Danfoss Heating
TPOne-S
Electronic Programmable Room Thermostat
Installation Guide

2TPOne-S
Danfoss can accept no responsibility for possible errors in catalogues, brochures, and other
printed material. All trademarks in this material are property of the respective companies.
Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
ErP Class
The products represented within this document are classified according
to, and allow completion of, the Energy Related Product (ErP) Directive
System Package fiche and the ErP system data label. ErP Labelling
obligation is applicable from 26th September 2015.
ERP Class Product Function and ErP Description
Additional
efficiency
gain
V
Modulating Room Thermostat, for use with
modulating heaters
An electronic room thermostat that varies the
flow temperature of the water leaving the
heater dependent upon measured room tem-
perature deviation from room thermostat set
point. Control is achieved by modulating the
output of the heater.
3%
ErP
5
Product
Class
SIMPLIFIED EU DECLARATION OF CONFORMITY
The simplified EU declaration of conformity referred to in Article 10(9) shall be
provided as follows:
Hereby, Danfoss A/S declares that the radio equipment type TPOne-S are in
compliance with Directive 2014/53/EU
The full text of the EU declaration of conformity is available at the following inter-
net address: heating.danfoss.com

Danfoss Heating 3
Installation Instructions
Specifications TPOne-S DBR
Operating Voltage 230V AC, 50 Hz
Setting temperature range 5-35°C -
Operating temprature range 0-45°C
Switch rating - 3A (1) at 230Vac
Switch type - SPST Type 1A
Transmission frequency 868.42 MHz
WiFi Specification 802.11b/g (2.4GHz) -
Transmission range (in
normal buildings) up to 30m
Transmission power Max 1 mW
IP rating IP20 IP40
On/off control Yes
Chrono-proportional control Yes
Operating mode Heating -
Construction EN 60730-2-9 EN 60730-1
Control pollution situation Degree 2
Rated impulse voltage 2.5kV
Ball pressure test 75°C
Dimensions (mm) H66 x W155 x D30 H84 x W84 x D30
Software Classification A
Important note RF products: Ensure that there are no large metal objects,
such as boiler cases or other large appliances, in line of sight between the
transmitter and receiver as these will prevent communication between
thermostat and receiver.

4TPOne-S
OK
Mounting
Thermostat positioning:
30
cm
MIN

30m MAX
Please note: This product should only be installed by
a qualified electrician or competent heating installer
and should be in accordance with the local wiring
regulations.
Note: These products use RF (Radio Frequency) technology to
communicate with each other and it is important that care is taken
during installation to ensure good wireless connection. Building
structure and materials may influence performance and large metal
objects such as boiler cases, appliances or mirrors in line of sight
between the thermostat and the receiver will prevent communication.
The receiver should be mounted near to the heat source leaving
a minimum distance of 30cm away from any metal enclosures or
appliance and positioned so that no large metal obstruction is between
the receiver and thermostat. The thermostat can be mounted remotely
up to 30m from the receiver while considering signal strength will
be reduce as it passes through walls and ceilings. Walls and ceilings
containing steel reinforcement or with metal foil lined insulation will
also have a significant effect on communication distance and may
block signal completely.
It is recommended that the RF connection should be checked
before permanently mounting the thermostat and where necessary
the location of the thermostat must be moved to ensure reliable
communication. The thermostat should be mounted at a height of
approximately 1.5m from the floor and away from draughts or heat
sources such as radiators, open fires or direct sunlight.

Danfoss Heating 5
TPOne-S wiring
Wiring
DBR Receiver
DBR Receiver
1NL 234
230 VacCOM OUT
(Not Used)
NL
230 Vac
Note: When using the table stand ONLY USE the power
supply and USB cable provided.

6TPOne-S
Comfort modes
User Interface
Display Navigation
Comfort Modes
Heating made easy: TPOne Comfort Modes simplify the way you
plan your heating day to day. You define your comfort modes in the
user schedule and manually override when you need, allowing you
to adapt your schedule to the way you live.
The Home, Away and Asleep comfort modes are linked to your
defined comfort temperatures. The schedule follows the daily
routine you have set or you just choose the comfort mode required
and TPOne will recall the settings you have defined.
The TPOne Standby Mode allows you to switch your heating off
when not required although the thermostat continues to monitor
the room temperature and call for heating should there be a risk of
frost damage.

