Daniela DAN6UC User manual

Appliance User Manual
60CM CONCEALED RANGEHOOD
DAN6UC
danielaappliances.com.au

P I02 9604 1226 E I[email protected] W |danielaappliances.com.au
PAGE 2
Daniela Appliances started in 1988. Formally known as Italnova,
the company began operating by selling other major leading brands.
Since then, Daniela Appliances has it’s own range, continuously
evolving, striving on delivering leading-edge quality products at
very competitive prices.
From an Italian heritage our brand Daniela was then established in
2005 from a father’s love to a daughter and naming it after Daniela, now
the new proprietor. Daniela has worked closely with her father for many
years learning from his decades of industry experience. Daniela with her
extensive knowledge and understanding of appliances, now continues
her father’s legacy with a modern flare.
Our products are extensively tested and come with ISO certification
certificates prior to importation. Daniela Appliances continuously
designs and sources the best parts, to bring you an elegant feel that will
last the test of time and for a third of the cost from a major brand.
Daniela Appliances is dedicated to oering our customers exceptional
products with exceptional service. Our commitment is to provide our
valuable customers the very best in technology with the very best in
safety that combines both the values that brings us market success.

P I 02 9604 1226 E I [email protected] W | danielaappliances.com.au
PAGE 3
DAN6UC
60CM CONCEALED RANGEHOOD
(DUCTED USE ONLY)
MODEL DAN6UC
Rated Voltage 220V - 240V
Rated Power Frequency 50Hz
Light Power 2 x 2W (LED)
Motor Power 230W
Total Power 234W
Motor 1
Diameter of Outlet Adapter 150mm
Dimension (mm) W600 x D277 x H300

P I02 9604 1226 E I[email protected] W |danielaappliances.com.au
PAGE 4
RECOMMENDATIONS AND SUGGESTIONS
• Daniela Appliances Pty Ltd will not be held liable for any damages resulting from incorrect
or improper installation.
• Please read this instruction manual before installing and using this range hood. Please keep
this instruction manual in a safe place for future reference.
• Only a qualified and trained service technician can undertake the work of installation and
servicing.
• Check that the main voltage corresponds to the one indicated on the rating plate fixed
inside the hood.
• If the hood is used in conjunction with non-electrical appliances (e. g. gas burning
appliances), a sucient degree of ventilation must be guaranteed in the room in order to
prevent the backflow of exhaust gas. The kitchen must have an opening directly with the
open air in order to guarantee the entry of clean air.
• The minimum distance is 750mm from the range hood to a gas hob, and is 650mm to an
electric hob. If the installation instructions for gas hobs specify a greater distance, this must
be taken into account.
SAVE THIS INSTRUCTION IN A SAFE PLACE FOR FUTURE REFERENCE
Thank you for choosing Daniela appliances!
Please read all instructions before using this appliance. This book contains valuable
information about operation, care and service. Keep it in a safe place for future
reference. Should the appliance be sold or transferred to another owner, or should
you move house and leave the appliance, always ensure that the book is supplied
with the appliance in order that new owner can be acquainted with the functioning of
the appliance and relevant warnings.
The manufacturer cannot be held responsible for any inaccuracies due to printing or
transcription errors that may be found in this handbook.
N.B.: the pictures shown in the figures in this handbook are purely indicative.

P I 02 9604 1226 E I [email protected] W | danielaappliances.com.au
PAGE 5
WARNING!
Under certain circumstances electrical appliances may be a dangerous hazard.
• Do not check the status of the filters while the cooker hood is operating
• Do not touch the light bulbs after appliance use
• Do not disconnect the appliance with wet hands.
• To reduce the risk of fire or electric shock, do not use this fan with any solid-state.
• Avoid free flame, as it can do damage to the filters from a fire hazard.
• Constantly check food frying to avoid that the overheated oil may become a fire hazard
• Disconnect the electrical plug prior to any maintenance or servicing.
WARNING
TWO OR MORE PEOPLE ARE REQUIRED TO INSTALL OR MOVE THIS APPLIANCE. FAILURE IN
DOING SO CAN CAUSE PHYSICAL HARM OR INJURIES.
• The range hood has been designed only for domestic use to eliminate kitchen fumes.
• Never use the hood for purposes other than what it has been designed for.
• Never leave high naked flames under the hood when it is in operation.
• Adjust the flame intensity to direct it onto the bottom of the pan only; making sure that it
does not engulf the pan sides.
• Deep fat fryers must be continuously monitored during use: overheated oil can burst
into flames.
• The hood should not be used by children or persons not instructed in its correct use.
MAINTENANCE
• Proper maintenance of the range hood will assure proper performance of the unit.
• Disconnect the hood from the main supply before carrying out any maintenance work.
• Clean and/or replace aluminium grease filters and activated charcoal filters after specified
period of time.
• Clean the hood using a damp cloth and a neutral liquid detergent.

