Davey Davey XP/T User manual

Installation and
Operating Instructions
for Davey XP/T & XJ/T
Pressure Systems with
Please pass these instructions on to the operator of this equipment.
WARNING : The Torrium2®controller, pump and associated pipework
operate under pressure. Under no circumstances should the Torrium2®
controller, pump or associated pipework be disassembled unless the
internal pressure of the unit has been relieved. Failure to observe this
warning will expose persons to the possibility of personal injury and may
also result in damage to the pump, pipework or other property.
WARNING: Failure to follow these instructions and comply with all applicable
codes may cause serious bodily injury and/or property damage.
NOTE: Prior to installation remove the inlet and outlet
pipe transport plugs & associated seals from the
suction and/or discharge ports.
Davey®Repair or Replacement Guarantee
In the unlikely event in Australia or New Zealand that this Davey product develops any malfunction
within two years of the date of original purchase due to faulty materials or manufacture, Davey will at
our option repair or replace it for you free of charge, subject to the conditions below.
Should you experience any difculties with your Davey product, we suggest in the rst instance that
you contact the Davey Dealer from which you purchased the Davey product. Alternatively you can
phone our Customer Service line on 1300 367 866 in Australia, or 0800 654 333 in New Zealand, or
send a written letter to Davey at the address listed below. On receipt of your claim, Davey will seek to
resolve your difculties or, if the product is faulty or defective, advise you on how to have your Davey
product repaired, obtain a replacement or a refund.
Your Davey Two Year Guarantee naturally does not cover normal wear or tear, replacement of product
consumables (i.e. mechanical seals, bearings or capacitors), loss or damage resulting from misuse
or negligent handling, improper use for which the product was not designed or advertised, failure to
properly follow the provided installation and operating instructions, failure to carry out maintenance,
corrosive or abrasive water or other liquid, lightning or high voltage spikes, or unauthorized persons
attempting repairs. Where applicable, your Davey product must only be connected to the voltage
shown on the nameplate.
Your Davey Two Year Guarantee does not cover freight or any other costs incurred in making a claim.
Please retain your receipt as proof of purchase; you MUST provide evidence of the date of original
purchase when claiming under the Davey Two Year Guarantee.
Davey shall not be liable for any loss of prots or any consequential, indirect or special loss, damage
or injury of any kind whatsoever arising directly or indirectly from Davey products. This limitation
does not apply to any liability of Davey for failure to comply with a consumer guarantee applicable to
your Davey product under the Australian or New Zealand legislation and does not affect any rights or
remedies that may be available to you under the Australian or New Zealand Consumer Legislation.
In Australia, you are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
Should your Davey product require repair or service after the guarantee period; contact your nearest
Davey Dealer or phone the Davey Customer Service Centre on the number listed below.
For a complete list of Davey Dealers visit our website (davey.com.au) or call:
* Installation and operating instructions are included with the product when purchased new.
They may also be found on our website.
P/N 400280-11 supersedes P/N 400280-10
AUSTRALIA
Customer Service Centre
6 Lakeview Drive,
Scoresby, Australia 3179
Ph: 1300 367 866
Fax: [phone]
Website: davey.com.au
Davey Water Products Pty Ltd
Member of the GUD Group
ABN 18 066 327 517
NEW ZEALAND
Customer Service Centre
7 Rockridge Avenue,
Penrose, Auckland 1061
Ph: 0800 654 333
Fax: [phone]
Website: daveynz.co.nz
® Davey & Torrium2 are registered trade marks of Davey Water Products Pty Ltd.
© Davey Water Products Pty Ltd 2011.

2 11
Prior to using this pump you must ensure that:
• Thepumpisinstalledinasafeanddryenvironment
• Thepumpenclosurehasadequatedrainageintheeventofleakage
• Anytransportplugsareremoved
• Thepipe-workiscorrectlysealedandsupported
• Thepumpisprimedcorrectly
• Thepowersupplyiscorrectlyconnected
• Allstepshavebeentakenforsafeoperation
AppropriatedetailsforalloftheseitemsarecontainedinthefollowingInstallation
andOperatingInstructions.Readtheseintheirentiretybeforeswitchingonthis
pump.IfyouareuncertainastoanyoftheseInstallationandOperatingInstructions
pleasecontactyourDaveydealerortheappropriateDaveyofceaslistedonthe
backofthisdocument.