Danfoss Heating 7
Comfort Modes
Home
Home Mode selects the home comfort
temperature typically when the home is
occupied during the day. The required
temperatures for Home mode are selectable
in the Temperature setting (see User Menu
> Temperatures.) A separate Home AM and
Home PM temperature can be chosen and
these are automatically set according to the
time of the day.
Note: When in Home mode if the home button
is pressed again a 1, 2 or 3 hour heating boost
is selected and the current home period is
extended by the chosen time period. The
chosen boost period is displayed under the
Home icon on the display.
Away
Away Mode selects the away comfort
temperature typically when the home is
unoccupied during the day. The required
temperature for Away mode is selectable in
the Temperature setting (see User Menu >
Temperatures).
Asleep
Asleep Mode selects the nightime comfort
temperature which is set between the end
of the last home period of the day and the
beginning of the first home period of the
following day. The required temperature for
Asleep mode is selectable in the Temperature
setting (see User Menu > Temperatures).
Standby
The TPOne can be placed in Standby
Mode. While in Standby the TPOne will
not control the heating system other than
to protect against frost damage (see User
Menu > Installer Settings > Frost Protect for
information on frost protect). Standby can
be cancelled by pressing the Standby button
again or by selecting another comfort mode.
Note: the standby option places the heating
control in standby only, if Hot Water is set
up this is not affected. To switch Hot Water
control off see User Menu > Hot Water > Mode

8TPOne-S
OK
Navigation
Menu
Press Menu to access the intuitive text menu.
The common feature User Menu will be
displayed first. Additional settings can found
in the User Setting option and more advance
settings can be found in the Installer Setting
option.
OK Select /
Confirm
Press OK to select menu options or confirm
settings. OK will be shown on the display
when it can be used or is required.
Menu
Back
Press to exit a menu option. Pressing 
while in a setting will result in that setting
change not be accepted. will also exit the
menu system. will be shown on the display
when it can be used
Naviga-
tion
The Navigation buttons are used to navigate
the TPOne menus and change setting values.
The up & down buttons are also used to
manually change the required temperature.
Navigation arrows will be shown on the
display when these buttons can be used.

Danfoss Heating 9
Button
Lock
Indicates that Button Lock has been activated to
avoid unintentional setting changes. To activate
buttons while button lock is active press the OK
button for 5 seconds. The Button Lock setting is
found in the Installer Menu.
Heat
Calling
When the current room temperature is below the
required room set temperature the TPOne will call
for heating from the connected heat source. This is
indicated by the Heat Calling icon.
Hot
Water
Calling
Where the TPOne-S has been set up for control
of domestic hot water the TPOne will call for
hot water heating according to the user set
schedule. This is indicated by the Hot Water
Calling icon.
The TPOne-S is connected by radio signal to a
receiver. The Radio Frequency icon will be displayed
to confirm that this connection is active and that the
TPOne-S is controlling the heating.
If connection is lost the icon will go off and a warning
will be shown at the top of the display.
Important Note: Ensure that there are no large metal
objects, such as boiler cases, other large appliances
or mirrors in line of sight between the transmitter
and receiver as these will prevent communication
between the TPOne-S and receiver.
Display
Info & Settings Status Icons Dates &
Warnings
21.5°
16:35 Mon
NOTE:
TPOne monitors several conditions and will provide warning or
information messages when necessary. Details on these can be
found on pages 26-29.

10 TPOne-S
Setup Wizard/ Unit
The setup wizard will run when power is first applied to the TPOne.
Once set the further changes can be made in the user and installer
setting menus.
 OK
RF Pairing
RF Pairing
Language
English 
 OK
Set Date
 04 - 02 - 2016 
 OK


Set Time
 24hr - 10 : 45 
 OK


OK
OK
OK
OK
OK
OK
OK
OK
READY
OK
DBR Receiver
21. 5
o
10:45 Thurs
Press button on
reciever to confirm
Press OK to pair
Hot Water Setup
 OFF 
 OK
OK
OK

Danfoss Heating 11
Set Temperatures/ Unit
Home AM - 21. 0
oC
Home PM - 22. 0
oC
Away - 16. 0
oC
Asleep - 12. 5
oC
 OK
User Menu
Temperatures
 OK


