DAS AUDIO LARA-SUB User manual

1
LARA Manual / LARA - SUB
LARA SUB
SERVICE MANUAL
www.dasaudio.com

2
LARA Manual / LARA - SUB
INDEX
FRONT SPEAKER REPLACEMENT 3
FRONT RIGGING HARDWARE REPLACEMENT 6
REAR RIGGING HARDWARE REPLACEMENT 8
REAR SPEAKER REPLACEMENT 10
POWER MODULE REPLACEMENT 13

3
LARA Manual / LARA - SUB
1- Front speaker replacement
REF. DESCRIPTION
A30009962 FRONT GRILLE
B20208920
20208530
18UXN
GM-18UXN
C30009937 PIN-10.30
D30009980 LEFT RIGGING HARDWARE
E30009981 RIGHT RIGGING HARDWARE
F20406631
30006118
20406641
30009979
MP-LARA-SUB
LITEMOD
KIT-DSP-LARA-SUB
FAN
G30009963 REAR GRILLE
H30010398 REJA MP
I30009965 REAR RIGGING HARDWARE
J30010414 PIN-12.43
A
B
B
C
J
E
C
D
F
B
H
G
I

4
LARA Manual / LARA - SUB
1- Front speaker replacement
20208530 (GM)
20208920 (SPEAKER)
NECESSARY TOOLS
H2
ALLEN4
Medium Strength

5
LARA Manual / LARA - SUB
1- Front speaker replacement
Fig.1
Remove the grille screws
Fig.2
Remove the grille
Fig.3
Remove the speaker screws
Fig.4
Extract the speaker parcially
Fig.5
Unplug teh speaker cable
Fig.6
Remove the speaker
REASSEMBLY
Fig.7
Stick the gasket to the spare speaker
Fig.8
Plug the speaker cable
Insert the speaker
Insert and tighten the screws to the
required torque following a star pattern
Fig.9
Place the grille
Fig.10
Insert and tighten the screws to the
required torque
Fig. 3, 4, 5 y 6
Fig. 9 y 10
Fig. 1 y 2
Fig. 7 y 8
H2
H2
Medium Strength
ALLEN4
ALLEN4
3N·m/2,2lb·ft 3N·m/2,2lb·ft

6
LARA Manual / LARA - SUB
2- Front rigging hardware replacement
30009937 (PIN-10.30)
30009980 (LEFT RIGGING HARDWARE)
30009981 (RIGHT RIGGING HARDWARE)
30009937 (PIN-10.30)
NECESSARY TOOLS
Z2
ALLEN5
High Strength

7
LARA Manual / LARA - SUB
2- Front rigging hardware replacement
FRONT GRILLE AND SPEAKER
DISASSEMBLY (see Op.1)
Remove the front grille and the front
speaker
RIGGING HARDWARE DISASSEMBLY
Fig.1
Remove the inner screws
Fig.2
Remove the external screws
Fig.3
Remove the rigging hardware as shown
in the figure
REASSEMBLY
Fig.4
Insert the rigging hardware as shown in
the picture
Fig.5
Insert and tighten the screws to the
required torque
Fig.6
Screw the inner screws
SPEAKER AND GRILLE ASSEMBLY
(see Op.1)
Assembly the front speaker and the front
grille
Fig. 2 Fig. 3
Fig. 5 Fig. 6
Fig. 1
Fig. 4
Z2
Z2
ALLEN5
ALLEN5
High Strength
8N·m/5,9lb·ft

8
LARA Manual / LARA - SUB
3- Rear rigging hardware replacement
30010414 (PIN-12.43)
30009965 (REAR RIGGING HARDWARE
NECESSARY TOOLS
ALLEN4
High Strength
ALLEN5

9
LARA Manual / LARA - SUB
3- Rear rigging hardware replacement
Fig.1
Remove the pin lock
Fig.2
Rotate the rod
Fig.3
Remove the central screws
Fig.4
Remove the external screws
Fig.5
Remove the rigging hardware
ASSEMBLY
Fig.6
Place the rigging hardware
Fig.7
Insert and tighten the external screws to
the required torque
Fig.8
Insert and tighten the central screws to
the required torque
Fig.9
Rotate the rod
Fig.10
Insert the pin lock
Fig. 1, 2, 3
Fig. 6, 7
Fig. 4, 5
Fig. 8, 9, 10
ALLEN4
High Strength High Strength
ALLEN5 ALLEN4
8N·m/5,9lb·ft 3N·m/2,2lb·ft

10
LARA Manual / LARA - SUB
4- Rear speaker replacement
20208530 (GM)
20208920 (SPEAKER)
H2
ALLEN4
High Strength
NECESSARY TOOLS

11
LARA Manual / LARA - SUB
4- Rear speaker replacement
REAR RIGGING HARDWARE DISASSEMBLY
(see op.3)
GRILLE DISASSEMBLY
Fig.1
Remove the perimetral grille screws
DESMONTAJE DEL ALTAVOZ
Fig.2
Remove the speaker screws
Fig.3
Extract the speaker flipping it
Fig.4
Disconnect the cables
Fig.5
Remove the speaker
Fig. 1
Fig. 3 y 4
Fig. 2
Fig. 5
ALLEN4 H2

12
LARA Manual / LARA - SUB
4- Rear speaker replacement
SPARE SPEAKER GASKET ASSEMBLY
Fig.6
Stick the gasket to the spare speaker
Fig.7
Place the speaker
Fig.8
Connect the cables
Fig.9
Insert the speaker while flipping it
Fig.10
Insert and tighten the screws to the re-
quired torque following a star pattern
GRILLE ASSEMBLY
Fig.11
Place the grille, insert and tighten the
screws to the required torque
REAR RIGGING HARDWARE ASSEMBLY
(see op.3)
Fig. 6
Fig. 10
Fig. 7, 8 y 9
Fig. 11
H2
3N·m/2,2lb·ft 3N·m/2,2lb·ft
ALLEN4
Fuerza media

13
LARA Manual / LARA - SUB
5- Power module replacement
20406631 (MODULE)
ALLEN4
Medium Strength
NECESSARY TOOLS

14
LARA Manual / LARA - SUB
5- Power module replacement
GRILLE DISASSEMBLY
Fig.1
Remove the PM grille screws and the
PM grille
POWER MODULE DISASSEMBLY
Fig.2
Remove the PM screws
Fig.3
Extract the PM partially
Fig.4
Disconnect the PM of the system from
the ingernal connector (see detail view)
Fig.5
Remove the PM
Fig. 1
Fig. 4 (detalle)
“Cube” connector
on pcb
Fig. 2, 3
Fig. 5
ALLEN4 ALLEN4

15
LARA Manual / LARA - SUB
5- Power module replacement
Fig. 6 (detail)
Fig. 8
“Cube” connector
on pcb
Fig. 7
Fig. 9
POWER MODULE ASSEMBLY
Fig.6
Connect the PM to the system with the
internal connector (see detail view)
Fig.7
Insert the MP
Fig.8
Insert and tighten the screws to the
required torque following a star pattern
GRILLE ASSEMBLY
Fig.9
Place the grille and insert and tighten
the screws to the required torque
3N·m/2,2lb·ft 3N·m/2,2lb·ft
ALLEN4 ALLEN4
Medium Strength Medium Strength