Congratulationsonyourpurchaseofahighquality,AustralianbuiltDaveypressure
system.Allcomponentshavebeendesignedandmanufacturedtogivetroublefree,
reliableoperation.
Yournewpressuresystemincorporates‘Torrium2®’,electronicowcontroller–a
Daveydesignedunitthatenablestheuseofahighlyefcientpumpdesignand
offersthefollowingbenets:–
1. Enablesthepumptodeliveraconstantowofwaterparticularlyatlowow
rates–reducingtheinconvenienceofpressurevariationinshowersetc.
2. Providesautomatic“cut-out”protectionshouldthepumprunoutofwateror
overheat*,shouldthepumpfailtostartduetolowvoltageorablockageinthepump.
3. Providesaneasytounderstandvisualrepresentationofthesystemstatus.
4. Hasadaptivepressurecut-inwhichallowsthepumptostartatapproximately
80%ofthemaximumpressureatlastshut-down.Thisallowsthecontrollerto
accommodatevaryinginletpressuresandpumpperformance.
5. Automaticretryfunctionsintheeventofacriticalsystemfault.
6. Pressureindicatorsoyoucaneasilytellwhatthepressureinyourwatersupply
systemisdoing.
7. Easyvisualguidetothestatusoftheinbuiltsurgearrestor.
8. Choiceofbothverticalandhorizontaloutlets.
*Motoroverload/overheatprotectionincluded.Motorhasitsownoverload/
overheatprotection.
 1. Torrium2®PrimingPlug
 2. Torrium2®ControlModule(TT45)
  orTT70forXJ70T
 3. DischargeOutlet(1”BSPM)
 4. SuctionInlet(1”BSPF,except
  forXJ90Twhichis11/4”)
 5. PumpBody
 6. Motor
 7. PrimingPlug
NOTES
Before installing your new pump, please read all instructions carefully as failures
caused by incorrect installation or operation are not covered by the guarantee. Your
Davey pressure system is designed to handle clean water. The system should not be
used for any other purpose without specic referral to Davey. The use of the system to
pump ammable, corrosive and other materials of a hazardous nature is specically
excluded.
NOTE:Priortoinstallationremovetheredtransportplugsfromthesuctionand/ordischarge.

3
NOTE: The Torrium2® controller tted to this pump is adaptive. If your
pump draws air or is subject to blockage, the Torrium2 adapts to its new
maximum pressure. This may result in your system pressure not dropping
below the new cut-in pressure and your pump not starting. Should this
occur, re-prime your pump units as detailed above. Should this not prove
successful, it is likely you have a blockage in the pump. You should
contact your Davey dealer for assistance.
Rotary Coupling Inlet
1” Male
Horizontal Outlet
1” Male
Priming Cap which covers the 1” Male Vertical Outlet
and access to the internal check valve.
Status Indicator
Lights
Prime Button Pressure
Indicator
Window
Fitting the Torrium2®directly to the Pump
TheTorrium2®isttedwitharotarycoupling.This
couplingallowsthepumpcontrollertobetted
simplyandeasilytothepumpdischarge.
Insidethebagcontainingtheseinstructionsisa1”
(FxF)socketandsomethreadtape.Wrapthread
tapearoundbothpumpoutletandTorrium2®inlet
andconnectthecontrollertothepumpwiththe
socket.Thecontrolleradaptornutisabletorotate
independentoftheTorrium2®andthecomplete
pump,thisallowsittobetightenedontothepump
easily.Foreaseofinstallationatighteningtoolis
includedwithTorrium2®totightenthecontrollernuttoensurearmconnectionto
yourcontroller.
Theabilitytorotatetheadaptornutalsomeansthatthecompletecontroller,once
ttedtothepump,canberotatedafull360ointhehorizontalplane,withoutcausing
thecouplingtounscrewfromthepumpoutlet.
With Torrium2®you can connect the discharge pipework to the
discharge port and/or the vertical priming port. The priming port is
able to be used as a discharge port.
