DART Controls DP4 Control Series User manual

DP4 CONTROL SERIES
P.O. Box 10
5000 W. 106th Street
Zionsville, Indiana 46077
Phone [phone]
Fax [phone]
www.dartcontrols.com
Instruction Manual
LT78 (0817)
DIGITAL SPEED POTENTIOMETER WITH DISPLAY
FOR AC AND DC DRIVES
CONTROLS
A-5-3462D

Warranty
Dart Controls, Inc. (DCI) warrants its products to be free from defects in material and workmanship. The exclusive rem-
edy for this warranty is DCI factory replacement of any part or parts of such product which shall within 12 months after
delivery to the purchaser be returned to DCI factory with all transportation charges prepaid and which DCI determines
to its satisfaction to be defective. This warranty shall not extend to defects in assembly by other than DCI or to any
article which has been repaired or altered by other than DCI or to any article which DCI determines has been subjected
to improper use. DCI assumes no responsibility for the design characteristics of any unit or its operation in any circuit
or assembly. This warranty is in lieu of all other warranties, express or implied; all other liabilities or obligations on the
part of DCI, including consequential damages, are hereby expressly excluded.
NOTE: Carefully check the control for shipping damage. Report any damage to the carrier immediately. Do not attempt
to operate the drive if visible damage is evident to either the circuit or to the electronic components.
All information contained in this manual is intended to be correct, however information and data in this manual are
subject to change without notice. DCI makes no warranty of any kind with regard to this information or data. Further,
DCI is not responsible for any omissions or errors or consequential damage caused by the user of the product. DCI
reserves the right to make manufacturing changes which may not be included in this manual.
WARNING
Improper installation or operation of this control may cause injury to personnel or control failure. The control must
be installed in accordance with local, state, and national safety codes. Make certain that the power supply is dis-
connected before attempting to service or remove any components!!! If the power disconnect point is out of sight,
lock it in disconnected position and tag to prevent unexpected application of power. Only a qualied electrician or
service personnel should perform any electrical troubleshooting or maintenance. At no time should circuit continuity
be checked by shorting terminals with a screwdriver or other metal device.
Quick Jump
What models and options are available?
See page 3.
Looking for detailed specications?
See page 3.
Want to get started fast?
See basic electrical hook-up details on page 5.
See mechanical installation details on page 4.
See some sample applications starting on page 18.
Need Help?
See troubleshooting on page 23.

1
Table of Contents
Introduction....................................................................................................................................... 2
General Features .............................................................................................................................. 2
Models & Options ............................................................................................................................. 3
Model Options .............................................................................................................................. 3
Available Options .......................................................................................................................... 3
Specications ................................................................................................................................... 3
Electrical ....................................................................................................................................... 3
Mechanical ................................................................................................................................... 3
Environmental............................................................................................................................... 3
Cut-out and Mounting Dimensions ............................................................................................... 4
Mechanical Installation.................................................................................................................... 4
Exploded Panel View .................................................................................................................... 4
Installation & Diagrams.................................................................................................................... 5
P1 Terminal Block Hook-Up Diagram ........................................................................................... 5
P1 Terminal Block Descriptions .................................................................................................... 5
-1 Option Wiring............................................................................................................................ 6
Basic Operating Information ........................................................................................................... 6
Visual Reference .......................................................................................................................... 6
How to Change a Parameter's Value (The Short Story) ............................................................... 7
Operating the User Interface (The Long Story) ............................................................................ 7
Detailed Conguration Instructions ............................................................................................... 8
Default Configuration .................................................................................................................... 8
Resetting the Unit to Factory Defaults .......................................................................................... 8
JP1 (Program Enable Jumper) .................................................................................................... 8
Software Parameters .................................................................................................................... 9
Parameter Descriptions .............................................................................................................. 11
Application Examples .................................................................................................................... 18
User Interface for Industrial Conveyor Oven with AC Drive ........................................................ 18
Digital Front Panel for Regenerative Industrial Treadmill ............................................................ 19
Programmable Digital Voltage Source with Enable Switch ......................................................... 21
Troubleshooting........................................................................................................................ 23
Technical Support Options ............................................................................................................... 23
What's Special About www.dartcontrols.com? ................................................................................. 23

2
Introduction
The DP4 digital potentiometer is a compact, microprocessor-based unit capable of being either field or
factory configured for a number of industry's user-interface needs. The DP4 allows the user to adjust
the displayed value via the front-panel push buttons. As the displayed value is raised or lowered, the
output signal from the DP4 follows proportionally according to the unit's configuration. These units
supports both unipolar and bipolar output and are capable of automatically inverting, scaling, and
offsetting the output as needed. Utilizing Dart's new modular bus design techniques, the DP4 series
is ideal for volume OEM applications requiring specialized inputs and outputs. Contact Dart Controls'
Sales Department for details. This flexibility makes the DP4 series ideal for applications such as:
Water and Waste Treatment Systems
Conveyor Oven Controllers
Synchronized Conveyor Lines
Its durable 1/8 DIN aluminum housings can be easily mounted in a panel or control cabinet. New
optional pluggable terminal block allows the installer to quickly install or replace units without the
hassle of physically removing and reattaching wires. The units can be ordered with either standard
European-style terminal block or optional “pluggable” connector.
General Features
- Microprocessor-based design combines the ultimate in responsiveness and accuracy in one package
- Digital front-end ensures long-term accuracy of output signal over time and temperature
- Non-volatile memory stores adjustable parameters even when power has been removed
- Factory or field programmable via front-panel keypad
- Adjustable parameters include display range, output range, output polarity, alarm options, etc.
- Internal program-enable jumper selectively prevents tampering with unit’s configuration
- Universal power supply accepts line voltages inputs from 85-265VAC @ 50-60Hz without switches
or jumpers. The unit automatically adjusts as needed.
- Transient voltage protection prolongs unit's life in harsh industrial environments
- Self-contained power supply for external sensor, limited to 5V @ 50mA
- Programmable alarm output with Form C contacts rated to 250VAC @ 5A
- 1/8 DIN durable aluminum housing for panel mounting.
- Large 4 digit, 1/2” LED display
- G.E. Lexan membrane and gasket (which are included) meet NEMA 4X standards when used with
NEMA 4X enclosures
- European terminal block or pluggable terminal block available
- Wide operating ambient temperature range of -10C to 45C (14F to 113F)
- Multiple operating modes including:
• Rate Mode – Displays in rate and non-rate units such as RPM, Gallons per Second, &
percent
• Time Mode – Displays in time units such as HH:MM, MM:SS, SS:TT, or other unit

