DALCNET DLB1248 Series Application guide

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.1/ 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]
FEATURES
•BLUETOOTH+FADER+DIMMER+DRIVER
•DC Input: 12-24-48 Vdc or 12-24 Vdc
•Remote command options:
-Bluetooth Low Energy (BLE Smart)
•Local command options:
-Normally Open push-button
•Adjusting the brightness of while light
•Current outputs or Voltage outputs for R-L-C load
•Voltage outputs for R load
•Typical efficiency > 95%
•Adjusting the brightness up to completed off
•Memory function
•Soft start and soft stop
•Optimized output curve
•Extended temperature range
•100% Functional test –5 Years warranty
→ For the whole and updated Device Manual refer to producer’s website: http://www.dalcnet.com
➢CONSTANT CURRENT VARIANTS (common anode)
Application: Dimmer
CODE
Input Voltage
Output
Channels
Commands
DLB1248-1CC350-BLE
12-48V DC
1 x 350mA
1
BLE-1 N.O. push button
DLB1248-1CC500-BLE
12-48V DC
1 x 500mA
1
BLE-1 N.O. push button
DLB1248-1CC700-BLE
12-48V DC
1 x 700mA
1
BLE-1 N.O. push button
DLB1248-1CC950-BLE
12-48V DC
1 x 950mA
1
BLE-1 N.O. push button
Any current value in the range from 350mA to 950mA is available on demand.
➢CONSTANT VOLTAGE VARIANTS (common anode)
Application: Dimmer
CODE
Input Voltage
Output
Channels
Commands
DLB1248-1CV-BLE
12-48V DC
1 x 6,5 A
1
BLE –1 N.O. push button
DLB1224-1CV-BLE
12-24V DC
1 x 10 A
1
BLE –1 N.O. push button
➢PROTECTIONS
DLC1248-1CV
DLC 1224-1CV
DLC1248-1CC
OTP
Over temperature protection1
✓
✓
OVP
Over voltage protection2
✓
✓
✓
UVP
Under voltage protection2
✓
✓
✓
RVP
Reverse polarity protection2
✓
✓
✓
IFP
Input fuse protection2
✓
✓
✓
SCP
Short circuit protection
✓
✓
OCP
Open circuit protection
✓
✓
✓
CLP
Current limit protection
✓
✓
1
Thermal Protection on the output channel in case of high temperature. The thermal intervention is detected by transistor (>150°C) or by constant current LED
driver regulation in current variant (>150°C).
2
Only control logic protection

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.2/ 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]
➢REFERENCE STANDARDS
EN 61347-1
Lamp controlgear - Part 1: General and safety requirements
EN 55015
Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment
EN 61547
Equipment for general lighting purposes - EMC immunity requirements
EN 50581
Technical documentation for the assessment of electrical and electronic products with respect to the restriction of
hazardous substances
➢TECHNICAL SPECIFICATIONS
Variants
Constant current
Constant voltage
350mA
500mA
700mA
950mA
12/24/48 Vdc
12/24 Vdc
Supply voltage
min: 10,8 Vdc .. max: 52,8 Vdc
min: 10,8 Vdc
max: 52,8 Vdc
min: 10,8 Vdc
max: 26,4 Vdc
Output voltage
min: Vin/4 - max: Vin-0,9V
=Vin
=Vin
Input current
max 0,35A
max 0,5A
max 0,7A
max 0,95A
max 6,5A
max 10A
Output current
350 mA
500 mA
700 mA
950 mA
max 8 A peak
max 10 A
Absorbed nominal power
@12V
4.2 W
6 W
8.4 W
11.4 W
@24V
8.4 W
12 W
16.8 W
22.8 W
@48V
16.8 W
24 W
33.6 W
45.6 W
Power loss in standby mode
<500mW
<500mW
Type of Load
R-L-C
R-L-C
R
Thermal shutdown
150°C
150°C
-
D-PWM dimming frequency
300 Hz
D-PWM resolution
16 bit
D-PWM range
0,1 –100 %
Storage Temperature
min: -40 max: +60 °C
Ambient Temperature
min: -10 max: +40 °C
Wiring
2.5mm2 solid - 2.5mm2stranded - 30/12 AWG
Wire preparation length
5,5 –6,5 mm
Protection grade
IP20
Casing material
Plastic
Packaging unit (pieces/unit)
Carton Box 21pz
Mechanical dimensions
44 x 57 x 25 mm
Package dimensions
263 x 178 x 82 mm
Weight
1000g

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.3/ 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]






➢INSTALLATION
To set the product, follow the instruction on the picture below:
1) connect the LED in the output terminal blocks “OUT” of the device.
2) connect the N.O. push button in the correct terminals of the device
3) connect the power supply (12-24 Vdc or 12-48 Vdc depending on the dimmer model) to terminal blocks “DC IN” of the device.

