Daybreak 1304 User manual

Questions in regards to your product email [email protected] Page 1/2
ASSEMBLY INSTRUCTIONS / PRODUCT NAME: #1304 Rollback Glider
HARDWARE
TOOLS
STEP 1
Assembly time: 20 min
Please be sure and remove all parts from your box and assemble your new furniture on a blanket so
you don’t damage your new furniture while assembling. Do not over tighten!!! Over tightening of
hardware can cause damage to the item.
ASSEMBLY INSTRUCTIONS
PRODUCT NAME: #1304 Rollback Glider
For assembling this product, you need the following tools:
Glider Base Assembly
a. Locate the Left Glider Base (5) and Right Glider base (6) as well as 2pcs. 14 1/4” Stretcher Boards (7).
b. Place Stretcher Boards in the the small incuts located on the Glider Base.
c. Use 6pcs. 2 1/2” Polybuster Screws (E) to fasten each side (small pilot holes) - repeat on the other side.
#2 Square Tip Bit with Drill Wrench 7/16” and 9/16” Soft Rubber Mallet
1
2
3
4
5
6
7
7
7
7
5
5
6
E
E
E
E
E
E
E
E
E
E
E
E
E
Glider Arms
x4
A
3/8” x 2 3/4” Carriage Bolts
x4
B
1/4” x 4” Carriage Bolts
x4
C
1/4” x 3” Carriage Bolts
x6
D
3/8”
Lock Nut
x8
G
2 1/2”
Polybuster Screws
x12
E
1/4”
Flange Nut
x10
H
3/8”
Flange Nut
x4
F

a. Locate Seat (2), Back (1), Right Arm (3) and Left Arm (4) assemblies.
b. Lay seat on the side and use 2pcs. 3” Carriage Bolts (D) to fasten the front legs to the seat (use a soft mallet
to pound the carriage bolts in). They should lay flat against the back of the head of carriage bolt.
c. Use 2pcs 4” Bolts (C) to fasten the back leg, seat and back together in a sandwich assembly - use Flange
Nuts (H) to tighten.
d. Line the hole in the side of the arm with the hole in the back side to fasten. Use 3” Bolts (D) and Flange
Nut (H) to fasten.
e. Repeat for the other side of chair.
a. Lay the chair on the side and use 4pcs. 2 3/4” Carriage Bolts (B) in the bottom hole on each leg - The bolt
head should be to the outside of chair and bolt sticking out on inside (use a soft mallet to pound the
carriage bolts in). They should lay flat against the back of the head of carriage bolt.
b. Use 4pcs. 3/8” Flange Nuts (F) on the inside of leg to tighten Bolt before moving on to mounting the Glider Arms (A).
c. Mount the 4pcs. Glider Arms (A) to the legs - use 3/8” Lock Nuts (G) to fasten the glider arms to the legs of the chair.
d. Place the other end of the glider arms on to the glider base and fasten using 4pcs. 3/8” Lock Nuts (G) (Be
careful to not allow it to swing and pinch your fingers!)
Questions in regards to your product email [email protected] Page 2/2
ASSEMBLY INSTRUCTIONS / PRODUCT NAME: #1304 Rollback Glider
STEP 3
STEP 2 Chair Assembly
Mounting Chair to Glider Base
1
1
1
1
2
2
2
2
3
4
3
3
3
3
3
3
4
4
5
6
B
B
B
B
B
F
F
F
F
F
G
G
G
G
G
G
G
A
A
A
A
A
D
DD
D
D
D
D
D
C
CC
C
CC
H
H
H
H
HH
HH
H
H
D
H
H
H
HH
G
G
5
G
A