3
Models & Options
Model Options
Available Options
Specications
Electrical
Mechanical
Environmental
Model Input Voltage
@ 50 - 60Hz Output Voltage
Pickup or
Encoder
Required?
DP4 85-265VAC 0-2 VDC
THROUGH
0-24 VDC
No
Line Input Voltage........................................................................................................Any Voltage from 85-265 VAC
Line Input Frequency...................................................................................................... Any Freq. from 48-62 Hertz
Display Range .......................................................................................................................................0.001 – 9999
Units of Operation ..................................................................................................... User Programmable, any Unit
Onboard Power Supply (Externally Accessible) ..................................................................................... 5V @ 50mA
Isolated Alarm Relay Output Ratings ..................................................................................................250VAC @ 5A
Pot Lo/Hi supply VDC range........................................................................................... 0-2 VDC through 0-24 VDC
Pot wiper VDC range....................................................................................... Pot Lo +50mV through Pot Hi -50mV
Display Type .................................................................................................................LED, Red, 4 Digit, ½” Height
Housing Type (with supplied gasket in NEMA 4X panel)...............................................................1/8 DIN NEMA 4X
Connector Style (pluggable connector optional) ................................................... 12-position 5mm European Style
Terminal Block Torque Setting................................................................................................ 4.4 in. lb. Max or .5Nm
Faceplate Material......................................................................................... Polycarbonate with GE Lexan Overlay
Housing Material ........................................................................................................................................Aluminum
Length (Required Panel Depth).................................................................................................... 4.625”, 117.48mm
Faceplate Width ........................................................................................................................... 4.539”, 115.29mm
Weight ASP10 .................................................................................................................. 0.900 lb, 14.4 oz, 408.22g
Operating Temperature Range ........................................................................................ -10C to 45C (14F to 113F)
Operating Humidity Range..................................................................................................... 95%, non-condensing
Option Sufx Description Example
-1 Expansion board which adds support for remote push button wiring via a
European-style terminal block. DP4-1
-P Optional pluggable European-style terminal block DP4-P
-9 Blank Lexan DP4-9

4
PANEL MOUNTING GASKET
(WITH THE ADHESIVE SIDE OF
GASKET FACING THE CUSTOMER
MOUNTING PANEL)
CUSTOMER
MOUNTING PANEL
(HOLE CUT-OUT FOR CONTROL
HOUSING APPROXIMATELY
3.622" WIDE BY 1.770" HIGH)
DP4
CONTROL
SUPPLIED WITH EACH CONTROL:
1) GASKET
2) (2) 6-32 X 3/4 PANHEAD BLACK OXIDE STAINLESS SCREWS
3) (2) #6 NUT WITH LOCKWASHER
Tac Item ValPage
Tach
Ite
m
ValuPage
3.622"
HOUSING DEPTH
4.625"
PA NEL CUT-OUT
1.770"
DP4
MICRO-DRIV
DIGITAL POT
ENTER
CONTROLS
4.000"
4.000"
.140 " x 2
0.885"
Alarm
Rev
FwdNeg
5.000"
4.625"
2.289"
1.656"
Mechanical Installation
Exploded Panel View
Cut-out and Mounting Dimensions

5
Installation & Diagrams
P1 Terminal Block Hook-Up Diagram
P1 Terminal Block Descriptions
P1-1 (AC / N) – For single phase AC lines connect the Neutral side of your AC line to this terminal.
For systems with two hot AC lines, connect either of the Hot AC lines to this terminal.
P1-2 (AC / L) – For single phase AC lines connect the Hot side of your AC line to this terminal. For
systems with two hot AC lines, connect either of the Hot AC lines to this terminal.
P1-3 (HI) - This is the POT HI reference terminal.This terminal must be connected to the most positive
speed pot input terminal of the partner control.This terminal will generally be referred to as Pot
HI or +V for positive supplies and Com for negative supplies.
P1-4 (WP) - This is the Wiper output terminal. This terminal will output an analog voltage signal
proportional to the referenced voltage signals connected to P1-3 (HI) and P1-5 (LO). This
terminal should be connected to the wiper or signal input of the partner control.
P1-5 (LO) - This is the POT LO reference terminal. This terminal must be connected to the most
negative speed pot input terminal of the partner control. This terminal will generally be referred
to as Pot LO or Com for positive supplies and –V for negative supplies.
P1-6 (COM) – This is the common point for the control logic. Any other equipment or source needing
to reference the control common will be connected to this terminal.
P1-7 (+5V) – This is a self-contained +5VDC power supply capable of up to 50mA. Various low-
voltage sensors can be driven from this supply if desired.
P1-8 (S1) – This is the programmable signal 1 input. It can be configured to perform a number of
special features including inhibit and jog.
P1-9 (S2) – This is the programmable signal 2 input. It can be configured to perform a number of
special features including inhibit and jog.
P1-10 (1NO) – This is the normally-open contact of the user assignable relay output.
P1-11 (1C) – This is the common contact of the user assignable relay.
P1-12 (1NC) – This is the normally-closed contact of the user assignable relay output.
AC INPUT
AC INPUT
P1-1
P1-2
P1-3
P1-4
P1-5
P1-6
P1-7
P1-8
DP4
2 AMP
HIGH OUTPUT
WIPER OUTPUT
COMMON
+5VDC
SIGNAL 1
P1-9
P1-10
P1-11
P1-12
}85-265VAC
}Form C
Relay output
(Programmable)
Alarm Output - Normally Open
Alarm Output - Common
Alarm Output - Normally Closed
* P1-8 & P1-9 signal inputs may be programmed for a number of functions.
SIGNAL 2
*
LOW OUTPUT
}Connect to the speedpot
of the control being driven.
High must be positive
voltage with respect to low.
*
}External Supply (+5V@50mA)
N
L
HI
W
LO
COM
+5V
S1
S2
NO
C
NC

