ITC237-PW1A-IRZ
Installation Manual
V 1.0

1 Overview
1.1 Objective
Standard construction documents for the sales staff, regional technical support,
engineering and construction personnel to ensure the device installed in accordance with
regulatory requirements.
1.2 Scope
The instructions apply to model ITC237-PW1A-IRZ integrated camera to snapshot
the construction commissioning guidance. The camera is suitable for parking
management systems, residential entrance management systems.
1.3 Device Structure
1.3.1 Appearance
ITC237-PW1A-IRZ appearance is shown in Figure 1- 1.
Figure 1- 1
1.3.2 Dimensions
ITC237-PW1A-IRZ dimensions are shown in Figure 1- 2. Unit is mm.

Figure 1- 2
1.3.3 Technical Parameter and Port Wiring
Parameter
Type
Parameter Name
Value
Model
ITC237-PW1A-IRZ
Camera
Sensor Type
1/1.9 inch CMOS
Shutter
1/12.5～1/10000，manual or auto
Min Illumination
0.002Lux/F1.2
（color）,0.0002Lux/F1.2（B/W）
Scan Method
Progressive
Day/Night
IR-CUT
Exposure Mode
Full auto, customize range,
customize
White Balance
Full auto, color temperature range
auto, customize color temperature
HLC
Support
Edge Enhance
Support
Lens
Lens Port
φ14
Focus
4mm~8mm
Aperture
F1.8
Aperture Control
DC drive
Zoom Type
Motorized
Parameter
Image Compression
Standard
JPEG
Image Resolution
1920×1080
Video Compression
Standard
H.264/H.264H/
Video Bit Rate
H.264 rate adjustable
Video Frame Rate
50
Video Resolution
1920×1080

Parameter
Type
Parameter Name
Value
Trigger
Mode
I/O Coil Trigger
Support
Video Detection
Support
Function
White List
Max support 10000 white list
vehicles, may directly link gateway output
Intelligent Recognition
Plate recognition, plate color, vehicle
color, brand recognition
Remote Control
Remote config, control via WEB
OSD Overlay
Support, may customize time,
location, direction, lane no.
Waterproof
Support, video/picture with
watermark parity
Port
Built-in IR Light
Built-in 2 LED IR lights
Network Port
1, 100M/1000M Ethernet port
Alarm Input Port
2-ch, optocoupler input(switch)，for
coil input
Alarm Output
1-ch, relay output, may used to link
gateway
Audio Port
N/A
General
Power Supply
AC 24V
External Frequency
Sync
Support
Consumption
<15W
Work Temperature
﹣30℃～﹢60℃
Protection Level
IP66
Work Humidity
≤95%
Dimensions
94.92mmX94.92mmX272.90mm
Weight
1.4kg
Waterproof group wiring port is shown in Figure 1- 3.

Figure 1- 3
No.
Port Note
Port Function
①
Audio Out
Audio Output Port
Output audio signal（N/A）
②
Audio In
Audio Input
Port
Input audio signal（N/A）
③
-
Network Port
Connect to standard Ethernet
④
ALARM_N
O
Alarm Output
Port
Output alarm signal
ALARM_C
OM
ALARM_IN
1
Alarm Input Port
1
IO input port, max support 2-ch
ALARM_IN
2
Alarm Input
Port 2
ALARM_G
ND
GND
⑤
POWER
Power Port
Input AC24V power

2 Device Installation
2.1 Installation Specifications
2.1.1 Standard Installation
See Figure 2- 1.
Height 1.2 meters
Horizontal distance 4 meters
Snapshot line position
Width ≤3.5 meters
Figure 2- 1
Note:
1. Camera monitoring the scene channel width requirements ≤3.5 m. > 3.5 m, requiring
physical isolation parallel with the camera at 3.5 m spacing, make the passageway to
meet the requirements of ≤3.5 m (Note: Refer to Fout! Verwijzingsbron niet
gevonden.);
2. The camera is mounted on the safety of the island, mounting bracket and channel
boundary spacing should be <0.15 m. > 0.15 m, it will increase the angle of view of
the license plate, the effects of camera algorithm (Note: Refer to Fout!
Verwijzingsbron niet gevonden.).
3. The camera installation height of 1.2 to 1.5 m, 1.2 m recommended;
4. Snapshot camera is mounted on the snapshot line (or coil) pitch (horizontal distance)
from 4 to 6 meters location, recommended 4 m;

