DAXYS DXYP04 User manual

Daxys Portable Electric Air Pump
Model:
Smart Bike Pump
User Manual
Model: BP188
Portable Electric Air Pump
User Manual

Daxys Portable Electric Air Pump
Model:
Smart Bike Pump
Thank you for purchasing the Smart Bike Pump. Please
read this user manual carefully before using this product ,
and keep it for future reference.
1. Packing list
1 x Smart Bike Pump
1 x Flexible hose with schrader valve
1 x Presta valve
1 x Inflating needle
1 x Nozzle for swimming ring
1 x Type-C cable
1 x Waterproof storage bag
2. Specification
Smart Bike Pump
Product model: BP188
Product size: 40x40x191mm
Weight: 380g
Inflation pressure: 120PSI (max)
Working temperature: -10~45° C
Battery capacity: 8.88Wh
Charging input: 5V/2A
--01--
Portable Electric Air Pump
Thank you for purchasing the Portable Electric Air Pump.
Please read this user manual carefully before using this
product , and keep it for future reference.
1. Packing list
1 x Portable Electric Air Pump
1 x Flexible hose with schrader valve
1 x Presta valve
1 x Inflating needle
1 x Nozzle for swimming ring
1 x Type-C cable
1 x Waterproof storage bag
2. Specification
Portable Electric Air Pump
Product model: DXYP04
Product size: 40x40x191mm
Weight: 380g
Inflation pressure: 120PSI (max)
Working temperature: -10~45° C
Battery capacity: 8.88Wh
Charging input: 5V/2A
--01--

Daxys Portable Electric Air Pump
Model:
3. Illustration
[a] Hose connector
[c] USB Type-C port
[e] Measured pressure
[g] Preset pressure value
[h] Battery Indicator
[d] Unit
[k] Working mode
[l] Preset +/-
[j] Power on / off
Inflation On/Off
[i] Unit switching
LED light
--02--
[f] Mode
[b] LED light

Daxys Portable Electric Air Pump
Model:
4. ATTENTION:
1) Do not leave during inflation
2) Keep away from combustible and explosives.
3) Avoid moisture, sand and prevent from falling.
4) Do not store the product in a place that is too cold or hot.
5) It is forbidden to throw the product into fire or discard it at
random due to the built-in lithium battery.
6) Not for children
5. How to use
5.1 Charging method
Green light：60~100%
Yellow light：30~60%
Red light：10~30%
The USB charger is recommended to use 5V / 2A. Use the
Type-C charging cable to connect the air pump and
power adapter (not included) for charging
Charging status: battery indicator flashes
Full state: the battery indicator is green and does not flash
The product cannot be used during charging.
--03--

Daxys Portable Electric Air Pump
Model:
5.2 Startup and shutdown
*Long press the power
button for 3 seconds,
as shown in the figure.
Switch on successfully
*Long press the power button for
3 seconds, as shown in the figure
Shut down successfully
*Automatic shutdown in 3 minutes
without operation
*Automatically shut down when
battery is low
5.3 Mode switching
Short press mode selection key [k] ,you can choose 5
inflatable scene modes. They are:
Scene mode Reference value Adjustable range
Car mode
Motorcycle mode
Bicycle mode
Custom mode
Ball mode
35PSI/2.4bar
40PSI
38PSI
100PSI
8PSI
0-65PSI
0-55PSI
0-120PSI
0-120PSI
0-15PSI
Startup Shutdown
--04--

Daxys Portable Electric Air Pump
Model:
5.4 Unit switching
Short press the unit switch key [i], you can switch the air pressure
display unit. The unit conversion formula is shown below
5.5 Preset pressure value
Short press +/- button [l]: adjust the preset pressure value +/- 0.5PSI
Long press +/- button [l]: can quickly adjust the preset pressure value
Note: The scene switch and preset pressure value are automatically
saved by the pump. You only need to switch the mode for
the next use, and the preset pressure will be automatically set.
5.6 Hose connection
Schrader valve Presta valve Inflating needle
The connection of the hose is shown in the following figure:
5.7 Start inflation
Short press the inflation switch [j] to start inflation. The digital
display of the real-time air pressure value [e] changes during inflation.
Noise cannot be avoided during inflation, and the hose pwill be heated
after long-term work.
Avoid touching the hose and joints [a] by your hands after long-term use.
High temperature zone
--05--

Daxys Portable Electric Air Pump
Model:
5.8 Stop inflation
* Short press the inflation switch [j]
to stop inflation manually.
* When the measured pressure [e]
reaches the preset pressure [g],
stop inflation automatically.
[e]Measured pressure
[g]Preset pressure
5.9 LED Lighting
* Long press LED [i] to turn on LED lighting.
* Press and hold the LED light button [i] to turn off the LED light.
5.10 Measuring pressure
After switching on, connect the hose to the measured object,
and the measured pressure value [e] shows the current pressure value.
5.11 Reset the pressure
After switching on, when the measured pressure value is not zero,
press the preset +/- key [l] for 3 seconds to enter auto reset.
--06--

Daxys Portable Electric Air Pump
Model:
Note:
The product has been calibrated the factory. Due to the difference in
altitude or the sensor tolerance, the measured pressure may not be
zero, manual clearing can improve the accuracy of pressure
detection. Do not connect inflatable objects when reseting.
6 High temperature safety precautions
When the hose is unscrewed, the air pipe and the joint will be
heated due to long-term work. Do not touch it with your
hands for a long time.
HOT
--07--

Daxys Portable Electric Air Pump
Model:
7 Common product pressure values
Category Type Pressure value
Bicycle Stroller
10~16inch t\re
20~30inch t\re
Road bike
Scooter / Wheelchair
/Moped
Motorcycle/
Electric car
Car
Ball
Car
Toy ball for kids
Basketball
Football
Volleyball
Rugby
18~30PSI
30~45PSI
38~55PSI
90~120PSI
30~45PSI
28~55PSI
2.2~2.8Bar
3~6PSI
7~9PSI
10~12PSI
4~6PSI
10~14PSI
--08--