6
-1 Option Wiring
The -1 option board is a module which allows external up and down push buttons to be wired to the
unit. These buttons operate exactly like the Up and Down buttons on the user interface. This module
is commonly used to allow PLCs or hand-held pendants to operate the front-panel remotely. Wires
for the external buttons are attached via a 3mm European terminal block on the -1 option board. The
buttons are activated by shorting the terminal labeled Com to either the Up or Down terminal.
Basic Operating Information
The DP4 digital potentiometer is a panel-mount digital-to-analog user interface. Put simply, it allows
the user to adjust the displayed value via push buttons on the front panel; and, outputs a proportional
signal according to its configuration. It can be configured to work with both single and bidirectional
partner drives. It also supports both unipolar and bipolar output supplies.
The DP4 can display values in rate and time formats. In Rate mode, output units such as Gallons-
per-Minutes, RPM, and Percent are possible with just a few minor adjustments. In Time mode, output
units such as Hours:Minutes (HH:MM), Minutes:Seconds (MM:SS), and Seconds:Ticks (SS:TT) are
supported. In Time modes, the output will be inversely proportional to the displayed value in order to
represent a programmable process time.
See the application examples in this manual for additional information on how the DP4 can be
configured.
Visual Reference
-1
-2
-3
DOWN UP
REMOTE SWITCHING
MICROPROCESSOR
SERIES PC BOARD
UP
DOWN
COMMON
-1 OPTION
BOARD
Tac Item ValPage
Tach
Ite
m
ValuPage
MICRO-DRIV
DIGITAL POT
ENTER
CONTROLS
Display Window
Up & Down Buttons
ENTER (Select) Button
Alarm
Rev
Fwd
Neg
Alarm Indicator
Forward Indicator
Reverse Indicator
Negative Indicator

7
How to Change a Parameter's Value (The Short Story)
1. Hold down the Enter button until Parameter-Selection Mode is entered
2. Using the Up and Down buttons, select the desired parameter number to view or edit
3. Press the Enter button to change the value of the parameter
4. Using the Up and Down buttons, change the parameter's value as desired
5. Press the Enter button to permanently save the changes (Return to Parameter-Selection Mode)
6. Select parameter zero and press the Enter button to return to Running Mode
Operating the User Interface (The Long Story)
Although the DP4 user interface is very versatile, it is also simple to setup and operate. With just a few
button presses, it allows the user to configure a number of adjustable parameters. The LED display
has three basic operating modes: Running Mode, Parameter-Selection Mode, and Value Mode. Each
of the three modes have specific visual indicators that allow the user to immediately determine the
current state or mode of the user interface. Parameter-Selection Mode and Value Mode can only
be entered if the Program Enable jumper is in the “On” position.
Running Mode is the default display of the unit when power is applied. The DP4 will spend the majority
of its time in this mode. In Running Mode, the display shows the target value in the appropriate user-
defined format of rate, time, or percentage. The control will continuously attempt to drive the motor at
the requested target rate. In this display mode, the Up and Down buttons increase or decrease the
displayed target value until either the display minimum or display maximum limit is reached. Depending
on the alarm configuration, these buttons may also serve as an alarm-silence or alarm-reset button.
Example displays for rate, time, and follower operating modes are 13.60, 45:30, and 9301.
Parameter-Selection Mode can be entered by simply pressing and holding the Enter button down for
three seconds. Once in Parameter-Selection Mode, the far left of the display will be a ‘P’. The right side
of the display will indicate the currently selected parameter number for editing purposes. Pressing the
Up or Down button will increase or decrease the selected parameter number on the display. Although
the parameter numbers are in numerical order, some numbers are skipped. These numbers represent
reserved parameters that are not yet implemented and are not displayed. Once the desired parameter
number is displayed, a press of the Enter button will change the display to the Value Mode. When in
Parameter-Selection Mode, pressing the Enter button with parameter 0 selected will cause the
unit to return to Running Mode. Example displays for Parameter-Selection Mode are P 1, P 12,
and P 54. See the Software Parameters for a list of available parameters.
Value Mode is used to modify the value of the selected parameter. When in Value Mode, the two
dots which form the colon, between digits two and three, will alternately flash (one, then the other) to
inform the user that a parameter’s value is being edited. Pressing the Up or Down button increases or
decreases the selected parameter’s value. See the Software Parameters for a list of allowable values
and ranges. Value changes take effect immediately. For example, when scrolling through the alarm
output conditions, the relay will activate as the always-active selection is passed. Once the desired value
is showing in the display window, pressing the Enter button again will return to Parameter-Selection
Mode. The new value is not saved in permanent memory until the Enter button is pressed. Removing
power from the unit while in Value Mode may result in the specified new value being lost.

