Daikin 2MXS-N Series Dimension Guide

EDUS121503A
2/3/4MXS-N Series
- Heat Pump -
Multi-Split Type Air Conditioners

EDUS121503A
Multi-Split Type Air Conditioners 2/3/4MXS-N Series i
Part 1 Multi-Split Type Air Conditioners 2/3/4MXS-N Series...........1
1. Power Supply ..............................................................................................3
2. Functions.....................................................................................................4
3. Specifications ............................................................................................11
3.1 Indoor Unit.................................................................................................. 11
3.2 Outdoor Unit ............................................................................................... 18
3.3 Combination Capacity: 2MXS18NMVJU .................................................... 21
3.4 Combination Capacity: 3MXS24NMVJU .................................................... 25
3.5 Combination Capacity: 4MXS36NMVJU .................................................... 37
4. Dimensions ...............................................................................................73
4.1 Indoor Unit.................................................................................................. 73
4.2 Outdoor Unit ............................................................................................... 81
5. Wiring Diagrams........................................................................................83
5.1 Indoor Unit.................................................................................................. 83
5.2 Outdoor Unit ............................................................................................... 86
6. Piping Diagrams........................................................................................88
6.1 Indoor Unit.................................................................................................. 88
6.2 Outdoor Unit ............................................................................................... 91
7. Capacity Tables ........................................................................................93
7.1 2MXS18NMVJU ......................................................................................... 93
7.2 3MXS24NMVJU ....................................................................................... 102
7.3 4MXS36NMVJU ....................................................................................... 148
7.4 Capacity Correction Factor by the Length of Refrigerant Piping
(Reference) .............................................................................................. 288
8. Operation Limit........................................................................................289
9. Fan Characteristics .................................................................................290
10.Sound Level ............................................................................................292
10.1 Measuring Location .................................................................................. 292
10.2 Indoor Unit................................................................................................ 293
10.3 Outdoor Unit ............................................................................................. 298
11.Electric Characteristics............................................................................299
Part 2 Installation Manual ...........................................................301
1. CTXG Series ...........................................................................................302
1.1 CTXG09/12/18QVJUW(S)........................................................................ 302
2. CTXS, FTXS, CDXS, FDXS Series.........................................................316
2.1 Safety Considerations .............................................................................. 316
2.2 CTXS07LVJU, FTXS09/12LVJU .............................................................. 318
2.3 FTXS15/18/24LVJU ................................................................................. 329
2.4 FDXS09/12LVJU, CDXS15/18/24LVJU ................................................... 339
3. FVXS Series............................................................................................350
3.1 FVXS09/12/15/18NVJU............................................................................ 350
4. FFQ Series..............................................................................................367
4.1 FFQ09/12/15Q2VJU................................................................................. 367
4.2 <BYFQ60B3W1> Decoration Panel ......................................................... 387

EDUS121503A
ii Multi-Split Type Air Conditioners 2/3/4MXS-N Series
4.3 <BYFQ60C2W1W(S)> Decoration Panel................................................. 390
4.4 <BRC1E73> Wired Remote Controller..................................................... 393
4.5 <BRC082A41W, BRC082A42W(S)> Wireless Remote Controller........... 413
5. Outdoor Unit............................................................................................420
5.1 2MXS18NMVJU, 3MXS24NMVJU, 4MXS36NMVJU............................... 420
Part 3 Operation Manual..............................................................439
1. CTXG, CTXS, FTXS, CDXS, FDXS, FVXS Series .................................440
1.1 Manual Contents and Reference Page .................................................... 440
1.2 Safety Considerations .............................................................................. 441
1.3 Names of Parts......................................................................................... 443
1.4 Preparation before Operation................................................................... 459
1.5 AUTO · DRY · COOL · HEAT · FAN Operation ........................................ 463
1.6 Adjusting the Airflow Direction and Rate .................................................. 466
1.7 COMFORT AIRFLOW / INTELLIGENT EYE Operation........................... 476
1.8 POWERFUL Operation ............................................................................ 481
1.9 POWERFUL / ECONO / OUTDOOR UNIT QUIET Operation ................. 482
1.10 ECONO / OUTDOOR UNIT QUIET Operation......................................... 484
1.11 OUTDOOR UNIT QUIET Operation......................................................... 485
1.12 ECONO Operation ................................................................................... 486
1.13 TIMER Operation ..................................................................................... 487
1.14 WEEKLY TIMER Operation ..................................................................... 491
1.15 Note for Multi System ............................................................................... 503
1.16 Care and Cleaning ................................................................................... 505
1.17 Troubleshooting........................................................................................ 521
1.18 Quick Reference....................................................................................... 537
2. FFQ Series..............................................................................................538
2.1 With <BRC1E73> Wired Remote Controller ............................................ 546
2.2 With <BRC082A41W, BRC082A42W(S)>
Wireless Remote Controller ..................................................................... 596
Part 4 Options ..............................................................................605
1. Option List ...............................................................................................606
1.1 Indoor Unit................................................................................................ 606
1.2 Outdoor Unit ............................................................................................. 608
2. Control Devices.......................................................................................609
2.1 <BRP072A43> Wireless LAN Connection Adaptor.................................. 609
2.2 <BRC944B2> Wired Remote Controller................................................... 617
2.3 <KRP413AB1S> Wiring Adaptor for Timer Clock /
Remote Controller .................................................................................... 631
2.4 <KRP928BB2S> Interface Adaptor for DIII-NET
(Residential Air Conditioner) .................................................................... 635
2.5 <KRP1C75> Adaptor for Wiring ............................................................... 638
2.6 <KRP4A74> Wiring Adaptor for Electrical Appendices ............................ 639
2.7 <KRP1BA101> Installation Box for Adaptor PCB .................................... 640
2.8 <KRCS01-4B> Remote Sensor................................................................ 642