Temperatures
 AM  21. 0
o
 OK
21. 5
o
10:45 Thurs


User Menu
Temperatures
 OK


OK
OK
OK
OK
OK
OK

OK

21. 0
o
Follow this routine to set required Comfort Mode temperatures.
Changes can be made for each mode, once all changes have been
made press OK and a confirmation screen will display the new
settings.
See page 25 for default temperatures

12 TPOne-S
Setup Schedule/ Unit
User Menu
Schedule - Heating
Schedule
Schedule
 OK


Heating
 OK


21. 5
o
10:45 Thurs
Schedule - Heating
OK
OK
Select Days
 OK


 OK
 
Mon Tues Weds Thurs
Fri Sat Sun 
Mon OK Thurs OK
OK
OK
OK
OK
OK
Follow this routine to set Heating Schedule. Days can be set
individually or grouped and options for weekdays and weekend
settings can be selected. All day combinations can then have one,
two or three Home Periods selected. TPOne will automatically fill in
the gaps with Away and Asleep Periods depending on the time of
the day.
Where TPOne-S is set up to control domestic hot water as well as
heating there is a dedicated Hot Water schedule which can be set
See page 24 for default schedule times

Danfoss Heating 13
Setup Schedule (Continued)
Schedule - Heating
Home Period - 1
Sechedule - Heating
User Menu
Mon Tues Weds Thurs
Fri Sat Sun 
 OK
 
OK OK
 OK
From To
06.00 08.30
OK
OK
OK
Home Period - 2
 OK
From To
12.30 13.30
OK
OK
OK
Home Period - 3
 OK
From To
17.30 22.30
OK
OK
OK
 OK
OK
Select Home Periods
 OK
 
3
OK
Your heating schedule
has been saved
Schedule


OK

3s
OK

14 TPOne-S
TPOne Programme via App
TPOne can be programmed via a smartphone App.
Download the App from App Store or Google Play by following the
QR code or by searching for TPOne.

Danfoss Heating 15
Pairing TPOne-S
Follow the prompts from the TPOne-S App to pair your TPOne-S.
User Settings
WiFi Setup
WiFi Setup
WiFi Setup
 OK


Press OK to setup
WiFi connection
21. 5
o
10:45 Thurs
OK
OK
Open TPOne Heating
App on mobile device
and follow setup
instructions
OK
User Menu
User Settings
 OK


OK
OK

16 TPOne-S
User Menu
Hot Water User override settings for Domestic Hot Water:
Boost - choose to extend the current hot water
heating period for 1, 2 or 3 hours. Once boost
time is finished hot water heating will return to
user set schedule.
Mode - choose between scheduled on or off.
Scheduled mode will follow the user set hot water
heating schedule. Off mode will switch hot water
heating off and will remain off until set back to
scheduled.
Default settings:
Boost - Off
Mode - Scheduled
Note: The Domestic Hot Water feature will be set at
installation and will require a separate hot water
cylinder thermostat and suitable wiring to the
boiler. If the TPOne has been installed for heating
only this menu option will not be given. The hot
water heating feature can be deactivated after
installation, see User Menu > Installer Settings >
Hot Water Setup
Click & Save Click & Save is an easy access saving function.
Switching Click & Save ON will reduce the user set
comfort temperatures by 1°C. Switching Click &
Save OFF will return TPOne to the user set comfort
temperatures.
Default setting: Off
Note: Independent tests have proven that a
reduction in home heating temperatures by 1oC
can save on average 10% energy.
Heating
Mode
Heating Mode will change the TPOne from a
thermostat with full user set heating schedule to a
manually set temperature only thermostat.
In schedule mode the thermostat will follow the
user set heating schedule.
In manual mode the user set schedule will be
ignored, the required comfort mode is then
chosen manually
Default setting: Scheduled

Danfoss Heating 17
Schedule User set heating schedule option:
Heating - settings for the daily heating schedule.
Choose weekday, weekend or independent daily
options and 1,2 or 3 periods per day.
Option to reset daily heating schedule to factory
defaults.
Hot Water - settings for the daily domestic hot
water schedule. Choose weekdays, weekend or
independent daily options and 1,2 or 3 periods
per day. (Option only available if TPOne has been
configured for domestic hot water control)
Option available to reset daily domestic hot water
schedule to factory defaults.
Summary - graphical overview of the set daily
heating or hot water schedule
Default settings: see default heating times later
in this guide
Tempertures User set comfort temperatures (heating),
individual comfort temperatures for Home AM,
Home PM, Away and Asleep.
Home AM and Home PM temperatures will be set
during the home periods chosen in the user set
heating schedule, see User Menu > Schedule
Away temperature will be set during the day
between the home periods. Asleep temperature
will be set during the night between the home
periods.
Default settings:
Home AM - 20°C
Home PM - 20°C
Away - 15°C
Asleep - 15°C
Holiday Holiday feature allows you to set in advance your
holiday dates. TPOne will reduce the heating
to your chosen Holiday temperature on the first
day set to save energy and will return to your set
schedule and mode temperatures on the return
date to ensure the home is comfortable for your
return.
Enter start and end date of your holiday and the
required energy saving home temperature.
User Menu (Continued)