8
Detailed Conguration Instructions
Default Conguration
When shipped from the factory, the following basic settings are in place:
Rate Mode Operation in % Units
Unipolar Output without Deadband
Decimal Point Display: XXX.X
Display Range: 0 - 100.0
Output Range: 0 - 100% of Applied Pot High Voltage
Signal Input 1 (S1) Mode: Force Output to 0% when Low
Signal Input 2 (S2) Mode: Force Output to 0% when Low
Alarm Output: Disabled
Resetting the Unit to Factory Defaults
The factory-default settings can be easily restored using either of two methods. Both methods require
the Program Enable jumper to be in the “On” position. The first is to apply power to the unit with both
the Enter and Down buttons pressed for 3 seconds. The second is to change the value of parameter
95 to 5.
JP1 (Program Enable Jumper)
The JP1 jumper is located under the dust cover on the back end of the upper board. When the jumper
is set to the "Off" position, all programming features are locked out to the front panel user. When the
jumper is in the "On" position, the programming parameters are open to change. JP1 is shipped from
the factory set in the "On" position.

9
Software Parameters
Parameter Description
Value Range
(units)
Factory
Default
User
Settings
0 Selecting this item exits to Running Mode n/a n/a
Read-Only Parameters
1 Model Number 40 – DP4 Unit 40
2 Software Build 1 – 9999 n/a
3 Hardware Version 1 – 9999 n/a
4 Serial Number – Major (reserved) n/a n/a
5 Serial Number – Minor (reserved) n/a n/a
General Setup
10 Operating Mode Rate Modes:
1 – Unipolar Output
2 – Unipolar Output with Deadband
3 – Bipolar Output
4 – Bipolar Output with Deadband
Time Modes:
5 – Unipolar Output
6 – Unipolar Output with Deadband
7 – Bipolar Output
8 – Bipolar Output with Deadband
Other Modes:
9 – Absolute Value Output with Relay
Direction Control
10 – Absolute Value Output with
Relay Direct. Control and Deadband
1
11 Display Intensity 0 – 31 (Dim – Bright) 26
12 Display Zero Blanking 1 – ___X Show at least 1 Digit
2 – __XX Show at least 2 Digits
3 – _XXX Show at least 3 Digits
4 – XXXX Show all 4 Digits
2
13 Decimal Point Position 0 – DP Disabled (XXXX)
1 – X.XXX
2 – XX.XX
3 – XXX.X
4 – XXXX.
3
15 Keypad Mode 1 – Linear, Constant Rate
2 – Non-linear, Accelerating Rate
2
16 Keypad Scroll Delay 0 – 30 (Fast – Slow) 10
18 Power-up Mode 1 – Default to Zero Display
2 – Default to Power-up Value
3 – Default to Previous Running Val.
3
19 Power-up Value 0 – 9999 (Display Units) 0
Display & Output Setup
20 Display Value at Minimum Output -9999 – 9999 (Display Units) 0
21 Display Value at Maximum Output -9999 – 9999 (Display Units) 1000
22 Display Value at Center Output (Bipolar Only) -9999 – 9999 (Display Units) 0
25 Output % - Minimum 0 – 1000 (1/10th Percent Units) 0
26 Output % - Maximum 0 – 1000 (1/10th Percent Units) 1000
27 Output % - Center (Bipolar Modes Only) 0 – 1000 (1/10th Percent Units) 500
28 Output Deadband Width 0 – 1000 (1/10th Percent Units) 0

10
Software Parameters, cont'd
Parameter Description
Value Range
(units)
Factory
Default
User
Settings
Signal Input #1 (S1) Setup
30 S1 Input Configuration 1 – Output 0% When S1 Low
2 – Output 0% When S1 High
3 – Output Setpoint When S1 Low
4 – Output Setpoint When S1 High
5 – Output 100% When S1 Low
6 – Output 100% When S1 High
7 – Lock Set Point when S1 is Low
(See: Parameter Description for details)
1
31 S1 Setpoint -9999 – 9999 (Display Units) 0
Signal Input #2 (S2) Setup
35 S2 Input Configuration 1 – Output 0% When S2 Low
2 – Output 0% When S2 High
3 – Output Setpoint When S2 Low
4 – Output Setpoint When S2 High
5 – Output 100% When S2 Low
6 – Output 100% When S2 High
7 – Lock Set Point when S2 is High
(See: Parameter Description for details)
1
36 S2 Setpoint -9999 – 9999 (Display Units) 0
Alarm Output Configuration
40 Activation Conditions 0 – Always Off
1 – Always On
2 – Active when Above upper limit
3 – Active when Below lower limit
4 – Active inside Range
5 – Active outside Range
6 – Active Zero or Equivalent Output
7 – Relay Direction Control Mode
0
41 Output Style & Reset Mode 1 – Constant & Auto Reset
2 – Constant & Manual Reset
3 – Pulsed & Auto Reset
4 – Pulsed & Manual Reset
1
42 Reset Configuration 1 – No Sil., Reset on Key
2 – No Sil., Reset on S2 High
3 – No Sil., Reset on S2 Low
4 – Sil., Reset on Key
5 – Sil., Reset on S2 High
6 – Sil., Reset on S2 Low
1
43 Display Flash On Active Alarm 0 – Alarm Flash Disabled
1 – Alarm Flash Enabled
0
44 Pulse on Time 1 – 3600 (seconds) 1
45 Pulse off Time 1 – 3600 (seconds) 1
46 Pulse Count 0 – 9999 (pulses) 0
47 Lower Limit 0 – 9999 (display units) 0
48 Upper Limit 0 – 9999 (display units) 9999
Parameter Memory Commands
95 Restore Settings to Factory Default 0 – Do Nothing & Exit
5 – Restore Factory Defaults
0
98 Save to User Default Area 0 – Do Nothing & Exit
1 – Save Setting
0
99 Restore from User Default Area 0 – Do Nothing & Exit
1 – Restore Settings
0

