Spectrum Industries Esports Shoutcaster Station 37382 User manual

0192426 Page 1 of 12
Assembly Instructions
Instructions de montage
Instrucciones de montaje
37382 - 84”W
37383 - 60”W
Esports Shoutcaster Station™
??
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Important
Avant d’utiliser ce produit:
• Veillez à lire ce guide
• Respectez les consignes de sécurité et d’utilisation
• Vériez que vous disposez de toutes les pièces
nécessaires à l’installation
Importante
Antes de utilizar este producto:
• Lea este manual
• Cumpla con todas las instrucciones de prevención de
accidentes y operativas
• Revise que todas las partes y las cantidades correctas
estén incluidas
Any parts damaged during shipment must be reported within 5
days of receipt. To report information regarding missing parts or
damage, to purchase parts or accessories, or if you have any
questions, please contact us.
Thank you for purchasing Spectrum products!
Les pièces endommagées pendant le transport doivent faire
l’objet d’un rapport dans les 5 jours de leur réception. Veuillez
prendre contact avec nous si des pièces manquent ou sont
abîmées, si vous avez des questions, ou encore pour acheter
des pièces ou des accessoires.
Merci pour votre achat d’un produit Spectrum!
Si alguna parte se dañó durante el embarque, deberá reportarla
en un lapso de 5 días a partir de la recepción. Para reportar
cualquier información sobre partes faltantes o dañadas, para
adquirirlas o comprar accesorios, o bien, si tiene alguna duda,
póngase en contacto con nosotros.
¡Gracias por adquirir productos Spectrum!
Owner’s Manual
Le manuel du propriétaire
El manual del propietario
VideoVideo
VidéoVidéo
VídeoVídeo
SpecsSpecs
SpécicationsSpécications
EspecicacionesEspecicaciones
800-235-1262800-235-1262
http://www.spectrumfurniture.com
84”W Shoutcaster 60”W Shoutcaster

0192426 Page 2 of 12
(1) 0159545
Cord channel
(1) 0159544
76” Reinforcement
bar
(1) 0158527
80” x 10”
Front worksurface
(1) 0158558
75.875” x 13.875”
Rear worksurface
(2) 0157945
Frame
37382 - 84" Shoutcaster
(1) 0159835
Top worksurface kit
(1) 0157952
Rear panel
(1) 0157954
Side panel-left
(1) 0158916
Side panel-right
Box #2 (84"W)
Box #1 (84"W)
37383 - 60" Shoutcaster
(1) 0158937
Cord channel
(1) 0158882
52” Reinforcement
bar
(1) 0158622
56” x 10”
Front Worksurface
(1) 0158778
51.75” x 13.75”
Rear Worksurface
(2) 0157945
Frame
Box #1 (60"W)
(1) 0159847
Top Worksurface kit
(1) 0158618
Rear panel
(1) 0157954
Side panel-left
(1) 0158916
Side panel-right
Box #2 (60"W)
Components

X 2
0192426 Page 3 of 12
37382
(84”W)
37383
(60”W)
Item # Description Qty Qty
038064 #14 x 3/4” PHSM 16 14
026064 1/4-20 x 5/8” PHMS 27 25
0100167 8-32 x 1/2” PH Thrd ctg 4 4
035594 #10 x 5/8” PHSM 32 32
0102063 1/4-20 x 35mm JC bolt 4 4
037700 1/4-20 x 70mm JC bolt 4 4
0191647 .257 ID x .5 OD x .5”L
Nylon spacer 4 4
37382
(84”W)
37383
(60”W)
Item # Description Qty Qty
0190604 3” Stem caster
w/ brake 2 2
0190603 3” Stem caster 2 2
0101649 2” x .625” Grommet 1 1
039622 2” Grommet 3 2
044555 3/8” Hole plug 2 2
036234 1/2” Flat steel washer 4 4
025039 4mm Hex wrench 1 1
(1) 0158553
Left Bracket
(1) 0158940
Right Bracket
(4) 0158933
Bracket
(1) 0158914
Center bracket
(2) 0159615
Bracket
(2) 0160831
Brace
Box #3
(84"W and 60"W)
(2) 0158560
Bracket
4mm
Hardware
Tools
Assembly tip: Do not tighten component fasteners completely
until all have been installed. Keeping them loose will help with
alignment between parts during assembly.
(1) 0159529
Left accent panel
(1) 0159530
Right accent panel

0192426 Page 4 of 12
1Attach brackets to audience-side panel
Audience-side panel
(2) #10 x 5/8”
PHSM
Bracket
2Connect leg frames to brackets
Be careful not to strip screw
holes during installation
(2) 1/4-20 x 5/8”
PHMS
Bracket
Frame X2
X4
X4
3Flip upside-down and install casters 4Flip upright, attach top worksurface
Locking
Caster X2
Caster
non-locking X2
Audience-side
User-side
Top worksurface
(4) #10 x 5/8”
PHSM
(1) #10 x 5/8”
PHSM
(1) #10 x 5/8”
PHSM
Center
bracket
Note: Assembly steps shown apply to both 60” single and 84” Double Shoutcaster Stations

0192426 Page 5 of 12
5Attach left / right side worksurfaces 6Attach left / right brackets
Side
worksurface X2
#10 x 5/8” PHSM
(4 required)
7Attach reinforcement bar to front wksf 8Attach front worksurface
Right
Bracket
Left
Bracket
1/4-20 x 5/8”
PHMS (4 req’d)
There are 3” of vertical adjustment
range during assembly. Choose
one set of holes for preferred work-
surface height.
Reinforcement bar
#14 x 3/4”
PHSM
Front Worksurface
Front Worksurface
#14 x 3/4” PHSM
(2 required)
#14 x 3/4” PHSM
(2 required)

