DAPAudio CORE CDMP-750 User manual

CDMP-750
ORDERCODE D1155
Highlite International B.V.
Vestastraat 2
6468 EX Kerkrade
The Netherlands

Congratulations!
You have bought a great, innovative product from DAP Audio.
The DAP Audio CDMP-750 brings excitement to any venue. Whether you want simple plug-&-play action
or a sophisticated show, this product provides the effect you need.
You can rely on DAP Audio, for more excellent audio products.
We design and manufacture professional audio equipment for the entertainment industry.
New products are being launched regularly. We work hard to keep you, our customer, satisfied.
For more information: [e-mail]
You can get some of the best quality, best priced products on the market from DAP Audio.
So next time, turn to DAP Audio for more great audio equipment.
Always get the best -- with DAP Audio !
Thank you!

1
Dap Audio
Dap Audio CDMP-750™ Product Guide
Warning ..........................................................................................................................................................................2
Unpacking Instructions ...........................................................................................................................................2
Safety-instructions ..................................................................................................................................................2
Operating determinations.....................................................................................................................................3
Return Procedure ....................................................................................................................................................4
Claims........................................................................................................................................................................4
Description.....................................................................................................................................................................5
Overview...................................................................................................................................................................5
Top .............................................................................................................................................................................6
Front ...........................................................................................................................................................................7
Back...........................................................................................................................................................................7
Installation......................................................................................................................................................................7
Set Up and operation...................................................................................................................................................7
Functions ........................................................................................................................................................................8
Operations .................................................................................................................................................................. 11
Loading CD’s ........................................................................................................................................................ 11
Unloading CD’s .................................................................................................................................................... 11
Selecting tracks .................................................................................................................................................... 11
Starting playback................................................................................................................................................. 11
Stop playback ...................................................................................................................................................... 12
Pausing................................................................................................................................................................... 12
Setting a cue point .............................................................................................................................................. 12
Setting a hot cue Point ....................................................................................................................................... 12
Cueing.................................................................................................................................................................... 12
Frame search ........................................................................................................................................................ 12
Scanning (fast forward/fast backward)............................................................................................................. 13
Time display........................................................................................................................................................... 13
Changing the pitch of the song ....................................................................................................................... 13
Program play ........................................................................................................................................................ 13
Loop play............................................................................................................................................................... 13
Auto loop play...................................................................................................................................................... 14
Reloop .................................................................................................................................................................... 14
Creating a hot loop............................................................................................................................................. 14
Relay play .............................................................................................................................................................. 14
Before switching off the power ............................................................................................................................... 15
CD’s ........................................................................................................................................................................ 15
Precaution on storage ........................................................................................................................................ 15
Maintenance.............................................................................................................................................................. 15
Troubleshooting ......................................................................................................................................................... 15
Product Specifications.............................................................................................................................................. 16

2
WARNING
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
• DAP CDMP-750
• Relay cable
• User manual
SAFETY INSTRUCTIONS
Every person involved with the installation, operation and maintenance of this system has to:
-be qualified
-follow the instructions of this manual
Before you initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the system.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the system are not subject to
warranty.
This system contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-
observance of this manual or any unauthorized modification to the system.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never leave any cables lying around.
Do not insert other objects then CD’s in the CD slot.
Do not connect this system to a dimmerpack.
CAUTION!
Keep this system away from rain and moisture!
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!

3
Do not switch the system on and off in short intervals, as this would reduce the system’s life.
Do not open the device and do not modify the device.
Only use system indoor, avoid contact with water or other liquids.
Avoid flames and do not put close to flammable liquids or gases.
Always disconnect power from the mains, when system is not used. Only handle the power-cord
by the plug. Never pull out the plug by tugging the power-cord.
Make sure you don’t use the wrong kind of cables or defective cables.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power-cord is never crimped or damaged. Check the system and the power-
cord from time to time.
Please turn off the power switch, when changing a signal cable.
If the device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do
not switch it on immediately. The arising condensation water might damage your system. Leave
the system switched off until it has reached room temperature.
If your Dap Audio device fails to work properly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Dap Audio dealer for
service.
Repairs, servicing and electric connection must be carried out by a qualified technician.
For replacement use fuses of same type and rating only.
WARRANTY: Till one year after date of purchase.
OPERATING DETERMINATIONS
This system is not designed for permanent operation. Consistent operation breaks will ensure that the
system will serve you for a long time without defects.
If this system is operated in any other way, than the one described in this manual, the product may suffer
damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious damage to people and property !
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
1) Your name
2) Your address
3) Your phone number
4) A brief description of the symptoms

