Daikin RZQ Series FCQ20EVA User manual

Service
Manual
RZQ Series
Heat Pump R410A 60Hz
RZQ20 / 24 / 36 / 45LVA
RZQ45 / 48MYL
SiME281501E

SiME281501E
iTable of Contents
TopAir RZQ Series
Heat Pump
R410A 60Hz
ED Reference
For items below, please refer to Engineering Data.
1. Introduction ............................................................................................ iv
1.1 Safety Cautions ....................................................................................... iv
1.2 Used Icons ............................................................................................ viii
Part 1 General Information ........................................................... 1
1. Model Name of Indoor / Outdoor Units ...................................................2
2. External Appearance...............................................................................3
Part 2 Functions............................................................................ 4
1. Functions.................................................................................................5
Part 3 Remote Controller .............................................................. 6
1. Wired Remote Controller.........................................................................7
1.1 Applicable Models ....................................................................................7
1.2 Names and Functions ..............................................................................8
1.3 MAIN/SUB Setting when Using 2 Remote Controllers ...........................11
1.4 Centralized Control Group No. Setting...................................................12
2. Wireless Remote Controller ..................................................................13
2.1 Applicable Models ..................................................................................13
2.2 Names and Functions ............................................................................13
2.3 Address and MAIN/SUB Setting.............................................................15
3. Service Mode ........................................................................................17
3.1 BRC1C61/BRC1D61 ..............................................................................17
Part 4 Function and Control........................................................ 19
1. Functions of Main Components and Thermistors .................................20
2. Function Outline ....................................................................................23
2.1 Indoor Unit..............................................................................................23
3. Operation Flow Chart ............................................................................25
3.1 Cooling / Dry Operation..........................................................................25
3.2 Heating Operation ..................................................................................26
No. Item ED No. Page Remarks
1 Specification EDTW281313A P. 9-22
2 Option List EDTW281313A P. 70-72

SiME281501E
Table of Contents ii
4. Function Details ....................................................................................27
4.1 Indoor Unit..............................................................................................27
4.2 Outdoor Unit ...........................................................................................32
Part 5 Field Setting ..................................................................... 48
1. Test Operation ......................................................................................49
1.1 Check Items before the Test Operation .................................................49
1.2 Test Operation........................................................................................49
2. Field Setting from Remote Controller....................................................51
2.1 Wired Remote Controller........................................................................51
2.2 Wireless Remote Controller ...................................................................52
2.3 Setting Contents and Code No. for Indoor Units ....................................53
2.4 Setting Contents and Code No. for Outdoor Units .................................57
3. Field Setting from Outdoor Unit PCB ....................................................60
3.1 Location of DIP Switch and BS Button...................................................60
3.2 Field Setting for Outdoor Unit.................................................................61
4. Emergency Operation ...........................................................................67
4.1 Forced Operation ...................................................................................67
4.2 Emergency Operation when the Remote Controller is Lost ...................68
Part 6 Service Diagnosis............................................................. 69
1. Maintenance Inspection ........................................................................71
1.1 Overview ................................................................................................71
2. Symptom-based Troubleshooting .........................................................74
2.1 Overview ................................................................................................74
2.2 Equipment does not Operate .................................................................75
2.3 Indoor Unit Fan Operates, but Compressor does not Operate ..............76
2.4 Cooling / Heating Operation Starts but Stops Immediately ....................77
2.5 After Unit Shuts Down, It cannot be Restarted for a While ....................78
2.6 Equipment Operates but does not Provide Cooling ...............................80
2.7 Equipment Operates but does not Provide Heating ...............................81
2.8 Equipment Discharges White Mist .........................................................82
2.9 Equipment Produces Loud Noise or Vibration .......................................83
2.10 Equipment Discharges Dust...................................................................84
2.11 Remote Controller LCD Displays "88" ....................................................84
3. Troubleshooting by LED Indications .....................................................85
3.1 Troubleshooting by LED on the Indoor Unit ...........................................85
3.2 Troubleshooting by LED on Outdoor Unit PCB......................................85
4. Troubleshooting by Remote Controller .................................................86
4.1 Procedure of Self-diagnosis by Remote Controller ................................86
4.2 Error Codes and Description ..................................................................89
4.3 Safety Devices .......................................................................................90
4.4 Error of External Protection Device ........................................................91
4.5 Indoor Unit PCB Abnormality .................................................................92
4.6 Drain Water Level System Abnormality..................................................93
4.7 Indoor Unit Fan Motor Abnormality ........................................................95
4.8 Swing Flap Motor Abnormality / Lock.....................................................96
4.9 Abnormal Power Supply Voltage............................................................98
4.10 Drain System Abnormality......................................................................99
4.11 Capacity Setting Abnormality ...............................................................100

