DAPAudio CORE CDMP-750 User manual

CDMP-750 V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: D1155
MANUAL
ENGLISH

1
Ordercode: D1155
CDMP-750
Table of contents
Warning ...............................................................................................................................................................................2
Unpacking Instructions.................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................3
Return Procedure..........................................................................................................................................................4
Claims..............................................................................................................................................................................4
Description of the device.................................................................................................................................................5
Features ..........................................................................................................................................................................5
Overview ........................................................................................................................................................................5
Frontside..........................................................................................................................................................................7
Backside .........................................................................................................................................................................7
Installation...........................................................................................................................................................................7
Set Up and Operation .......................................................................................................................................................7
Functions .............................................................................................................................................................................8
Operations ........................................................................................................................................................................13
Loading a CD ...........................................................................................................................................................13
Unloading a CD .......................................................................................................................................................13
Selecting tracks........................................................................................................................................................13
Starting playback ....................................................................................................................................................13
Stop playback ..........................................................................................................................................................14
Pausing.......................................................................................................................................................................14
Setting a cue point..................................................................................................................................................14
Setting a hot cue Point ...........................................................................................................................................14
Cueing .......................................................................................................................................................................14
Frame search............................................................................................................................................................15
Scanning....................................................................................................................................................................15
Time display...............................................................................................................................................................15
Changing pitch of the song ..................................................................................................................................15
Program play ............................................................................................................................................................16
Loop play ..................................................................................................................................................................16
Set auto loop length ...............................................................................................................................................16
Auto loop play..........................................................................................................................................................16
Reloop........................................................................................................................................................................16
Creating a hot loop.................................................................................................................................................17
Relay play (two CD players)..................................................................................................................................17
Before switching off the power .....................................................................................................................................17
CDs ................................................................................................................................................................................17
Precaution on storage ...............................................................................................................................................17
Maintenance....................................................................................................................................................................18
Troubleshooting ...............................................................................................................................................................18
Product Specifications....................................................................................................................................................19
Dimensions........................................................................................................................................................................20
Notes ..................................................................................................................................................................................21

2
Ordercode: D1155
CDMP-750
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have arrived in good condition. Notify the dealer immediately and retain
packing material for inspection if any parts appear damaged while shipping or the carton itself shows
signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
• DAP CDMP-750
•Power cable (170 cm)
• RCA Male cable L/R > RCA Male cable L/R (50 cm)
•User manual
Safety Instructions
Every person involved with the installation, operation and maintenance of this system needs to:
•be qualified
•follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the system.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused to the system by manual modifications are not subject to
warranty.
This system contains no user-serviceable parts. Refer servicing to qualified technicians only.

3
Ordercode: D1155
CDMP-750
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the system.
Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never leave any cables lying around.
Do not insert other objects than CDs in the CD slot.
Do not connect this system to a dimmerpack.
Do not switch the system on and off in short intervals, as this may reduce the unit’s lifespan.
Do not open the device and do not modify the device.
Only use system indoor, avoid contact with water or other liquids.
Avoid flames and do not store in the vicinity of flammable liquids or gases.
Always disconnect power from the mains when the unit is not used. Only handle the power cord by
the plug. Never pull out the plug by tugging the power cord.
Make sure you do not use the inappropriate kind of cables or defective cables.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power cord is never crimped or damaged. Check the system and the power
cord from time to time.
Please turn off the power switch, when changing a signal cable.
If the device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation might damage your system.
Leave the system switched off until it has reached room temperature.
If your Dap Audio device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Dap Audio dealer for service.
Repairs, servicing and electric connection must be carried out by a qualified technician.
For replacement use fuses of same type and rating only.
WARRANTY: Until one year from date of purchase.
Operating Determinations
This system is not designed for permanent operation. Consistent operation breaks will ensure that the
system will serve for a longer amount of time without defects.
If this system is operated in any other way than the one described in this manual, the product may suffer
damages and the warranty can become void.
Any other operation may lead to various hazards like short-circuit, burns, electric shock, etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious injuries and/or damage of property !

4
Ordercode: D1155
CDMP-750
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the
device. Be prepared to provide the model number, serial number and a brief description of the cause for
the return. Be sure to properly pack the device, any shipping damage resulting from inadequate
packaging is the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or
replace product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to
use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a device is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

5
Ordercode: D1155
CDMP-750
Description of the device
Features
The CDMP-750 is a professional DJ CD/MP3 Player from DAP Audio.
• LCD display with blue backlight
• Pitch control +/- 8/16/100%
• Electronic anti shock buffer (15 seconds)
• Seamless loop function
• Beat related auto loop function
• Scratch function
• Cue function
• 5 digital BPM related effects
• 4 memories for hotloops or cues
• Program function
• USB stick/hard disk port
• Relay function
• Adjustable brake and start time
• Master tempo function
• Reverse play
• Auto BPM function
Overview
Fig. 01

6
Ordercode: D1155
CDMP-750
Fig. 02
USB port
Memory C button
CD/ USB button
Reloop/ Exit
Edit / encoder
Memory D button
Folder button
Reverse button
Prog. button
Eject button
Relay button
FX on/off button
Search LED
FX select button
Scratch LED
Title button
Jogmode button
Time button
Jog wheel
Single button
Cue button
Pitch + Button
Tap button
Pitch - Button
Play/ Pause button
Pitch control fader
Rec button
Pitch range 8% LED
LCD Display
Pitch range 16% LED
Memory A button
Brake button
Loop In button
Range button
Memory B button
Master tempo button
Loop Out button
Pitch range 100% LED

