Danfoss Termix VMTD-F-B User manual

DEN-GT VI.CW.C1.02 / LUK40110 © Danfoss 04/2011 1
Instructions Termix VMTD-F-B
District heating substation for
direct heating and
instantaneous domestic hot water
Table of Contents Declaration of conformity ............................... 2
Safety notes ...................................................... 3
Storage .............................................................. 3
Disposal ............................................................. 3
Mounting .......................................................... 4
Pipe connections ................................................ 4
Electrical connection .......................................... 5
Filling, start-up ................................................... 5
Design ............................................................... 6
Schematic diagram (example) ........................ 6
Control .............................................................. 7
Maintenance ..................................................... 8
Troubleshooting DHW ..................................... 9
Troubleshooting HE ...................................... 10

Termix VMTD-F-B - substation for direct HE and DHWInstructions
DEN-GT
VI.CW.C1.02 / LUK40110 © Danfoss 04/2011
2
Declaration of conformity
Declaration of compliance
We
Gemina Termix A/S
Member of the Danfoss Group
Navervej 15-17
DK-7451 Sunds
Do hereby on our own responsibility declare that the following products:
Termix Substations
Covered by this declaration is in conformity with the following directive(s), standard(s) or
other normative document(s), provided that the products are used in accordance with our
instructions.
EU Directives:
Machinery Directive 2006/42/EEC
EN ISO 14121-1 Safety of machinery - Risk assessment
EN 60204-1-Safety of machinery - Electrical equipment of machines
EMC Directive 2004/108/EEC
EN 61000-6-2 2007 Electromagnetic compatibility- Generic standard: Immunity industry
EN 61000-6-3 2007 Electromagnetic compatibility- Generic standard: Emission for
residential, commercial and light industry
PED Directive 97/23/EEC
All substations that falls under Article 3.3 and category 1 shall not be CE-marked
according to this directive, however all essential safety requirements from the PED
Directive 97/23/EEC are followed to ensure hydraulic safety
This declaration is immediately annulled, if the product is interfered with in any way,
which interferes with the above mentioned directives and standards, with out the
written consent from Gemina Termix A/S.
Time and place
2010.01.05 - Sunds
Lars Ginnerup
Responsible for quality

Instructions
DEN-GT VI.CW.C1.02 / LUK40110 © Danfoss 04/2011 3
Termix VMTD-F-B - substation for direct HE and DHW
Safety notes The following instructions refer to the standard
design of substation. Special versions of
substations are available on request.
To avoid injury to persons and damage to the
device, it is absolutely necessary to read and
observe these instructions carefully.
Assembly, start-up and maintenance work must be
performed by qualified and authorized personnel
only.
Please comply with the instructions issued by the
system manufacturer or system operator.
Unused connections and shut-off valves must
be sealed with a plug. Should the plugs require
removal, this must only be done by an authorized
service technician.
Warning of high pressure and temperature
The maximum temperature of the flow medium in
a substation is 120 °C.
The maximum operating pressure of the substation
is 10 bar.*
* PN 16 versions are available on enquiry
The heat exchangers test pressure is 30 bar.
Be aware of the installation’s permissible system
pressure and temperature.
The risk of persons being injured and equipment
damaged increases considerably if the
recommended permissible operating parameters
are exceeded.
The substation installation must be equipped with
safety valves, however, always in accordance with
local regulations.
Warning of hot surface
The substation has got hot surfaces, which can
cause skin burns. Please be extremely cautious in
close proximity to the substation.
Power failure can result in the motor valves
being stuck in open position. The surfaces of the
substation can get hot, which can cause skin burns.
The ball valves on district heating supply and return
should be closed.
Warning of transport damage
Before substation installation, please make sure
that the substation has not been damaged during
transport.
Sound level
≤ 55 dB
Corrosion protection
All pipes and components are made of stainless
steel and brass.
The maximum chloride compounds of the flow
medium should not be higher than 150 mg/l.
The risk of equipment corrosion increases
considerably if the recommended level of
permissible chloride compounds is exceeded.
Storage Any storage of the substation which may be
necessary prior to installation should be in
conditions which are dry and heated.
Disposal
This product consists of materials which must not
be disposed of together with domestic waste.
Dismantle the product and sort the components
in various groups before disposal. Observe the
disposal rules of the local legislation.

