Danby Fresh DFG19 Assembly instructions

Model Modèle
D
FREEZER
CONGÉLATEUR
Owner’s Use and Care Guide
Guide d’utilisation et soins de Propriètaire
C
E
R
T
I
F
I
E
D
C
E
R
T
I
F
I
E
D
MODEL • MODÈLE
FOR YOUR SAFETY: Read these instructions carefully before operating the unit.
POUR VOTRE SÉCURITÉ: Lire attentivement ces instructions avant d’utiliser l’appareil.
OWNER’S USE AND CARE GUIDE
GUIDE D’UTILISATION ET SOIN DE PROPRIÈTAIRE
DFG19
DFG24
2017.01.06

CONTENTS * TABLE DES MATIÈRES
DANBY FRESH GROWER
Owner’s Use and Care Guide..........1
• Electrical Requirements
• Grounding Instructions
• Safety Requirements
• Operating Instructions
• Care and Maintenance
• Frequently Asked Questions
• Troubleshooting
• Warranty
DANBY FRAIS CULTIVATEUR
Guide d’utiliser et soin propriètaire.......
Read and follow all safety rules and operating instructions before first
use of this product.
Veuillez lire attentivement les consignes de sécurité et les
instructions d’utilisation avant l’utilisation initiale de ce produit.
TO OBTAIN WARRANTY YOU MUST PROVIDE A VALID PROOF OF
PURCHASE.
STAPLE YOUR RECEIPT TO THIS PAGE FOR FUTURE REFERENCE.
POUR OBTENIR LE GARANTIE, VOUS DEVEZ FOURNIR UNE
PREUVE D’ACHAT VALIDE. AGRAFER VOTRE REÇU À CETTE PAGE
POUR RÉFÉRENCE FUTURE.

1
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
ELECTRICAL REQUIREMENTS
To avoid installation or operation difficulties, read these instructions thoroughly.
• This appliance must be grounded. Connect only to a properly grounded outlet. See “Grounding
Instructions” section.
• Do not operate this appliance if it has a damaged power cord or plug.
• Never allow children to operate, play with, or crawl inside the appliance.
• Never clean appliance parts with flammable fluids. The fumes can create a fire hazard or explosion.
• Do not store or use gasoline or any other flammable vapors or liquids in the vicinity of this or any
other appliance. The fumes can create a fire hazard or explosion.
• Do not splice the power cord that is equipped with this appliance.
• Keep power cord away from heated surfaces.
• Do not immerse power cord, plug or the appliance itself in water.
• Do not use this product near water for example, in a wet basement, laundry room or near a sink.
• Do not use corrosive chemicals or vapors in this appliance.
• Use this appliance only for its intended use, as described in this manual.
• Do not cover or block the fan openings on the appliance.
• This appliance is intended for household use only. Do not operate or store this appliance outdoors.
An empty appliance is a very dangerous attraction to children. Remove either the gasket or
door from unused appliances, or take some other action that will guarantee it harmless.
DANGER: Risk of child entrapment. Before you throw away your old appliance:
• Take off doors.
• Leave the shelves in place so that children may not easily climb in.
DON’T WAIT! DO IT NOW!
IMPORTANT WARNING
SAVE THESE INSTRUCTIONS!
GROUNDING INSTRUCTIONS
This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed and grounded. This appliance must be grounded.
In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current.
WARNING - Improper use of the grounding plug can result in a risk of electric shock. Consult a quali-
fied electrician or service agent if the grounding instructions are not completely understood, or if doubt
exists as to whether the appliance is properly grounded.
If the outlet is a standard 2-prong wall outlet, it is your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
For best operation, plug this appliance into its own electrical outlet to prevent flickering of lights, blow-
ing of fuse or tripping of circuit breaker
DO NOT USE AN EXTENSION CORD
Use an exclusive 115V wall outlet. Do not connect your appliance to extension cords or together with
another appliance in the same wall outlet. Do not splice the cord. Do not under any circumstances cut
or remove the third (ground) prong from the power cord. Do not use and adapter plug with this appli-
ance.