5. Scene width adjustment, take a picture of the license plate from 100 to 140 pixels to
identify the best effect.
6. We recommend using a coil to snapshot program.
2.1.2 Before Installation
Many factors affect the camera identification, such as channel width outside the camera
monitoring capabilities, the camera installation point setting unreasonable. These are the
physical factors related vision camera can face up to identify whether the conditions of the
license plate or license plate angle question meets, from a technical level, cannot be
solved. Therefore, in front of the camera installation is a good program, to be
circumvented. The following is a preliminary plan to install cameras Important note:
1. The installation position of the camera in the vehicle into the parking lot should be
planned passage complete turn, straighten the front and then moved back 4 meters
The vehicle has a turning procedure when entering (or exiting) parking lot entrance
channel, when the license plate and the camera is a certain angle, cause the camera
not face license plate or license plate angle is too large, the impact of recognition.
Therefore, the camera should be set up to snapshot the point of complete turn in the
vehicle at the camera front plate. Determine the position of the camera to snapshot
the line, the camera mounting position can be determined by reference to standard
protocols that snapshot the line after 4 meters. See Fout! Verwijzingsbron niet
gevonden..

C
Right turn
Left turn
Yellow section is
vehicle’s continuous
turning area, do not
set snapshot line
here!
Entrance Exit
Red line and below are
finished turning area,
plate is upright, you can
draw snapshot line!
Install camera at 4
meters behind
snapshot line
Parking lot entrance/
exit
Figure 2- 2
2. The camera monitor channel width 3.5 meters maximum. Greater than 3.5 m, and
respond channel do physical isolation, to meet the requirements;
3. The camera bracket mounting points and channel boundary of Requirement: The
camera mounting bracket and channel boundary spacing of less than 0.15 m
spacing, as shown in Fout! Verwijzingsbron niet gevonden.:

Entrance channel
Width≤3.5 meters
Camera
bracket
Camera bracket
and lane border
＜1.15 meter
Pedestrian
island
Snapshot coil
Channel is too wide,
make physical isolation
Figure 2- 3
2.2 Coil Cut
2.2.1 Coil Cut Specification
Select coil snapshot scheme system, need to cut coil, see Figure 2- 4.

Figure 2- 4
Note:
1. Coil edge safety distance 30cm;
2. Coil edge depends on lane width;
3. Coil length (vehicle driving direction) 60cm;
4. Coil wind 4 times.
2.2.2 Coil Recommendation
Loop coils are buried beneath the road surface, it is required that it should have good heat
resistance, cold resistance, pull, anti-corrosion performance and flexibility. FVN1.5 ㎡
recommended temperature cables.
2.2.3 Process Requirement
Coil detection system, in order to ensure that the camera is stable coil normal snapshot,
and correct construction process coil is a coil job security. Therefore, make construction
according to process requirements.
Coil cut process is in Figure 2- 5,

Figure 2- 5
Note:
1. Grooving width requirement of 30 ~ 50mm width, depth requirement 8mm;
2. When cutting, the four corners should be cut 45 ° chamfer, the coil wire protection;
3. Before the assembly line, to deal with grooving to clean up, to ensure that no debris
trough; if cleaned with water trough, the need for air-drying operation blow tank, to be
completely dry before winding groove;
4. Wrap, tap to be reserved well refuges hand in hand well set aside a certain redundancy;
5. Wind clockwise order around 5 bar. When wound, blunt-by-turn required the cable
compaction;
6. A coil to the cable hand hole section leads to two lines to be twisted, requires at least 20
pair / m density;
7. Upon completion of the winding, the need to refill the survey line groove. The main test
parameters off and the coil inductance inductance values required to be between 80 ~
1000uH;
8. Recommend to use about 80 ℃asphalt fill slots. Avoid foaming when filling slots drip
hollow, uneven, etc., affect the performance and appearance. After the asphalt dried, the
excess part of the road leveled.
2.3 AUX Installation Bracket
ITC237-PW1A-IRZ model of camera, can be used for docking two stents, one for
companies supporting pole bracket, the other is widely used in engineering all-direction
bracket. According to user matching stand is different, their installations vary greatly, the
following camera supports the installation of two stents described in detail.

2.3.1 Standard Bracket Installation
Standard bracket and pedestal are shown in Figure 2- 6.
Figure 2- 6
2.3.2 All-direction Bracket Matching
Project common all-direction bracket has two models of WS2790 and 8081, both are
identical interfaces. The following uses 8081 stand as an example, this project uses
bracket installation method:
1. Adopts all-direction joint to install, must used all-direction bracket, see Figure 2- 7.