0192426 Page 6 of 12
9Attach brackets to rear worksurface
#14 x 3/4” PHSM
(2 per)
10 Install rear worksurface
Front worksurfaceRear worksurface-level
#14 x 3/4” PHSM
(2 per)
Rear Worksurface
Bracket
Bracket
1/4-20 x 5/8” PHMS
(2 per bracket)
Rear worksurface-recessed
2” Grommet
3/8” Hole plug
Rear Worksurface
11 Adjust and secure rear worksurface 12 Install cord channel
#10 x 5/8” PHSM
(3 required)
Cord channel

0192426 Page 7 of 12
Left accent
panel
Right accent
panel
Left side
panel
Right side
panel
Rounded edge
(1) 8-32 x 1/2”
PH Thrd ctg
(in upper hole)
(1) 8-32 x 1/2”
PH Thrd ctg
(in lower hole)
Flange
Flange
Be careful not to strip screw
holes during installation
15 Attach side panel to each accent panel 16 Align accent / side panel assembly
Note: Do not tighten screws completely-leave about 1/16”
gap between each screw head and the worksurface.
Repeat on opposite side. These screws will support the
accent / side panels during alignment in Step 16.
14 Secure styrene backer with brace
Accent
panel
Rounded edge
13 Install support screws in worksurfaces
#10 x 5/8”
PHSM
Brace
Styrene backer
Side worksurface
#10 x 5/8”
PHSM
Top worksurface
Slot
Slot
X2
X2
X2
X1
Accent / side
panel assembly
Shoutcaster

0192426 Page 8 of 12
17 Secure accent / side panel assembly
1/4-20 x 70mm
JC bolt
Nylon
spacer
Nylon
spacer
1/4-20 x 35mm
JC bolt
(2 on audience-side)
Accent / side
panel assembly
1/4-20 x 70mm
JC bolt
Rounded edge
Note: Nylon spacers go between the leg
frame and side panel at rounded edge.
1/4-20 x 5/8” PHMS
(2 required)
18 Install CPU sling bracket
CPU sling
bracket
Note: The CPU sling bracket is for use with the optional
Adjustable Narrow CPU Sling - 95513 (not included).
19 Caster operation

Monitor Mount - 37387
• Adjustable VESA-compatible display mount
• Provides display monitor mounting on audience-side
84”W Shoutcaster - 37382 only (most monitors up to 55” diag)
• One mount included
• Unit weight: 8 lb [3.6 kg]
• Shipping weight: 9 lb [4.1 kg]
Swivel VESA Monitor Mount - 37388
• Provides display monitor mounting in recessed worksurface
(most monitors up to 24” diag)
• Provides display monitor mounting on audience-side
60”W Shoutcaster - 37383 only (most monitors up to 32” diag)
• Internal travel stops-provide 4-direction tilt, 4° left, 4° right, 16° up,
and 6° down (Specic monitor size, shape, and mounting location
will determine exact angles of tilt)
• Works with 75mm and 100mm VESA mounts
• Includes mounting screws
• One mount included
• Unit weight: 1.19 lb [.54 kg]
• Shipping weight: 2 lb [.91 kg]
Audience-side
X 2
X 3
Audience-side
84”W Shoutcaster
X 1
60”W Shoutcaster
84”W Shoutcaster
0192426 Page 9 of 12
Accessories

LED Lighting Kit - 37386
• Provides custom backlighting
options for corner columns
• Includes RGB LED ribbon, power
supply, and RF remote control
• Shipping weight: .5 lb [.23 kg]
Customized Logo Panel - Single - 37385
• Single panel: 29”W x 30”H
• Made of 3mm PVC sheet
• Easily attaches and removes with hook and loop fasteners
• New logos require a rst time logo charge, to get panel
customized-contact Spectrum for details
• Unit weights:
1.5 lb [.68 kg]
• Shipping weights:
2 lb [.91 kg]
CPU Tray - 37389
• Provides CPU tower storage
under worksurface
• 9.25”W x 20”D x 1”H
• Each Shoutcaster can support
up to 2 CPU trays (1 per side)
• Unit weight: 10 lb [4.5 kg]
• Shipping weight: 11 lb [5 kg]
60”W Shoutcaster
84”W Shoutcaster Customized Logo Panel - Double - 37384
• Double panel: 53”W x 30”H
• Made of 3mm PVC sheet
• Easily attaches and removes with hook and loop fasteners
• New logos require a rst time logo charge, to get panel
customized-contact Spectrum for details
• Unit weights:
2 lb [.91 kg]
• Shipping weights:
2.5 lb [1.14 kg]
Note: A white column accent (backer) will maximize the brightness eect
when used with the optional 37386 LED Lighting Kit.
Colored accent panels can be ipped over to reveal white if the LED Kit
is purchased later or if white accent is desired.
Adjustable Narrow
CPU Sling - 95513
• Provides CPU tower storage
under worksurface
• 5”-8.5”W x 18”D x 18”H
• Each Shoutcaster can support
(2) CPU slings (1 per side)
• Unit weight: 10.4 lb [4.7 kg]
• Shipping weight: 11.4 lb [5.2 kg]
0192426 Page 10 of 12