EDUS121503A
Multi-Split Type Air Conditioners 2/3/4MXS-N Series iii
3. Options for Indoor Unit ............................................................................645
3.1 <KDT25N32, KDT25N50> Insulation Kit for High Humidity ..................... 645
3.2 <BRYQ60A2W(S)> Sensor Kit................................................................. 646
3.3 <KDBQ44BA60A> Panel Spacer ............................................................. 648
3.4 <KDDQ44XA60> Fresh Air Intake Kit ...................................................... 650
4. Options for Outdoor Unit .........................................................................652
4.1 <KPW063A4> Air Direction Adjustment Grille.......................................... 652
4.2 <KKG063A42> Back Protection Wire Net ................................................ 654
4.3 <KKG063A43> Side Protection Wire Net................................................. 655

EDUS121503A
iv Multi-Split Type Air Conditioners 2/3/4MXS-N Series

EDUS121503A
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 1
1
Part 1
Multi-Split Type
Air Conditioners
2/3/4MXS-N Series
1. Power Supply ..............................................................................................3
2. Functions.....................................................................................................4
3. Specifications ............................................................................................11
3.1 Indoor Unit.................................................................................................. 11
3.2 Outdoor Unit ............................................................................................... 18
3.3 Combination Capacity: 2MXS18NMVJU .................................................... 21
3.4 Combination Capacity: 3MXS24NMVJU .................................................... 25
3.5 Combination Capacity: 4MXS36NMVJU .................................................... 37
4. Dimensions ...............................................................................................73
4.1 Indoor Unit.................................................................................................. 73
4.2 Outdoor Unit ............................................................................................... 81
5. Wiring Diagrams........................................................................................83
5.1 Indoor Unit.................................................................................................. 83
5.2 Outdoor Unit ............................................................................................... 86
6. Piping Diagrams........................................................................................88
6.1 Indoor Unit.................................................................................................. 88
6.2 Outdoor Unit ............................................................................................... 91
CTXG09QVJUW
CTXG09QVJUS
CTXG12QVJUW
CTXG12QVJUS
CTXG18QVJUW
CTXG18QVJUS
CTXS07LVJU
FTXS09LVJU
FTXS12LVJU
FTXS15LVJU
FTXS18LVJU
FTXS24LVJU
FDXS09LVJU
FDXS12LVJU
CDXS15LVJU
CDXS18LVJU
CDXS24LVJU
FVXS09NVJU
FVXS12NVJU
FVXS15NVJU
FVXS18NVJU
FFQ09Q2VJU
FFQ12Q2VJU
FFQ15Q2VJU
2MXS18NMVJU
3MXS24NMVJU
4MXS36NMVJU

EDUS121503A
2Multi-Split Type Air Conditioners 2/3/4MXS-N Series
7. Capacity Tables ........................................................................................93
7.1 2MXS18NMVJU ......................................................................................... 93
7.2 3MXS24NMVJU ....................................................................................... 102
7.3 4MXS36NMVJU ....................................................................................... 148
7.4 Capacity Correction Factor by the Length of Refrigerant Piping
(Reference) .............................................................................................. 288
8. Operation Limit........................................................................................289
9. Fan Characteristics .................................................................................290
10.Sound Level ............................................................................................292
10.1 Measuring Location .................................................................................. 292
10.2 Indoor Unit................................................................................................ 293
10.3 Outdoor Unit ............................................................................................. 298
11.Electric Characteristics............................................................................299

EDUS121503A Power Supply
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 3
1
1. Power Supply
Note: Power Supply Intake ; Outdoor Unit
Indoor Unit Outdoor Unit Power Supply
CTXG, CTXS, FTXS Series CTXG09QVJUW 2MXS18NMVJU
3MXS24NMVJU
4MXS36NMVJU
1 phase, 208 - 230 V, 60 Hz
CTXG09QVJUS
CTXG12QVJUW
CTXG12QVJUS
CTXG18QVJUW
CTXG18QVJUS
CTXS07LVJU
FTXS09LVJU
FTXS12LVJU
FTXS15LVJU
FTXS18LVJU
FTXS24LVJU
CDXS, FDXS Series FDXS09LVJU
FDXS12LVJU
CDXS15LVJU
CDXS18LVJU
CDXS24LVJU
FVXS Series FVXS09NVJU
FVXS12NVJU
FVXS15NVJU
FVXS18NVJU
FFQ Series FFQ09Q2VJU
FFQ12Q2VJU
FFQ15Q2VJU

Functions EDUS121503A
4Multi-Split Type Air Conditioners 2/3/4MXS-N Series
2. Functions
Category Functions
CTXG09/12/18QVJUW(S)
Category Functions
CTXG09/12/18QVJUW(S)
Basic
Functions
Inverter (with inverter power control) zHealth &
Cleanliness
Air-purifying filter —
Operation limit for cooling — Photocatalytic deodorizing filter —
Operation limit for heating — Air-purifying filter with photocatalytic
deodorizing function —
PAM control —
Compressor Oval scroll compressor — Titanium apatite photocatalytic
air-purifying filter (option) z
Swing compressor —
Rotary compressor — Longlife filter (option) —
Reluctance DC motor — Air filter (prefilter) z
Comfortable
Airflow
Power-airflow flap (horizontal blade) — Wipe-clean flat panel z
Power-airflow dual flaps zWashable grille —
Power-airflow diffuser — Filter cleaning indicator —
Wide-angle louvers (vertical blades) zGood-sleep cooling operation —
Auto-swing (up and down) zTimer WEEKLY TIMER operation z
Auto-swing (right and left) z24-hour ON/OFF TIMER z
3-D airflow z72-hour ON/OFF TIMER —
COMFORT AIRFLOW operation zNIGHT SET mode z
Comfort
Control
Auto fan speed zWorry Free
(Reliability &
Durability)
Auto-restart (after power failure) z
Indoor unit quiet operation zSelf-diagnosis (R/C, LED) z
NIGHT QUIET mode (automatic) — Wiring error check function —
OUTDOOR UNIT QUIET operation (manual) zAnti-corrosion treatment of outdoor heat
exchanger —
INTELLIGENT EYE operation —
2-area INTELLIGENT EYE operation zFlexibility Multi-split/split type compatible indoor unit —
Quick warming function — Flexible power supply correspondence —
Hot-start function zHigh ceiling application —
Automatic defrosting — Chargeless —
Operation Automatic operation zEither side drain (right or left) z
Program dry function zPower selection —
Fan only z°F/°C changeover R/C temperature display
(factory setting: °F) z
Lifestyle
Convenience
New POWERFUL operation (non-inverter) —
Inverter POWERFUL operation zRemote
Control Remote control adaptor
(normal open pulse contact) (option) z
Priority-room setting —
COOL/HEAT mode lock — Remote control adaptor
(normal open contact) (option) z
HOME LEAVE operation —
ECONO operation zDIII-NET compatible (adaptor) (option) z
Indoor unit ON/OFF button zWireless LAN connection (option) z
Signal receiving sign zRemote
Controller
Wireless z
R/C with back light zWired (option) z
Temperature display —
Note: z: Available
— : Not available