P I02 9604 1226 E I[email protected] W |danielaappliances.com.au
PAGE 6
WARNING!
• Children don’t recognize the risks of electrical appliances. Therefore, use or keep the
appliance only under supervision of adults and out of the reach from children.
• Do not use this product outdoors.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction, concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
• There should be adequate ventilation of the room when the range hood is used at the
same time as appliances burning gas or other fuels.
• There is a fire risk if cleaning is not carried out in accordance with instructions.
• The exhaust air must not be discharged into a flue which is used for exhausting fumes
from appliances burning gas or other fuels.
ELECTRICAL SHOCK HAZARD AND FIRE
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING:
A. Installation work and electrical wiring must be done by qualified person(s) in accordance
with all applicable codes and standards, including fire-rated construction.
B. Sucient air is needed for proper combustion and exhausting of gases through the flue
(chimney) of fuel burning equipment to prevent back drafting.
C. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other
hidden utilities.
D. Ducted fans must always be vented to the outdoors.

P I 02 9604 1226 E I [email protected] W | danielaappliances.com.au
PAGE 7
INSTALLATION & USE
OPERATION OF CONTROLS
• The hood is operated using using the electronic switch on the faceplate.
• The light switch turns the lamps on and o.
The fan switch turns the fan on to three speed settings:
1. Low speed
2. Medium speed
3. High speed
INSTALLATION OF THE DUCT WORK
NOTE: Please ensure that these filters are completely dry before using.
NOTE: THIS RANGEHOOD IS FOR DUCTED USE ONLY.
THIS RANGEHOOD CANNOT BE RECIRCULATED!
CAUTION:
To reduce the risk of noise or fire, use metal ductwork is preferred.
1. Decide where the ductwork will run between the hood and the outside.
2. A straight, short duct run will allow the hood to perform most eciently.
3. Long duct runs, elbows, and transitions will reduce the performance of the hood. Use as few
of them as possible. Larger ducting may be required for best performance with longer duct
runs. You will lose 100m3of suction for every elbow in your ducting.
4. The air must not be discharge into a flue that is used for exhausting fumes from appliances
burning gas or other fuels” “Regulations concerning the discharge of air have to be fulfilled.
5. Install wall cap. Connect round metal ductwork to cap and work back towards
hood location. Use duct tape to seal the joints between duct work sections.
1 - LOW SPEED
2 - MEDIUM SPEED
3 - HIGH SPEED LOW MEDIUM HIGH LIGHT

P I02 9604 1226 E I[email protected] W |danielaappliances.com.au
PAGE 8
INSTALLATION OF ELECTRICAL
Electrical wiring must be done by a qualified person(s) in accordance with all applicable codes
and standards. This range hood must be properly grounded. Turn o electrical power at service
entrance before wiring. If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard. Do not use the plug and
an extension cord other than the ones initially supplied with the hood.
INSTALLATION OF THE HOOD
NOTE: On stainless steel hoods, carefully remove the plastic protective film from all exterior
surfaces of the hood and chimney prior to final installation.
NOTE: At least two people will be required to mount the hood.
Before beginning installation, and to better handle the hood, we advise removing the face plate.
1. Attach the air outlet adapter over the hood. Tighten it with 4 screws.
2. The range hood is designed to operate with 150mm exhaust Ducting.
FIXING UNIT IN CABINETRY
1. Before fixing the hood to the unit, drill a hole of 165mm diameter for 150mm,
135mm or 120mm exhaust ducting in the wall unit.
2. Check the position of the power outlet and consider where the power cable will run, since a
hole might have to be made in the wall unit to accommodate it.
3. On the other side of the hood there are 2 spring steel fittings to assist the installation.
Adjust the height of the spring steel to match the thickness of the mounting panel.
The hood can be slid into the opening and these springs will take some of the weight
while the mounting screws are fitted.
4. Lift the range hood and fit through the opening of the cabinet. Secure the unit by using
4 long mounting screws (ST5*45) =. Two into each side.
5. Refit the filter and close the panel.
6. Make the electrical connection.
NOTE
• Exhaust air must not be discharged into a flue which is used for exhausting fumes from
appliance burning gas or other fuels.
• If the instructions for installation for the gas hob specify a greater distance that 750mm,
this has to be taken into account.
• The regulations concerning the discharge of exhaust air have to be followed.
• Check with the local authority for building codes for exhaust ducting requirements.