4
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

5
Description of the device
Features
The CDMP-750 is a professional DJ CD/MP3 Player from DAP Audio.
• LCD display with blue backlight
• Pitch control +/- 8/16/100%
• Electronic anti shock buffer (15 seconds)
• Seamless loop function
• Beat related auto loop function
• Scratch function
• Cue function
• 5 digital BPM related effects
• 4 memories for hotloops or cues
• Program function
• USB stick/hard disk port
• Relay function
• Adjustable brake and start time
• Master tempo function
• Reverse play
• Auto BPM function
Overview

6
Top
Fig. 1
1) USB port 20)Memory C button
2) CD/ USB button 21)Reloop/ Exit
3) Edit / encoder 22)Memory D button
4) Folder button 23)Reverse button
5) Prog. button 24)Eject button
6) Relay button 25)FX on/off button
7) Search LED 26)FX select button
8) Scratch LED 27) Title button
9) Jogmode button 28)Time button
10)Jogwheel 29)Single button
11)Cue button 30)Pitch + Button
12)Tap button 31)Pitch - Button
13)Play/ Pause button 32)Pitch control fader
14) Rec button 33)Pitch range 8% LED
15)LCD Display 34)Pitch range 16% LED
16)Memory A button 35)Brake button
17)Loop In button 36)Range button
18)Memory B button 37)Master tempo button
19)Loop Out button 38)Pitch range 100% LED

7
Front Back
Fig. 2
39)Disc Slot
40)Digital out
41)Line out L/R
42)Remote jack
43)Relay jack
44)Power switch
45)AC Power
Installation
Remove all packing materials from the CD Player. Check that all foam and plastic padding is removed.
Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. The power supply is printed on the back of the device.
Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connections
1. Turn off the power (44)switch.
2. Connect the line out L/R (41)outputs to the input of your mixer.
CAUTION: Be sure that the power is off, when connecting the cables.

8
Functions
NAMES AND FUNCTIONS
Below is a description of the functions of the controls.
1. USB port
Use this port to connect a USB stick or an external hard disk. The USB port is only active when you’re in
USB mode.
Note: The CDMP-750 can handle a maximum of 2 Tbyte, 999 folders and 999 files.
2. CD/ USB button
Use this button to select CD mode or USB mode.
3. Edit / encoder
This encoder has a dual function, in normal mode dialing the encoder clockwise, allows you to skip a
track forwards, dialing counterclockwise will skip a track backwards.
Depending on the mode you are in, the edit encoder can also be used for: adjusting the loop length,
selecting folders or selecting a playlist format.
Clicking the edit encoder allows you to enter certain parameters. For more info, see the chapter on
operations on page 11 –14.
4. Folder button
Push this button to open the folder menu. While in the folder menu Folder will appear in the display.
Select a folder by rotating the edit (3) encoder and open the folder by pushing the edit (3) encoder.
5. Prog button
This button allows you to toggle the program mode on or off. See page 13, Program play.
6. Relay button
Pushing this button allows you to toggle the relay mode on or off. If the FX section is switched in, this
button allows you to toggle between gain and parameter.
7. Search LED
Indicates the CDMP-750 is in search mode. See page 12, Frame search.
8. Scratch LED
Indicates the CDMP-750 is in scratch mode. In scratch mode, you can use the jogwheel for scratch
effects.
9. Jog mode button
Pushing the jog mode button allows you to select search mode indicated by the search (7) LED,
scratch mode, indicated by the scratch (8) LED or normal (no LED lit). If no mode is active,
the jogwheel is in pitch bend mode. If there is no jogwheel (10) action while in search mode or
scratch mode for 10 seconds, the unit will return to normal (pitch bend) mode.
10.Jogwheel
The jogwheel is used for setting cues, scratch effects and performing a fast search depending on
the mode the unit is in.
11.Cue button
Push this button during playback to return to the position at which playback started.
12. Tap button
Tap this button to determine the BPM of the music manually.
Push and hold this button to start auto BPM mode.
13. Play/ Pause button
This button allows you to toggle between pause mode and playback mode.
14. Memo Loop/Cue button
Pushing this button allows you to store a Hot Loop or a Hot Cue.
Pushing and holding the memo loop/cue (14)button and dialing the jogwheel (10)allows you to set
the length of the auto Loop.
After the auto loop length is set up, the memo loop/cue (14) button will light up, indicating the unit is
ready to execute the auto loop playback. Pushing the loop in (17) button will automatically start
and finish a loop with the length previously set up. The bar length of auto loop can be selected from
1/32 to 32/1. During loop playback, dialing the edit (2) encoder allows you to (re)adjust the loop
length.