WARNING: When servicing or attending pump, always ensure power
is switched off and lead unplugged. Electrical connections should be
serviced only by qualied persons. If the electrical supply lead of this
pressure system is damaged, it must be replaced.
NOTE:
a) For protection, the Davey® pump motor is tted with an automatic
“over temperature” cut-out. Constant tripping of this overload device
indicates a problem e.g. low voltage at pump, excessive ambient
temperature (above 50°C) in pump enclosure.
b) The Torrium2®control device may have to be reset after rectifying any
of the above operating troubles. This is done by pushing in the “prime”
button and releasing it after 2 seconds, or switching the power supply
off then on.
Care should also be taken when servicing or disassembling pump to avoid
possible injury from pressurised water. Unplug pump, relieve pressure by
opening a tap on the discharge side of the pump and allow any hot water in
the pump to cool before attempting to dismantle.
During servicing, use only approved, non-petrochemical based oring and
gasket lubrication. If unsure, consult your Davey Dealer for advice.
WARNING: Do not use hydrocarbon based or hydrocarbon propelled
sprays around the electrical components of this pump.
In accordance with AS/NZS 60335.2.41 we are obliged to inform you that
this pump is not to be used by children or inrm persons and must not be
used as a toy by children.
NOTE: The Torrium2®controller is adaptive. If your pump draws air or is subject to
blockage, the Torrium2®adapts to its new maximum pressure. This may result in
your system pressure not dropping below the new cut-in pressure and your pump
not starting. This is more likely to occur when boosting mains pressure. Should this
occur, re-prime your pump unit. Should this not prove successful, it is likely you have
a blockage in the pump. You should contact your Davey dealer for assistance.
10

4 9
Trouble Shooting Check List
a) PUMP HAS STOPPED OR MOTOR RUNS FOR SHORT PERIOD ONLY
WHEN SWITCHED ON OR PRIME BUTTON PUSHED, BUT DOES
NOT PUMP - YELLOW STATUS INDICATOR LIGHT ILLUMINATED.
 1. Suctionlineandpumpbodynotlledwithwater.
 2. Airleaksinsuctionlinesorsuctionpipenotunderwater.
 3. Airtrappedinsuctionlines(alsopossiblewithoodedsuctionduetouneven
riseinpiping;eliminatehumpsandhollows).
 4. Nowateratsourceorwaterleveltoolow.
 5. Valveonsuctionlinesclosed.Openvalve&pumpwillrestartautomatically
orpress“Prime”button.
b) PUMP SWITCHES ON AND OFF FREQUENTLY (CYCLING)
 1. Cyclingmayoccasionallybecausedbyoatvalvesllingtanks.
 2. Leakingtaps,oatvalvesetc.checkplumbing.
 3. Leakingcheckvalve/footvalve.
c) MOTOR DOESN’T START WHEN SWITCHED ON - INDICATOR LIGHTS NOT
ILLUMINATED
 1. Powernotconnectedornopoweravailablefromsupplyoutlet.
d) MOTOR STOPS - YELLOW STATUS INDICATOR LIGHT IS ILLUMINATED.
 1. Motor”overtemperature”cut-outtripped.ConsultDaveydealer.
 2. Motornotfreetoturn-e.g.ajammedimpeller.ConsultDaveydealer.
 3. Primebuttonhasbeenheldinfortoolong.Releaseprimebuttonand
switchoffpowerfor1minutetoallowunittoreset.
 4. YourTorrium2®hasdetectedhighwatertemperatureinthepump.Oncethe
waterhascooledtheTorrium2®willautomaticallyrestartthepump.
e) PUMP WILL NOT STOP
 1. Waterleaksondischargesideofpump.
f) PUMP WILL OPERATE NORMALLY INITIALLY BUT WILL NOT RESTART
ON WATER DEMAND - STATUS INDICATOR LIGHT NOT ILLUMINATED
 1. Powersupplyproblem-seec)1.
g) PUMP WILL OPERATE NORMALLY INITIALLY BUT WILL NOT RESTART ON
WATER DEMAND - YELLOW STATUS INDICATOR LIGHT IS ILLUMINATED.
