DAYLIFF AQUASTRONG SMART 45 Installation instructions

AQUASTRONG SMART 45
Water Boosting Pump
Installation &
Operating Manual

INDEX
© Davis & Shirtliff Ltd 2021
Contents herein are not warranted
SPECIFICATIONS
1.
1
3.
INSTALLATION 4
3.2 Minimum Space 4
3.3 System Sizing
4
3.1 Location 4
3.4 Piping Connection
5
3.5 Mains Water Pressure Boosting
6
3.6 Suction from a Well
6
3.7 Suction from fresh Water Tank
6
4. OPERATION 7
7. TERMS OF WARRANTY 12
4.2 Starting the Pump 7
4.3 Setting the Correct Pressure
7
4.1 Priming the Pump 7
4.4 Control Panel
8
5. TROUBLE SHOOTING 10
6. MAINTENANCE AND STORAGE 11
2.
WARNINGS AND SYMBOLS 3

1
1. SPECIFICATIONS
Congratulations on selecting Dayliff Aquastrong Smart 45 Water
Boosting System. They are manufactured to the highest standards and
if installed and operated correctly will give many years of efcient and
trouble free service. Careful reading of this Installation Manual is
therefore important, though should there be any queries they should
be referred to the equipment supplier.
Set
Pressure
Operating
Pressure
Permanent Magnet
Motor High Efficiency
Variable Speed
Pressure Constant
Hot Water
0
Handling to 80 C
Eco-friendly Low Noise
(60dB)
Warning
Indicator Lights
3
FLOW RATE(m /hr)
12 3 45
5
10
15
20
55
45
40
50 PUMP FULL SPEED
4.5 BAR
3
FLOW RATE(m /hr)
12 3 45
5
55
2500RPM
10
15
20
25
35
45
40
30
50
3000RPM
3500RPM
4000RPM
4500RPM
5200RPM
PUMP HEAD(m)
35
30
6
25 2.5 BAR
DEFAULT SET
3.5 BAR
4 BAR
6
0 0
FIXED PRESSURE PERFORMANCE FIXED SPEED PERFORMANCE

2
PUMP
Dayliff Aquastrong SMART45 is a highly innovative smart variable speed
water boosting pump ideal for automatic pressurised water supply for houses,
apartments, offices and other small-scale applications where reliable water supply
is demanded, the variable speed technology providing constant pressure at
varying water demand. Particular features include:-
• Innovative inverter controlled variable speed technology that
minimises energy consumption.
• Optimised self-priming hydraulic design with that includes four-
stage AISI304 stainless steel impellers, high-spec mechanical seal that
accommodates dry-running and integral pressure and flow sensors.
• Permanent magnet air cooled DC motor that features high efficiency
with quiet (60dB) operation and inbuilt thermal overload and dry run
protection.
• Fully automatic operation with the option of adjustable constant
pressure settings that matches flow with demand and constant speed
function that varies pressure with demand.
• Easy to use LED control panel with display for operating mode, motor
speed, operating pressure and various fault indicators.
• Convenience features including adjustable inlet and outlet connectors
for installation flexibility, inbuilt non-return valve and integral maintenance
free 1L pressure tank.
• 2-year guarantee.
• GS certification in accordance with the EU Uniform EN and the German
Industrial DIN Standards.
Dayliff Aquastrong SMART45 is an exceptionally advanced product that uses
state of the art inverter technology to provide the perfect solution for a complete
water supply system in all domestic and residential water supply applications.
Insulation: F Enclosure Class:IPX5 Power: 750W, 1x240V
Max Speed: 5200rpm
OPERATING CONDITIONS
Pumped Liquid: Thin, clean, chemically non-aggressive liquids without solid
particles or fibres
0
Max. Ambient Temp: 55 C
0
Max. Liquid Temp: 80 C
Max Suction Depth:8m

2. WARNINGS AND SYMBOLS
If the water contains sand, gravel or other debris, install a
lter on the inlet side to protect the pump and installation.
NOTE
3
Weight:17kg
Installation Arrangement
Check the direction of ow indicated by an arrow on the
pump casing and install the pump between the isolating
valves. When replacing pump maintain the same direction
of ow.
Ensure no water leakage onto the pump motor or its
electrical connections during installations, venting or
operations as this may cause electrical shocks.
Non-approved replacement parts may not be used.
Any action that doesn’t comply with safety warning sign may
cause personal injury, pump damage and losses in property.
Users must also comply with the local safety regulations.
WARNING
WARNING
WARNING
WARNING
Electrical work to be carried out by competent qualied and
licensed electrician.
WARNING
Do not start the pump until it has been properly primed.
WARNING