SAVE THESE INSTRUCTIONS!
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAFETY REQUIREMENTS
• This appliance is not intended for use by persons (including children) whose physical, sensory
or mental capabilities may be different or reduced, or who lack experience or knowledge, unless
such persons receive supervision or training to operate the appliance by a person responsible for
their safety.
• Ensure that the unit is turned off and unplugged before any changes are made to the light system.
• Keep the door closed as much as possible to ensure proper temperature and moisture levels for
your plants.
• Always unplug the power cord and disconnect the timer when not in use.
• Only use genuine spare parts from Danby or those that have been CSA, UL or CE approved.
• The LED light panel is not water proof. Do not spray water on the surface, sides or back of the
light panel.
• Do not look directly at the LED light with the naked eye as this can cause retinal damage.
• Recommended operating temperature is between 20 ~ 30 °C (68 ~ 86 °F).
• Recommended operating humidity is below 80%.
• The LED panel cannot be exposed to corrosive materials.
• The LED panel is for indoor growing only and should not be used outdoors.
• Do not touch the surface of the light system while the power is connected as it can get hot.
• Do not use the LED panel during a thunderstorm to avoid a surge that could damage the light
system.
• Do not cover shelves with aluminum foil or any other material which may prevent air circulation.
LOCATION
Select a location with a strong level floor that can support the weight of the unit and the plants grown
inside.
Allow 5 inches (12.7 cm) between the back of the appliance and the wall. Allow 1 inch (2.5 cm) of
space between the sides of the appliance and any adjacent walls.
Avoid direct sublight and heat. Direct sunlight may affect the acrylic coating of the appliance or the
growing cycle of your plants. Nearby heat sources can overheat the unit and cause high internal tem-
peratures that may harm your plants.
Operating Instructions
LEVELING INSTRUCTIONS
Beneath the appliance there are two leveling legs that are located on
either side of the vent. It is important that your unit is level. To level the
unit:
1. Move the appliance to its final location.
2. Have someone gently lean against the front of the unit to take some
weight off the leveling legs.
3. Turn the leveling legs clockwise to raise the unit or counter-clock-
wise to lower it. Continue in this manner until the unit is level.
Fig A
Raises
the Leg
(lowers
the unit) Lowers
the Leg (raises
the unit)
2

3
FEATURES
1. Tempered glass door: Used to reflect and absorb heat.
Note: door swing cannot be reversed.
2. Magnetic door gasket: Tight fitting seals to ensure that
excess moisture cannot enter or escape the unit.
3. Handle
4. Mars Hydro Light system: Not pictured. Can be set to
vegitative or blooming light cycles.
5. Shelves: Two metal wire shelves provided.
6. Leveling legs: Used to ensure the unit it level and stable.
7. Fan: Not pictured. Fan will run continuously to ensure your
plants have adequate fresh air.
Note: Your appliance may look slightly different based on the
cabinet that was used to build the Danby Fresh Grower.
Note: Two plastic trays are included with the unit. Place plant
pots on these trays to ensure that if water leaks from the plant
pots it will not leak from the unit and damage your floors.
2
3
1
5
6
4
Operating Instructions
SHELVES - DGA19
Make sure the shelf is aligned with the lock block when taking the shelf
out or putting it back into the unit.
To remove a rack from its locked position, tilt the rack as shown and pull
outward.
To re-install, ensure the rack is resting securely on the support brackets
and push the rack inward until it locks into place.
SHELVES - DGA24
To remove shelves:
Fully extend the shelf you wish to remove.
Lift the front of the shelf up.
Holding the shelf track, push the shelf in, then up to release from
the rear dampers.

Operating Instructions
OPERATING INSTRUCTIONS
The Danby Fresh Grower will arrive fully assembled (will it?) and ready to use. Ensure that
you plug the power cord into a 3 prong grounded outlet.
The fan in the unit will run continuously to ensure that your plants have adequate fresh air. The fan
can only be turned off by unplugging the unit.
Two metal wire shelves are included with the unit that can be removed and adjusted to different levels
to accomodate different growing heights. Please use caution when removing a shelf as it may be un-
balanced, heavy or contain residual water. Do not remove shelving without first removing everything
on the shelf.
Timer function
The timer can be used to create a regular light and dark cycle for your lights just as they would re-
ceive outside. The timer will turn the light on and off as required based on the settings you choose.
Keep in mind that different plants will grow best under different light cycle conditions; some need
more light and some need less. We recommend checking the seed packet for informaiton on the best
light cycle to choose for your plants.
The circular face of the timer can be turned clockwise to set the current time. The current time is indi-
cated by aligning the arrow on the timer face with the corresponding hour of the day.
Based on the type of plants you are growing, decide at which hours you would like the light to be on
and off.Around the outside of the timer face are buttons which encompass 15 minutes of time each.
To set the time, press down each button during the time frame that you would like the light to remain
on.
Ensure that you plug the timer into a 3 prong grounded outlet and then plug the power cord of the
grower into the timer. Ensure that the switch on the top of the timer is set to “timer on”.
You can change the hours that the light is on or off at any time by pulling up or pushing down the but-
tons around the outside of the timer face.
Growing tips
There are two switches on the LED light system which will provide different types of light depending
on what stage of growth your plants are in.
The Growth setting is best used when your plants are seedlings or in the early phases of growth.
When your plants are big enough to flower and bloom, turn on both the Growth and Bloom buttons
to provide the full spectrum of light. The length of the growth and blooming growing cycles will vary
depending on what type of plants you are growing.
In general for most herbs and vegetables, we recommend the following light cycles:
Growth cycle: 18 hours on / 6 hours off or 20 hours on / 4 hours off for approximately 20 to 30 days.
Bloom cycle: 12 hours on / 12 hours off for approximately 20 - 30 days.
Typically most herbs and vegetables have a maturity date between 45 - 90 days. How long your
plants take to mature will vary based on what type of plants you are growing.
Note: Danby Products Ltd will accept no liability for any lost plants or weak harvests based on inap-
propriate use of the timer and light system.
4