Termix VMTD-F-B - substation for direct HE and DHWInstructions
DEN-GT
VI.CW.C1.02 / LUK40110 © Danfoss 04/2011
4
Mounting The substation must be installed and connected
by authorized service personnel.
Installation must be in compliance with local
standards and regulations.
Allow adequate space around the substation for
mounting and maintenance purposes.
The station must be mounted so that
components, keyholes and labels are placed
correctly. If you wish to mount the station
differently please contact your supplier.
Prior to installation, all substation pipes and
connections should be cleaned and rinsed.
Due to vibration during transport, all substation
connections must be checked and tightened before
installation.
Where substations are to be wall-mounted, drillings
are provided in the back mounting plate. Floor
mounted units have support.
Each connection on the substation is labelled.
If a strainer is supplied with the station it must be
fitted according to schematic diagram. Please note
that the strainer may be supplied loose.
Pipe connections Internal installation and district heating pipes
connections must be made using threaded, flanged
or welded connections.
District heating (DH) - In the following sections,
DH refers to the heat source which supplies the
substations. A variety of energy sources, such as
oil, gas or solar power, could be used as the primary
supply to Danfoss substations. For the sake of
simplicity, DH can be taken to mean the primary
supply.
Connections:
1. Hot water circulation (HWC) (Optional)
2. District heating (DH) supply
3. District heating (DH) return
4. Cold water mains (CWM)
5. Domestic cold water (DCW)
6. Domestic hot water (DHW)
7. Heating (HE) supply
8. Heating (HE) return
Connections sizes:
DH + HE: G ¾” (int. thread)
CWM + DCW + DHW: G ¾” (int. thread)
Dimensions (mm):
Without cover:
H 710 x W 528 x D 150
With cover (mount on wall variant):
H 800 x W 540 x D 190
With cover (built-in wall variant):
H 915-980 x W 610 x D 150
Weight (approx.): 20 kg
The pipe placement can deviate from the
shown drawing. Please note the markings on
the station.

Instructions
DEN-GT VI.CW.C1.02 / LUK40110 © Danfoss 04/2011 5
Termix VMTD-F-B - substation for direct HE and DHW
Electrical connection
Electrical connections must be made by an
authorised electrician only.
Electrical connections must be made in accordance
with current regulations and local standards.
Before making electrical connections, please note
the following:
- Please read the relevant parts of safety notes.
- The substation must be connected to 230 V AC
and earth.
- The substation must be electrically connected
so that it can be disconnected for repairs.
Filling, start-up Prior to installation, all substation pipes and
connections should be cleaned and rinsed.
Before start-up, check that:
- pipes are connected according to the circuit
diagram,
- threaded connections are tightened.
When carrying out first fill, the heat exchanger
must be slowly filled with water until it reaches
working pressure.
The shut-off valves should then be opened and the
unit observed as it enters service. Visual checking
should confirm temperatures, pressures, acceptable
thermal expansion and absence of leakage. If the
heat exchanger operates in accordance with design,
it can be put to regular use.
All Danfoss heat exchangers and substations are
pressure tested prior to delivery.

Termix VMTD-F-B - substation for direct HE and DHWInstructions
DEN-GT
VI.CW.C1.02 / LUK40110 © Danfoss 04/2011
6
Design
Heat exchanger, DHW
Thermostatic controller, DHW
Differential pressure controller
On/off valve
Strainer
Your substation might look different than the substation shown.
Schematic diagram
(example)
HE
supply
HE
return
DHW
CWM
DH
supply
DH
return
DCW
Substations as supplied may be different to those shown on Danfoss literature.
B Plate heat exchanger DHW
1 Ball valve
7 Thermostatic valve
9 Strainer
14 Sensor pocket, energy meter
31 Differential pressure controller
41A Fitting piece, Energy meter
41B Fitting piece, Cold water mains
69 On/off valve

