side panelFigure 1-2
Table 1-1 Appearance description
No. Name Description
1 Touch screen 13.3-inch touch screen.
2 Speaker Audio output.
3 Fingerprint sensor Adds fingerprint data or unlock by fingerprint.
At most 3 fingerprints can be added for each user.
4 Adjusting board Remove the control module when connecting control module and
data collection modules.
5 Rear cover —
6 White light Provides extra light when recognizing faces.
Provides extra light to the camera in dark condition.
7 Camera Recognizes face information. You can unlock the Station through
face recognition.
8 Axle housing. Connects the control module and data collection modules. One is
on the top, and the other is at the bottom.

4
No. Name Description
9 Connector. Transfers the data from control module and data collection
modules
10 Heat dissipation
hole —
11 Ports Include power input port, USB ports, Ethernet ports, and RS-232
port. For details, see Table 1-2.
1.2.2 Appearance of Data Collection Modules
Appearance of data collection modulesFigure 1-3

5
Put body cameras into docks for data collection. When there are more than 1 data collection
modules, the data of the body cameras in the two docks of the first row will be collected first.
There are two icons below the dock: indicates recharging; indicates collecting data.
When a dock cannot be opened, you can open it with the key.
Description of Buttons1.3
PortsFigure 1-4
Table 1-2 Port description
No. Name Description
1 Power input
Inputs 100 V–240 V AC power for the Station.
After shutting down the Station, the fan will work for a period
to cool the Station.
2 USB ports Connect to USB storage devices (USB2.0 and USB3.0), mouse,
and more.
3 Ethernet
2 Gigabit ports.
When you use two ports at the same time, only one port can
obtain the gateway automatically. For the other Ethernet card,
disable the function of obtaining IP address automatically.
4RS-232 Used for common serial debugging, IP address configuration
and data transmission of transparent serial.

6
Power on1.4
The cover of the Station has static electricity, which might cause electric shock. To avoid electric
shock, make sure the Station is well grounded.
Connect the power cable and network cable.Step 1
Press the power button.Step 2
The whole process will take a period of time. Please be patient.
Device Connection1.5
1.5.1 Connecting Control Module and Data Collection Module
You can connect 4 data collection modules to the control module at most.
For the installation details, see the instructions on the positioning map.
Fix the control module on the wall.Step 1
Stick the positioning map of data collection module on the wall.Step 2
Fix the data collection module according to the instruction on the positioning map.Step 3
1.5.2 Connecting Body Camera and Data Collection Module
After starting the Station, connect body cameras to the Station, and then you can collect data from
body cameras and recharge them.
Make sure that the connection of body cameras and data collection module is proper, and the body
cameras are placed in slots correctly. If the body cameras are not placed in slots properly, the
cameras might drop when docks open, or the docks cannot be opened.
The slots are special for MPT220 body camera by default. If you want to use for MPT210 body camera,
use the separate slot in the accessories package.
Open the dock through the touch screen or the key, and then take out the data cable.Step 1
Do not drag the data cable too harsh. Otherwise, it might result in invalid spring or
loosening port connection!

7
Take out data cable (MPT220 slot)Figure 1-5
Take out data cable (MPT210 slot)Figure 1-6
Connect the data cable to the body camera until the Station pops up connection successfulStep 2
dialog box.

8
Connect device (MPT220 slot)Figure 1-7
Connect device (MPT210 slot)Figure 1-8
After the connection, put the body camera into the dock, and then you can collect data andStep 3
recharge the body camera.
For MPT220 body camera, insert the device into the slot.
For MPT210 body camera, insert the clip into the slot. Only MPT210 body camera with
the latest clip can be inserted into the slot. See Figure 1-8.

9
Data collection (MPT220 slot)Figure 1-9
Data collection (MPT210 slot)Figure 1-10

10
2HDD Installation
You can install six 10T HDDs (hard disk drives).
To avoid insufficient storage space, HDDs larger than 2T are recommended.
To reduce the writing pressure of each HDD, we recommend you to install at least 2 HDDs with
the same capacity for data collection and recharging.
Loosen the screws on the rear cover, and then remove the rear cover.Step 1
Remove rear coverFigure 2-1
Disconnect the cables between main board and HDD plate.Step 2
Loosen cableFigure 2-2
Loosen the four fixed screws on the HDD box, and then take out the box.Step 3

11
Take out HDD boxFigure 2-3
Fix HDDsStep 4
Fix HDDFigure 2-4
Install HDDs. Push the fixed HDDs in the HDD box.Step 5
Install HDDFigure 2-5
Push HDDs in the direction as the HDD port and main board port show.
Fix the HDD box in the chassis.Step 6
Install HDD boxFigure 2-6

12
Connect the cable between main board and HDD plate.Step 7
Fix the cover.Step 8
Fix the coverFigure 2-7

13
3Configuration and Operation
Main interfaceFigure 3-1
Table 3-1 Main interface description
No. Description
1 Unlock the dock by one tap.
2 Alarm. Tap it, and the alarm tune is disabled.

14
No. Description
3 Alarm information display. The red light flashes when there is alarm.
4 External USB storage device. Grey means no USB storage device is connected.
5 View HDD capacity.
6 : Indicates a file is being uploaded; : Indicates no file is being uploaded.
7 Login, logout, restart, shutdown, and editing the user information.
8
indicates collecting data in priority, which can improve the collecting speed of the
corresponding dock.
To enable this function, you need to connect at least two data collection modules. The
function is supported by the two docks of the first row in each data collection module.
9
View update methods of the Station and body cameras.
Click Bind Enforce on the Device Info interface, enter the enforcer name and enforcer
No., click Search, and then select the enforcer that you want to bind.
10 Switch interfaces of data collection modules. It supports 4 interfaces at most.
File Management3.1
3.1.1 File Collection
After collecting data files from body cameras, the Station will upload the files to the platform
according to the configuration in Storage.
3.1.2 Viewing Files
Double-click a file to view the details, and you can do the operations of fast play, slow play, zoom in
or zoom out.
User3.2
Administrator can add user, delete user and edit user permissions as needed.
3.2.1 User Management
Select Setting > Account > User.Step 1

15
User managementFigure 3-2
Click Add to add users.Step 2
You can add faces and fingerprints, and configure user permissions. All permissions are
enabled by default.
Add usersFigure 3-3

16
3.2.2 Adding Enforcer
Select Setting > Account > Enforcer, and then click Add to add users. Enter enforcer department,
enforcer No., enforcer name, password, and confirm password, and add face and fingerprint as
needed.
Adding enforcerFigure 3-4
3.2.3 Resetting Password
Select Setting > Account > Password Reset, and enter the recovery email address and the security
questions.
Table of contents
Popular Data Logger manuals by other brands

Tidal Engineering
Tidal Engineering Synergy Series Technical manual

T&D
T&D TR-5xU Series user manual

Solinst
Solinst LevelVent 5 quick start guide

Douglas Battery
Douglas Battery datatrac Installation and operation manual

Inova
Inova FireFly DR31 Quick reference guide

EAS Electric
EAS Electric EASManager instruction manual
