davoline Super 1505T Operation and maintenance manual

6
GB
CONTENTS
Installation
Connecting to electricity
Useful information
Safety instructions
Before using for the first time
Recycling Environmental protection
Operation
How to save energy when using the hotplates
Cleaning - Maintenance
Before requesting Service

6
Installation
Remove any packaging material and printed matter from inside the oven.
Place the appliance on a level, dry, heat resistant surface at a height of approximately 100cm.
Do not place the appliance in a cupboard.
The sides of the appliance may become hot during use, therefore an empty space of about 10cm all around is
required.
Make sure that the oven door opens easily, without being obstructed by any objects.
To install the appliance you will need an earthed Shuko plug of 220-230 V, with a 16 fuse (2,5 mm2line).
If you use an extension, it should be 32,5 mm2 and earthed. If the indicator lights show a faint flicker, turn the plug
in the socket.
Do not remove the plug from the power supply cord, as the appliance is not designed to be permanently connected to
the electrical power supply.
Unplug the appliance after each use and during cleaning.
Connecting to electricity
The applianceoperates with an AC power supply of 220-230 V/ 50 Hz. For this reason, check whether the electrical
circuit you will be using meets with the above mentioned requirements.
Check whether the electrical outlet you will be connecting the appliance to is earthed. If you use an extension, check
that the extension line is also earthed.
The total power level during operation is:
Model
Hotplate 1500 W
Hotplate 1000 W
Hotplate 450 W
Electrical power
Super 1505T
1,2 kW
Super 3505
x
x
3,15 Kw
Super 4005
x
x
2,7 Kw
Super 4505
x
x
x
3,15 Kw
This appliance has been manufactured according to the EC Directives 73/23/ , 90/396  93/68 with a type B fire
protection grading.

6
Useful Information
Do not use abrasive products or objects when cleaning the appliance (sharp objects, aggressive cleaning agents, etc)
that may cause scratches in the surfaces.
Never use cookware (pots, frying pans, etc) with a wet base.
Clean the oven after each use, to avoid a buildup of dirt that will be harder to clean each time.
Safety instructions
Keep the power supply cord away from heated surfaces.
Do not use the appliance if you notice some fault in power supply cord or in its operation, to avoid the possibility of
electric shock or fire.
If crack or fault appears on a hotplate, avoid its use.
Do not place food on the oven door to avoid damage.
Only use the appliance for the purpose for which it was designed.
Do not use the appliance to dry paper, clothes or any other flammable material.
 danger of burns to children
is obvious.
Do not let young children touch the oven during use because the oven door develops intense heat.
Before using for the first time
Keep potentially dangerous packaging materials from the appliance (plastic bags, polystyrene pieces,etc) away from
children.
Before connecting the appliance for the first time, clean all enamel surfaces and accessories with hot water. Clean the
oven interior with hot water in which you have dissolved a spoonful of soda (to 1lt of water)
Connect the appliance. Turn on all hotplates at their highest setting and let them heat up a few minutes with nothing
placed on them.
Turn off the knobs by turning them to the 0 setting.
Read the instructions for use of the hotplates and oven to become familiarized with the use of the appliance.
Heat the oven by turning the temperature selector (thermostat) to the 200 setting.
Let the oven warm up for about 30 minutes without placing anything inside.
Turn off the oven by turning the temperature selector to the 0 setting.
During heating you may notice a strong smell. This is caused by the heat coming into contact with the strong
insulation material around the oven for the first time.
Do not worry, the smell will disappear within minutes.
Recycling –Environmental Protection
The packaging material used is recyclable and bears the relevant recycling stamp.
Environmentally friendly materials were used during the manufacturing of the appliance. When you wish to dispose of
the appliance, respect the local news for the protection of the environment and the recycling of electrical appliances.
Before disposing with the appliance, remove the plug form the power supply cord.
Operation
Using the hotplates
All appliances have 2 or 3 metal hotplates. The 1500W (180mm diameter ) and 1000W (145mm diameter) hotplates are
controlled by push in-pop out rotational knobs with 7 settings. The small 450W hotplate (80mm diameter) has no settings,
only a switch with an on / off selection. The function of th e push in pop out rotational 7 setting knob is simple: the
position of the knob regulates the amount of heat.
0
1/2
1
11/2
2
21/2
3
Off
Keeping food
warm
Heating food
Slow Cooking
Slow boil
Rapid boil
Full heat
to start
The indicator light of the relevant hotplate lights up
Since the applied specifications set a limit to the power that the power supply cord can convey, when the oven is on, the
medium 1000W hotplate (145mm diameter) is automatically disconnected.

