SKF H Series Instruction Manual

User and maintenance instructions
Model , series “H”
Air operated oil pump
Date of issue October 
Form number 
Version 

Contents
Declaration of Incorporation . . . . . . . . 
U.K. Declaration of Incorporation . . . . 
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 
Signal words for safety . . . . . . . . . . . . . . 
Specifications . . . . . . . . . . . . . . . . . . . . . 
To fill reservoir . . . . . . . . . . . . . . . . . . . 
To prime system . . . . . . . . . . . . . . . . . . . 
Supply lines. . . . . . . . . . . . . . . . . . . . . . . 
Feeder lines . . . . . . . . . . . . . . . . . . . . . . 
Injectors . . . . . . . . . . . . . . . . . . . . . . . . . 
Vent valve . . . . . . . . . . . . . . . . . . . . . . . . 
Safety unloader. . . . . . . . . . . . . . . . . . . . 
Service parts. . . . . . . . . . . . . . . . . . . . . . 
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . 
*Indicates change,


This Declaration of Incorporation is issued
under sole responsibility of the
manufacturer. Lincoln Industrial Corporation
hereby declares that the partly completed
machinery stated below:
Name: Oil pump
Model number(s):
Description:
Year of CE: 
in its intended use, is in conformity with the
relevant union harmonization legislation:
Machinery Directive //EC
(Article  Partly Completed Machinery)
 (series H)
Air-operated oil pump
//
Declaration of Incorporation* DOCUMENT NUMBER
403641.DoI
Manufacturer name/address:
Lincoln Industrial Corporation
 N. Hanley Road
St. Louis, MO  U.S.A.
TEL: + () - FAX: + () -
Authorized to compile the technical file:
SKF Lubrication Systems Germany GmbH
Heinrich-Hertz-Straße -
 Walldorf, Germany
TEL: + () -
EMAIL: [e-mail] WEBSITE: www.skf.com
and conforms to the following harmonized
standards:
EN ISO : 
Hydraulic fluid power - General rules and
safety requirements for systems and their
components
EN ISO : 
Safety of machinery. General principles for
design. Risk assessment and risk
reduction
EN ISO :
Pneumatic fluid power. General rules and
safety requirements for systems and their
components
EN ISO :+A:
Pumps and pump units for liquids -
Common safety requirements
EN :+A:
Liquid pumps. Safety requirements.
Procedure for hydrostatic testing
I, the undersigned of Lincoln Industrial Corporation, do hereby declare that the equipment specified above, in its intended use, conforms to
the requirements of the above EC Directive(s).
___________________________________
Robert Collins
Technical Compliance Manager
St. Louis, MO, U.S.A.
The following EHSR (Essential Health and
Safety Requirements) have been applied:
..a – ..b – ..c – .. – .. –
.. – .. – .. – .. – .. – ..
– .. – .. – .. – .. – . – .. –
... – .. – ..
The manufacturer maintains a technical file
summary sheet containing test reports and
product documentation:
Technical file summary sheet number:
The partly completed machinery shown
above should not be put into service until the
final machinery into which it is to be
incorporated has been declared in conformity
with the provisions of the directive, where
appropriate.
RA
*Indicates change,


U.K. Declaration of Incorporation* DOCUMENT NUMBER
UK403641CA
Manufacturer name/address:
Lincoln Industrial Corporation
 N. Hanley Road
St. Louis, MO  U.S.A.
TEL: + () - FAX: + () -
Authorized to compile the technical file:
SKF (U.K.) Limited
 Canada Close
Banbury, Oxfordshire, OX RT, GBR
EMAIL: [e-mail] WEBSITE: www.skf.com
This U.K. Declaration of Incorporation is
issued under sole responsibility of the
manufacturer. Lincoln Industrial Corporation
hereby declares that the partly completed
machinery stated below:
Name: Oil pump
Model number(s):
Description:
Year of CE: 
in its intended use, is in conformity with the
relevant union harmonization legislation:
Supply of Machinery (Safety) Regulations
 (S.I. :)
along with the following Directive(s) that
were also applied with the above legislation:
EN ISO : 
Hydraulic fluid power - General rules and
safety requirements for systems and their
components
EN ISO : 
Safety of machinery. General principles
for design. Risk assessment and risk
reduction
EN ISO :
Pneumatic fluid power. General rules and
safety requirements for systems and their
components
EN ISO :+A:
Pumps and pump units for liquids -
Common safety requirements
EN :+A:
Liquid pumps. Safety requirements.
Procedure for hydrostatic testing
I, the undersigned of Lincoln Industrial Corporation, hereby declare that the equipment specified above, in its intended use, conforms with the
Essential Health and Safety Requirements of U.K. legislation Supply of Machinery (Safety) Regulations  No.  Annex I, Declaration of
Incorporation by the time of placing it on the market.
___________________________________
Robert Collins
Technical Compliance Manager
St. Louis, MO, U.S.A.
The following EHSR (Essential Health and
Safety Requirements) have been applied:
..a – ..b – ..c – .. – .. –
.. – .. – .. – .. – .. – ..
– .. – .. – .. – .. – . – ..
– ... – .. – ..
The manufacturer maintains a technical file
summary sheet containing test reports and
product documentation:
Technical file summary sheet number:
The partly completed machinery shown
above should not be put into service until the
final machinery into which it is to be
incorporated has been declared in conformity
with the provisions of the directive, where
appropriate.
 (series H)
Air-operated oil pump
RA
// *Indicates change,