SiME281501E
iii Table of Contents
4.12 Transmission Error between Indoor Unit PCB and Fan PCB...............101
4.13 Thermistor Abnormality ........................................................................103
4.14 Combination Error between Indoor Unit PCB and Fan PCB ................104
4.15 Humidity Sensor System Abnormality ..................................................105
4.16 Room Temperature Thermistor in Remote Controller Abnormality ......106
4.17 Outdoor Unit PCB Abnormality.............................................................107
4.18 High Pressure Abnormality (Detected by the High Pressure Switch)...108
4.19 Low Pressure Abnormality ...................................................................110
4.20 Compressor Motor Lock .......................................................................112
4.21 Outdoor Unit Fan Motor Abnormality....................................................114
4.22 Electronic Expansion Valve Abnormality..............................................116
4.23 Discharge Pipe Temperature Control Error..........................................119
4.24 High Pressure Switch System Abnormality ..........................................121
4.25 Thermistor System Abnormality ...........................................................122
4.26 Pressure Sensor Abnormality...............................................................123
4.27 Outdoor Unit PCB Abnormality.............................................................124
4.28 Radiation Fin Temperature Rise ..........................................................126
4.29 DC Output Overcurrent ........................................................................128
4.30 Electronic Thermal (Time Lag) .............................................................130
4.31 Stall Prevention (Time Lag)..................................................................132
4.32 Transmission Error between Control and Inverter PCB .......................134
4.33 Transmission Error between Control and Inverter PCB .......................135
4.34 Open Phase or Power Supply Voltage Imbalance ...............................137
4.35 Radiation Fin Thermistor (R10T) or Related Abnormality ....................138
4.36 Defective Capacity Setting ...................................................................139
4.37 Refrigerant Shortage (Error).................................................................140
4.38 Refrigerant Shortage ............................................................................141
4.39 Power Supply Voltage Abnormality......................................................142
4.40 Transmission Error between Indoor Unit and Outdoor Unit .................143
4.41 Transmission Error between Indoor Unit and Remote Controller.........146
4.42 Transmission Error between MAIN Remote Controller
and SUB Remote Controller.................................................................147
4.43 Field Setting Switch Abnormality..........................................................148
4.44 Centralized Address Setting Error........................................................150
4.45 Transmission Error between Indoor and Outdoor Unit /
Piping and Wiring Mismatch / Refrigerant Shortage ............................151
4.46 Check ...................................................................................................152
Part 7 Appendix......................................................................... 166
1. Wiring Diagrams..................................................................................167
1.1 Indoor Units ..........................................................................................167
1.2 Outdoor Units .......................................................................................169

SiME281501E Introduction
iv
1. Introduction
1.1 Safety Cautions
Cautions and
Warnings
Be sure to read the following safety cautions before conducting repair work.
The caution items are classified into “ Warning” and “ Caution”. The “ Warning”
items are especially important since they can lead to death or serious injury if they are not
followed closely. The “ Caution” items can also lead to serious accidents under some
conditions if they are not followed. Therefore, be sure to observe all the safety caution items
described below.
About the pictograms
This symbol indicates the item for which caution must be exercised.
The pictogram shows the item to which attention must be paid.
This symbol indicates the prohibited action.
The prohibited item or action is shown in the illustration or near the symbol.
This symbol indicates the action that must be taken, or the instruction.
The instruction is shown in the illustration or near the symbol.
After the repair work is complete, be sure to conduct a test operation to ensure that the
equipment operates normally, and explain the cautions for operating the product to the
customer.
1.1.1 Cautions Regarding Safety of Workers
Warning
Be sure to disconnect the power cable plug from the plug socket before
disassembling the equipment for repair.
Working on the equipment that is connected to the power supply may cause an
electrical shook.
If it is necessary to supply power to the equipment to conduct the repair or
inspecting the circuits, do not touch any electrically charged sections of the
equipment.
If the refrigerant gas is discharged during the repair work, do not touch the
discharged refrigerant gas.
The refrigerant gas may cause frostbite.
When disconnecting the suction or discharge pipe of the compressor at the
welded section, evacuate the refrigerant gas completely at a well-ventilated
place first.
If there is a gas remaining inside the compressor, the refrigerant gas or
refrigerating machine oil discharges when the pipe is disconnected, and it may
cause injury.
If the refrigerant gas leaks during the repair work, ventilate the area. The
refrigerant gas may generate toxic gases when it contacts flames.
The step-up capacitor supplies high-voltage electricity to the electrical
components of the outdoor unit.
Be sure to discharge the capacitor completely before conducting repair work.
A charged capacitor may cause an electrical shock.
Do not start or stop the air conditioner operation by plugging or unplugging the
power cable plug.
Plugging or unplugging the power cable plug to operate the equipment may
cause an electrical shock or fire.