7
Ordercode: D1155
CDMP-750
Installation
Remove all packing materials from the CD Player. Check if all the foam and plastic padding is removed.
Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. The power supply is printed on the backside of the device.
Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connections:
01) Turn off the Power switch (44).
02) Connect the Line out L/R (41) outputs to the input of your mixer.
CAUTION: Ensure that the power is off while connecting the cables.
Frontside
Backside
Disc Slot
Digital out
Line out L/R
Remote jack
Relay jack
Power switch
Power cord
Fig. 03

8
Ordercode: D1155
CDMP-750
Functions
Names and Functions
Below is a description of the control functions.
01) USB port
Use this port to connect a USB stick or an external hard disk. The USB port is only active when you’re in
USB mode.
Note: The CDMP-750 can handle a maximum of 2 Tbyte, 999 folders and 999 files.
02) CD/ USB button
Use this button to select CD mode or USB mode.
03) Edit / encoder
This encoder has a dual function, in normal mode turning the encoder clockwise allows you to skip a
previous track, while turning counterclockwise will skip a following track.
Depending on the mode you are in, the edit encoder can also be used for: adjusting the loop
length, selecting folders or selecting a playlist format.
Clicking the edit encoder allows you to enter certain parameters.
For more info, see the chapter on operations on page 12.
04) Folder button
Press this button to open the folder menu. While in the folder menu, the folder will appear in the
display. Select a folder by rotating the Edit encoder (03) and open the folder
by pressing the Edit encoder (03).
05) Prog. button
This button allows you to toggle the program mode on or off. See page 15, Program play.
06) Relay button
Pressing this button allows you to toggle the relay mode on or off. If the FX section is switched in, this
button allows you to toggle between gain and parameter.
07) Search LED
Indicates that the CDMP-750 is in search mode. See page 14, Frame search.
08) Scratch LED
Indicates that the CDMP-750 is in scratch mode. In scratch mode, you can use the jog wheel for
scratch effects.
09) Jog mode button
Pressing the jog mode button allows you to select search mode - indicated by the Search LED (07)
button, scratch mode - indicated by the Scratch LED (08) button or normal mode (no LED lit).
If none of the modes is active, the Jog wheel (10) is in pitch bend mode. If there is no Jog wheel (10)
action while in search mode for 10 seconds, the unit will return to normal (pitch bend) mode.
10) Jog wheel
The jog wheel is used for setting cues, scratch effects and performing a fast search depending on
the mode the unit is in.
11) Cue button
Press this button during playback to return to the position at which playback started.
12) Tap button
Tap this button to determine the BPM of the music manually.
Press and hold this button to start auto BPM mode.
13) Play/ Pause button
This button allows you to toggle between pause mode and playback mode.
14) Rec button
Pressing this button allows you to store a Hot Loop or a Hot Cue.
Pressing and holding the Rec (14) button and turning the Jog wheel (10) allows you to set
the length of the auto Loop.
After the auto loop length is set, the Rec (14)button will light up, indicating that the unit is
ready to execute the auto loop playback. Pressing the Loop In (17) button will automatically start
and finish the loop with the length previously set up. The bar length of auto loop can be selected
from 1/32 to 32/1. During loop playback, turning the Edit encoder (03) allows you to (re)adjust the
loop length.

9
Ordercode: D1155
CDMP-750
15) LCD Display
Fig. 04
TOTAL TRACK: Shows the current track number or the folder number while selecting folders.
: Indicates that the unit is in playback mode
: Indicates that the unit is in pause mode
CUE: indicates that a cue point has been memorized.
CD: Indicates that the unit is in CD mode.
USB: Indicates that the unit is in USB mode.
PC: No function in the CDMP-750.
CONTINUE: When lit, the unit is in continuous play mode and will not stop after each track.
ELAPSED: Shows the actual playing time.
TOTAL: Shows the total playing time for a whole CD.
REMAIN: Shows how much time is left for the track playing at this moment.
TIME BAR: Indicates playing time.
TRACK: Shows a track number.
MINUTES: Shows elapsing or remaining time, depending on time mode setting.
SECONDS: Shows elapsing or remaining seconds, depending on time mode setting.
FRAMES: The CD Player breaks down a second into 75 frames for accurate cueing. This shows the
elapsing or remaining frames, depending on mode setting.
MODE DISPLAY: The mode display consists of 9 alphanumeric characters just beneath time display
and shows useful information such as: FX parameters, MP3 file’s name and folder number etc.
Folder name will not be displayed.
PITCH: Indicates the current pitch.
PROG: Lights up to indicate that there is a program list existing in normal playback. Blinks when a
program list is running.
MT:Lights up when performing master tempo function.
RELOOP: Lights up when performing the loop function.
BPM: Shows BPM value.
AUTO: Indicates that the AUTO BPM function is activated.
16) Memory A button
This button allows you to store a hotloop and/or a hotcue in memory A.
17) Loop In button
This button allows you to set the start point for the loop.
18) Memory B button
This button allows yout to store a hotloop and/or a hotcue in memory B.
19) Loop Out button
The loop out button allows you to set the end point for the loop. Pressing the button again, allows
you
to edit the loop.
20) Memory C button
This button allows yout to store a hotloop and/or a hotcue in memory C.
21) Reloop/ Exit button
Press this button to either exit or call the Loop playback.
22) Memory D button
This button allows yout to store a hotloop and/or a hotcue in memory D.
23) Reverse button
Use this button to toggle the reverse mode on or off. In reverse mode, the built in LED will light up and
the current track will be played backwards.
24) Eject button
Press this button to open and close the disc holder. The disc holder can’t be opened during