EDUS121503A Functions
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 5
1
Category Functions
CTXS07LVJU
Category Functions
CTXS07LVJU
Basic
Functions
Inverter (with inverter power control) zHealth &
Cleanliness
Air-purifying filter —
Operation limit for cooling — Photocatalytic deodorizing filter —
Operation limit for heating — Air-purifying filter with photocatalytic
deodorizing function —
PAM control —
Compressor Oval scroll compressor — Titanium apatite photocatalytic
air-purifying filter z
Swing compressor —
Rotary compressor — Longlife filter (option) —
Reluctance DC motor — Air filter (prefilter) z
Comfortable
Airflow
Power-airflow flap (horizontal blade) — Wipe-clean flat panel z
Power-airflow dual flaps zWashable grille —
Power-airflow diffuser — Filter cleaning indicator —
Wide-angle louvers (vertical blades) zGood-sleep cooling operation —
Auto-swing (up and down) zTimer WEEKLY TIMER operation z
Auto-swing (right and left) z24-hour ON/OFF TIMER z
3-D airflow z72-hour ON/OFF TIMER —
COMFORT AIRFLOW operation zNIGHT SET mode z
Comfort
Control
Auto fan speed zWorry Free
(Reliability &
Durability)
Auto-restart (after power failure) z
Indoor unit quiet operation zSelf-diagnosis (R/C, LED) z
NIGHT QUIET mode (automatic) — Wiring error check function —
OUTDOOR UNIT QUIET operation (manual) zAnti-corrosion treatment of outdoor heat
exchanger —
INTELLIGENT EYE operation z
2-area INTELLIGENT EYE operation — Flexibility Multi-split/split type compatible indoor unit —
Quick warming function — Flexible power supply correspondence —
Hot-start function zHigh ceiling application —
Automatic defrosting — Chargeless —
Operation Automatic operation zEither side drain (right or left) z
Program dry function zPower selection —
Fan only z°F/°C changeover R/C temperature display
(factory setting: °F) z
Lifestyle
Convenience
New POWERFUL operation (non-inverter) —
Inverter POWERFUL operation zRemote
Control Remote control adaptor
(normal open pulse contact) (option) z
Priority-room setting —
COOL/HEAT mode lock — Remote control adaptor
(normal open contact) (option) z
HOME LEAVE operation —
ECONO operation zDIII-NET compatible (adaptor) (option) z
Indoor unit ON/OFF button zWireless LAN connection (option) —
Signal receiving sign zRemote
Controller
Wireless z
R/C with back light zWired (option) z
Temperature display —
Note: z: Available
— : Not available

Functions EDUS121503A
6Multi-Split Type Air Conditioners 2/3/4MXS-N Series
Category Functions
FTXS09/12LVJU FTXS15/18/24LVJU
Category Functions
FTXS09/12LVJU FTXS15/18/24LVJU
Basic
Functions
Inverter (with inverter power control) zzHealth &
Cleanliness
Air-purifying filter — —
Operation limit for cooling — — Photocatalytic deodorizing filter — —
Operation limit for heating — — Air-purifying filter with photocatalytic
deodorizing function ——
PAM control — —
Compressor Oval scroll compressor — — Titanium apatite photocatalytic
air-purifying filter zz
Swing compressor — —
Rotary compressor — — Longlife filter (option) — —
Reluctance DC motor — — Air filter (prefilter) zz
Comfortable
Airflow
Power-airflow flap (horizontal blade) — — Wipe-clean flat panel zz
Power-airflow dual flaps zz Washable grille — —
Power-airflow diffuser — — Filter cleaning indicator — —
Wide-angle louvers (vertical blades) zz Good-sleep cooling operation — —
Auto-swing (up and down) zzTimer WEEKLY TIMER operation zz
Auto-swing (right and left) zz 24-hour ON/OFF TIMER zz
3-D airflow zz 72-hour ON/OFF TIMER — —
COMFORT AIRFLOW operation zz NIGHT SET mode zz
Comfort
Control
Auto fan speed zzWorry Free
(Reliability &
Durability)
Auto-restart (after power failure) zz
Indoor unit quiet operation zz Self-diagnosis (R/C, LED) zz
NIGHT QUIET mode (automatic) — — Wiring error check function — —
OUTDOOR UNIT QUIET operation
(manual) zz Anti-corrosion treatment of outdoor heat
exchanger ——
INTELLIGENT EYE operation zzFlexibility Multi-split/split type compatible indoor
unit zz
2-area INTELLIGENT EYE operation — —
Quick warming function — — Flexible power supply correspondence — —
Hot-start function zz High ceiling application — —
Automatic defrosting — — Chargeless — —
Operation Automatic operation zz Either side drain (right or left) zz
Program dry function zz Power selection — —
Fan only zz °F/°C changeover R/C temperature
display (factory setting: °F) zz
Lifestyle
Convenience
New POWERFUL operation
(non-inverter) —— Remote
Control Remote control adaptor
(normal open pulse contact) (option) zz
Inverter POWERFUL operation zz
Priority-room setting — — Remote control adaptor
(normal open contact) (option) zz
COOL/HEAT mode lock — —
HOME LEAVE operation — — DIII-NET compatible (adaptor) (option) zz
ECONO operation zz Wireless LAN connection (option) — —
Indoor unit ON/OFF button zzRemote
Controller
Wireless zz
Signal receiving sign zz Wired (option) zz
R/C with back light zz
Temperature display — —
Note: z: Available
— : Not available