11
Parameter Descriptions
Parameter 0 – Exit to Running Mode
When parameter 0 is selected in Parameter-Selection Mode, the unit will return to Running Mode
and display the running value. This should be selected once the changes to the parameters
are completed.
Parameter 1 – Model Number (Read Only)
This is a number which represents the base model number for the product. The model code
for the DP4 is 40.
Parameter 2 – Software Build (Read Only)
The software build is a code which identifies the software version of the unit.
Parameter 3 – Hardware Version (Read Only)
The hardware version is a code which identifies which hardware was used to build the unit.
Parameter 4 & 5 – Serial Number, Major & Minor (Read Only)
These parameters are reserved for future use as an electronic serial number and are unique
to each manufactured unit.
Parameter 10 – Operating Mode
This parameter defines the operating mode for the entire unit. There are two basic modes of
operation, Rate and Time. In Rate modes, the unit displays in rate and non-time-based units
such as RPM, Gallons per Hour, and Percent of Maximum Output. In Time modes, the unit
displays in time-based units using the format AA:BB. The AA:BB format can be adjusted to
represent Hours:Minutes or Minutes:Seconds.
Mode 1 – Rate Mode, Unipolar Output
Mode 2 – Rate Mode, Unipolar Output with Deadband
Mode 3 – Rate Mode, Bipolar Output
Mode 4 – Rate Mode, Bipolar Output with Deadband
Mode 5 – Time Mode, Unipolar Output
Mode 6 – Time Mode, Unipolar Output with Deadband
Mode 7 – Time Mode, Bipolar Output
Mode 8 – Time Mode, Bipolar Output with Deadband
Mode 9 – Other Mode, Absolute Value Output with Relay Direction Control
This mode allows the DP4 to interface with bi-directional Controls that have FWD and
REV command inputs and use the absolute value of the pot to determine speed only. In
this mode, the user must configure the following parameter:
Display Min, Max, and Center
Output Min and Max
Output Deadband (Mode 10 Only!)
Mode 10 – Other Mode, Absolute Value Output with Relay Direction Control and with
Deadband Funcion
Same as Mode 9, except deadband is supported. Must set Deadband value at Item 28.
Parameter 11 – Display Intensity
This parameter adjusts the intensity of the LED display digits in the front panel of the unit. The
values of 0 – 31 correspond to a gradual change from very dim to very bright. This is often
useful when the DP4 is used in the same panel as other pieces of equipment with LED display
and a uniform display brightness is desired. Simply adjust the DP4 to match its surroundings.
Parameter 12 – Display Zero Blanking
This selects the number of display digits that are required to be displayed regardless of the
display value. For example, with a Display Zero Blanking setting of 3 and a displayed value of
6, the display would show "_006".
Mode 1: ___X Always show at least 1 digit
Mode 2: __XX Always show at least 2 digits
Mode 3: _XXX Always show at least 3 digits
Mode 4: XXXX Always show all 4 digits

12
Parameter 13 – Decimal Point (DP) Position
This selects the format of the display with respect to the decimal point’s position. This parameter
does not affect the value entry for other parameters. The decimal point is only displayed in Rate
modes. For example, if the user desires to display numbers such as 12.34 or 1.05, then parameter
13 should be set to 2.
Mode 0: Fixed XXXX (DP disabled)
Mode 1: Fixed X.XXX
Mode 2: Fixed XX.XX
Mode 3: Fixed XXX.X
Mode 4: Fixed XXXX.
Parameter 15 – Keypad Mode
This parameter selects the operating mode of the front-panel push buttons. In some applications,
increasing or decreasing the scroll rate provides the user more controllability when entering settings.
Parameters 14 and 15 affect only the Up and Down buttons when the user interface is in Running Mode.
These settings also apply to remote Up / Down buttons which are attached via the -1 option board.
Mode 1: Linear, Constant Rate
In linear mode, pressing and holding the Up or Down buttons will cause the display to continuously
change value in the requested direction until either the Display Minimum or Display Maximum is
reached. The displayed value will scroll at a constant rate which is specified using parameter 16.
Mode 2: Non-linear, Accelerating Rate
In non-linear mode, pressing and holding the Up or Down buttons will cause the display to
continuously change value in the requested direction until either the Display Minimum or Display
Maximum is reached. The displayed value will initially scroll at a slow rate and increase in speed
until the maximum scroll rate is achieved. The initial scroll rate is specified using parameter 16.
Parameter 16 – Keypad Scroll Mode
This parameter sets the scroll speed for the front-panel push buttons. The function of this parameter
varies slightly depending on the Keypad Mode. See parameter 15 for more details.
Parameter 18 – Power-Up Mode
This parameter defines the mode which determines the default Running Value when power is initially
applied to the DP4.
Mode 1: Default to Zero
When in this mode, the unit will default to zero (display units).
Mode 2: Default to Power-Up Value
When in this mode, the unit will default to the Power-up Value, parameter 19.
Mode 3: Default to Previously Running Value
When in this mode, the unit will default to the previous running value before power was removed.
A previous running value must have been active for at least 3 seconds to be recalled after power
has been disconnected and reapplied.
Parameter 19 – Power-Up Value
When Power-up Mode is set to 2, this parameter will designate the default display value at power-up
in display units.
Parameter 20 – Display Value at Minimum Output
This parameter defines the lower end of the display range. This is the value which limits how low
the user is able to scroll the displayed value in Running Mode. In Rate and Time modes, this value
is set in display units. This parameter is set without consideration for the decimal point's position.
For example, setting this parameter to 125 would set the lower display limit at 12.5, 0.125, or 125
seconds according to the other configuration parameters.
Parameter 21 – Display Value at Maximum Output
This parameter defines the upper end of the display range. This is the value which limits how high
the user is able to scroll the displayed value in Running Mode. In Rate and Time modes, this value is
set in display units. This parameter is set without consideration for the decimal point's position. For
example, setting this parameter to 1000 would set the upper display limit at 100.0, 1.000, or 1000
seconds according to the other configuration parameters.