3. INSTALLATION
1
2
36
5
4
1. Pressure Tank
2. Flow Sensor
3. Pressure Sensor
4. Rear Bearing
5. Front Bearing
6. Mechanical Seals
3.1 Location
The pump can be installed indoors or outdoors but it must not be exposed to
inclement weather. It is recommended that the pump is installed near a drain or in
a drip tray connected to a drain in order to lead away possible condensation from
cold surfaces.
3.2 Minimum Space
The pump requires a minimum space of 620x400x530mm. Even though the
pump does not require much space, it is recommended that there is enough
room for service and maintenance access.
3.3 System Sizing
The pump is factory set with 3bar outlet pressure which can be adjusted
according to demand. The tank pre-charge pressure is 1.25bar.
In case of suction lift of more than 6m, the pump outlet pressure must be at least
2m water column or 0.2bar minimum. Inorder to obtain optimum operation, the
suction lift should be kept as low as possible.
4

5
Always loosen and tighten the union nuts on the inlet and
outlet port by hand. Damage to the inlet and outlet ports
increases the risk of leakage.
WARNING
3.4 Piping Connection
Ensure that the pump is not stressed by the piping system.
Flexible hose is strongly recommended.
WARNING
1. Turn the union nuts by hand to loosen the inlet and outlet ports.
2. Seal the pipe fittings using thread tape.
3. Carefully screw the inlet and outlet connections onto the pipe fittings using a pipe
wrench or similar tool. Keep the union nut on the pipe fitting if it has been removed
from the pump.
4. Fasten the connections to the inlet and outlet. Hold the connection with one hand
and tighten the union nut with the other hand.
Inlet and outlet port
Fig1. Pipe Connection
Union nut

6
3.5 Mains Water Pressure Boosting
5
1
2
2
2
5
1. Highest tap
2. Ball Valve
3. Inlet Filter
4. Foot Valve with
Strainer
5. Drip Tray
Install the pump on a small stand to prevent the ventilation
holes from being ooded.
NOTE
1
2
3
4
H1
H2
4
3
2
1
3.6 Suction from a Well 3.7 Suction from Water Tank
Maximum suction lift is 8m. For well applications, inlet pipe
must be submersed atleast 0.5m.
NOTE

7
4. OPERATION
4.1 Priming the pump
Unscrew the priming plug and pour atleast 1.2 litres of water into the pump.
4.2 Starting the pump
1. Open a tap to prepare the pump for venting.
2. Plug pump onto power and the pump will start shortly.
3. Allow water to flow out until it stops bubbling, when all the air is expelled,
close the tap.
4. Open the highest tap in the installation.
5. Adjust the pressure set point to required pressure by adjusting the buttons
on the control panel.
6. Close the tap.
7. The pump is ready for use.
4.3 Setting the correct pressure
The pump can be set between 1.0 to 5.5bar at intervals of 0.5bar. The factory
setting is 3bar.
The default pressure of 3.0 bar will suit most applications. The difference
between the inlet and outlet pressure must not exceed 3.5bar. Example: If the
inlet pressure is 0.5bar, the maximum outlet pressure should be 4bar. If the
pressure is set too high the pump will operate intermittently.
The difference between the inlet and outlet pressure
should not exceed 3.5bar.
NOTE

8
Bar
Maximum Set Point
Well application
Tank below ground level
Tank above ground level
3.0
3.5
4.0
3Bar 4Bar
Boosting from well or tank
5.5Bar
5Bar
4.5Bar
Boosting from mains
The pressure settings of 4.5, 5.0
and 5.5bar require a positive
inlet pressure and the settings
must only be used when boosting
from the water mains.
WARNING
4.4 Control Panel
Press ‘switch’ button to start the pump, press the switch button again to switch it off.
The pump can be changed automatically from Auto mode to forced start mode by
pressing down the switch button for 8 seconds.
+
up
switch
_
down