EDUS121503A Functions
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 7
1
Category Functions
FDXS09/12LVJU CDXS15/18/24LVJU
Category Functions
FDXS09/12LVJU CDXS15/18/24LVJU
Basic
Functions
Inverter (with inverter power control) zzHealth &
Cleanliness
Air-purifying filter — —
Operation limit for cooling — — Photocatalytic deodorizing filter — —
Operation limit for heating — — Air-purifying filter with photocatalytic
deodorizing function ——
PAM control — —
Compressor Oval scroll compressor — — Titanium apatite photocatalytic
air-purifying filter ——
Swing compressor — —
Rotary compressor — — Longlife filter (option) — —
Reluctance DC motor — — Air filter (prefilter) zz
Comfortable
Airflow
Power-airflow flap (horizontal blade) — — Wipe-clean flat panel — —
Power-airflow dual flaps — — Washable grille — —
Power-airflow diffuser — — Filter cleaning indicator — —
Wide-angle louvers (vertical blades) — — Good-sleep cooling operation — —
Auto-swing (up and down) — — Timer WEEKLY TIMER operation — —
Auto-swing (right and left) — — 24-hour ON/OFF TIMER zz
3-D airflow — — 72-hour ON/OFF TIMER — —
COMFORT AIRFLOW operation — — NIGHT SET mode zz
Comfort
Control
Auto fan speed zzWorry Free
(Reliability &
Durability)
Auto-restart (after power failure) zz
Indoor unit quiet operation zz Self-diagnosis (R/C, LED) zz
NIGHT QUIET mode (automatic) — — Wiring error check function — —
OUTDOOR UNIT QUIET operation
(manual) zz Anti-corrosion treatment of outdoor heat
exchanger ——
INTELLIGENT EYE operation — — Flexibility Multi-split/split type compatible indoor
unit z—
2-area INTELLIGENT EYE operation — —
Quick warming function — — Flexible power supply correspondence — —
Hot-start function zz High ceiling application — —
Automatic defrosting — — Chargeless — —
Operation Automatic operation zz Either side drain (right or left) — —
Program dry function zz Power selection — —
Fan only zz °F/°C changeover R/C temperature
display (factory setting: °F) zz
Lifestyle
Convenience
New POWERFUL operation
(non-inverter) —— Remote
Control Remote control adaptor
(normal open pulse contact) (option) zz
Inverter POWERFUL operation zz
Priority-room setting — — Remote control adaptor
(normal open contact) (option) zz
COOL/HEAT mode lock — —
HOME LEAVE operation — — DIII-NET compatible (adaptor) (option) zz
ECONO operation zz Wireless LAN connection (option) — —
Indoor unit ON/OFF button zzRemote
Controller
Wireless (option) zz
Signal receiving sign zz Wired (option) zz
R/C with back light zz
Temperature display — —
Note: z: Available
— : Not available

Functions EDUS121503A
8Multi-Split Type Air Conditioners 2/3/4MXS-N Series
Category Functions
FVXS09/12/15/18NVJU
Category Functions
FVXS09/12/15/18NVJU
Basic
Functions
Inverter (with inverter power control) zHealth &
Cleanliness
Air-purifying filter —
Operation limit for cooling — Photocatalytic deodorizing filter —
Operation limit for heating — Air-purifying filter with photocatalytic
deodorizing function —
PAM control —
Compressor Oval scroll compressor — Titanium apatite photocatalytic
air-purifying filter z
Swing compressor —
Rotary compressor — Longlife filter (option) —
Reluctance DC motor — Air filter (prefilter) z
Comfortable
Airflow
Power-airflow flap (horizontal blade) — Wipe-clean flat panel z
Power-airflow dual flaps — Washable grille —
Power-airflow diffuser — Filter cleaning indicator —
Wide-angle louvers (vertical blades) zGood-sleep cooling operation —
Auto-swing (up and down) zTimer WEEKLY TIMER operation z
Auto-swing (right and left) — 24-hour ON/OFF TIMER z
3-D airflow — 72-hour ON/OFF TIMER —
COMFORT AIRFLOW operation — NIGHT SET mode z
Comfort
Control
Auto fan speed zWorry Free
(Reliability &
Durability)
Auto-restart (after power failure) z
Indoor unit quiet operation zSelf-diagnosis (R/C, LED) z
NIGHT QUIET mode (automatic) — Wiring error check function —
OUTDOOR UNIT QUIET operation (manual) zAnti-corrosion treatment of outdoor heat
exchanger —
INTELLIGENT EYE operation —
2-area INTELLIGENT EYE operation — Flexibility Multi-split/split type compatible indoor unit —
Quick warming function — Flexible power supply correspondence —
Hot-start function zHigh ceiling application —
Automatic defrosting — Chargeless —
Operation Automatic operation zEither side drain (right or left) —
Program dry function zPower selection —
Fan only z°F/°C changeover R/C temperature display
(factory setting: °F) z
Lifestyle
Convenience
New POWERFUL operation (non-inverter) —
Inverter POWERFUL operation zRemote
Control Remote control adaptor
(normal open pulse contact) (option) z
Priority-room setting —
COOL/HEAT mode lock — Remote control adaptor
(normal open contact) (option) z
HOME LEAVE operation —
ECONO operation zDIII-NET compatible (adaptor) (option) z
Indoor unit ON/OFF button zWireless LAN connection (option) —
Signal receiving sign zRemote
Controller
Wireless z
R/C with back light zWired (option) —
Temperature display —
Note: z: Available
— : Not available