Care and Maintenance
CLEANING
Cleaning the Inside:
• Walls, floor, inside window and shelves - Some water deposits and dust can be removed with a
dry paper towel, others may require a damp cloth.
Cleaning the Outside:
• Outer Case - It is important to keep the area clean where the door seals against the cabinet.
Clean this area with a soapy cloth. Rinse with a damp cloth and let dry.
• Door - Wipe with a damp cloth and dry thoroughly. Some paper towels may scratch the glass on
the door. Use only mild, non-abrasive detergents applied with a clean sponge or soft cloth. Rinse
well with damp cloth.
NOTE: Do not use cleaners containing ammonia or alcohol on the appliance. Ammonia or alcohol can
damage the appearance of the appliance. Never use any commercial / abrasive cleaners or sharp
objects on any part of the appliance.
FREQUENTLY ASKED QUESTIONS
1. How do I set my timer?
• The circular face can be turned clockwise to set the current time. The current time is indicated by
aligning the arrow on the circular face with the corresponding current hour of the day. On the pe-
rimeter of the circular face are notches that can be pushed in and out to set the times that the light
will be on or off. When the notches are pushed down, than the light will be on. Notches pulled up
will result in the light being off. Each notch represents 15 minutes of time. You can control which
hours are on or off by working around the current time you set in the beginning.
2. How do I control the fans?
• The fans are meant to be on constantly so that plants will always have an uninterrupted source of
fresh air circulating through the unit.
3. How do I control the light?
• The light is meant to be set on a timer so that plants have a consistent, predictable light and dark
cycle to get the best results. The timer ensures that you never have to remember to turn the light
on or off.
4. How often do I need to water?
• The best tip for watering is to use the trays provided. Place plant pots into the tray and water by
adding approximately an inch of water to the tray for the plants to soak up as needed. Try to keep
as least some water in the trays at all times.
5. Why does the light look purple?
• The purple tint of the light is the result of a combination of colors derived from the sun’s spectrum.
Simple white grow lights do not provide plants with the full spectrum of light that the sun provides
so the result is less healthy plants and less hearty harvests. Our ultra-efficient and advanced LED
full spectrum lights cover more spectrum than any other grow lights. The combination of the reds
and blues among other colors create the purplish color.
6. There is no power to the unit.
• Ensure that there are no blown fuses or tripped circuit breakers in your home. Ensure that the
power plug is fully inserted into the outlet. Unplug the unit, wait 2 minutes and then plug it back in.
Should you have any questions or concerns about the functioning of your unit that is not described
above, please call our Toll Free Number: 1-800-263-2629 for assistance. The call centre is available
Monday to Thursday 8:30 am - 5:00 pm Eastern Standard Time and Friday 8:30 am - 4:00 pm EST.
5

6
WARRANTY PLACE HOLDER
No service, only replacement of individual
parts. No replacement on chassis.
Spoke to Linda, she has concerns on how the
warranty will be administered. She suggests
we do 90 days for all components. She says if
we are installing the light we are voiding the
warranty on the light and all responsibility
will fall to us. She thinks 2 years is too much
on a component that we do not hold the certi-
fication for.
MARS HYDRO LIGHT SYSTEM TECHNICAL SPECIFICATIONS
The LED light system is a 90 Watt full spectrum LED comparable to 250 Watt professional grow
lights. Specifications are as follows:
Draw power: 120V: 102W±5%, 240V: 100.6W±5%
BTU: 409
Amps: 0.847@ 120v | 0.462@ 240v
Voltage: 85 V - 265 V
Noise rating: 56 decibles
Net weight: 7 lb. (2.48 Kg)
Dimensions: 12” x 12” x 2” (30cm x 30cm x 6cm)
Coverage: 2’ x 2’ (60cm x 60cm)
Lifespan: 50,000 hours
View angle of LEDs: 90° - 120°
Light spectrum: 440nm, 460nm, 630nm, 660nm,730nm(IR), 2700k-3000k
Ideal ambient temperature: 80°F -100°F (30°C - 40°C)

Tel: 1-800-26-
(1-800-263-2629)
CONGÉLATEUR
Le numéro de modèle se trouve sur la plaque
d’information sur la paroi arriere de l’appareil.
Toutes les pieces de rechange ou commandes speciales
sont disponsibles de votre centre regional de service
autorise. Pour exiger le service et-ou le nom de votre
centre de service regional, signalez le numéro sans frais
de Danby.
Ayez les renseignements suivants á la portée de la main
lors de la commande de pièce ou service:
Genre de produit
Numéro de modèle
Description de la pièce
REEZER
The model number can be found on the serial plate located
on the back panel of the unit.
All repair parts available for purchase or special order when
you visit your nearest service depot. To request service
and/or the location of the service depot nearest you, call
Danby toll free.
When requesting service or ordering parts, always provide
the following information:
Product Type
Model Number
Part Description
Danby Products Limited, Guelph, Ontario, Canada N1H 6Z9
Danby Products Inc. Findlay, Ohio, U.S.A. 45840
Printed in Canada
Imprimé au Canada