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.4/ 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]
➢TECHNICAL NOTES
Installation:
•Installation and maintenance must be performed only by qualified personnel in compliance with current regulations.
•The product must be installed inside an electrical panel protected against overvoltages.
•The product must be installed in a vertical or horizontal position with the cover / label upwards or vertically; Other positions are not
permitted. It is not permitted to bottom-up position (with the cover / label down).
•Keep separated the circuits at 230V (LV) and the circuits not SELV from circuits to low voltage (SELV) and from any connection with this
product. It is absolutely forbidden to connect, for any reason whatsoever, directly or indirectly, the 230V mains voltage to the bus or to
other parts of the circuit.
Power supply:
•For the power supply use only a SELV power supplies with limited current, short circuit protection and the power must be dimensioned
correctly. In case of using power supply with ground terminals, all points of the protective earth (PE = Protection Earth) must be
connected to a valid and certified protection earth.
•The connection cables between the power source "low voltage" and the product must be dimensioned correctly and they should be
isolated from every wiring or parts at voltage not SELV. Use double insulated cables.
•Dimension the power supply for the load connected to the device. If the power supply is oversized compared with the maximum
absorbed current, insert a protection against over-current between the power supply and the device.
•For the constant current output, the voltage of LED module (Vf) must be less of 5V at the voltage of power supply.
Command:
•The length of the connection cables between the local commands (N.O. Push button or other) and the product must be less than 10m;
the cables must be dimensioned correctly and they should be isolated from every wiring or parts at voltage not SELV. Use double
insulated shielded and twisted cables.
•All the product and the control signal connect at the local command (N.O. Push button or other) must be SELV (the devices connected
must be SELV or supply a SELV signal)
Outputs:
•The length of the connection cables between the product and the LED module must be less than 10m; the cables must be dimensioned
correctly and they should be isolated from every wiring or parts at voltage not SELV. Is preferable to use shielded and twisted cables.

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.5/ 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]
➢LOCAL COMMAND
PUSH DIMMER FEATURE
The intensity and the status (ON/OFF) is controlled by the N.O. push button.
Button
Intensity
Click
Double click
Long pressure (>1s) from OFF
Long pressure (>1s) from ON
Long pressure (>5s) case BLE from ON
On/Off
Maximum intensity
Turn ON at 1% (Nightly Time), then dimmer up/down
Dimmer up/down
To recognition of BlueDimmer App (pairing APP)

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.6/ 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]
  
➢BLUETOOTH SMART SETUP
FEATURES
•Bluetooth LOW ENERGY 4.1
RELATION WITH LOCAL COMMANDS
Both local and remote commands can act simultaneously.
The remote control can monitor the output status in real time.
ADRESSSING
Unique ID
✓
CHANNEL MAPS
The intensity and the status (ON/OFF) is controlled by a Bluetooth device
Channel
Function
Value
1
Dimmer
Intensity [0.255]
COMPATIBLE APPS
•Bluedimmer
The BlueDimmer Low Energy applications is used to control through smartphone and tablet modules and
strip LED connected to the dimmer DLB1248-BLE-1CH.
The APP implements the following functions:
•Turning on
•Turning off
•Dimmer up and down
•master dimmer multi source

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.7/ 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]
➢BLUEDIMMER SOFTWARE INSTRUCTIONS
Necessary conditions for the correct use of the device:
•APPLE device with ON Bluetooth Low Energy 4.1 version
•ANDROID device with ON Bluetooth Low Energy 4.1 version
•Dalcnet Product DLB1248 with BLE smart function
•Strip Led or spotlight
•N.O. Push-Button
•Bluedimmer App, available on the App Store and Play Store, download for free.
SCHEME

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.8/ 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]
➢APP INSTALLATION ON THE DEVICE
Download for free and install the application on your smartphone and tablet.
OSSERVATION:
On the version of Android 6.0 is necessary allow at BlueDimmer application to access
Your location.
START UP SEQUENCE IMAGES
Automatic research and identification of DALCNET DLB1248 with BLE function products.
N.B.:
Manual research is possible by clicking on the lens symbol at the bottom of your device’s screen.
Example of results of the research:
-Device in blue = device associated and ready for use
-Device in black = new device to pair
-Device in grey = device already associated but not available

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.9/ 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]
HOW TO ASSOCIATE THE DEVICE TO THE BLUEDIMMER APPLICATION
1- Set selectors S1 and S2 according to the load you want to drive.
2- Select on the smartphone/tablet the connected device.
The strip led or spotlight connected to the selected device will automatically light on
3- Keep press for 5 sec the push button connected to the light-on-led for pairing. From firmware version 1.2 the pairing is automatic.

DLB1248 single channel
EASY-BLE
Device Manual
Made in Italy
Rev. 2020-10-27
Pag.10 / 10
DALCNET S.r.l, Registered office: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
Headquarters: Via Lago di Garda, 22 –36077 Altavilla Vicentina (VI) –Italy
VAT: IT0423100235 –Tel. [phone] - www.dalcnet.com –[e-mail]
4- On the screen will appear a box to name the strip led or spotlight controlled by DALCNET BLE device.
For ex.: you can name 'kitchen' the light in the kitchen, and 'living' the one in the living room. This is a simple way to control the lights in your
house.
5- DALCNET device has now been correctly paired and ready for use.
You will see the lamp name on the display. Here you can start controlling your led light.
White
LEGEND:
on/off
dimmer
back to search devices menu