Introduction SiME281501E
v
Be sure to wear a safety helmet, gloves, and a safety belt when working at a
high place (more than 2 m). Insufficient safety measures may cause a fall
accident.
In case of R410A refrigerant models, be sure to use pipes, flare nuts and tools
for the exclusive use of the R410A refrigerant.
The use of materials for R22 refrigerant models may cause a serious accident
such as a damage of refrigerant cycle as well as an equipment failure.
Warning
Caution
Do not repair the electrical components with wet hands.
Working on the equipment with wet hands may cause an electrical shock.
Do not clean the air conditioner by splashing water.
Washing the unit with water may cause an electrical shock.
Be sure to provide the grounding when repairing the equipment in a humid or
wet place, to avoid electrical shocks.
Be sure to turn OFF the power switch and unplug the power cable when
cleaning the equipment.
The internal fan rotates at a high speed, and cause injury.
Be sure to conduct repair work with appropriate tools.
The use of inappropriate tools may cause injury.
Be sure to check that the refrigerating cycle section has cooled down enough
before conducting repair work.
Working on the unit when the refrigerating cycle section is hot may cause
burns.
Use the welder in a well-ventilated place.
Using the welder in an enclosed room may cause oxygen deficiency.

SiME281501E Introduction
vi
1.1.2 Cautions Regarding Safety of Users
Warning
Be sure to use parts listed in the service parts list of the applicable model and
appropriate tools to conduct repair work. Never attempt to modify the
equipment.
The use of inappropriate parts or tools may cause an electrical shock,
excessive heat generation or fire.
If the power cable and lead wires have scratches or deteriorated, be sure to
replace them.
Damaged cable and wires may cause an electrical shock, excessive heat
generation or fire.
Do not use a joined power cable or extension cable, or share the same power
outlet with other electrical appliances, since it may cause an electrical shock,
excessive heat generation or fire.
Be sure to use an exclusive power circuit for the equipment, and follow the local
technical standards related to the electrical equipment, the internal wiring
regulations, and the instruction manual for installation when conducting
electrical work.
Insufficient power circuit capacity and improper electrical work may cause an
electrical shock or fire.
Be sure to use the specified cable for wiring between the indoor and outdoor
units. Make the connections securely and route the cable properly so that there
is no force pulling the cable at the connection terminals.
Improper connections may cause excessive heat generation or fire.
When wiring between the indoor and outdoor units, make sure that the terminal
cover does not lift off or dismount because of the cable.
If the cover is not mounted properly, the terminal connection section may cause
an electrical shock, excessive heat generation or fire.
Do not damage or modify the power cable.
Damaged or modified power cable may cause an electrical shock or fire.
Placing heavy items on the power cable, and heating or pulling the power cable
may damage the cable.
Do not mix air or gas other than the specified refrigerant (R410A / R22) in the
refrigerant system.
If air enters the refrigerating system, an excessively high pressure results,
causing equipment damage and injury.
If the refrigerant gas leaks, be sure to locate the leaking point and repair it
before charging the refrigerant. After charging refrigerant, make sure that there
is no refrigerant leak.
If the leaking point cannot be located and the repair work must be stopped, be
sure to perform pump down and close the service valve, to prevent the
refrigerant gas from leaking into the room. The refrigerant gas itself is
harmless, but it may generate toxic gases when it contacts flames, such as fan
and other heaters, stoves and ranges.
When relocating the equipment, make sure that the new installation site has
sufficient strength to withstand the weight of the equipment.
If the installation site does not have sufficient strength and if the installation
work is not conducted securely, the equipment may fall and cause injury.