18 TPOne-S
User Settings
WiFi Setup Option to connect the TPOne-S to the internet to
allow remote smart phone control. Ensure the
TPOne-S App is downloaded before selecting WiFi
Setup, see page 15 for details.
Note: TPOne-S will operate and control your
heating without connection to the internet. Only
setup WiFi if there is a home WiFi network and
internet connection available.
Set Date Option to set the current date.
Set Time Option to set the current time and 12 or 24hr clock
setting.
Button Click Button Click is an audible feedback feature
to confirm button press. Button Click can be
switched On or Off
Default setting: On
Backlight When buttons are pressed on the TPOne the
display backlight will come on to aid viewing.
Where backlight is not required this feature can be
switched off.
Default setting: On
Language Choose menu language
Default: English
Note: if required a reset menu language feature
is available, press and hold OK for 5 secs and the
option to change language will be given.
User Reset User Reset will return user settings only to the
TPOne-WiFi factory default.
Note: User Reset will not reset settings in the first
level user menu or the date and time.
Information Information on product type, software level and
boiler service interval date if set.
Connectivity Information on TPOne-S connectivity status

Danfoss Heating 19
Installer Settings
Hot Water
Setup
The TPOne-S can be used as a single channel
programmable thermostat to control the
temperature regulation of the heating system only
or as a two channel programmable thermostat
to control the heating and the time schedule of
a domestic hot water circuit. The domestic hot
water selection will have been chosen in the
startup wizard on initial installation. Choose this
setting after installation to switch the domestic
hot water option on/off.
Default: Set at startup
Note: Settings in the menu which are required for
domestic hot water are only accessable if the Hot
Water Setup is switched on. TPOne-S controls
only the time schedule for domestic hot water and
should always be used with a suitable hot water
cylinder thermostat.
RF Pairing The TPOne-S must be paired to a compatible
receiver/boiler relay. The initial pairing is made
in the startup wizard. If pairing was not made at
startup or if pairing is required to a new receiver/
boiler relay select this setting to start new pairing.
Control Type This allows the thermostat to be set to run in On/
Off mode or in chrono-proportional 3, 6 or 12
cycle rate.
Default: Chrono 6
Note: for condensing boiler control tests have
shown that boiler efficiency is significantly
improved when controlled by a chrono-
proportional type controller

20 TPOne-S
Start-up
Method
This feature allows the thermostat to start up the
heating system in three different ways.
Normal - Heating is turned up or down at the
programmed times.
Delayed start (or Economy Setting) -
Set the period start times in the normal way
taking into account the time that the building
takes to heat on an average day. The thermostat
monitors switch on time, actual temperature and
wanted temperature and delays the start of the
heating if the actual temperature is close to the
programmed temperature. Delayed Start in TPOne
is dynamic and will adjust automatically to the
home heating characteristics while maximising
energy savings.
Optimised Start (or Comfort Setting) -
This allows you to programme the time at
which you would like to be up to the required
temperature. The thermostat then calculates
how soon before the required time the heating is
turned up. Optimised Start in TPOne is dynamic
and will adjust automatically to the home heating
characteristics to reach required temperature at
the required time.
Default: Normal
Temperature
Limits
This allows the upper and lower temperature of
the thermostat setting range to be limited.
Defaults:
Minimum 5°C,
Maximum 35°C
Frost Protect To help protect against damage to the heating
system caused by extreme low temperatures the
TPOne includes a Frost Protect level. This is the
minimum temperature level and is also used when
the TPOne is placed in standby mode.
Default: 5°C
Temperature
Override
This establishes the degree of manual temperature
override available to the user, No Limit, Limited +/-
2°C or No Override
Default: No Limit
Installer Settings (Continued)
