Integrated Interface
DY-700K
Instruction
Manual
Danacoid International Pte Ltd.

!2!/!7!
!
I. Product Appearance and
Description
! Power indicator: The indicator of power supply,
which becomes on when the device is electrified
" RUN indicator: The indicator of device running,
which becomes on during signal transmission
# LAN indicator: The indicator of internet access,
which becomes on when the cable is
well-connected
# Panel: Display the name and IP address of the
interface machine
! Ground terminal: Used for connection of device
shell and grounding wire terminal or bolt
" RESET key: Use a long and thin object to press
the key for 10 seconds to reset the device
parameters and restore factory settings
$ Power port: Connect to the power cable for
power supply
# HDMI interface: Transmit audio and video signal;
HDMI IN is the input interface that connects to
the interface of signal source; HDMI OUT is the
output interface that connects to the interface of
display device
% Internet Access: For internet access or power
over Ethernet (POE)

!3!/!7!
!
& Audio interface: Transmit audio signal; LINE IN
is the input interface that connects to the
interface of signal source; LINE OUT is the
output interface that connects to the interface of
amplification equipment
' Dial Switch: Select the operating mode of the
interface machine, dial IN and the interface
machine becomes input interface machine; dial
OUT, and the interface machine becomes output
interface machine
( USB interface: Used for KVM, connect to
keyboard and mouse
) RS232 interface: Exert control over interface
machine through 232 wire
II. Product Features
n 4K ultra-high-definition interface machine,
integrated input and output
n Support input of signals like VGA, DVI and
HDMI
n Support 4K@30HZ ultra-high-definition input,
support a resolution within
800x600~3840x2160, and support
customization
n Support real-time coding of H.265 hardware,
compatible with H.264 hardware
n Support sync acquisition of audio and video,
ensuring the sync transmission of audio and
video
n Support local ring-out of signals, signal
distributor not required
n Integrated KVM function
n Support dynamic captions

!4!/!7!
!
n Support ultra-high-definition image or video
base
n Integrated central control function,
standardized programmable serial peripheral
interface
n Support unlimited distribution of video
streams
n Support preview and echo of real-time signal,
WYSIWYG
n Support single-screen or multi-screen splicing
and display, achieve accurate synchronous
splicing, automated calibration, with a sync
error below 0.1ms
n Support dual-network hardware backup
n Adopt embedded hardware, ensuring 7*24
stable operation

!5!/!7!
!
III. Product Specifications
Product Model
DM-700LK
Input Mode
1-channel HDMI v1.4 input and
1-channel dual-track stereo input,
3.5mm audio jack, 1-channel
HDMI ring-out
Output Mode
1-channel HDMI v1.4 output and
1-channel dual-track stereo output,
3.5mm audio jack; USB: 2 USB
interfaces, achieve KVM function
Network
2 RJ45 interfaces, 1000Mbps
Ethernet
Serial
Communication
1 D-Sub 9, support RS232 or 485
control protocol
OLED Panel
Display of IP address, device name
and other information
Indicators
POWER indicator, LINK indicator,
RUN indicator
Power Supply
DC12V 3A (POE optional)
Power
Consumption
20W
Operating
Temperature
0~ +40
Operating
Humidity
10% ~ 90%, non-condensing
Dimensions
250*161.5*34mm

!6!/!7!
!
IV. System Architecture
1) Confirm that there is DHCP server or router with
DHCP functions in the network, so as to allocate
legitimate IP addresses to all network devices in the
system
2) Set the IP address of MICS server as static, such as
192.168.1.80, which will be beneficial to client login
and IIS setting
3) Conduct system connection and construction in
accordance with the above architecture
4) Connect the decoding device to the display device
(DLP/LCD or projector) through HDMI cable, and
connect the internet interface of decoding node to the
exchange through Cat5e or Cat6
5) Connect the signal source (computer, DVD, analog
camera, Blu-ray DVD, high-definition camera etc.) to
the coding nodes of MICS system through respective
dedicated cable, and connect the internet interface of

!7!/!7!
!
coding node to the exchange through Cat5e or Cat6
cable
6) All devices are electrified for operation