9
Full Automatic Mode: In automatic mode, set pressure and operating
pressures are shown on the display. Adjust the pump’s pressure by pressing the
“+” or “-” button. Setting ranges from 1.5 to 5.5bar.
Forced Start Mode: In forced mode, motor speed is shown on the display.
Adjust the motor rotations’ speed by pressing “+” or “-” button. The speed ranges
from 2,500 to 5,200 rpm.
Hold on the “+” and “-” button simultaneously for 1.5 seconds to reset the pump.
Set
Pressure
Operating
Pressure
Warning Indicator
Lights
Faulty LED Indicator Guidelines
Setting
pressure
Operating
pressure
+_
upswitch down
M
-SMART45
1. Power supply failure
3. The pump is blocked
Switch on the power supply. Check the
cables and cable connection for defects,
loose connections or for blown fuses in the
electrical installation.
Check whether there is any leakage in the
pipeline or the tap and repair.
Check whether there is foreign matter in the
pump and clean. The pump will work
normally. The indicator light will then turn
off. If not, contact authorized D&S dealer.
2. Pipeline leakage

10
M
switch
4. Dry running fault
Check the water supply and prime the
pump.
5. Overheating protection
Switch off the pump, wait for the motor to
cool down and restart. If the indicator does
not go off, contact authorized D&S dealer.
6. Faulty Pressure Sensor
Repair or replace sensor and fit tightly back
in the pump. Restart the pump, the
indicator will then go off.
7. Faulty Flow Sensor
Repair or replace sensor and fit tightly back
in the pump. Restart the pump, the
indicator will then go off
5. TROUBLE SHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Pump does not
run
No power
Motor overheating due to:
i) Liquid temperature being too high
ii) Blocking by foreign bodies
Eliminate the cause of overheating
Residual current circuit breaker
triggered Reset circuit breaker
Replace motorMotor defective
Pump runs with
no water output
Clear blockage
Suction opening is blocked
Prime the pumpPump drawing in air
Clean the suction area
Pump blocked by foreign bodies
Check connections and power
supply

11
PROBLEM POSSIBLE CAUSE SOLUTION
Flow rate
insufficient
Readjust to allowable delivery height
Delivery height too big
Use pressure line with larger
Pressure line diameter too small
Clean suction openingSuction opening is blocked
Straighten pressure linePressure line is kinked
Pressure line leaks
Pump runs very
loudly
Ensure there is sufficient water at
suction
Pump drawing in air
With correct installation and operation, Smart 45 does not need regular
maintenance.
During periods of inactivity, the pump must be disconnected from the power
supply and placed in a dry location.
Proceed as follows;
1. Switch off the pump using on/off button.
2. Disconnect from the power supply.
3. Open a tap to release pressure in the pipe system.
4. Close the isolating valves and drain the pipes.
5. Gradually loosen the priming plug to release the pressure in the pump.
6. Remove the drain plug to drain the pump.
6. MAINTENANCE AND STORAGE
diameter
Seal pressure line and tighten
threaded connections

If equipment failure occurs in the normal course of service having been
competently installed and when operating within its specified duty limits warranty
will be provided as follows:-
Ÿ Up to 1 year - The item will be replaced or repaired at no charge.
ŸOver 1 year, less than two years - The item will be replaced or
repaired at a cost to the customer of 50% of the Davis & Shirtliff
market price.
The warranty on equipment supplied or installed by others is conditional upon the
defective unit being promptly returned free to a Davis & Shirtliff ofce and
collected thereafter when repaired. No element of site repair is included in the
warranty and any site attendance costs will be payable in full at standard
charegeout rates. Also proof of purchase including the purchase invoice must be
provided for a warranty claim to be considered.
12
7. TERMS OF WARRANTY
i) General Liability
ii) Standard Warranty
• In lieu of any warranty, condition or liability implied by law, the liability of Dayliff
(hereafter called the Distributor) in respect of any defect or failure of
equipment supplied is limited to making good by replacement or repair
(at the Distributor’s discretion) defects which under proper use appear therein
and arise solely from faulty design, materials or workmanship within a
specified period. This period commences immediately after the equipment
has been delivered to the customer and at its termination all liability
ceases. Also the warranty period will be assessed on the basis of the date
that the Distributor is informed of the failure.
ŸThis warranty applies solely to equipment supplied and no claim for
consequential damages, however arising, will be entertained. Also the
warranty specifically excludes defects caused by fair wear and tear, the effects
of careless handling, lack of maintenance, faulty installation, incompetence
on the part of the equipment user, Acts of God or any other cause beyond the
Distributors's reasonable control. Also, any repair or attempt at repair carried
out by any other party invalidates all warranties.

INS481A-03/21