EDUS121503A Functions
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 9
1
Category Functions
FFQ09/12/15Q2VJU with BYFQ60B3W1 FFQ09/12/15Q2VJU with BYFQ60C2W1W(S)
Category Functions
FFQ09/12/15Q2VJU with BYFQ60B3W1 FFQ09/12/15Q2VJU with BYFQ60C2W1W(S)
Basic
Functions
Inverter (with inverter power control) zzHealth &
Cleanliness
Auto cleaning filter — —
Operation limit for cooling — — Air-purifying filter — —
Operation limit for heating — — Photocatalytic deodorizing filter — —
PAM control — — Air-purifying filter with photocatalytic
deodorizing function ——
Standby electricity saving — —
Compressor Oval scroll compressor — — Titanium apatite photocatalytic
air-purifying filter (option) ——
Swing compressor — —
Rotary compressor — — Longlife filter (option) zz
Reluctance DC motor — — Air filter — —
Comfortable
Airflow
Power-airflow flap (horizontal blade) — — Filter cleaning indicator zz
Power-airflow dual flaps — — Wipe-clean flat panel — —
Power-airflow diffuser — — Washable grille zz
Wide-angle louvers (vertical blades) — — MOLD PROOF operation — —
Auto-swing (up and down) zz Good-sleep cooling operation — —
Auto-swing (right and left) — — Timer Schedule TIMER operation z+1z+1
Individual flap control — z+1 72-hour ON/OFF TIMER z+2z+2
3-D airflow — — Off Timer (power off forget prevention) z+1z+1
COMFORT AIRFLOW operation — — NIGHT SET mode — —
Comfort
Control
Auto fan speed z+1z+1 Worry Free
(Reliability &
Durability)
Auto-restart (after power failure) zz
Indoor unit quiet operation — — Self-diagnosis (R/C, LED) zz
NIGHT QUIET mode (automatic) — — Wiring error check function — —
OUTDOOR UNIT QUIET operation
(manual) —— Anti-corrosion treatment of outdoor heat exchanger ——
Presence and floor sensor (option) — z+1 Flexibility Multi-split/split type compatible indoor
unit zz
Hot-start function zz
Draft prevention zz H/P, C/O compatible indoor unit — —
Automatic defrosting zz Flexible power supply correspondence — —
Operation Automatic operation zz Chargeless — —
Program dry function zz Either side drain (right or left) — —
Fan only zz Power selection — —
Setback function z+1z+1 °F/°C changeover R/C temperature
display (factory setting: °F) z+1z+1
Lifestyle
Convenience
New POWERFUL operation
(non-inverter) —— Remote
Control Remote control adaptor
(normal open pulse contact) (option) ——
Inverter POWERFUL operation — —
Priority-room setting — — Remote control adaptor
(normal open contact) (option) ——
COOL/HEAT mode lock — —
HOME LEAVE operation — — DIII-NET compatible (adaptor) (option) — —
ECONO operation — — Remote
Controller
Wireless (option) zz
Indoor unit ON/OFF button — — Wired (option) zz
Signal receiving sign z+2
+3
z+2
+3
R/C with back light z+1z+1
Note: z: Available
— : Not available
+1: With wired remote controller
+2: With wireless remote controller
+3: Receiving sound only

Functions EDUS121503A
10 Multi-Split Type Air Conditioners 2/3/4MXS-N Series
Category Functions
2MXS18NMVJU 3MXS24NMVJU 4MXS36NMVJU
Category Functions
2MXS18NMVJU 3MXS24NMVJU 4MXS36NMVJU
Basic
Functions
Inverter (with inverter power control) zzHealth &
Cleanliness
Air-purifying filter — —
Operation limit for cooling Refer to
P. 289
Photocatalytic deodorizing filter — —
Operation limit for heating Air-purifying filter with photocatalytic
deodorizing function ——
PAM control zz
Compressor Oval scroll compressor — — Titanium apatite photocatalytic
air-purifying filter ——
Swing compressor zz
Rotary compressor — — Longlife filter (option) — —
Reluctance DC motor zz Air filter (prefilter) — —
Comfortable
Airflow
Power-airflow flap (horizontal blade) — — Wipe-clean flat panel — —
Power-airflow dual flaps — — Washable grille — —
Power-airflow diffuser — — Filter cleaning indicator — —
Wide-angle louvers (vertical blades) — — Good-sleep cooling operation — —
Auto-swing (up and down) — — Timer WEEKLY TIMER operation — —
Auto-swing (right and left) — — 24-hour ON/OFF TIMER — —
3-D airflow — — 72-hour ON/OFF TIMER — —
COMFORT AIRFLOW operation — — NIGHT SET mode — —
Comfort
Control
Auto fan speed — — Worry Free
(Reliability &
Durability)
Auto-restart (after power failure) — —
Indoor unit quiet operation — — Self-diagnosis (R/C, LED) zz
NIGHT QUIET mode (automatic) zz Wiring error check function zz
OUTDOOR UNIT QUIET operation
(manual) zz Anti-corrosion treatment of outdoor heat exchanger zz
INTELLIGENT EYE operation — — Flexibility Multi-split/split type compatible indoor
unit ——
2-area INTELLIGENT EYE operation — —
Quick warming function zz Flexible power supply correspondence — —
Hot-start function — — High ceiling application — —
Automatic defrosting zz
Chargeless
98.4
ft
(30 m)
131.6
ft
(40 m)
Operation Automatic operation — —
Program dry function — —
Fan only — — Either side drain (right or left) — —
Lifestyle
Convenience
New POWERFUL operation
(non-inverter) —— Power selection — —
°F/°C changeover R/C temperature
display (factory setting: °F) —— Inverter POWERFUL operation — —
Priority-room setting zzRemote
Control Remote control adaptor
(normal open pulse contact) (option) ——
COOL/HEAT mode lock zz
HOME LEAVE operation — — Remote control adaptor
(normal open contact) (option) ——
ECONO operation — —
Indoor unit ON/OFF button — — DIII-NET compatible (adaptor) (option) — —
Signal receiving sign — — Wireless LAN connection (option) — —
R/C with back light — — Remote
Controller
Wireless — —
Temperature display — — Wired (option) — —
Note: z: Available
— : Not available

