Daikin Altherma EKRTCTRL2 User manual

EKRTCTRL1
EKRTCTRL2
EKWHCTRL0
EKWHCTRL1
EKPCBO
USER MANUAL
Daikin Altherma
heat pump convector options

2
DAIKIN EUROPE N.V.
Compliance
We would first of all like to thank you for having chosen one of our products.
We are sure you will be happy with it because it represents the state of the art in the technology of
home air conditioning.
By following the suggestions contained in this manual, the product you have purchased will operate
without problems, giving you optimum room temperatures with minimum energy costs.
This unit complies with the following European Directives:
• Low voltage 2014/35/EU; • Electro-magnetic compatibility 2014/30/EU;
The pictograms in the next chapter provide the necessary
information for correct, safe use of the appliance in a rapid,
unmistakable way.
Symbols
U
User
- Refers to pages containing instructions or information
for the user.
I
Installer
- Refers to pages containing instructions or information
for the installer.
S
Service
- Refers to pages containing instructions or information
for the CUSTOMER TECHNICAL ASSISTANCE
SERVICE installer.
Editorial pictograms
Safety pictograms
Warning
- The operation described may cause physical harm if
not carried out in accordance with safety regulations.
Dangerous electrical current
- Make personnel aware that the operation described
may lead to electrical shocks if not carried out in
accordance with safety regulations.
High temperature danger
- Of safety regulations, the risk of burns caused by
contact with components with high temperatures.
Prohibition
- Refers to prohibited actions.

3
1 GENERAL
1.1 General warnings ...................................................................5
1.2 Fundamental safety rules .............................................................5
2 EKRTCTRL1
2.1 SMART TOUCH electronic control panel with device side continuous modulation ....................6
2.2 Display...........................................................................6
2.3 Key function.......................................................................6
2.4 General On Switch ..................................................................7
2.5 Activation .........................................................................7
2.6 Heating/cooling operation modes setting..................................................7
2.7 Stand By ......................................................................... 7
2.8 Temperature selection ...............................................................7
2.9 Automatic operation ................................................................8
2.10 Silent operation ....................................................................8
2.11 Night-time operation ................................................................8
2.12 Operation at maximum ventilation speed .................................................8
2.13 Key lock..........................................................................8
2.14 Reduce brightness to minimum.........................................................8
2.15 Deactivation .......................................................................9
2.16 Room temperature probe regulation offset.................................................9
2.17 Switching off for long periods ..........................................................9
2.18 Error signals .......................................................................9
3 EKWHCTRL1
3.1 Wall-mounted SMART TOUCH electronic control panel with room probe .........................10
3.2 Display..........................................................................10
3.3 Key function......................................................................10
3.4 General On Switch .................................................................11
3.5 Activation ........................................................................11
3.6 Heating/cooling operation modes setting.................................................11
3.7 Stand By ........................................................................ 11
3.8 Temperature selection ..............................................................11
3.9 Automatic operation ...............................................................12
3.10 Silent operation ...................................................................12
3.11 Night-time operation ...............................................................12
3.12 Operation at maximum ventilation speed ................................................12
3.13 Key lock.........................................................................12
3.14 Reduce brightness to minimum........................................................12
3.15 Deactivation ......................................................................13
3.16 Room temperature probe regulation offset................................................13
3.17 Switching off for long periods .........................................................13
3.18 Error signals ......................................................................13