Introduction SiME281501E
vii
Check to make sure that the power cable plug is not dirty or loose, then insert
the plug into a power outlet securely.
If the plug has dust or loose connection, it may cause an electrical shock or fire.
Be sure to install the product correctly by using the provided standard
installation frame.
Incorrect use of the installation frame and improper installation may cause the
equipment to fall, resulting in injury.
For unitary type
only
Be sure to install the product securely in the installation frame mounted on the
window frame.
If the unit is not securely mounted, it may fall and cause injury.
For unitary type
only
When replacing the coin battery in the remote controller, be sure to disposed
of the old battery to prevent children from swallowing it.
If a child swallows the coin battery, see a doctor immediately.
Warning
Caution
Installation of a leakage breaker is necessary in some cases depending on the
conditions of the installation site, to prevent electrical shocks.
Do not install the equipment in a place where there is a possibility of
combustible gas leaks.
If the combustible gas leaks and remains around the unit, it may cause a fire.
Check to see if the parts and wires are mounted and connected properly, and
if the connections at the soldered or crimped terminals are secure.
Improper installation and connections may cause excessive heat generation,
fire or an electrical shock.
If the installation platform or frame has corroded, replace it.
Corroded installation platform or frame may cause the unit to fall, resulting in
injury.
Check the grounding, and repair it if the equipment is not properly grounded.
Improper grounding may cause an electrical shock.

SiME281501E Introduction
viii
1.2 Used Icons
Icons are used to attract the attention of the reader to specific information. The meaning of each
icon is described in the table below:
Be sure to measure the insulation resistance after the repair, and make sure
that the resistance is 1 Mor higher.
Defective insulation may cause an electrical shock.
Be sure to check the drainage of the indoor unit after the repair.
Defective drainage may cause the water to enter the room and wet the furniture
and floor.
Do not tilt the unit when removing it.
The water inside the unit may spill and wet the furniture and floor.
Be sure to install the packing and seal on the installation frame properly.
If the packing and seal are not installed properly, water may enter the room and
wet the furniture and floor.
For unitary type
only
Caution
Icon Type of
Information
Description
Note:
Note A “note” provides information that is not indispensable, but may
nevertheless be valuable to the reader, such as tips and tricks.
Caution
Caution A “caution” is used when there is danger that the reader, through
incorrect manipulation, may damage equipment, loose data, get
an unexpected result or has to restart (part of) a procedure.
Warning
Warning A “warning” is used when there is danger of personal injury.
Reference A “reference” guides the reader to other places in this binder or
in this manual, where he/she will find additional information on a
specific topic.

SiME281501E
1General Information
Part 1
General Information
1. Model Name of Indoor / Outdoor Units ...................................................2
2. External Appearance...............................................................................3

SiME281501E Model Name of Indoor / Outdoor Units
General Information 2
1. Model Name of Indoor / Outdoor Units
Note: : New model or changed model
Model series Indoor unit Outdoor unit Power supply intake
Ceiling Mounted
Cassette Type
(Round Flow)
FCQ20EVA RZQ20LVA
Outdoor unit: 1 phase, 220V, 60Hz
FCQ24EVA RZQ24LVA
FCQ36EVA RZQ36LVA
FCQ45EVA RZQ45LVA
FCQ36EVA RZQ36LVA Outdoor unit: 3 phase, 220V, 60Hz
FCQ45EVA RZQ45LVA
FCQ36EVA RZQ36LVA Outdoor unit: 3 phase, 380V, 60Hz
FCQ45EVA RZQ45LVA
Duct Connection
Middle and High Static
Pressure Type
FBQ20EVA RZQ20LVA
Indoor unit: 1 phase, 220V, 60Hz
Outdoor unit: 1 phase, 220V, 60Hz
FBQ24EVA RZQ24LVA
FBQ36EVA RZQ36LVA
FBQ45EVA RZQ45LVA
FBQ36EVA RZQ36LVA Indoor unit: 1 phase, 220V, 60Hz
Outdoor unit: 3 phase, 220V, 60Hz
FBQ45EVA RZQ45LVA
FBQ45EVA RZQ45MYL Indoor unit: 1 phase, 220V, 60Hz
Outdoor unit: 3 phase, 380V, 60Hz
FBQ48EVA RZQ48MYL