6
Using the oven
The oven cooks in the conventional way, i.e.: with the top and bottom element or the grill. The oven is controlled by a
push in pop out rotational temperature selector switch that is located on the front of the cooker. O   
         grill.
To use the oven (top and bottom element) turn the push in-pop out temperature selector and set the desired
temperature.
0 The oven is off.
50-2500The oven is on (indicator light is on). The oven is operating at the selected temperature.
To use the grill (top element) turn the push in pop out temperature selector to the indication grill
oven to preheat (empty oven) until the grill turns red. Then place the baking tray with the food in
the oven. Turn the selector switch to 0when the cooking is done.
To set timer on the SUPER 1505T model, turn the knob to the desired time or to the left to the manual operation
(). When the time is up, a characteristic signal will sound and the oven will switch off automatically. Turn
the temperature selector and timer (if in manual model) back to 0.
Keep the door closed when using the grill.
Oven temperature for food and pastries
The temperature settings below are approximate. If you wish to modify the cooking time, then you should also change
the temperature settings accordingly.
Meat with potatoes (roast) 180-2000C
Fish 180-2000C
Stuffed vegetables 180-2000C
Meat with pasta (yiouvetsi) 200-2200C
Pastitsio-Moussaka 160-1800C
Cheese / Spinach pies 150-1700C
Desserts 150-1700C
Biscuits 140-1600C
Cakes 160-1800C
Grilled meat 200-2200C
What you should note when using the oven
Do not place aluminum foil or baking trays on the bottom of the oven as this may cause damage to the
enamel surface.
Never clean the oven with aggressive detergents as this may cause damage to the enamel surface.
Do not use any sharp implements when cleaning the oven only a dry or slightly moist cloth.
How to save energy when using the hotplates
Saving energy while cooking depends to a great extent on the cookware you will be using. Suitable cookware should
have a flat base of a relevant thickness so as to come into good contact with the hotplate surface and absorb heat
easily. Your cookware should not be smaller in size than the hotplate you will be using. The whole hotplate surface
should always be covered and thus be protected from overheating. During cooking or boiling, we suggest that your
cookware always be covered with a lid for faster and more economic cooking. Furthermore, just before cooking time
is complete, turn the switch to the 0 setting so that boiling can conclude with the residual heat in the hotplate.
Cleaning - Maintenance
Always disconnect the appliance from the main power supply before cleaning - maintenance.
To clean all surfaces (enamel, glass, hotplates, oven) use hot water with a mild, non-aggressive cleaning
agent and a cloth or soft sponge.
Never use wire, metal sponges, strong detergents or scouring powder as these will scratch the surfaces.
When cleaning the baking trays/grill tray, fill with hot soapy water immediately after use to soften any food
residue and then clean this off easily with a sponge.
Before requesting the Service
If you read and follow the instructions on the previous pages carefully, no problem should arise with your cooker.
However, if you need help, before you request Service, check whether you have followed the correct procedure
described in the instructions of the manual.
If the appliance is not working properly:

6
Check that the plug is properly connected to a suitable wall outlet.
Check that the electricity supply has not been disconnected at the fuse box.
The company reserves the right to change or modify the above mentioned data in its continuous efforts for
improvement of its appliance.