4
4 EKRTCTRL2
4.1 SMART TOUCH electronic control panel with fixed speed modulation............................14
4.2 Display..........................................................................14
4.3 Key function......................................................................14
4.4 General On Switch .................................................................15
4.5 Activation ........................................................................15
4.6 Heating/cooling operation modes setting.................................................15
4.7 Stand By ........................................................................ 15
4.8 Temperature selection ..............................................................15
4.9 Ventilation speed regulation ..........................................................16
4.10 Key lock.........................................................................16
4.11 Reduce brightness to minimum........................................................16
4.12 Deactivation ......................................................................16
4.13 Room temperature probe regulation offset................................................17
4.14 Switching off for long periods .........................................................17
4.15 Error signals ......................................................................17
5 EKPCBO
5.1 On-board speed selector for connecting to standard thermostat. ...............................18
5.2 LED indications ...................................................................18
5.3 General On Switch .................................................................18
5.4 Activation ........................................................................19
5.5 Stand By ........................................................................ 19
5.6 Ventilation speed regulation ..........................................................19
5.7 Deactivation ......................................................................19
5.8 Switching off for long periods ......................................................... 19
5.9 Error status warnings ...............................................................19
6 MAINTENANCE
6.1 External cleaning .................................................................. 20
6.2 Air suction filter cleaning .............................................................20
6.3 Suggestions for power saving .........................................................22
7 TROUBLESHOOTING
7.1 Troubleshooting ...................................................................23
7.2 Troubleshooting table ............................................................... 23

5
S
I
U
1.1
1.2
General waenings
Fundamental safety rules
This instruction is an integral part of the booklet of the
appliance on which the kit is installed. Please consult
this booklet for general warnings and fundamental safety
rules.
This manual is designed only for the qualified and
authorised installation technician, who must be
sufficiently trained and in possession of all psycho-
physical requirements as per the law.
All operations must be carried out with care and
according to best practices, and in compliance with
workplace safety regulations.
After unpacking, check that the contents are intact and
that all parts are included. If not, contact the agent who
sold the appliance to you.
It is forbidden to modify the safety or adjustment
devices without authorisation from and indications of the
manufacturer.
It is forbidden to dispose of, or leave in the reach of
children, the packaging materials which could become
a source of danger.
Repairs or maintenance must be performed by the
Technical Assistance Service or by qualified personnel
in accordance with this manual. Do not modify or tamper
with the appliance as this could create dangerous
situations and the manufacturer will not be liable for any
damage caused.
GENERAL
Remember that some fundamental safety rules should
be followed when using a product that uses electricity
and water, such as:
The unit can be used by children over the age of
8, and by people with reduced physical, sensory or
mental capabilities, or with no experience or necessary
knowledge, as long as they are monitored or after they
have received instructions on the safe use of the unit
and have understood the dangers involved.
Children must not play with the appliance.
The cleaning and maintenance that must be
performed by the user should not be carried out by
children without supervision.
It is forbidden to touch the appliance with wet hands
or body when barefoot.
It is forbidden to carry out any cleaning before having
disconnected the appliance from the electricity mains
supply by turning the system master switch to "OFF".
It is forbidden to modify the safety or adjustment
devices or adjust without authorisation and indications
of the manufacturer.
It is forbidden to pull, cut or knot the electrical cables
coming out of the appliance, even if it is disconnected
from the mains supply.
It is forbidden to poke objects or anything else through
the inlet or outlet grills.
It is forbidden to open the doors which access the
internal parts of the appliance without first turning the
system master switch to "OFF".
It is forbidden to dispose of or leave in the reach of
children the packaging materials which could become
a source of danger.
It is forbidden to climb onto the appliance or rest any
object on it.
The external parts of the appliance can reach
temperatures of more than 70°C.

6
S
U
I
AB
2.1
2.2
2.3
A Display
B Keys
These controls make room temperature adjustment (with
offset settable from the keyboard) completely autonomous
through the AUTO, SILENT, NIGHT and MAX programmes
by means of a probe located in the lower part of the device,
ensuring anti-freeze safety even when set to stand-by.
The control panel has a memory, so settings will not be
lost if the appliance is switched off or in the power supply
is cut.
Controls cannot be installed on the FWXM-series.
After 20 seconds from the last action the panel
brightness will be reduced for improved night-time
comfort, and the room temperature will appear on the
display. Press any key to restore maximum brightness.
The 10 kΩ water temperature probe positioned in the
device battery regulations the minimum level when heating
(30°C) and the maximum level when cooling (20°C).
The various functions are set using 8 backlit keys:
Any statuses and alarms are also shown on the display by
using 8 specific symbols:
EKRTCTRL1
Automatic operation
Silent operation
Maximum ventilation speed
Night-time operation
Heating on
Cooling on
Supervision on Flashing with presence switch CP
closed.
Alarm indicator (solid light)
Panel off indicator
Resistance active indicator
Temp + is for increasing the set temperature
Temp - is for decreasing the set temperature
Heating / Cooling: for changing the operation
mode between heating and cooling
Sets the regulation ventilation speed between
a minimum and maximum value to an entirely
automatic mode
Night-time operation: limits ventilation speed
to a contained level and the set temperature
is adjusted automatically.
Maximum speed operation: Allows for the
maximum ventilation speed to be set
ON/Stand-By: for activating the device or for
putting it in stand-by.
Silent: limits ventilation speed to a more
contained value
SMART TOUCH electronic control panel with device side continuous modulation
Display
Key function