 1. Suctionairleak-pumphaspartiallylostprime.
 2. Blockedimpellersorsuction.
 3. Dischargevalveclosed-openvalve.
WARNING: Automatic reset thermal overloads may allow the pump to restart
without warning. Always disconnect the pump motor from the electrical
supply before maintenance or repairs.
WARNING: When servicing or attending pump and/or controllers, always
ensure power is switched off and lead unplugged. Electrical connections
should be serviced only by qualied persons.
Choosing a Site
Chooseasitewitharmbaseandasclosetothewatersourceaspossiblewith
correctpowersupply.Makesureyourpressuresystemisalwaysconnectedtoan
adequate,reliablesourceofcleanwater.
Housing your Davey Pressure System
Toprotectyourpressuresystemfromtheweather,makesurethe
pumphouseisbothwaterproof,frostfreeandhasadequate
ventilation.Thepumpshouldbehorizontallymountedona
rmbaseallowingfordrainage,toavoiddamagetoooring
etc.,thatovertimemayoccurfromleakingpipejointsor
pumpseals.Donotmountthepumpvertically.
Discharge Connections
TheTorrrium2®offerstheoptionofusingoneorbothoutletoptions.
Useofthehorizontaloutletonlyallowsforeither:
1. Easyaccesstoprimethepumpand/ortheremovaloftheinbuiltTorriumcheck
valve
2. Fitmentofapressuretank(upto20litrecapacity)ontotheprimingport/vertical
dischargeport
Ifyouusetheverticaloutletinsteadoraswell,youneedtoconsideraccesstothe
inbuiltcheckvalveintheTorrium.Daveysuggestyouuseaexibleconnectionand/
orunionconnectiontoallowforeaseofaccesstothecheckvalve.
Pressure Indicator Window
Torriumhasaneasytoreadpressureindicatorwindowonthesideoftheinbuilt
pressurevessel–seeFigure1onpage3.
Ifthepressureislowthewindowwillshowmainlyred.Ifthepressureisat
maximum(i.e.450kPaforTT45and700kPaforTT70models)thewindowwillshow
mainlygreen.
Thewindowcanalsohelpanalysetheoccurrenceofunwantedleaks.Ifthecolour
bandinthewindowismovingtowardsred,thisshowsthatpressureisdecreasing.
Ifthecolourbandinthewindowismovingtowardsgreen,thisshowsthatpressure
isincreasing.
WARNING: Some insects, such as small ants, nd electrical devices
attractive for various reasons. If your pump enclosure is susceptible to
insect infestation you should implement a suitable pest control plan.
Maintenance
Theonlyregularattentionyournewpressuresystemmayrequirewillbeifyou
haveusedanadditionalpressuretank.Dependingonthetankusedyoumayneed
tocheckthepressuretank’sairchargeevery6months.Followtheinstructions
applicabletoeachtank.
WARNING : Under no circumstances should Torrium2®controller be
disassembled. Failure to observe this warning will expose persons to the
possibility of personal injury and may also result in damage to other property.
Do not dismantle, no user serviceable parts, spring under pressure.

8 5
Auto-retry and Water Return Modes
ShouldyourTorrium2®detectalossofprime,afterstoppingthepump,itwillwait
veminutesbeforeactivatingAuto-retryandWaterReturnmodes.Auto-retry
automaticallystartsthepumptoseeifthepumpisnowprimed.Itdoesthisafter5
mins,30mins,1hr,2hrs,8hrs,16hrsand32hrs.Waterreturnmodewillrestart
thepumpautomaticallyiftheTorrium2®detectswaterowthroughit.
Electrical Power Surge Protection
Anelectricalpowersurgeorspikecantravelonthesupplylinesandcauseserious
damagetoyourelectricalequipment.TheTorrium2®ttedtothispumphasametal
oxidevaristor(MOV)ttedtohelpprotectit’scircuit.ThisMOVisa“sacricial”
device,meaningthatiteffectivelyisgraduallydamagedeverytimeittakesasurge.
TheMOVisnotalightningarrestorandmaynotprotecttheTorrium2®iflightningor
averypowerfulsurgehitsthepumpunit.