External Appearance SiME281501E
3General Information
2. External Appearance
Indoor unit
Wired
remote controller
Wireless
remote controller
Outdoor unit
FCQ FBQ-DA
BRC1C61 BRC1D61
BRC7F632F (for FCQ)
BRC4C62 (for FBQ-DA)
Signal receiver unit
(for FCQ)
Signal receiver unit
(for FBQ-DA)
RZQ20LVA
RZQ24LVA
RZQ36LVA
RZQ45LVA
RZQ45MYL
RZQ48MYL

SiME281501E
Functions 4
Part 2
Functions
1. Functions.................................................................................................5

Functions SiME281501E
5Functions
1. Functions
Note: : Functions exist.
— : No functions
1 : Applicable when wired remote controller is used
2 : For the outdoor units
3 : Applicable when BRC1D61 is used
4 : Option
5 : Applicable when BRC1C61 is used
Items Features
Indoor
unit FCQ20-45EVA FBQ20-48EVA
Outdoor
unit
RZQ20-45LVA
RZQ45-48MYL
RZQ20-45LVA
RZQ45-48MYL
Comfort Auto swing —
Swing pattern selection —
Draft prevention function (heating) —
Switchable fan speed (2 step) (2 step)
Auto airflow rate — —
High fan speed mode — —
Program “Dry” 
High ceiling application —
Two selectable temperature-sensors
(1) 
Hot start (after defrost) 
Year-round cooling applicable 
Remote
controller
Weekly schedule timer (3) 
On/Off timer (5) 
Cleanliness Anti-bacterial air filter (4)
Mould-proof air filter — —
Silver ion anti-bacterial drain pan 
Mould-proof drain pan — —
Work &
servicing
Drain pump mechanism —
Pre-charged for up to 30 m (2) 
Long-life filter (4)
Filter sign 
Ceiling soiling prevention —
Low gas pressure detection (2) 
Emergency operation 
Self-diagnosis function 
Control
features
Auto-restart 
Auto cooling/heating changeover 
Control by 2 remote controllers 
Group control by 1 remote controller 
External command control 
Centralized remote control 
Interlock control 
DIII-NET communication standard 
Options High-efficiency filter 
Ultra long-life filter —
Fresh air intake kit —
Others Anti corrosion treated heat exchanger
(2) 

SiME281501E
Remote Controller 6
Part 3
Remote Controller
1. Wired Remote Controller.........................................................................7
1.1 Applicable Models ....................................................................................7
1.2 Names and Functions ..............................................................................8
1.3 MAIN/SUB Setting when Using 2 Remote Controllers ...........................11
1.4 Centralized Control Group No. Setting...................................................12
2. Wireless Remote Controller ..................................................................13
2.1 Applicable Models ..................................................................................13
2.2 Names and Functions ............................................................................13
2.3 Address and MAIN/SUB Setting.............................................................15
3. Service Mode ........................................................................................17
3.1 BRC1C61/BRC1D61 ..............................................................................17

Wired Remote Controller SiME281501E
7Remote Controller
1. Wired Remote Controller
1.1 Applicable Models
Model Series FCQ-EV FBQ-EV
Remote Controller Heat Pump BRC1C61
Wired Remote Controller with Weekly
Schedule Timer BRC1D61