13
Parameter 22 – Display Value at Center Output
This defines the center value for the display in bipolar (or bidirectional) modes of operation. In
bipolar applications, this value should be set to the display value that corresponds to a null or
zero output. When in Running Mode, display values above this will produce an output toward the
programmed Maximum Output %;whereas, display values below this will produce an output toward
the programmed Minimum Output %. As the display value approaches the number programmed
in this parameter, the DP4 will produce an output that approaches the percentage programmed in
parameter 28. See parameters 25 - 27 and the application examples for additional information.
Parameter 25 – Minimum Output % (in 1/10 percent units)
This parameter sets the output percentage which corresponds to the minimum display value,
parameter 20. This parameter has a range of 0 to 1000 which represents 0.0 to +100.0 percent
of output. When the user is adjusting the display value towards the programmed minimum
display, the output will linearly approach the value of this parameter. For example, setting this
parameter to 25 will configure the DP4 to output 2.5% when the user adjusts the display value
to equal the display minimum, parameter 20. Setting this minimum percentage higher than the
maximum (parameter 26) will cause the polarity of the output to be inverted. See parameters
20 - 22 and the application examples for additional information.
Parameter 26 – Maximum Output % (in 1/10 percent units)
This parameter sets the output percentage which corresponds to the maximum display value,
parameter 21. This parameter has a range of 0 to 1000 which represents 0.0 to +100.0 percent of
output. When the user is adjusting the display value towards the programmed maximum display,
the output will linearly approach the value of this parameter. For example, setting this parameter
to 850 will configure the DP4 to output 85.0% when the user adjusts the display value to equal
the display maximum, parameter 21. Setting this maximum percentage lower than the minimum
(parameter 25) will cause the polarity of the output to be inverted. See parameters 20 - 22 and
the application examples for additional information.
Parameter 27 – Center Output % (in 1/10 percent units)
This defines the center percentage for the output in bipolar (or bidirectional) modes of operation.
In bipolar applications, this value should be set to the percentage of output that corresponds
to a null or zero output of the partner drive. When in Running Mode, display values above the
display center (parameter 22) will produce an output toward the programmed Maximum Output
%; whereas, display values below the display center (parameter 22) will produce an output toward
the programmed Minimum Output %. As the display value approaches the programmed display
center value (parameter 22), the DP4 will produce an output that approaches the percentage
programmed in this parameter. See parameters 20 - 22 and the application examples for
additional information.
Parameter 28 – Output Deadband % (in 1/10 percent units)
This defines the width of the output's deadband. This is the range of output percentage values
which will produce a zero or center output percentage in unipolar and bipolar modes respectively.
This value is the width of the range in percentage units. For example: If the DP4 were configured
for bipolar operation and this parameter were set to 50, then any output which was within 5%
of the center output percentage would be forced to the center output value. See parameters
20 - 22 and the application examples for additional information.
Parameter 30 – Signal Input 1 (S1) Conguration
This parameter determines the operating mode of signal input 1 (S1).
Mode 1: Output 0% When S1 Low
When the S1 input is at an electrically low state or wired to the unit's common, the DP4
will force its output to 0%. Once the S1 input returns to an electrically high (+5V) state or
allowed to float disconnected, the output will once again correspond to the display value.
Mode 2: Output 0% When S1 High
When the S1 input is at an electrically high (+5V) state or allowed to float disconnected,
the DP4 will force its output to 0%. Once the S1 input returns to an electrically low state
or wired to the unit's common, the output will once again correspond to the display value.