Iftheinstallationissubjecttoelectricalpowersurgesorlightningwestrongly
recommendtheuseofsuitableadditionalsurgeprotectiondevicesonALLelectrical
equipment.
Surge Protector Status Window
ToallowyoutocheckthestatusoftheinbuiltMOVintheTorrium2®there is a
viewingwindowatthebackoftheTorrium2®abovethepowerleadentry/exit
grommet.TheMOVisthebluediscshapedcomponent.Shoulditbeconsumed
duetopowerspikesitwillalmostalwaysblackentheviewingport.Thiswillindicate
anon-warrantablefailure.
InaccordancewithAS3350.2.41weareobligedtoinformyouthatthispumpisnot
tobeusedbychildrenorinrmpersonsandmustnotbeusedasatoybychildren.
Pipe Connections
ForbestperformanceuseP.V.C.or
polythenepipesatleastthesame
diameterasthepump’sinletanddelivery
outletopenings.Largerdiameterpipe
maybeusedtominimiseresistanceto
owwhenpumpinglongerdistances.
NOTE: For protection, the Davey pump motors are tted with an automatic
reset thermal overload, constant tripping of this overload indicates a
problem e.g. low voltage at pump, excessive temperature (above 50°C) in
pump enclosure.
Power Connection
Connectleadtopowersupplydesignatedonpumplabel.Donotuselong
extensionleadsastheycausesubstantialvoltagedrop,poorpumpperformance
andmaycausemotoroverload.
The Davey Torrium2® tted to this pump has status indicator light mounted
on its front panel. These lights will only work when unit is connected to an
electrical supply.
The electrical connections and checks must be made by a qualied
electrician and comply with applicable local standards.
For Automatic Pressure Pumps Installed with a
Mains Pressure Hot Water System
Toprotectyoursystemfromdamagecausedbyback
pressurefromhotwatersystems.Youshouldalways
haveinstalledonthehotwaterinletanapprovednon-
returnvalve.
Connection of Mains Scheme or Town Water
Supply to either Suction or Discharge of Pumps &
Pressure Systems
MostWaterSupplyAuthoritieshavestrictregulationsregardingdirectconnectionof
pumpstomainswatersupplies.Inmostcasesanisolatingtankisrequiredbetween
mainssupplyandpump.Daveyalsorecommendthismethod.Directlyapplied
mainspressurecanexceedpumpoperatingpressureanddamagepump.
Davey Water Products Pty Ltd can not
accept responsibility for loss or damage
resulting from incorrect or unauthorised
installations.
NOTE: Always ensure hot water
systems are installed in compliance with
manufacturers recommendations and in
accordance with all local regulations.
Priming and Operation
TheTorrium2®modulettedtoyourXPorXJsystemisprovidedwithapushbutton
“Prime”button.Thisbuttonisusedduringinitialprimingofthepumpandalsoacts
asaresetbuttoniftheTorrium2®switchesoutinpumpprotectionmode.
1. Removeprimingplugandll
casingandsuctionline(onooded
suction,simplyopengatevalveto
pump).Whenfull,replacepriming
plug.
2. Ensureoutletnearest
 topumpisopen.
3. Ensureallvalvesinsuctionline
areopen.
4.Switchonpower-The
statusindicatorlight
willbeilluminated
greenandthepump
willrun.Afullow
ofwatershouldbe
dischargedfromthe
opentap.
5.Ifthepumpstopswiththetapopen
seetroubleshootingchecklist.
6. Closetheopenoutletortapand
thepumpshouldstopafterafew
seconds(thestatusindicatorlight
shouldbeilluminatedred(constant).
Ifnot,consultthetroubleshooting
checklist.
To Reset if Pump switches out in
Pump Protection Mode
1. Makesurepumpisprimed.
2. Opentap,pushprimebutton.
3. Closetapandpumpwillstop.

6 7
Where to use Check Valves and Foot Valves
TheTorrium2®controllerhasaninbuiltnon-return(check)valvetted.Inooded
suctioninstallationsthereisnoneedtohaveasuctionnon-returnvalve.
Insuctionliftinstallationsafootvalvewillnormallyberequiredforthepumpto
retainprime.