SiME281501E Wired Remote Controller
Remote Controller 8
1.2 Names and Functions
1.2.1 BRC1C61
hr
hr
C
C: 3PA59583-16Z
2
10
11
3
1
4
5
6
7
8
14
15
16 17 18
19
20
21
22
12
9
13
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
ON/OFF BUTTON
Press the button and the system will start.
Press the button again and the system will stop.
OPERATION LAMP (RED)
The lamp lights up during operation.
DISPLAY “ ” (UNDER CENTRALIZED
CONTROL)
When this display shows, the system is UNDER
CENTRALIZED CONTROL.
DISPLAY “ ” “ ” “ ” “ ”
(VENTILATION/AIR CLEANING)
This display shows that the total heat exchange
and the air cleaning unit are in operation
(These are optional accessories).
DISPLAY “ ” “ ” “ ” “ ” “ ”
(OPERATION MODE)
This display shows the current OPERATION
MODE. For cooling only type, “ ” (Auto)
and “ ” (Heating) are not installed.
DISPLAY “ TEST” (INSPECTION/TEST
OPERATION)
When the INSPECTION/TEST OPERATION
BUTTON is pressed, the display shows the
system mode is in.
DISPLAY “ ” (PROGRAMMED TIME)
This display shows the PROGRAMMED TIME
of the system start or stop.
This display shows the set temperature.
DISPLAY “ ” (FAN SPEED)
DISPLAY “ ” (SET TEMPERATURE)
This display shows the set fan speed.
DISPLAY “ ” (AIRFLOW FLAP)
DISPLAY “ ”(TIME TO CLEAN AIR FILTER)
If that particular function is not available, pressing
the button may display the words “NOT
AVAILABLE” for a few seconds.
When running multiple units simultaneously the
“NOT AVAILABLE” message will only be appear
if none of the indoor units is equipped with the
function. If even one unit is equipped with the
function, the display will not appear.
DISPLAY
“ ” (DEFROST)
NON-FUNCTIONING DISPLAY
TIMER MODE START/STOP BUTTON
TIMER ON/OFF BUTTON
INSPECTION/TEST OPERATION BUTTON
This button is used only by qualified service
persons for maintenance purposes.
PROGRAMMING TIME BUTTON
Use this button for programming “START and/or
STOP” time.
TEMPERATURE SETTING BUTTON
Use this button for SETTING TEMPERATURE.
FILTER SIGN RESET BUTTON
FAN SPEED CONTROL BUTTON
Press this button to select the fan speed,
HIGH or LOW, of your choice.
OPERATION MODE SELECTOR BUTTON
Press this button to select OPERATION MODE.
AIRFLOW DIRECTION ADJUST BUTTON
NOTE
• For the sake of explanation, all indications are shown
on the display in the above figure contrary to actual
running situations.

Wired Remote Controller SiME281501E
9Remote Controller
1.2.2 BRC1D61
C: 3P107422-3D
1 ON/OFF BUTTON
Press the ON/OFF button to start or stop the system.
2 OPERATION LAMP
The operation lamp lights up during operation or
blinks if an error occurs.
3 OPERATION MODE ICON
These icons indicate the current operation mode
(FAN, DRY, AUTOMATIC, COOLING, HEATING).
4 VENTILATION MODE ICON
These icons indicate the current ventilation mode
(Heat Reclaim Ventilator only) (AUTOMATIC, HEAT
EXCHANGE, BYPASS).
5 VENTILATION ICON
The ventilation icon appears when the ventilation is
adjusted with the ventilation amount button (Heat
Reclaim Ventilator only). Simultaneously, the ventilation
amount is indicated by the fan speed icon (see 22).
6 AIR CLEANING ICON
This icon indicates that the air cleaning unit (option) is
operational.
7 LEAVE HOME ICON
The leave home icon shows the status of the leave
home function.
ON
FLASHING
OFF
Leave home is enabled
Leave home is active
Leave home is disabled
8 EXTERNAL CONTROL ICON
This icon indicates that another controller with higher
priority is controlling or disabling your installation.
9 CHANGE-OVER UNDER CENTRALIZED
CONTROL ICON
This icon indicates that the change-over of the
installation is under centralized control assigned to
another indoor unit or optional cool/heat selector
connected to the outdoor unit (= main remote
controller).
10 DAY OF THE WEEK INDICATOR
MON TUE WED THU FRI SAT SUN
The day of the week indicator shows the current week
day (or the set day when reading or programming the
schedule timer).
11 CLOCK DISPLAY
The clock display indicates the current time (or the
action time when reading or programming the
schedule timer).
12 MAXIMUM SET TEMPERATURE
The maximum set temperature indicates the
maximum set temperature when in limit operation.
13 MINIMUM SET TEMPERATURE
The minimum set temperature indicates the minimum
set temperature when in limit operation.
14 SCHEDULE TIMER ICON
This icon indicates that the schedule timer is enabled.

