Dawn Dina Series User manual

Vanity Installation Guide
Onix Series
ww w.d awn us a .n et
Kitchen & Bath Products, Inc.
Please read all instructions carefully before s tarting the installation.
IMPORTANT: Recommended for professional installers only. The installer maintains responsibility for installing the product safely.
Please read all instrucons carefully before starng the installaon.
IMPORTANT: Recommended for professional installers only. The installer maintains responsibility for installing the product safely.
Vanity Installaon Guide
Dina Series (Top Mount)
12” Linen Cabinet
(Available in White & Black)
24” Cabinet
(Available in White & Black)

INSTALLATION GUIDE DINA SERIES
2
PARTS
DIMENSIONS
*Drawings are for reference only. Please refer to actual product for exact size, shape, color, and parts.
*Dawn reserves the right to make revisions in the design of faucets without noce for improvement of product performance and quality.
Note: Faucet sold separately.
Actual product parts may look dierent.

INSTALLATION GUIDE DINA SERIES
3
MATERIALS & TOOLS
BEFORE YOU BEGIN
INSTALLATION
• Comply with Plumbing Codes
Before installing any Dawn product in your home, you should make sure that you are in compliance with all local plumbing
codes.
• Check Product Condion
Before installaon, please check the condion of the product and, if appropriate, its components. If there is any problem
with the product and/or its components, please contact the store you purchased it from for a replacement. As soon as you
have inspected your product, please return it to its original packaging unl you are ready to install it.
• Handle with Care
To protect its nish and avoid damage before and aer installaon, please handle the product with care. For care and clean-
ing ps aer installaon, please refer to the Care and Cleaning Guide in this instrucon guide.
1. Install the Vanity
• Use a stud nder to locate and mark the wall studs.
• Remove the drawer(s) from the vanity cabinet. Li and place the vanity cabinet in posion against the nished wall. Make
sure the top is level and the supply valves clear any drawers and/or shelves in the cabinet.
• Drill pilot holes through the vanity back and the nished wall. For holes not inline with studs, push or hammer in wall anchors
that are made for your wall surface.
• Secure the cabinet to the nished wall with screws.
2. Install the Vanity Top
• Run a bead of silicone adhesive around the top of the vanity cabinet. Place the vanity top on top of the cabinet and press
rmly in place. Let the silicone adhesive cure.
• Assemble the faucet and the sink drain to the vanity top.
• Connect the water supply lines and the drain.
• Reinstall the drawer(s).
• Apply a bead of caulk along the back edge against the wall. Clean up any excess.
Allow 24 hours to dry.
• Turn on the water to test for leaks.
IMPORTANT: Recommended for professional installers only. The installer maintains responsibility for installing the product safely.
Safety Glasses, Pencil, Level, Tape Measure, Stud Finder, Assorted Screwdrivers, Assorted Wrenches,
Drill, Screw Gun, Caulking Gun, Hammer, Screws, Nail Anchors/Molly Screws
LEGAL DISCLAIMER:
• This instrucon guide is done as a public service to customers of Dawn Kitchen & Bath Products, Inc. (“Dawn”). For special situaons or further assistance, please consult professionals.
• All products should be inspected by customers upon receipt and before any installaon. Any defecve product should be reported immediately and should NOT be installed.
• Requirements may vary for installaon in a granite, marble, stone, or butcher block countertop.
• Installaon by professional installers is highly recommended. Dawn assumes no liability for any damages incurred through the use of informaon provided in this guide.

INSTALLATION GUIDE DINA SERIES
4
PARTS
*Drawings are for reference only. Please refer to actual product for exact size, shape, color, and parts.
*Dawn reserves the right to make revisions in the design of faucets without noce for improvement of product performance and quality.
Note: Faucet sold separately.
Countertop not included.
Actual product parts may look dierent.
MATERIALS & TOOLS
BEFORE YOU BEGIN
INSTALLATION
• Check Product Condion
Before installaon, please check the condion of the product and, if appropriate, its components. If there is any problem with
the product and/or its components, please contact the store you purchased it from for a replacement. As soon as you have
inspected your product, please return it to its original packaging unl you are ready to install it.
• Handle with Care
To protect its nish and avoid damage before and aer installaon, please handle the product with care. For care and cleaning
ps aer installaon, please refer to the Care and Cleaning Guide in this instrucon guide.
1. Install the Vanity
• Use a stud nder to locate and mark the wall studs.
• Remove the drawer(s) from the vanity cabinet. Li and place the vanity cabinet in posion against the nished wall. Make
sure the top is level and the supply valves clear any drawers and/or shelves in the cabinet.
• Drill pilot holes through the vanity back and the nished wall. For holes not inline with studs, push or hammer in wall anchors
that are made for your wall surface.
• Secure the cabinet to the nished wall with screws.
IMPORTANT: Recommended for professional installers only. The installer maintains responsibility for installing the product safely.
Safety Glasses, Pencil, Level, Tape Measure, Stud Finder, Assorted Screwdrivers, Assorted Wrenches,
Drill, Screw Gun, Caulking Gun, Hammer, Screws, Nail Anchors/Molly Screws

