Dakota Digital LDM-CA01 User manual

MAN#650162
1
Dual Intensity LED Marker Lights
LDM-CA01 LDM-CR01
LDM-CA25 LDM-CR25
LDM-CA50 LDM-CR50
BLACK
GROUND
BLUE
+12 V
FOR LOW
BRIGHTNESS
VIOLET
+12 V
FOR HIGH
BRIGHTNESS
BODY PANEL WITH HOLE CUT
FOR LIGHT
LIGHT HOUSING
MOUNTING CUP
LOCKING NUTS
#4-40
GASKET BLACK
GROUND
BLUE
+12 V
FOR LOW
BRIGHTNESS
VIOLET
+12 V
FOR HIGH
BRIGHTNESS
Thank you for purchasing Dakota Digital LED marker lights, please take a moment to inventory your
parts and installation hardware. The Marker lights are shipped with all of the necessary components
to mount them. As shown in Figure 1 above:
2 Light assemblies
2 Mounting cups
2 Gaskets
3 Locking # 4- 40 nuts
6 Push-lock connectors
Installation
1. Determine mounting location and position for the lights. Verifying there is enough room behind
the panel/body for the lights and a safe place to route the wires where they will not be cut or
wear due to vibrations/movement.
2. Cut out the appropriate template from the 3 styles provided and tape it to the body in the
desired location. Using the template as a guide, cut the hole using the appropriate tools. Start
by cutting just inside the black line, test fitment, and trim as necessary for a snug fit. Be
extremely careful to avoid cutting any material outside of the gray lines as this would be visible.
3. Use the hardware supplied to secure the marker light into the body. First, install the gasket
around the light, then feed the wires through the hole and slide the marker light into place.
Place the clamp over the studs and secure it using the supplied lock nuts. Tighten until snug.
See the figure above if you have any questions.

MAN#650162
2
4. The marker lights have two brightness levels, they can be connected to a keyed power source,
along with another switched source to flash or enable the second brightness level.
The connections are:
BLACK - Ground, connect to a good chassis ground or negative side of battery
BLUE - Low Brightness, connect to keyed +12 V for running light operation
VIOLET - High Brightness, connect to an auxiliary switched +12 V source, or a flasher for
flashing operation
Note: If only one brightness level is desired, connect the black ground wire and the +12 V
wire for the desired brightness level, leaving the remaining wire disconnected.
Use the supplied moisture resistant pigtail connectors to attach the wires from the new LED assembly
to the existing vehicle harness, solder may also be used. Insert the appropriate wire from vehicle
harness and mating LED assembly wire into a connector and crimp.
The correct crimp method for the supplied connectors is:
1.) Insert UNSTRIPPED wires into the connector and ensure they are all they way in by
observing the clear bottom of the connector to see the wires are touching the end.
2.) Use pliers to push the blue cap down flush with the edge of the clear body, completing the
connection. The connection will only be correct if pressed firmly down with pliers.
WARRANTY
All DAKOTA DIGITAL instruments are warranted free of defects in material and workmanship for 2 years from the
date of purchase. In the event of a problem with one of our products within the warranty period, DAKOTA DIGITAL will
replace or repair the instrument at no charge. (The decision to repair or replace is solely that of DAKOTA DIGITAL.
DAKOTA DIGITAL is not responsible for shipping costs of products returned under warranty or for labor charges for
product installation and removal.) This warranty becomes invalid if the product is misused, altered or installed incorrectly.
For warranty coverage, you must first call to receive an RMA#. Ship the product transportation prepaid via
UPS or insured Parcel Post. A copy of the original invoice or dated bill of sale along with a description of the defect is
also required. Make sure that the RMA number is clearly visible on the outside of the package as well as inside on the
paper work.
The above warranties, both expressed and implied, do not cover damages caused by improper installation,
misuse, abuse, fire, unauthorized modifications, floods or acts of God, or reimbursement of customer or shop time. The
extent of the warranty is limited only to the product and does not cover any loss or damage to vehicle, equipment, or non-
DAKOTA DIGITAL products.
SERVICE AND REPAIR
DAKOTA DIGITAL offers complete service and repair of its product line. In addition, technical consultation is
available to help you work through any questions or problems you may be having installing one of our units.
Should you ever need to send the unit back for repairs, please package the product in a good quality box along
with plenty of packing material. Ship the product by UPS or insured Parcel Post. Be sure to include your RMA#, a
complete description of the problem, your full name and address (street address preferred), and a telephone number
where you can be reached during the day. A return authorization number (RMA#) for products being return for
repair is required. Do not send any money. We will bill you for the repair charges.
4510 W. 61ST St. N., Sioux Falls, SD 57107
Phone: [phone] FAX: [phone]
www.dakotadigital.com
[e-mail]
©Copyright 2006 Dakota Digital Inc.