7
S
U
I
2.4
2.5
2.6
2.7
2.8
20.5
In order to manage the device via the control panel, this
must be connected to the mains electricity.
If a general switch is installed on the power line, this must
also be switched on.
- Turn the device on by activating the general switch
One of the two symbols flashing means that the water
temperature (hot or cold) is not sufficient, and stops
the fan until the temperature reaches a level suitable for
reaching the required temperature.
If after switching the power on the board detects the
H2 probe, start-up occurs in normal conditions with the
minimum and maximum thresholds.
The board also has a function when there is no H2 probe,
in such cases the fan stop thresholds are ignored.
When the control is in this operating mode, anti freezing is
in any case guaranteed. If the ambient temperature drops
below 5°C, the solenoid valves on the hot water output
and the boiler are opened.
The adjustment range is from 16 to 28°C in intervals of
0.5°C, but out-of-range values are also accepted, from
5°C to 40°C (unless in auto mode).
Only set these values for brief periods, and then set a
intermediate value.
The controller is very precise - set it to the required value
and wait for the controller to regulate itself according to the
actual room temperature detected.
To activate the device
Key Operation Display
Keep the Heating / Cooling key pressed for approx. 2 seconds to change the mode
between heating and cooling, which is indicated by the 2 symbols that appear if heating
or cooling is active.
When heating, the symbol displays when the set point is higher than ambient
temperature, both are off when the set point is lower.
When cooling, the symbol displays when the set point is lower than ambient temperature,
both are off when the set point is higher.
Key Operation Display
Press and hold the ON Stand-By key for approx. 2 seconds. No illuminated signals on
the display at all means that the system is in stand-by (no operation). Off
Key Operation Display
Press the ON Stand-by key From off to on
Select one of the 4 operating modes by pressing the relative key.
Key Operation Display
Set the required room temperature using the two increase/decrease keys to set the
temperature value on the 3-digit display.
General On Switch
Activation
Heating/cooling operation modes setting
Temperature selection
Stand By

8
S
U
I
2.9
2.10
2.11
2.12
2.13
2.14
bL
00
Ventilation speed adjustment is carried out automatically
between the minimum and maximum values, according to
the distance of the actual room temperature from the set
point, according to a PI-type algorithm.
Ventilation speed is limited to a contained maximum value.
By selecting this mode, ventilation speed is limited to a
very contained level and the set temperature is adjusted
automatically, as follows:
- decreases by 1°C after one hour and by another degree
after two hours in heating mode;
- increases by 1°C after one hour and by another degree
after two hours in cooling mode;
In this operation mode, the maximum possible power level
is activated whether heating or cooling.
Once the desired room temperature is reached, we
recommend selecting one of the other 3 operation modes
for increased comfort and sound levels.
Key Operation Display
By pressing both the + and - keys for 3 seconds, all keys are locked locally, and this is
indicated by "bL" appearing on the display.
All actions are disabled to the user and whenever any key is pressed, "LOC" will appear.
To unlock the keys, repeat the sequence.
Key Operation Display
Press and hold the Max Operation key. The function being activated is indicated by the
relevant symbol appearing on the display.
Key Operation Display
Press and hold the Night-time operation key. The function being activated is indicated
by the relevant symbol appearing on the display.
Key Operation Display
Press and hold the Silent key. The function being activated is indicated by the relevant
symbol appearing on the display.
Key Operation Display
Press and hold the AUTO key. The function being activated is indicated by the relevant
symbol appearing on the display.
After 20 seconds from the last action, the panel brightness
will be reduced for improved night-time comfort, and the
room temperature will appear on the display.
If this brightness is still disturbing, the display can be
switched off completely.
Key Operation Display
With the display off, press and hold the + key for 5 seconds until "01" is displayed.
Use the - key to change the value to 00 and wait 20 seconds to check the setting has
been accepted.
Automatic operation
Silent operation
Night-time operation
Operation at maximum ventilation speed
Key lock
Reduce brightness to minimum