14
Mode 3: Ouput Setpoint When S1 Low
When the S1 input is at an electrically low state or wired to the unit's common, the DP4
will force its output to a percentage which corresponds to the programmed jog setpoint,
parameter 31. Once the S1 input returns to an electrically high (+5V) state or allowed to
float disconnected, the output will once again correspond to the display value.
Mode 4: Output Setpoint When S1 High
When the S1 input is at an electrically high (+5V) state or allowed to float disconnected,
the DP4 will force its output to a percentage which corresponds to the programmed jog
setpoint, parameter 31. Once the S1 input returns to an electrically low state or wired to
the unit's common, the output will once again correspond to the display value.
Mode 5: Output 100% When S1 Low
When the S1 input is at an electrically low state or wired to the unit's common, the DP4 will
force its output to 100%. Once the S1 input returns to an electrically high (+5V) state or
allowed to float disconnected, the output will once again correspond to the display value.
Mode 6: Output 100% When S1 High
When the S1 input is at an electrically high (+5V) state or allowed to float disconnected,
the DP4 will force its output to 100%. Once the S1 input returns to an electrically low state
or wired to the unit's common, the output will once again correspond to the display value.
Mode 7: Lock Set Point when S1 is Low
“LOC” is displayed when one of the front panel buttons is pressed with S1 in an electrically
Low State. Program by bringing S1 terminal P1-8 to electrically High state or allow S1 to float
when disconnected from Common terminal P1-6. Enter Program Mode, Select Parameter
30, Press Enter, select value item 7, Press Enter again.
Note: (Select a value 1-6 to Exit the LOCK Set Point than press enter) Select Parameter
0 and press enter to Exit Program Mode. Activate for the new changes to take effect by
cycling AC power Off/On.
Parameter 31 – Signal Input 1 (S1) Setpoint
When the S1 configuration, parameter 30, is set to one of the setpoint (jog) modes(modes 3
or 4), this parameter defines the jog setpoint in display units. This parameter is always set in
display units.
Parameter 35 – Signal Input 2 (S2) Conguration
This parameter determines the operating mode of signal input 2 (S2).
Mode 1: Output 0% When S2 Low
When the S2 input is at an electrically low state or wired to the unit's common, the DP4
will force its output to 0%. Once the S2 input returns to an electrically high (+5V) state or
allowed to float disconnected, the output will once again correspond to the display value.
Mode 2: Output 0% When S2 High
When the S2 input is at an electrically high (+5V) state or allowed to float disconnected,
the DP4 will force its output to 0%. Once the S2 input returns to an electrically low state
or wired to the unit's common, the output will once again correspond to the display value.
Mode 3: Ouput Setpoint When S2 Low
When the S2 input is at an electrically low state or wired to the unit's common, the DP4
will force its output to a percentage which corresponds to the programmed jog setpoint,
parameter 36. Once the S2 input returns to an electrically high (+5V) state or allowed to
float disconnected, the output will once again correspond to the display value.
Mode 4: Output Setpoint When S2 High
When the S2 input is at an electrically high (+5V) state or allowed to float disconnected,
the DP4 will force its output to a percentage which corresponds to the programmed jog
setpoint, parameter 36. Once the S2 input returns to an electrically low state or wired to
the unit's common, the output will once again correspond to the display value.
Mode 5: Output 100% When S2 Low
When the S2 input is at an electrically low state or wired to the unit's common, the DP4 will
force its output to 100%. Once the S2 input returns to an electrically high (+5V) state or
allowed to float disconnected, the output will once again correspond to the display value.

15
Mode 6: Output 100% When S2 High
When the S2 input is at an electrically high (+5V) state or allowed to float disconnected,
the DP4 will force its output to 100%. Once the S2 input returns to an electrically low state
or wired to the unit's common, the output will once again correspond to the display value.
Mode 7: Lock Set Point when S2 is High
“LOC” is displayed when one of the front panel buttons is pressed with S2 in an electrically
High State. Program by bringing S2 terminal P1-9 to electrically Low state or wire to unit’s
Common terminal P1-6. Enter Program Mode, Select Parameter 35, Press Enter, select
value item 7, Press Enter again.
Note: (Select a value 1-6 to Exit the LOCK Set Point than press enter) Select Parameter
0 and press enter to Exit Program Mode. Activate for the new changes to take effect by
cycling AC power Off/On.
Parameter 36 – Signal Input 2 (S2) Setpoint
When the S2 configuration, parameter 35, is set to one of the setpoint (jog) modes(modes 3
or 4), this parameter defines the jog setpoint in display units. This parameter is always set in
display units.
Parameter 40 – Alarm 1 Conditions
This defines which conditions will result in the alarm 1 output being activated.
Mode 0: Always Inactive
The alarm output will remain in an inactive state. In this state, the NC and C contacts
will be internally electrically connected.
Mode 1: Always Active (When Power Is Applied)
The alarm output will become active when the power is applied to the unit. In this state,
the NO and C contacts will be internally electrically connected.
Mode 2: Active When Display Value Above Limit
The alarm output will activate when the displayed value is above the upper limit setting,
parameter 48.
Mode 3: Active When Display Value Below Limit
The alarm output will activate when the displayed value is below the lower limit setting,
parameter 47.
Mode 4: Active When Display Value Inside Range
The alarm output will activate when the displayed value is greater than or equal to lower
limit settings and less than or equal to the upper limit setting.
Mode 5: Active When Display Value Outside Range
The alarm output will activate when the displayed value is less than the lower limit setting
or greater than upper limit setting.
Mode 6: Active When Display Value Results in a Zero or Equivalent Output
If the display is set to a value that produces a zero output or is within the programmed
deadband, then the alarm is activated.
Mode 7: Relay Direction Control Mode
In this mode, the relay output will determine which direction is being requested. This will
typically be used with Item 10 modes 9 & 10.
Forward = relay not energized; Reverse = relay energized
Parameter 41 – Alarm 1 Output Style & Reset Conguration
This setting configures the output mode and reset method for the alarm output.
Mode 1: Constant & Auto Reset
In this mode, the alarm output will remain active until the alarm condition ceases to exist.
The alarm will automatically reset when the conditions return to normal.
Mode 2: Constant & Manual Reset
In this mode, the alarm output will remain active until the alarm is reset manually. See
parameter 42 for details.