Instructions
DEN-GT VI.CW.C1.02 / LUK40110 © Danfoss 04/2011 7
Termix VMTD-F-B - substation for direct HE and DHW
Control Differential pressure controller
The differential pressure controller smooths out the
fluctuations in pressure arriving from the district
heating network. The operating pressure in the
substation is thus held steady.
TP7000
TP7000 electronic 7 day programmable room
thermostat.
Signals from this can be used to control zone
valves.
DHW temperature control
There are various types of DHW temperature control
used in Danfoss substations.
DHW temperature should be adjusted to 45-50 °C,
as this provides optimal utilisation of DH water. At
DHW temperatures above 55 °C, the possibility of
lime scale deposits increases significantly.
Thermostatic control
DHW temperature is adjusted as follows:
To increase temperature, turn the handle on
the thermostatic controller to select a higher
number.
To decrease temperature, turn the handle on the
thermostatic controller to select a lower number.
AVTB controller (20-60 °C)
The temperature setting is as follows:
1 = 20 °C 4 = 60 °C
2 = 35 °C 5 = 70 °C
3 = 50 °C
The AVTB operates at its best at DH supply
temperatures of up to 90°C.
The values are intended as a guide.

Termix VMTD-F-B - substation for direct HE and DHWInstructions
DEN-GT
VI.CW.C1.02 / LUK40110 © Danfoss 04/2011
8
Safety valve
The purpose of the safety valve is to protect the
substation from excessive pressure.
The blow-off pipe from the safety valve must not be
closed. The blow-off pipe outlet should be placed so
that it discharges freely and it is possible to observe
any dripping from the safety valve.
It is recommended to check the operation of safety
valves at intervals of 6 months. This is done by
turning the valve head in direction indicated.
Strainer
Strainers should be cleaned regularly by authorized
personnel. The frequency of cleaning would depend
on operating conditions and the manufacturer’s
instructions.
GTU Pressure Equalizer
The GTU Pressure Equalizer absorbs the expansion
on the secondary side of the Termix water heaters
and can be used as a substitute to the safety
valve.
Furthermore the pressure equalizer absorbs a
possible increase in pressure, so a discharge outlet
is omitted.
The GTU Pressure Equalizer may not be applied in
systems with hot water circulation.
Return temperature limiter
FJVR (10-80 °C)
The return limiter type FJVR automatically controls
the return temperature from radiators, convectors
and floor heating pipes.
Maintenance Each substation requires little monitoring, apart
from routine checks and cleaning of strainers.
Regular inspections of the substation according to
this Instruction are recommended, which should
include checks of all operating parameters such
as meter readings.
Spare parts can be ordered from Danfoss. Please
ensure that any enquiry includes the substation
serial number.

Instructions
DEN-GT VI.CW.C1.02 / LUK40110 © Danfoss 04/2011 9
Termix VMTD-F-B - substation for direct HE and DHW
Troubleshooting DHW
We recommend that troubleshooting be carried
out only by authorized personnel.
In the event of operating disturbances, the following
basic features should be checked before carrying
out actual troubleshooting:
- the substation is connected to electricity,
- the strainer on the DH supply pipe is clean,
- the supply temperature of the DH is at the
normal level (summer, at least 60 °C -
winter, at least 70 °C),
- the differential pressure is equal to or higher
than the normal (local) differential pressure in
the DH network – if in doubt, ask the DH plant
supervisor,
- pressure on the system - check the HE pressure
gauge.
Problem Possible cause Solution
Too little or no DHW
Strainer in supply or return line clogged. Clean strainer(s).
DHW circulation pump out of order or
with setting too low. Check circulation pump.
Defective or clogged non-return valve. Replace – clean.
No electricity. Check.
Wrong setting of automatic controls,
if any.
To adjust an electronic controller for
DHW, pls. note enclosed instructions for
electronic controller.
Scaling of the plate heat exchanger. Replace – rinse out.
Defective motorized valve. Check (use manual function) - replace.
Defective temperature sensors. Check – replace.
Defective controller. Check – replace.
Hot water in some taps but
not in all.
DCW is being mixed with the DHW, e.g.
in a defective thermostatic mixing valve
or non
Check – replace.
Defective or clogged non-return valve
on circulation valve. Replace – clean.
Tap temperature too high;
DHW tap load too high.
Thermostatic valve adjusted to a too
high level. Check - set
Temperature drop during
tapping.
Scaling of the plate heat exchanger. Replace – rinse out.
Larger DHW flow than the substation
has been designed for. Reduce DHW flow.