9
S
U
I
2.15
2.16
2.17
2.18
00.0
E1
E2
E3
Gr
When switching off for a season or for holidays, proceed
as follows:
- Deactivate the device
- Turn the general unit switch to off.
The antifreeze function is not active.
As the detection probe is towards the bottom of the
device, the temperature detected may at times differ from
the actual room temperature.
By using this function, the value displayed can be adjusted
in a range from -9/+12 K in intervals of 0.1°C.
Use this adjustment with care, and only after having
actually detected a discrepancy compared with the actual
room temperature using a reliable device!
Key Operation Display
With the display off, press and hold the - key for 5 seconds to access the menu which
allows adjustment (using the + and - keys) of the AIR probe offset displayed, from -9
to +12 K in 0.1 K intervals.
After 20 seconds from the last action, the panel switches off and the setting is stored.
The controller also ensures anti freezing when in stand-by.
Key Operation Display
Press and hold the ON Stand-By key for approx. 2 seconds. No illuminated signals on
the display at all means that the system is in stand-by (no operation). Off
Switching off for long periods
Error signals
Deactivation
Room temperature probe regulation offset
Error Display
Faulty room temperature (AIR) probe
Problem with fan motor (e.g. blockage caused by foreign objects, faulty rotation sensor).
Water temperature probe fault
In this case, ensure that the probe installed is 10 kΩ.
Engaging of grille microswitch S1 due to filter cleaning operation
The flashing of one of the 2 symbols indicates that the water temperature (hot or cold) is not
and causes the fan to Stop.

10
S
U
I
3.1
3.2
3.3
EKWHCTRL1
The remote wall-mounted control EKWHCTRL1 is an
electronic thermostat with a room temperature probe for
controlling one or more (up to a maximum of 30) fan coils
/ cooler-radiators in broadcast mode (with simultaneous
control transmission) equipped with electronic control for
EKWHCTRL0 remote operation .
The control panel has a memory, so settings will not be lost
if the appliance is switched off or in the power supply is cut.
Any anomalies on individual connected terminal are
not indicated on the wall panel.
Anti-freeze protection is guaranteed via the
temperature probe when in stand-by.
After 20 seconds from the last action, the panel
brightness will be reduced and the room temperature
will appear on the display. Press any key to restore
maximum brightness.
Any statuses and alarms are also shown on the display by
using 8 specific symbols:
Automatic operation
Silent operation
Maximum ventilation speed
Night-time operation
Heating on
Cooling on
Supervision on Flashing with presence switch CP
closed.
Alarm indicator (solid light)
Panel off indicator
Resistance active indicator
The various functions are set using 8 backlit keys:
Temp + is for increasing the set temperature
Temp - is for decreasing the set temperature
Heating / Cooling: for changing the operation
mode between heating and cooling
Sets the regulation ventilation speed between
a minimum and maximum value to an entirely
automatic mode
Night-time operation: limits ventilation speed
to a contained level and the set temperature
is adjusted automatically.
Maximum speed operation: Allows for the
maximum ventilation speed to be set
ON/Stand-By: for activating the device or for
putting it in stand-by.
Silent: limits ventilation speed to a more
contained value
Display
Wall-mounted SMART TOUCH electronic control panel with room probe
Key function