16
Mode 3: Pulse & Auto Reset
In this mode, the alarm output will pulse on and off until the alarm condition ceases to
exist. The pulsed modes are commonly used for audible alarms where a constant output
would be considered distracting or awkward. The alarm will automatically reset when the
conditions return to normal.
Mode 4: Pulse & Manual Reset
In this mode, the alarm output will pulse on and off until the alarm is reset manually. See
parameter 42 for reset details. The pulsed modes are commonly used for audible alarms
where a constant output would be considered distracting or awkward.
Parameter 42 – Alarm 1 Reset Conguration
This setting determines which actions will cause an active alarm to be silenced or reset.
Mode 1: No Silencing, Reset On Any Button Press
In this mode, an active alarm cannot be silenced. Once the alarm condition ceases to
exist, however, any user-interface button may be pressed to cause a manual reset.
Mode 2: No Silencing, Reset On S2 Input High (Not Wired To Common)
Similar to Mode 1. Once the alarm condition ceases to exist, setting the S2 input to a
high (+5V) state or allowing it to float disconnected will cause a manual reset.
Mode 3: No Silencing, Reset On S2 Input Low (Wired To Common)
Similar to Mode 1. Once the alarm condition ceases to exist, setting the S2 input to a low
(COM) state or wiring it to common will cause a manual reset.
Mode 4: Silencing Enabled, Reset On Any Button Press
When the conditions for an active alarm persist, pressing any user-interface button will
result in the alarm being silenced or deactivated, but not reset. A second attempt to reset
the alarm must be made after the condition cease to exist to clear the alarm.
Mode 5: Silencing Enabled, Reset On S2 Input High (Not Wired To Common)
Similar to Mode 4. Setting the S2 input to a high (+5V) state or allowing it to float
disconnected will cause the alarm to be silenced or reset depending on the current state
of the alarm conditions.
Mode 6: Silencing Enabled, Reset On S2 Input Low (Wired To Common)
Similar to Mode 4. Setting the S2 input to a low (COM) state or wiring it to common
will cause the alarm to be silenced or reset depending on the current state of the alarm
conditions.
Parameter 43 – Alarm 1 Display Flash On Alarm
This will cause the display to flash when an alarm condition is active.
Parameter 44 – Alarm 1 Pulse on Time
This parameter defines the number of seconds the output should be enabled during the ‘on’
phase of an active pulsing alarm’s output.
Parameter 45 – Alarm 1 Pulse off Time
This parameter defines the number of seconds the output should be disabled during the ‘off’
phase of an active pulsing alarm’s output.
Parameter 46 – Alarm 1 Pulse Count
This setting determines how many pulses are output when the alarm is activated and is
configured in pulse output style. When 0 is entered, the unit will be set for continuous pulses
while the alarm is active.
Parameter 47 – Alarm 1 Lower Limit
This setting defines either the lower limit or lower end of a range for the alarm region. Alarm
limits are set in display units without regard to decimal point or colon position. In Rate Modes,
a limit of 123 could represent a display value of 123, 12.3, 1.23, or 0.123. When in Time Mode,
a limit of 123 would represent 1:23 on the display.

17
Parameter 48 – Alarm 1 Upper Limit
This setting defines either the upper limit or upper end of a range for the alarm region. Alarm
limits are set in display units without regard to decimal point or colon position. In Rate Mode, a
limit of 123 could represent a display value of 123, 12.3, 1.23, or 0.123. When in Time Mode,
a limit of 123 would represent 1:23 on the display.
Parameter 95 – Factory Default Command
When set to a value of 5, the unit will be reset to factory default settings. This can also be
achieved by applying power to the unit with both the Enter and Down buttons depressed. The
programming jumper must be in the "On" position for this method to function.
Parameter 98 – Save to User Default Area Command
When set to a value of 1, the unit will store all adjustable parameters to the user default area.
The user default area is intended to be a location where an OEM or integrator can store settings
specific to their application. Using this, an OEM can easily refresh their custom settings in the
field if an end-user accidentally reconfigures the unit unsuccessfully. Another common use for
this area is testing and initial setup. The user can store known-good settings here and easily
experiment without the fear of losing the optimal configuration.
Parameter 99 – Restore from User Default Area Command
When set to a value of 1, the unit will restore all adjustable parameters from the user default
area. See parameter 98 for additional information.

18
Application Examples
User Interface for Industrial Conveyor Oven with AC Drive
Description:
An industrial tunnel oven currently uses an AC invertor drive with an attached speedpot to control
the motor which drives its train. Because the process time for the oven is known, it is preferred
that the user be able to set the process time in minutes and seconds on a digital display. Using
a DP4, this is quite simple and requires a minimum amount of installation and training effort
to complete. In this example, a DP4 has been connected to the existing AC invertor drive and
a remote speed select switch which allows the user to select from one of two preprogrammed
time settings (2 or 4 minutes) or to enter a manual mode where the display of the unit can
be directly adjusted using the front panel’s up and down arrow buttons. The desired display
range is from 90 seconds (1:30) to 600 seconds (10:00). Calibration and measurement from
the previously installed speed potentiometer has shown that a voltage output of 30% - 76% of
the applied reference voltage from the AC invertor will produce the desired time range.
Application Diagram:
Heat Source
Tach Ite
m
ValuPage
DIGITAL POT
ENTER
CONTROLS
6:30
Oven Speed Select Switch
Drive Train Specs:
1380 RPM at non-reduced
motor shaft equates to
6 minutes and 40 seconds
of tunnel time
Tunnel Oven
AC Gear Motor
Coupling to
Chain Drive
Connect to
Coupling
Dart DP4
Contol
AB
SPEED 1 SPEED 2
Partner
Motor
Controller
Variable-Frequency
AC Control
MANUAL
Alarm
Rev
FwdNeg
