Techni Mobili RTA-8211 User manual

B11 190612
Scan QR Code to view
full assembly video

P.1 RTA-8211 P.1
 3OHDVHUHDGFDUHIXOO\WKHDVVHPEO\LQVWUXFWLRQV
EHIRUHWKHLQVWDOODWLRQ
 'RQRWGLVFDUGWKLVPDQXDORUDQ\RI WKHSDFNDJLQJ
PDWHULDOXQWLOWKHXQLWKDVEHHQ FRPSOHWHO\DVVHPEOHG
 6FDQ45&RGHWRYLHZIXOODVVHPEO\DQGVWHS YLGHR
 0LJKWUHTXLUHWZRSHRSOH

MAIN PARTS LIST
P.2 RTA-8211 P.2
14
x1
13
x1
15
x8
16
x1
17
x1
18
x1 20
x1
1
x2
2
x2
3
x2
4
x2
5
x2
6
x2
7
x2
8
x2
9
x1
10
x1
11
x1
12
x1
19
x1
Sets
• Scanner panel sliders
•Drawers left panel • Drawers right panel • Drawers front panel
• Drawers bottom panel • Drawers back panel • Handles • Drawer sliders
• Left panel • Right panel • Scanner panel • Back panel
• Drawer box bottom panel • Drawer box top panel • Studs • CPU box left panel
• CPU shelf auxiliary panel • CPU box right panel • CPU box back panel
• CPU box bottom panel

MAIN PARTS LIST
P.3RTA-8211 P.3
21
x1
22
x1
23
x1
24
x1
25
x4
26
x2
27
x1
28
x3
29
x1
• CPU box top panel • Keyboard Sliders • Keyboard panel • Tabletop
• Slider Base • Support tubes
for tabletop • Central back panel • Support tubes for
accessory shelf
panel
•Accessory shelf panel
9
11
12
3
3
13
14
16 18
19
20
17
23
24
26
29
28
10
LOCATION OF THE MAIN PARTS ( FOR REFERENCE )

P.4 RTA-8211 P.4
A
B
D
C
E
6X40 MM
3X15 MM
4X35 MM
4X20 MM
4X14 MM
16
26
8
4
12
PART QTY. ITEM PART QTY. ITEM
F6X12 MM
4
G4X4 MM
4
J
6X35 MM
K
5
1
L
36X30 MM
5X40 MM
M
6
N
6X25 MM
SCREWDRIVER
GROMMET
WASHER
20
H
2
I
Φ 5 X17 MM
2
4
LIST OF SCREWS AND FITTINGS
ALIGNMENT DIRECTION

P.5 RTA-8211 P.5
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
❶Do a quick inventory to make
sure the package contains all the
parts and hardware listed in the
assembly instructions.
❷Missing, damaged and
defective parts can be replaced
at no cost to you. Please refer
to the CONTACT card included
with the product.
❸The replacement parts service
is limited to the continental United
States. If you reside in Hawaii,
Puerto Rico, U.S. Dependencies or
other countries, please contact the
supplier from where the unit was
purchased.
❹If during assembly you find
an issue or need clarification,
please contact our Customer
Service for assistance. Please
refer to the CONTACT card
included with the product.
❺On each step read the
instructions and analyze the
illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten or
force the screws as they
might break, strip, damage
the threads of the holes or
get stuck inside the part.
❻Make sure you understand
which hardware will be used on
each step. Using the wrong size
of screw, bolt or pin might strip
the threads or cause damage to
the part in which it is being used.
❼To avoid misalignments,
always leave the screws loose
and tighten them until all pieces
are positioned correctly.
❾Sometimes the laminate might cover partially or entirely the
hole on a panel. If there is no visible hole for the screw, pass
and press the tip of your finger over the area where the hole
should be located to feel the indentation, and once found,
carefully pierce the laminate to reveal the hole underneath.
❿If the hole seems too small for the screw, first make sure
you are using the correct size of screw and that it’s been
installed in the correct hole. If the hole still appears to be too
small, carefully pierce the laminate to reveal the hole’s actual
size.

3
1
2
5
1
2
6
1
2
3
3
7
STEPS FOR ASSEMBLY
P.6 RTA-8211 P.6
STEP 1
Hardware:
L6x25mm x4
Scan QR Code to
view this step
STEP 2
Hardware:
C4X35mm
x2
D
4X20mm
Scan QR Code to
view this step
x4

Holes for
scanner sllder
Holes for
top drawer
Holes for
bottom drawer
10
9
88
FRONT
FRONT
Use screws (B) to assemble the flat
drawer sliders (8) on the middle and
bottom sets of slider holes as indicated.
The wheels will be facing towards the
front of the panels.
8
8
STEPS FOR ASSEMBLY
P.7RTA-8211 P.7
STEP 3
Hardware:
B3x15mm x4
STEP 4
Hardware:
B
3x15mm x8
X2 X2
Scan QR Code to
view this step
Scan QR Code to
view this step