P I 02 9604 1226 E I [email protected] W | danielaappliances.com.au
PAGE 9
LAMPS
This range hood may require 2 LED lamps (DC 12V, 2W Max)
NOTE: Always switch o the electrical supply before carrying out any operation on the appliance.
TO CHANGE THE LIGHTS
1. Using a sharp blade, slide it in between the surrounds of the
light and the stainless steel. The light will pop out.
2. Undo the terminal connection and replace the LED
with the same kind.
CAUTION
• The surface of the light cover may be hot. Take care when
replacing led lamps
• The led lamp may be hot. Take care when replacing led lamps
Note: We recommend only using led lamps of the same specification as the one being replaced.
HOOD CLEANING
Stainless steel is one of the easiest materials to keep clean. Occasional care will help preserve its
fine appearance.
CLEANING TIPS
• Hot water with soap or detergent is all that is usually needed.
• Follow all cleaning by rinsing with clear water. Wipe dry with a clean, soft cloth to avoid
water marks.
• For discolorations or deposits that persist, use a non-scratching household cleanser or
stainless-steel polishing powder with a little water and a soft cloth.
• For stubborn cases use a plastic scouring pad or soft bristle brush together with cleanser
and water. Rub lightly in direction of polishing lines or “grain” of the stainless finish.
Avoid using too much pressure that may damage the surface.
• Do not allow deposits to remain for long periods of time.
• Do not use ordinary steel wool or steel brushes. Small bits of steel may adhere
to the surface causing rust.
• Do not allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain
in contact with stainless steel for extended periods. Many of these compounds contain
chemicals that may be harmful. Rinse with water after exposure and wipe dry with
a clean cloth.
• Painted surfaces should be cleaned with warm water and mild detergent only.

P I02 9604 1226 E I[email protected] W |danielaappliances.com.au
PAGE 10
When you unpack the appliance, make sure that it has not been damaged in any way. If you have
any doubts at all DO NOT INSTALL OR USE THE APPLIANCE. In this instance please contact your
retailer or Daniela Appliances direct. Keep packing material such as plastic bags, polystyrene,
nails or screws out of the reach of children, as they are a choking hazard.
This symbol on the product or in the instruction manual means that your electrical and electronic
equipment should be disposed at the end of its life separately from your household waste. There
are separate collection systems for recycling in the EU. For more information, please contact your
local authority or the retailer where you purchased the appliance.
TROUBLESHOOTING
SYMPTOMS POSSIBLE CAUSE ACTION
No response of the lamps
and the motor
1. The plug is o from the power socket
2. Power cord is damaged
3. Fuse on the PCB is damaged
4. Switch is damaged
1. Ensure that the plug is put into the
power socket properly
2. Replace the power cord if the power
cord is damaged
3. Replace the fuse on the PCB
4. Repair the switch
5. Contact Daniela Appliances Pty Ltd
The hood body gives
out strong vibrations
and loud noises
1. The hood has not been installed
properly according to the installation
process described in the
instruction manual
2. Check the joint connection of
each part for damage
1. Ensure the hood has been installed
properly according to the user
manual by a qualified technician
2. Replace carbon filters with new sets
The air exhaust
performance is bad
1. The duct is damaged
2. Grease Filters or
charcoal filter clogged
1. Exhaust air outlet clogged
2. Repair or replace the damaged duct
3. Replace or clean the filters
4. Clear the air exhaust outlet