Termix VMTD-F-B - substation for direct HE and DHWInstructions
DEN-GT
VI.CW.C1.02 / LUK40110 © Danfoss 04/2011
10
Troubleshooting HE Problem Possible cause Solution
Too little or no heat.
Strainer clogged in DH or HE circuit
(radiator circuit). Clean gate/strainer.
The filter in the heat meter on DH circuit
clogged.
Clean the filter (after consulting the DH
plant operator).
Defective or wrongly adjusted
differential pressure controller.
Check the operation of the differential
pressure controller – clean the valve
seat if required.
Sensor defective – or possibly dirt in the
valve housing.
Check the operation of the thermostat -
clean the valve seat if required.
Automatic controls, if any, wrongly set
or defective - possibly power failure.
Check if the setting of the controller
is correct – see separate instructions.
Check the power supply. Temporary
setting of motor to “manual” control –
see instructions on automatic controls.
Pump out of operation.
Check if the pump is receiving power
and that it turns. Check if there is air
trapped in the pump housing - see
pump manual.
The pump is set at too low speed of
rotation.
Set the pump at higher speed of
rotation.
Pressure drop – the pressure drop on
the radiator circuit shows lower than
recommended operating pressure.
Fill water on the system and check the
functioning of the pressure expansion
vessel if required.
Air pockets in the system. Vent the installation thoroughly.
Limiting of the return temperature
adjusted too low. Adjust according to instructions.
Defective radiator valves. Check – replace.
Uneven heat distribution in building
because of incorrectly set balancing
valves, or because there are no
balancing valves.
Adjust/install balancing valves.
Diameter of pipe to substation too small
or branch pipe too long. Check pipe dimensions.
Uneven heat distribution. Air pockets in the system. Vent the installation thoroughly.
DH supply temperature
too high.
Wrong setting of thermostat or of
automatic controls, if any.
Adjust automatic controls, - see
instructions for automatic controls.
Defective controller. The controller does
not react as it should according to the
instructions.
Call automatic controls manufacturer or
replace the regulator.
Defective sensor on self-acting
thermostat. Replace thermostat, - or sensor only.
DH supply temperature
too low.
Wrong setting of automatic controls,
if any.
Adjust automatic controls – see
instructions for automatic controls.
Defective controller. The controller does
not react as it should according to the
instructions.
Call in automatic controls manufacturer
or replace controller.
Defective sensor on self-acting
thermostat. Replace thermostat - or sensor only.
Wrong placement/fitting of outdoor
temperature sensor.
Adjust location of outdoor temperature
sensor.
Strainer clogged. Clean gate/strainer.

Instructions
DEN-GT VI.CW.C1.02 / LUK40110 © Danfoss 04/2011 11
Termix VMTD-F-B - substation for direct HE and DHW
Problem Possible cause Solution
Poor cooling.
Too small heating surface/too small
radiators compared to the total heating
requirement of the building.
Increase total heating surface.
Poor utilization of existing heating
surface. Defective sensor on self-acting
thermostat.
Make sure the heat is distributed evenly
across the full heating surface – open all
radiators and keep the radiators in the
system from heating up at the bottom.
It is extremely important to keep the
supply temperature to the radiators as
low as ever possible, while maintaining
a reasonable level of comfort.
The system is single pipe loop. The system should feature electronic
controls as well as return sensors.
Pump pressure too high. Adjust pump to a lower level.
Air in system. Vent the system.
Defective or incorrectly set radiator
valve(s). Single pipe loop systems
require special one-pipe radiator valves.
Check – set/replace.
Dirt in the motorized valve or in the
differential pressure controller. Check – clean out.
Defective motorized valve, sensor or
automatic controller. Check – replace.
Electronic controller not adjusted
correctly. Adjust according to instructions.
Noise in system. Pump pressure too high. Adjust pump to a lower level.
Heat load too high. Defective motorized valve, sensor or
electronic controller Check – replace.

Termix VMTD-F-B - substation for direct HE and DHWInstructions
12 VI.CW.C1.02 / LUK40110 Produced by Danfoss A/S © 04/2011
Gemina Termix A/S • Member of the Danfoss Group • Navervej 15-17 • DK-7451 Sunds • Denmark
Tel.: [phone] • Fax: [phone] • [e-mail] • www.heating.danfoss.com