Figure 2- 7
2. The whole effect after installation. See Figure 2- 8.
Figure 2- 8
3. Bracket dimensions are shown in Figure 2- 9.
Camera Bracket
Figure 2- 9

3 Common Application and Wiring Reference
3.1 Camera Common Application
Figure 3- 1
Note:
1. In above figure, dotted line is an optional device connected to device, the actual
project have this device, determined according to the user program.
2. In above figure, the two vehicle inspection device, the camera supports IO signal
vehicle inspection device access;
3.2 Wiring Reference
Device connected to camera are vehicle detector, gateway. Network connects to platform at
rear. See Figure 3- 2.

Figure 3- 2
3.3 Camera Wiring Network Waterproof
When you wire camera, you shall make sure network is water-proof, prevent crystal head
copper aging.
The accessories bag provides network water-proof joint, see Figure 3- 3.
Figure 3- 3

Note:
➢Take out network waterproof head from random accessories bag;
➢Insert network head in to waterproof joint;
➢Make crystal head, test cable;
➢Match cable, fasten waterproof joint.
4 System Debugging
4.1 Device Login
Access camera via IE, on WEB you can browse and set camera real-time data and
parameter, default IP address is 192.168.1.108. If you use IP to login device for the first
time, you shall notice the following.
4.1.1 IE Browser Recommendation
Windows XP OS requires IE 7 or higher version. Windows 7 OS requires IE 7 to 9
versions.
Note:
If you use a high version of IE, you may encounter abnormalities in login and display.
4.1.2 Download Browser Control Unit
Initial use IE browser to log device can not log situation is likely to arise, it is because the
computer IE browser internet options, security protection level is set too high to prevent
the camera caused WEB control download, so Adjustment IE browser security settings.
Open IE browser, in the Properties → Security → Custom Level option can be browser
security level adjustment, this will ActiveX control / plug-in option is set to Enable, you can
successfully download controls.
To adjust IE Browser security level:

1. Right-click on Internet option of the IE browser's Properties or click on the IE page
tool, open Internet Properties / Options window, select the Security tab, click Custom
Level parameter button, see Figure 4- 1.
Figure 4- 1
2. The ActiveX controls and plug-related options are set to enable;
3. Click Apply to complete the IE browser security level configuration.
4.1.3 Browser Notification
Company facilities are using IE to access, log in to different procedure is recommended
before the camera, remove the PC version of original download WEB controls and
browser history, to avoid conflict.
To remove controls and IE browser history data:
Delete browsing history IE browser: Right-IE browser → Properties →General →
delete browser history →Delete All;
Delete computer WEB control methods: My computer → C disk → Program Files →
Remove webrec folder.
Note: WEB control shall be closed before deleting the browser.

4.1.4 WEB Page Intro
IE after login camera, WEB page display, see Figure 4- 2, please refer WEB Operation
Manual for page functions.
Figure 4- 2
4.2 Scene Requirements
See Figure 4- 3.

Figure 4- 3
Note:
View of all channels on the right, leaving the left side of excess;
Trigger lines (snapshot) in the image at 1/3;
When adjust the camera angle, try to make sure the license plate level.
4.3 Camera General Parameter Note
The camera in the parking lot entrances and exits the application, common (possibly
modified) are snapshot, intelligent business, white list, camera attributes and Network
parameters, related parameters are described below.
4.3.1 Snapshot
Intelligent traffic all relevant parameters are associated with intelligent transportation
business, its highly targeted, unable to cope with the global default parameters.
Therefore, some parameters need to be adjusted according to project requirements.
4.3.1.1 Lane Property
Lane Properties page, the most commonly used is the enable snapshot and Event
Configuration Advanced Configuration two parameters. enable snapshot can be selected
as the machine monitoring capability, maximum support open 5-lane snapshot, the default

one lane open. Advanced Configuration parameter event configuration, it can perform
snapshot direction (the direction of the camera relative to the vehicle) the selection,
provide forward, reverse two-way three directions, default bidirectional.
See Figure 4- 4.
Figure 4- 4
4.3.1.2 Snapshot
Snapshot page, often uses OSD parameter. OSD parameter is overlaid information after the camera snapped
pictures of parameters, selected according to the actual situation of the project, see Figure 4- 5.
Figure 4- 5