5
CARE AND CLEANING
Dawn® Vanity Cabinets
Wood naturally darkens over me or changes slightly in color due to light exposure and may go unnoced from day to day. However,
over an extended period of me it may become more noceable, depending on the amount of sunlight exposure. Our warranty
replacement products are not guaranteed to have an exact match. Any imperfecons such as small surface splits, small dark pits or
dark mineral streaks are natural and will not be considered as defects.
• Do regular roune cleaning rather than an occasional aggressive single cleaning.
• Dust frequently with a so cloth and occasionally use a wood cleaner that is not silicone based.
• Do not place in direct sunlight or near windows with direct sunlight exposure.
• Avoid extreme temperature changes and keep away from heater and air condioning units.
• Do not allow liquids to remain on the wood surfaces for longer than necessary.
• Liquid absorpon will cause wood to warp, bubble, and crack, and your nish may peel.
Dawn® Glass Sinks
Dawn® glass sinks are manufactured to our highest possible standards and regulaons to ensure you receive the utmost quality.
Dawn® tempered glass sinks are made to last because the tempering process makes them stronger than annealed glass. That does
not mean they are indestrucble, but rather more durable and praccal for everyday use. We have a few recommendaons to make
your sink last and maintain its sheen. Glass is subject to thermal stress when it experiences extreme hot or cold condions suddenly.
Glass needs me to be heated or cooled to extreme temperatures, and sudden changes can cause stress cracks to the product.
• Clean regularly with hot water and a mild detergent soluon applied with a so cloth or sponge to remove deposits.
• Rinse thoroughly and towel dry aer every use to prevent water spots and mineral deposits.
• Drying your sink aerwards will help prevent water spots.
• Rain-X®, which is available at most automove departments can be applied to keep your Dawn® sink water spot free.
Dawn® Ceramic Sinks
To keep your Dawn® products the center of aenon, we suggest you follow these guidelines to maintain its quality and beauful
aesthecs. Deep clean once a week with an approved cleanser and a so cloth or sponge rather than an occasional aggressive single
cleaning.
Water quality can also aect your Dawn® sink making it appear dull or stained. Lime scale is notorious for absorbing liquids like
coee, tea, and wine making the stained or nged look. To remove lime scale build up on your Dawn ® sink, use a lime scale cleaning
agent, such as CLR®. You can also soak the sink in 1 part white vinegar and 3 parts water to help loosen problemac areas making it
much easier to sponge away debris. Make sure to use a non-abrasive pad/sponge with a ceramic cleaner.
Do’s and Don’ts
• Clean regularly with hot water and a mild detergent soluon applied with a so cloth or sponge to remove deposits.
• Rinse thoroughly and towel dry aer every use to prevent water spots and mineral deposits.
• Drying your sink aer each use will help prevent water spots and lime scale.
• To remove lime scale or water spots, only use cleaners made specically for that purpose. Apply cleaners to cleaning cloths,
pads, or sponges rst, and test in a small area; do not apply directly onto the product.
• Do not allow any cleaning product to remain on your sink longer than necessary.
• Do not leave rubber patches, wet sponges, cloths, cleaning pads, or dishpans in the sink.
• Do not use coarse abrasive powders and metallic scourers, such as steel wool or brushes with metal bristles.
• Do not allow liquid soap or other cleansers to dry on the surface of the sink.
• Do not use detergents or soaps that contain acid or that are not dissolvable.