EDUS121503A Specifications
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 11
1
3. Specifications
3.1 Indoor Unit
60 Hz, 208 - 230 V
Notes: 1. +See page 21 ~ 72 “Combination Capacity”.
2. SL: The Quiet fan level of the airflow rate setting.
Model CTXG09QVJUW CTXG09QVJUS
Cooling Heating Cooling Heating
Rated Capacity +9 kBtu/h Class 9 kBtu/h Class
Front Panel Color White Silver
Airflow Rate
H
cfm
(m³/min)
279 (7.9) 367 (10.4) 279 (7.9) 367 (10.4)
M 212 (6.0) 265 (7.5) 212 (6.0) 265 (7.5)
L 162 (4.6) 205 (5.8) 162 (4.6) 205 (5.8)
SL 134 (3.8) 117 (3.3) 134 (3.8) 117 (3.3)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.07 - 0.07 0.13 - 0.12 0.07 - 0.07 0.13 - 0.12
Power Consumption (Rated) W 13 - 13 26 - 26 13 - 13 26 - 26
Power Factor (Rated) % 89.2 - 80.7 96.2 - 94.2 89.2 - 80.7 96.2 - 94.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212)
Packaged Dimensions (H × W × D) in. (mm) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389)
Weight (Mass) Lbs (kg) 27 (12) 27 (12)
Gross Weight (Gross Mass) Lbs (kg) 36 (16) 36 (16)
Sound Pressure
Level H / M / L / SL dB(A) 38 / 32 / 25 / 21 41 / 34 / 28 / 21 38 / 32 / 25 / 21 41 / 34 / 28 / 21
Sound Power Level dB — — — —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4) φ1/4 (φ6.4)
Gas in. (mm) φ3/8 (φ9.5) φ3/8 (φ9.5)
Drain in. (mm) φ11/16 (φ18) φ11/16 (φ18)
Drawing No. 3D105562 3D105565
Model CTXG12QVJUW CTXG12QVJUS
Cooling Heating Cooling Heating
Rated Capacity +12 kBtu/h Class 12 kBtu/h Class
Front Panel Color White Silver
Airflow Rate
H
cfm
(m³/min)
353 (10.0) 420 (11.9) 353 (10.0) 420 (11.9)
M 230 (6.5) 300 (8.5) 230 (6.5) 300 (8.5)
L 162 (4.6) 219 (6.2) 162 (4.6) 219 (6.2)
SL 134 (3.8) 124 (3.5) 134 (3.8) 124 (3.5)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.13 - 0.12 0.19 - 0.17 0.13 - 0.12 0.19 - 0.17
Power Consumption (Rated) W 26 - 26 38 - 38 26 - 26 38 - 38
Power Factor (Rated) % 96.1 - 94.2 96.1 - 97.1 96.1 - 94.2 96.1 - 97.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212)
Packaged Dimensions (H × W × D) in. (mm) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389)
Weight (Mass) Lbs (kg) 27 (12) 27 (12)
Gross Weight (Gross Mass) Lbs (kg) 36 (16) 36 (16)
Sound Pressure
Level H / M / L / SL dB(A) 45 / 34 / 26 / 22 45 / 37 / 29 / 22 45 / 34 / 26 / 22 45 / 37 / 29 / 22
Sound Power Level dB — — — —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4) φ1/4 (φ6.4)
Gas in. (mm) φ3/8 (φ9.5) φ3/8 (φ9.5)
Drain in. (mm) φ11/16 (φ18) φ11/16 (φ18)
Drawing No. 3D105563 3D105566
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3

Specifications EDUS121503A
12 Multi-Split Type Air Conditioners 2/3/4MXS-N Series
60 Hz, 208 - 230 V
Notes: 1. +See page 21 ~ 72 “Combination Capacity”.
2. SL: The Quiet fan level of the airflow rate setting.
Model CTXG18QVJUW CTXG18QVJUS
Cooling Heating Cooling Heating
Rated Capacity +18 kBtu/h Class 18 kBtu/h Class
Front Panel Color White Silver
Airflow Rate
H
cfm
(m³/min)
364 (10.3) 438 (12.4) 364 (10.3) 438 (12.4)
M 286 (8.1) 350 (9.9) 286 (8.1) 350 (9.9)
L 233 (6.6) 265 (7.5) 233 (6.6) 265 (7.5)
SL 219 (6.2) 212 (6) 219 (6.2) 212 (6)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 29 29
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.14 - 0.14 0.21 - 0.21 0.14 - 0.14 0.21 - 0.21
Power Consumption (Rated) W 28 - 28 42 - 42 28 - 28 42 - 42
Power Factor (Rated) % 96.1 - 87.0 96.2 - 87.0 96.1 - 87.0 96.2 - 87.0
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212) 11-15/16 × 39-5/16 × 8-3/8 (303 × 998 × 212)
Packaged Dimensions (H × W × D) in. (mm) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389) 12-11/16 × 43-3/8 × 15-5/16 (322 × 1,101 × 389)
Weight (Mass) Lbs (kg) 27 (12) 27 (12)
Gross Weight (Gross Mass) Lbs (kg) 36 (16) 36 (16)
Sound Pressure
Level H / M / L / SL dB(A) 46 / 40 / 35 / 32 47 / 41 / 35 / 32 46 / 40 / 35 / 32 47 / 41 / 35 / 32
Sound Power Level dB — — — —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4) φ1/4 (φ6.4)
Gas in. (mm) φ1/2 (φ12.7) φ1/2 (φ12.7)
Drain in. (mm) φ11/16 (φ18) φ11/16 (φ18)
Drawing No. 3D105564 3D105567
Model CTXS07LVJU
Cooling Heating
Rated Capacity +7 kBtu/h Class
Front Panel Color White
Airflow Rate
H
cfm
(m³/min)
332 (9.4) 350 (9.9)
M 261 (7.4) 290 (8.2)
L 194 (5.5) 233 (6.6)
SL 145 (4.1) 219 (6.2)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof
Running Current (Rated) A 0.09 - 0.08 0.11 - 0.10
Power Consumption (Rated) W 18 - 18 21 - 21
Power Factor (Rated) % 96.2 - 97.8 91.8 - 91.3
Temperature Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-5/8 × 31-1/2 × 8-7/16 (295 × 800 × 215)
Packaged Dimensions (H × W × D) in. (mm) 10-13/16 × 34-1/4 × 14-7/16 (274 × 870 × 366)
Weight (Mass) Lbs (kg) 20 (9)
Gross Weight (Gross Mass) Lbs (kg) 29 (13)
Sound Pressure
Level H / M / L / SL dB(A) 38 / 32 / 25 / 22 38 / 33 / 28 / 25
Sound Power Level dB 54 54
Heat Insulation Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4)
Gas in. (mm) φ3/8 (φ9.5)
Drain in. (mm) φ5/8 (φ16.0)
Drawing No. 3D075490
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3