Insomesuctionliftinstallationstheremaybegoodreasontoremovetheinbuilt
checkvalvetoensurethatthedischargepressureisalsoappliedtothesuctionline
andfootvalve.Thiscouldbewherethesuctionlinewasverylongorwherethere
wasconcernregardingaleakingfootvalve.Thismaynotalwaysbeapplicableand
itisacceptabletoretaintheinbuiltcheckvalveintheTorrium2onsuctionliftswith
goodsuctionplumbing.
Shouldtheinbuiltcheckvalveberemovedthough,anadditionalaccumulator
shouldbettedtotheTorrium2,ordischargepipeworkasapplicable,toensurethe
pumpisnotcycledonshutdown.Thesizeofthisaccumulatorwilldependonthe
size,lengthandtypeofpipeusedonthesuction.
Torrium2 Check Valve Removal
Useunionsatpipeconnectionstoenableeasyremoval
andservicing.Usesufcienttapetoensureairtightseal
andhandtightenonly.Topreventstrainonpumpthreads
alwayssupportheavyinletandoutletpipes.Ifthereis
alikelihoodthewatersupplymaycontainsolidparticles
suchaspiecesofplantorvegetablematter,altershould
beinstalledbeforethepumptoavoidblockingofwater
ways.Laysuctionpipeataconstantgradienttoavoidair
pocketswhichmayreducepumpefciency.
NOTE: Suction leaks are the largest cause of poor pump performance and
are difcult to detect. Ensure all connections are completely sealed using
thread tape only.
Flexible pipe should be considered to allow for movement between
building, pump and/or water supply. Braided hose, reinforced hose or
polythene pipe are suitable.
Do not use pipe thread sealing compounds on any part of this pump. ONLY
use Teon sealing tape.
Removeprimingcapand
turnovercap.Lugson
capwillengagecheck
valvetounscrew.
Extra Draw-off Capacity
TheTorrium2®controllerhasanin-builtaccumulatorwhichwillaccommodatesmall
leaks.Insomeapplicationsitmaybeappropriatetoinstalladditionalaccumulator
(Supercellpressuretank)capacity.Theseapplicationsincludes:
• Longsuctionlines(seeSuctionLines/Lift)
• Lowowappliancesconnectedtothepump,suchasevaporativeair
conditioners,slowllingtoiletcisterns,etc.
Anyadditionalaccumulatorscanbeinstalledeitherinplaceofthepriming
plug(seeFigure1)fortanksupto20litrestotalcapacity,orforlargertanks,
downstreamofthecontroller(ie.betweenthecontrollerandtherstoutlet).
Whereextradraw-offcapacityisutilisedtheadditionalpressuretankshouldhavea
pre-chargeof70%ofthemaximumsystem(shut-off)pressure.
Evaporative coolers, RO lters and extra draw-off
capacity
WhereaTorrium2®equippedpumpisrequiredtosupplywatertoanevaporative
cooler,reverseosmosis(R.O.)lterorsimilarlowowdevice,theTorrium2®willdetect
thelimiteddemand.ThiswillresultintheTorrium2®adaptingtotheslowdemand.The
pumpstartpressurewillbeallowedtodroptoalowercutinpressureeachtimelow
owsaredetected.Toprovidethemaximumdraw-offfromtheadditionalpressuretank,
thetank’spre-chargeshouldbesetat45%ofthepumpshut-offpressure.
Ifnormalowisrequiredfromyoursystem,Torrium2®willinitiateinstantstart.
FittheSupercellpressuretank(upto20litrestotalcapacity)tothetankconnection/
priming port with thread tape and pipe socket.Firmlyhand tighten.Forlargertanks,
theseshouldbeinstalleddownstreamofthecontroller.
NOTE: If tting a tank to the priming port, you may require a 1”
BSP socket, since both Torrium2®prime port and tank are 1” male
threads.
DO NOT USE THREAD SEALING COMPOUNDS, HEMP OR PIPE DOPE!
Installationswithoodedsuctionrequire
agateorisolatingvalvesowatersupply
canbeturnedoffforpumpremovaland
servicing.
Abrasive Materials
The pumping of abrasive materials will cause damage to the pressure
system which will then not be covered by the guarantee.