SiME281501E Wired Remote Controller
Remote Controller 10
3P107422-3D
15 ACTION ICONS 1 2 3 4 5
These icons indicate the actions for each day of the
schedule timer.
16 OFF ICON OFF
This icon indicates that the OFF action is selected
when programming the schedule timer.
17 INSPECTION REQUIRED and
These icons indicate that inspection is required.
Consult your installer.
18 SET TEMPERATURE DISPLAY
This indicates the current set temperature of the
installation (not shown in LIMIT operation or in FAN or
DRY mode).
19 SETTING SETTING
Not used, for service purposes only.
20 AIRFLOW DIRECTION ICON
This icon indicates the airflow direction (only for
installations with motorised airflow flaps).
21 NOT AVAILABLE
is displayed whenever a non-installed option
is addressed or a function is not available.
NOT
AVAILABLE
NOT
AVAILABLE
22 FAN SPEED ICON
This icon indicates the set fan speed.
23
DEFROST/HOTSTART MODE ICON
This icon indicates that the defrost/hotstart mode is
active.
24 AIR FILTER CLEANING TIME ICON
This icon indicates the air filter must be cleaned.
Refer to the manual of the indoor unit.
25 ELEMENT CLEANING TIME ICON
This icon indicates the element must be cleaned
(Heat Reclaim Ventilator only).
26
VENTILATION MODE BUTTON
The ventilation mode button operates the Heat
Reclaim Ventilator; refer to the Heat Reclaim
Ventilator manual for more details.
27 V
ENTILATION AMOUNT BUTTON
This button sets the ventilation amount; refer to the
Heat Reclaim Ventilator manual for more details.
28 INSPECTION/TEST OPERATION BUTTON
Not used, for service purposes only.
TEST
29 PROGRAMMING BUTTON
This button is a multi-purpose button.
Depending on the previous manipulations of the user,
the programming button can have various functions.
30
SCHEDULE TIMER BUTTON
This button enables or disables the schedule timer.
31 TIME ADJUST BUTTON
These buttons are used to adjust the clock or, when in
programming mode, to adjust the programmed action
time. Both buttons have an auto-repeat function.
32 TEMPERATURE ADJUST BUTTONS
These buttons are used to adjust the current setpoint
or, when in programming mode, to adjust the
programmed setpoint temperature (step = 1˚C). Both
buttons are also used to adjust the day of the week.
33 OPERATION CHANGE/MIN-MAX BUTTON
This button is a multi-purpose button. Depending on
the previous manipulations of the user, it can have
following functions.
1select the operation mode of the installation
(FAN, DRY, AUTOMATIC, COOLING, HEATING)
2toggle between minimum temperature and
maximum temperature when in limit operation
34 SETPOINT/LIMIT BUTTON
This button toggles between setpoint, limit operation
or OFF (programming mode only).
35
FAN SPEED BUTTON
This button toggles between L (Low), H (High), HH
(very High), (Automatic).
36 AIRFLOW DIRECTION ADJUST BUTTON
This button enables to adjust the airflow direction.
37 AIR FILTER CLEANING TIME ICON RESET
BUTTON
This button is used to reset the air filter cleaning time
icon.
max
min
L H HH

Wired Remote Controller SiME281501E
11 Remote Controller
1.3 MAIN/SUB Setting when Using 2 Remote Controllers
Situation
The MAIN/SUB setting is necessary when 1 indoor unit is controlled by 2 remote controllers. When you use 2
remote controllers (control panel and separate remote controller), set one to MAIN and the other to SUB.
Setting
The remote controllers are set at factory to MAIN, so you only have to change 1 remote controller from MAIN
to SUB. To change a remote controller from MAIN to SUB, proceed as follows:
1.3.1 BRC1C61/BRC1D61
Step Action
1Insert a flathead screwdriver into the recess between the upper and lower part of the remote
controller, as shown in the illustration below. Gently pry off the upper part of the controller, working
from the 2 possible positions.
2Turn the MAIN/SUB changeover switch on the PCB to “S”.
Upper part of the
remote controller
Lower part of the
remote controller
S
M
S
M
The switch is set to MAIN (factory
setting)
Set the switch to SUB.