EDUS121503A Specifications
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 13
1
60 Hz, 208 - 230 V
Notes: 1. +See page 21 ~ 72 “Combination Capacity”.
2. SL: The Quiet fan level of the airflow rate setting.
Model FTXS09LVJU FTXS12LVJU
Cooling Heating Cooling Heating
Rated Capacity +9 kBtu/h Class 12 kBtu/h Class
Front Panel Color White White
Airflow Rate
H
cfm
(m³/min)
381 (10.8) 420 (11.9) 403 (11.4) 438 (12.4)
M 279 (7.9) 321 (9.1) 307 (8.7) 335 (9.5)
L 194 (5.5) 233 (6.6) 205 (5.8) 240 (6.8)
SL 145 (4.1) 219 (6.2) 155 (4.4) 212 (6.0)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.09 - 0.08 0.11 - 0.10 0.13 - 0.12 0.14 - 0.13
Power Consumption (Rated) W 18 - 18 21 - 21 26 - 26 28 - 28
Power Factor (Rated) % 96.2 - 97.8 91.8 - 91.3 96.2 - 94.2 96.2 - 93.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-5/8 × 31-1/2 × 8-7/16 (295 × 800 × 215) 11-5/8 × 31-1/2 × 8-7/16 (295 × 800 × 215)
Packaged Dimensions (H × W × D) in. (mm) 10-13/16 × 34-1/4 × 14-7/16 (274 × 870 × 366) 10-13/16 × 34-1/4 × 14-7/16 (274 × 870 × 366)
Weight (Mass) Lbs (kg) 20 (9) 22 (10)
Gross Weight (Gross Mass) Lbs (kg) 29 (13) 31 (14)
Sound Pressure
Level H / M / L / SL dB(A) 41 / 33 / 25 / 22 42 / 35 / 28 / 25 45 / 37 / 29 / 23 45 / 39 / 29 / 26
Sound Power Level dB 57 58 61 61
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4) φ1/4 (φ6.4)
Gas in. (mm) φ3/8 (φ9.5) φ3/8 (φ9.5)
Drain in. (mm) φ5/8 (φ16) φ5/8 (φ16)
Drawing No. 3D075491A 3D075492A
Model FTXS15LVJU FTXS18LVJU
Cooling Heating Cooling Heating
Rated Capacity +15 kBtu/h Class 18 kBtu/h Class
Front Panel Color White White
Airflow Rate
H
cfm
(m³/min)
568 (16.1) 593 (16.8) 583 (16.5) 625 (17.7)
M 477 (13.5) 505 (14.3) 484 (13.7) 526 (14.9)
L 385 (10.9) 417 (11.8) 385 (10.9) 431 (12.2)
SL 360 (10.2) 371 (10.5) 360 (10.2) 399 (11.3)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.31 - 0.29 0.31 - 0.29 0.32 - 0.30 0.32 - 0.30
Power Consumption (Rated) W 38 - 38 38 - 38 38 - 38 38 - 38
Power Factor (Rated) % 58.9 - 57.0 58.9 - 57.0 57.1 - 55.1 57.1 - 55.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 13-3/8 × 41-5/16 × 9-3/4 (340 × 1,050 × 248) 13-3/8 × 41-5/16 × 9-3/4 (340 × 1,050 × 248)
Packaged Dimensions (H × W × D) in. (mm) 13 × 45-11/16 × 16-7/8 (331 × 1,160 × 429) 13 × 45-11/16 × 16-7/8 (331 × 1,160 × 429)
Weight (Mass) Lbs (kg) 31 (14) 31 (14)
Gross Weight (Gross Mass) Lbs (kg) 44 (20) 44 (20)
Sound Pressure
Level H / M / L / SL dB(A) 45 / 40 / 35 / 32 43 / 38 / 33 / 30 46 / 41 / 36 / 33 45 / 40 / 35 / 32
Sound Power Level dB 61 59 62 61
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4) φ1/4 (φ6.4)
Gas in. (mm) φ1/2 (φ12.7) φ1/2 (φ12.7)
Drain in. (mm) φ5/8 (φ16) φ5/8 (φ16)
Drawing No. 3D075043A 3D075044A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3