STEPS FOR ASSEMBLY
P.8RTA-8211 P.8
STEP 5
Hardware:
B
3x15mm
x6
STEP 6
Hardware:
x8
15
910
4
4
910
4
4
20
15 X4
13
15 X4 STEP 7
Hardware:
x4
A6X40mm
9
10
13
Back of panel
(13)has 2 holes
for next step.
N
12
10
13
10 12
STEP 8
Hardware:
x4
K
5x40 mm
Scan QR Code to
view this step
Scan QR Code to
view this step
Scan QR Code to
view this step
Scan QR Code to
view this step
Attach the bolts (A) to the drawers’ box bottom panel (13),
then assemble the Left and Right panels (9) and (10) as shown.
x2
L
6x25 mm
IMPORTANT: Make sure you use in this step the correct sliders ( 4 ) which are longer and have more holes than sliders ( 22 ).
Use screws ( B ) to assemble the scanner sliders ( 4 ) to the top sets of slider holes on panels ( 9 ) and ( 10 ) in the following order:
First open the slider slowly until the first hole on the front of the slider is visible through the big opening, and attach to the front hole on the
panels as shown. The open the slider completely and attach to the 2 back holes as shown.
Secure the back panel (12) to the side panels
(9) and (10) using screws (K) as shown.
Attach the bolts (L) to the drawers box bottom panel
(13), and assemble the back panel (12) as shown.
Then attach the grommet (N) to the back panel (12).

11
11
4
9
10
14
13
16 18
20
18
16
19
N
18
19
STEPS FOR ASSEMBLY
P.9RTA-8211 P.9
STEP 9
Hardware:
A6X40mm
STEP 10
Hardware:
B3X15mm
STEP 11
Hardware:
A6X40mm
STEP 12
Hardware:
x4
K
5x40mm
Scan QR Code to
view this step
Scan QR Code to
view this step
Scan QR Code to
view this step
Scan QR Code to
view this step
x4
x4
x4
x2
L
6x25 mm

16
18
21
STEPS FOR ASSEMBLY
P.10 RTA-8211 P.10
STEP 13
Hardware:
A6X40mm
STEP 14
Hardware:
L6X25mm
Scan QR Code to
view this step
Scan QR Code to
view this step
x4
x4

25
22
22
24
25 X4
24
26
26
STEPS FOR ASSEMBLY
P.11RTA-8211 P.11
STEP 15
Hardware:
F6X12mm
STEP 16
Hardware:
x4
G4X4mm
STEP 17
Hardware:
x8
E4X14mm
Scan QR Code to
view this step
Scan QR Code to
view this step
Scan QR Code to
view this step
x4

P.12RTA-8211 P.12
STEPS FOR ASSEMBLY
STEP 18
Hardware:
x4
L6X25mm
x4
H6X35mm
STEP 19
Hardware:
x4
E4X14mm
Scan QR Code to
view this step
Scan QR Code to
view this step
x2
I
2 PERSONS
REQUIRED

29
29
28
17
3
3
P.13RTA-8211 P.13
STEPS FOR ASSEMBLY
STEP 20
Hardware:
J6X30mm x3
STEP 21
Hardware:
H6X35mm x3
STEP 22
Hardware:
H6X35mm x3
Scan QR Code to
view this step
Scan QR Code to
view this step
Scan QR Code to
view this step
x4
M
Insert the Pins (M) into one of the
3 sets of holes on the CPU box
side panels (16 & 18), and
place the Auxiliary panel (17).
Slide in the drawers starting with the bottom one,
then top drawer. The top drawer might need to be
inserted at an angle with its front facing down.

P.14RTA-8211 P.14
FINAL STEP
ALL DONE!
Give yourself a nice pat on the back. You did a great job!

P.15RTA-8211 P.15
AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE
FOLLOWING WARNINGS FOR CARE AND MAINTENANCE:
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and water, then dry
with a clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as underneath the
tabletop.
•Do not seat on the unit or lean against it.
•Do not allow small children to play under or over the unit, or inside the CPU cabinet.
•Do not allow small children to reach inside the drawers or CPU cabinet without your supervision.
•The unit must be handled by at least 2 persons when moving in the same or adjacent rooms.
•Before moving the unit, make sure to remove any object that is heavy or might fall off. Please note that
lifting from the tabletop with too much weight on the product might lead to part damage/separation.
•When lifting the unit, use both hands and bend your knees, not your backs.
•When transporting the unit to places far away, protect and secure the unit to avoid damage in transit. You
may also disassemble it partially.
•Shall any part of the unit become defective during the warranty period, replacement parts might be
available to you at no charge. Please refer to the WARRANTY card included with the product.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes liability for
damages or consequences due to accidents, incorrect assembly, negligence, improper use, modifications,
or not heeding the above warnings.