6
WARRANTY
RETURN POLICY
ASKING FOR ASSISTANCE
All Dawn® products carry limited lifeme warranty unless otherwise noted. Dawn® products have been manufactured and tested to the highest
quality standards by Dawn Kitchen & Bath Products, Inc. (“Dawn®”). Dawn® warranes are limited to Dawn® products purchased and installed in
the United States.
Limited Lifetime Warranty
Dawn® warranes all of its products to be free from manufacturing defects in material and workmanship during normal residenal use for as
long as the original purchaser owns his or her home. This warranty only extends to the original consumer and this warranty is non-transferable. If
any defect is found in normal residenal use, Dawn® will, at its own elecon, repair, provide a replacement part of product, or make appropriate
adjustment at no charge (excluding labor charges and other incidental or consequenal costs). Damage to a product caused by accident, misuse, or
abuse is NOT covered by this warranty. Improper care and cleaning will void the warranty. If Dawn® is unable to provide a replacement and repair
cannot be made, Dawn® may elect to refund the purchase price to the original consumer purchaser in exchange for the return of the product.
(IMPORTANT: The original consumer/purchaser should be responsible for inspecng products upon receipt. Any defecve product should be
reported immediately and should NOT be installed.)
One-Year Limited Warranty
Dawn® sinks, vanies, as well as kitchen and bath accessories are warranted to be free of defects in material and workmanship for one year from
date of purchase. Dawn® will, at its own elecon, repair, replace or make appropriate adjustment where Dawn® inspecon discloses any such
defects occurring in normal usage within one (1) year aer purchase. Dawn® is not responsible for removal or installaon costs. This warranty
voids if the product has been moved from its original installaon locaon. Defecve parts or products will be replaced on availability basis. Dawn®
warranty does not apply to any local building codes. It is the customer’s responsibility to comply with all local plumbing codes before installaon.
Dawn® vanies are made from natural raw materials. Grain and color dierences among wood, plant species, stone, and minerals occur naturally
and are not considered a defect. All wood darkens with age, which is considered a natural feature and not a defect. If a replacement part is needed,
exact color or grain match cannot be guaranteed. Exposure to direct sunlight may cause color variaon and/or surface damage and will not be
covered under warranty. Tempered glass may have a green nt which is a result of the tempering process and is not considered a defect. Color
variaon in stone is also a natural occurrence, and therefore new or replacement pieces may not match store display samples.
DAWN® WARRANTIES DO NOT COVER, AND DAWN® DISCLAIMS ANY LIABILITY FOR:
• Condions or damage NOT resulng from defects in material or workmanship.
• Condions or damage resulng from:
—Normal wear and tear, improper installaon or maintenance, misuse, abuse, negligence, accident, moving (pping) or alteraon,
scratches or handling damages.
—Use of abrasive cleaning products or the use of the product in any manner contrary to the product instrucons.
—Condions in the home such as excessive water pressure, water quality or corrosion.
• Labor, shipping or other costs for removal, installaon, replacement or return of product for warranty service.
• Parts, accessories, connected materials or related products that are not manufactured by Dawn®.
• Imperfecons such as checks (small surface splits), pitch pockets (small dark holes), grain or darker mineral streaks are natural and are not
considered defects.
• An invoice number will be required for proof of purchase
Dawn® reserves the right to inspect any Dawn® product reported to be defecve prior to any repair or replacement. Repair and replacement costs
EXCLUDE shipping, labor, and consequenal expenses. To obtain warranty service contact Dawn® either through your Dealer, Plumbing Contractor,
Home Center or E-retailer, or by contacng Dawn® at the contact informaon listed at the very top. Proof of purchase (original sales receipt) and
descripon of problem must be provided with all warranty claims.
You may only return new, uninstalled, or unused items sold and fullled by Dawn Kitchen & Bath Products, Inc. for a full refund within 30 days of
delivery. Items must be returned in its original package. Returns of used items or returns aer 30 days of delivery may be accepted with a 15%
restocking fee. Dawn will pay for return shipping costs only if the return is a result of our fault. If you receive a faulty product and need to exchange
it for the same product, please contact our customer service via phone, fax, or e-mail to request a replacement. If you would like to exchange a
product for a dierent one, please rst return the original product to our locaon at 27688 Industrial Blvd., Hayward, CA 94545 and then place a
new order.
PARTIAL REFUNDS MAY BE GIVEN TO:
• Most of the items that are returned aer 30 days of delivery
• Any item not returned in the condion it was delivered
• Any item that has obvious signs of use
• A 15% restocking fee will apply to all used items or items returned aer 30 days of delivery.
Dawn Customer Service Department
27688 Industrial Blvd., Hayward, CA 94545
Toll-Free: 877-DAWN-USA (877-329-6872)
E-mail: [email protected] Web: www.dawnusa.net © 2017 Dawn Kitchen & Bath Products, Inc