Specifications EDUS121503A
14 Multi-Split Type Air Conditioners 2/3/4MXS-N Series
60 Hz, 208 - 230 V
Notes: 1. +See page 21 ~ 72 “Combination Capacity”.
2. SL: The Quiet fan level of the airflow rate setting.
Model FTXS24LVJU
Cooling Heating
Rated Capacity +24 kBtu/h Class
Front Panel Color White
Airflow Rate
H
cfm
(m³/min)
643 (18.2) 699 (19.8)
M 494 (14.0) 572 (16.2)
L 350 (9.9) 445 (12.6)
SL 328 (9.3) 403 (11.4)
Fan
Type Cross Flow Fan
Motor Output W 48
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof
Running Current (Rated) A 0.57 - 0.51 0.57 - 0.51
Power Consumption (Rated) W 69 - 68 69 - 68
Power Factor (Rated) % 58.2 - 58.0 58.2 - 58.0
Temperature Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 13-3/8 × 41-5/16 × 9-3/4 (340 × 1,050 × 248)
Packaged Dimensions (H × W × D) in. (mm) 13 × 45-11/16 × 16-7/8 (331 × 1,160 × 429)
Weight (Mass) Lbs (kg) 31 (14)
Gross Weight (Gross Mass) Lbs (kg) 46 (21)
Sound Pressure
Level H / M / L / SL dB(A) 51 / 44 / 37 / 34 48 / 42 / 37 / 34
Sound Power Level dB 67 64
Heat Insulation Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4)
Gas in. (mm) φ5/8 (φ15.9)
Drain in. (mm) φ5/8 (φ16)
Drawing No. 3D075045A
Model FDXS09LVJU FDXS12LVJU
Cooling Heating Cooling Heating
Rated Capacity +9 kBtu/h Class 12 kBtu/h Class
External Static Pressure inAq (Pa) 0.12 (30) 0.12 (30)
Airflow Rate
H
cfm
(m³/min)
305 (8.6) 305 (8.6) 305 (8.6) 305 (8.6)
M 280 (7.9) 280 (7.9) 280 (7.9) 280 (7.9)
L 260 (7.4) 260 (7.4) 260 (7.4) 260 (7.4)
SL 235 (6.7) 235 (6.7) 235 (6.7) 235 (6.7)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.58 - 0.52 0.58 - 0.52 0.58 - 0.52 0.58 - 0.52
Power Consumption (Rated) W 72 - 72 72 - 72 72 - 72 72 - 72
Power Factor (Rated) % 59.7 - 60.2 59.7 - 60.2 59.7 - 60.2 59.7 - 60.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 7-7/8 × 27-9/16 × 24-7/16 (200 × 700 × 620) 7-7/8 × 27-9/16 × 24-7/16 (200 × 700 × 620)
Packaged Dimensions (H × W × D) in. (mm) 10-13/16 × 36-5/16 × 30-1/4 (274 × 923 × 768) 10-13/16 × 36-5/16 × 30-1/4 (274 × 923 × 768)
Weight (Mass) Lbs (kg) 47 (21) 47 (21)
Gross Weight (Gross Mass) Lbs (kg) 64 (29) 64 (29)
Sound Pressure
Level H / M / L dB(A) 35 / 33 / 31 35 / 33 / 31 35 / 33 / 31 35 / 33 / 31
Sound Power Level dB 51 51 51 51
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4) φ1/4 (φ6.4)
Gas in. (mm) φ3/8 (φ9.5) φ3/8 (φ9.5)
Drain in. (mm) φ25/32 (φ20) φ25/32 (φ20)
Drawing No. 3D075493 3D075494
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3

EDUS121503A Specifications
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 15
1
60 Hz, 208 - 230 V
Notes: 1. +See page 21 ~ 72 “Combination Capacity”.
2. SL: The Quiet fan level of the airflow rate setting.
3. The operating sound is based on the rear side suction inlet and the external static pressure 0.16 in. H2O (40 Pa).
Operating sound for bottom suction inlet : [operating sound for rear side suction inlet] +5 dB.
However, when installation resulting in lower external static pressure becomes low is carried out,
the operation sound may rise by more than 5 dB.
Model CDXS15LVJU CDXS18LVJU
Cooling Heating Cooling Heating
Rated Capacity +15 kBtu/h Class 18 kBtu/h Class
External Static Pressure inAq (Pa) 0.16 (40) 0.16 (40)
Airflow Rate
H
cfm
(m³/min)
424 (12.0) 424 (12.0) 424 (12.0) 424 (12.0)
M 388 (11.0) 388 (11.0) 388 (11.0) 388 (11.0)
L 353 (10.0) 353 (10.0) 353 (10.0) 353 (10.0)
SL 297 (8.4) 297 (8.4) 297 (8.4) 297 (8.4)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 130 130
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.79 0.79 0.79 0.79
Power Consumption (Rated) W 172 172 172 172
Power Factor (Rated) % 94.4 94.4 94.4 94.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 7-7/8 × 35-7/16 × 24-7/16 (200 × 900 × 620) 7-7/8 × 35-7/16 × 24-7/16 (200 × 900 × 620)
Packaged Dimensions (H × W × D) in. (mm) 10-1/2 × 43-9/16 × 29-9/16 (266 × 1,106 × 751) 10-1/2 × 43-9/16 × 29-9/16 (266 × 1,106 × 751)
Weight (Mass) Lbs (kg) 60 (27) 60 (27)
Gross Weight (Gross Mass) Lbs (kg) 75 (34) 75 (34)
Sound Pressure
Level H / M / L / SL dB(A) 37 / 35 / 33 / 31 37 / 35 / 33 / 31 37 / 35 / 33 / 31 37 / 35 / 33 / 31
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4) φ1/4 (φ6.4)
Gas in. (mm) φ1/2 (φ12.7) φ1/2 (φ12.7)
Drain in. (mm) VP20 (O.D. φ1-1/32 (φ26), I.D. φ25/32 (φ20)) VP20 (O.D. φ1-1/32 (φ26), I.D. φ25/32 (φ20))
Drawing No. C: 3D075721 C: 3D075722
Model CDXS24LVJU
Cooling Heating
Rated Capacity +24 kBtu/h Class
External Static Pressure inAq (Pa) 0.16 (40)
Airflow Rate
H
cfm
(m³/min)
565 (16.0) 565 (16.0)
M 523 (14.8) 523 (14.8)
L 477 (13.5) 477 (13.5)
SL 395 (11.2) 395 (11.2)
Fan
Type Sirocco Fan
Motor Output W 130
Speed Steps 5 Steps, Quiet, Auto
Air Filter Removable, Washable, Mildew Proof
Running Current (Rated) A 0.79 0.79
Power Consumption (Rated) W 160 160
Power Factor (Rated) % 90.3 92.8
Temperature Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 7-7/8 × 43-5/16 × 24-7/16 (200 × 1,100 × 620)
Packaged Dimensions (H × W × D) in. (mm) 10-1/2 × 52-1/16 × 30-1/4 (266 × 1,323 × 768)
Weight (Mass) Lbs (kg) 66 (30)
Gross Weight (Gross Mass) Lbs (kg) 84 (38)
Sound Pressure
Level H / M / L / SL dB(A) 38 / 36 / 34 / 32 38 / 36 / 34 / 32
Heat Insulation Both Liquid and Gas Pipes
Piping
Connections
Liquid in. (mm) φ1/4 (φ6.4)
Gas in. (mm) φ5/8 (φ15.9)
Drain in. (mm) VP20 (O.D. φ1-1/32 (φ26), I.D. φ25/32 (φ20))
Drawing No. 3D080590
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