P I 02 9604 1226 E I [email protected] W | danielaappliances.com.au
PAGE 11
FURTHER INFORMATION
It is a warranty requirement that proof of purchase must be provided when booking a service call.
Please be advised that without this proof of purchase, your warranty may not be honoured.
All warranty will be voided, if not installed by a licensed technician or tradesman.
Please record their details below for future reference:
TECHNICAN / TRADESMAN WHO INSTALLED: ..............................................................................................
.......................................................................................................................................................................................
LICENSE NUMBER: ..................................................................................................................................................
DATE OF INSTALLATION:.......................................................................................................................................
INSTALLATION RECEIPT NUMBER:.....................................................................................................................
If you require more information, service, warranty or spare parts enquiries
please contact customer care.
DANIELA APPLIANCES PTY LTD
[phone] (9am – 5pm EST, Monday – Friday)
NOTE: Model number and details are to be recorded below for future reference.
Please have the following information ready before calling our customer care team.
Model number:..........................................................................................................................................................
Serial number:...........................................................................................................................................................
Place of purchase:....................................................................................................................................................
Date of purchase (NOT Installation): ...................................................................................................................
Receipt or Invoice Number:...................................................................................................................................

P I02 9604 1226 E I[email protected] W |danielaappliances.com.au
PAGE 12
TERMS AND CONDITIONS
TERMS OF WARRANTY
Daniela appliances warrants to the original purchaser of appliance providing the product is installed specifically
for their intended use, under proper care, domestic/residential use and maintenance of the products supplied by
Daniela appliances, will be free from defects in workmanship and materials subject to the terms and conditions
to follow.
Daniela Appliances warranty only applies to the original owner and is not transferable.
Our warranty covers rectification free of charge for any faults arising from defective materials or components and
faulty workmanship. The product will be repaired or replaced at the discretion of Daniela Appliances.
NOTE: All costs of installation, stone benchtop replacement, cabinetry replacement or repair, sink/tapware
removal, un-installation, cartage, freight, travelling expenses and insurance are to be paid by the customer.
RETURN POLICY
Kindly inspect your goods at time of delivery.
If you notice any damage to your goods please notify our delivery team at the time of delivery. Recommend you
thoroughly inspect your goods at this time. If you notice any damage to your goods please call with in 24 hours
of receiving delivery, please notify Daniela Appliances Pty Ltd immediately. Evidence of damage will be required.
If for any reason you need to return an item please call Daniela Appliances Pty Ltd on (02 )9604-1226, within
48 hours of receiving the goods or appliances.
If your goods remain boxed and in an unopened condition, they may be returned with in 30 days of the invoice
date for a full refund. A collection fee of $50 will be charged should you require Daniela Appliances Pty Ltd to
collect the stock.
If your goods have been unboxed but otherwise are in as new condition (Have not been used or connected) a
20% restocking fee (20% of the purchase price) will apply.
Daniela Appliances Pty Ltd DOES NOT DEAL WITH FACTORY SECONDS, DAMAGES OR OPENED GOODS, and
charges restocking fees to cover the return costs. A collection fee of $50 or the delivery charge if greater than
the $50 will apply.
Please note that if you request connection of your appliance, Daniela Appliances Pty Ltd will unbox the product at
the time of delivery. We recommend you inspect your goods thoroughly at time of delivery, as to avoid extra charges.
Return of goods are to be covered by the customer, or alternatively can be returned in person to Daniela
Appliances Pty Ltd, at no extra charge. Please note that a collection fee of $50 or greater will be charged should
you wish Daniela Appliances Pty Ltd, to collect the stock on your behalf.
You as a customer have a duty of care for the product whilst in your possession. If products are damaged by you,
and subsequently returned, a charge will be made to repair the product to its original condition. Please be aware
that where repair is economically viable, no refund will be given.
All refunds will be issued when goods arrive back to Daniela Appliances warehouse and have been inspected by
a sta member of our team. Refunds will be made by the same method used for purchase.
We are unable to accept returns of any goods that you have attempted to install or have used.
If there are any further queries, please don’t hesitate to contact Daniela Appliances Pty Ltd on [phone].
THANK YOU.

P I 02 9604 1226 E I [e-mail] W | danielaappliances.com.au
PAGE 13
Cooking
Style
with

P I02 9604 1226 E I[email protected] W |danielaappliances.com.au
PAGE 14
NOTES & SKETCHES

P I 02 9604 1226 E I [email protected] W | danielaappliances.com.au
PAGE 15
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
..........................................................................................................................................................................................
NOTES

danielaappliances.com.au
P I02 9604 1226 E [e-mail] A I8/10 Hume Road, Smithfield NSW 2164P I02 9604 1226 E I[email protected] A I8/10 Hume Road, Smithfield NSW 2164
