Davies Craig EBP25 User manual

03/04/2019 EBP25 INSTALLATION INSTRUCTIONS
77 Taras Avenue
P.O. Box 363
Altona North
Vic 3025 Australia
Phone: [phone]
Fax: [phone]
[e-mail]
www.daviescraig.com.au
EBP25 INSTALLATION INSTRUCTIONS
Congratulations on your purchase of the Davies, Craig EBP25.
PLEASE READ ALL THESE INSTRUCTIONS THOROUGHLY BEFORE YOU START WORK.
DON’T RUSH - ENSURE YOU HAVE FULL UNDERSTANDING OF THE WORK AHEAD BEFORE YOU
COMMENCE. ENSURE YOU HAVE ALL TOOLS AND COMPONENTS REQUIRED.
COMPONENTS:
EBP25 - PUMP
EBP25 wiring loom
EBP25 Plug adaptor
NEW EBP25 INSTALLATION
Install the EBP®into the hose. If required mount the EBP®using attached bracket.
For the best results the EBP®should be located low in the system and close to the outlet of
the radiator, intercooler or tank.
You will need to use the EBP25 wiring loom (supplied) when wiring the EBP®.
REPLACING EXISTING EBP25 (PART #9005 OR #9105)
Replace your old EBP25 (part #9005 or #9105) with your new EBP25 and if required
mount the EBP®using attached bracket.
To reuse the existing wiring, the EBP25 plug adaptor (supplied) can be used.
WIRING DIAGRAM
NOTE: It’s recommended that a relay (not supplied) is used to supply power to the EBP25.
EBP25 WIRING LOOM
EBP25 PLUG ADAPTOR
Wiring for Control by Thermatic®switch
Davies, Craig has a full range of Thermatic®Switches available in both mechanical (#0401,
#0404 & #0400) and Digital Thermatic®Switches (#0444 & #0500).
Wire the pump as directed by the wiring instructions provided with the Thermatic®Switch.
All Davies, Craig Thermatic®Switches are ON/OFF.
To allow the EBP®to run on after hot shutdown, wire the Switch direct to the battery.

03/04/2019 EBP25® INSTALLATION INSTRUCTIONS
WARNINGS
Do not operate your EBP® dry as damage may occur and your warranty will be
jeopardised.
DO NOT ATTEMPT to tamper with the EBP®including loosening or removing any
bolts/screws as this will void any warranty. If you suspect there is a fault or
defective product please contact Davies, Craig IMMEDIATELY.
These installation instructions will suit most applications but there are circumstances
surrounding some engine designs, environments, and the nature of the system involved,
which may require other installation arrangements not outlined here. Frequently Asked
Questions (FAQ) are listed on our website www.daviescraig.com.au . Emails can be directed
to [e-mail] or Telephone [phone] during business hours.
WARRANTY
Davies, Craig Pty Ltd warrants for a period of two years or 2000 hours continuous running (whichever is
the lesser) from the date of purchase. Davies, Craig will carry out, free of cost, any repairs that are
reasonably necessary to correct any fault in the operation of your Davies, Craig product provided that
such a fault is directly attributable to a defect in the workmanship or materials used in the manufacture
of the part(s). This warranty is void if the product is misused, altered, tampered with or is installed or
used in a manner that is inconsistent with Davies, Craig’s written recommendations and/or installation
instructions. Labour and consequential costs are excluded. DAVIES, CRAIG PTY. LTD.
Register your warranty at: daviescraig.com.au under the support tab.