*Indicates change,
Safety*
The assembly must be installed, maintained
and repaired exclusively by persons familiar
with the instructions.
Always disconnect power source
(electricity, air or hydraulic) from the
equipment when it is not being used.
This equipment generates high pressure.
Extreme caution should be used when
operating this equipment as material leaks
from loose or ruptured components can
inject fluid through the skin and into the
body. If any fluid appears to penetrate the
skin, seek attention from a doctor
immediately. Do not treat injury as a simple
cut. Tell attending doctor exactly what type of
fluid was injected.
Any other use not in accordance with
instructions will result in loss of claim for
warranty or liability.
• Do not misuse, over-pressurize, modify
parts, use incompatible chemicals, fluids,
or use worn and/or damaged parts.
• Do not exceed the stated maximum
working pressure of the equipment or of
the lowest rated component in your
system.
• Always read and follow the manufacturer’s
recommendations regarding fluid
compatibility, and the use of protective
clothing and equipment.
• Failure to comply may result in personal
injury and/or damage to equipment.
CAUTION
Do not operate equipment without
wearing personal protective gear.
Wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing pro-
tection used for appropriate conditions
will reduce personal injuries.
Failure to comply may result in light
personal injury.
WARNING
Do not allow any body part
to be trapped by equipment.
Body parts can be crushed
by subassemblies during
operation.
Failure to comply may result in death
or serious physical injury.
WARNING
Do not allow fluid to leak
onto floor when operating
equipment. If spill occurs,
clean any fluid on floor before continuing
operation.
Failure to comply may result in death
or serious personal injury.
WARNING
Do not use this equipment to supply,
transport, or store hazardous
substances and mixtures in accordance
with annex I part - of the CLP
regulation (EG /) or HCS 
CFR . marked with GHS,
GHS and GHS hazard pictograms
shown:
Explanation of signal
words for safety
NOTE
Emphasizes useful hints and
recommendations as well as
information to prevent property damage
and ensure efficient trouble-free
operation.
CAUTION
Indicates a dangerous situation that can
lead to light personal injury if
precautionary measures are ignored.
WARNING
Indicates a dangerous situation that
could lead to death or serious injury if
precautionary measures are ignored.
DANGER
Indicates a dangerous situation that will
lead to death or serious injury if
precautionary measures are ignored.
WARNING
Do not operate equipment
without reading and fully
understanding safety
warnings and instructions.
Failure to follow warnings and
instructions may result in serious injury.


Specifications
Lubricant output (in (cm)) Reservoir Lubricant operating pressure
Ratio Per cycle Per min at  psi (, bar) capacity Air inlet Lubricant outlet Type of system Minimum Maximum Recommended
: .)  (,)  pints / in NPTF /in NPTF SL-  psi   psi  psi
( l) SL- (, bar) (, bar) (, bar)
SL-
SL-
Description
Model  oil pump is used as the
pumping unit for a centralized lubrication
system having a single line circuit of SL-,
SL-, SL- or SL- injectors.
It is an air operated reciprocating pump
that discharges an established amount of
lubricant (.in(, cm))) into the
circuit for each pump cycle.
This pump can be used with an air control
system, a time control and a pressure switch
supplied by the owner/operator.
WARNING
Do not operate unit with combustible
gas.
Failure to comply may result in
serious personal injury and/or damage
to the equipment.
) Based on lubricants that are free of entrapped air. Lubricants that are aerated will reduce output of pump.
NOTE
Pressure is set and controlled through
pressure switch.


14 / in
(362 mm)
16 / in
(413 mm)
23 / in
(591 mm)
2 / in
(63,5 mm)
1
2
345
6
7
8
9
10
11
12
1)
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
30 33 31
32
29
34
9 in
(228 mm)
14
14
14
12
Fig. 
) Restrictor  may be added between tee () and plug () to reduce pump noise.
Pump speed and output per minute will be reduced accordingly.


Operation
Lube cycle initiates when pump times out.
Air solenoid is energized to deliver air to
pump and vent valve. Pump dispenses
lubricant through injectors to bearings. Once
all bearings receive lubricant, pressure rises
in system to actuate pressure switch. When
pressure switch actuates, control is reset to
de-energize solenoid valve, cutting off air to
pump and vent valve. Pump stops, pressure
vents and pressure switch de-actuates.
Control begins timing toward next lube
event.
To prime system
Supply lines
Allow lubricant to bleed around vent plug to
expel air pockets trapped between pump
and supply line connection. Continue
operating pump until lubricant flows around
any plug.
Feeder lines
Fill each feed line with lubricant before
connecting lines to outlets of injectors and
bearings to prevent having to cycle each
injector.
Injectors
Check injectors for proper operation by
observing movement of indicator stems.
To fill reservoir
Lubricant reservoir is filled through
filler cap () at top of reservoir. Strainer ()
is located in filler cap. Strainer should be
removed from filler cap and cleaned
periodically.
To lubricate air valve
mechanism
Refer to Fig. IPB , page .
 Disconnect air to pump.
 Remove four cover screws (),
cover plate () and cover plate
gasket ().
 Remove and disassemble
air valve casting () from pump.
 Clean or flush air valve casting to remove
any chips, or other foreign particles prior
to reassembly.
 Pack cavity with grease before replacing
toggle assembly (). Use approximately
 /ounces ( ml) NLGI  light grade
water repellent grease.
 Replace cover gasket, cover and screws.
Tighten to avoid air leaks.
 Inspect parts at least once each year.
Vent valve
Vent valve () operates with compressed air
from same source that operates pump.
When pump is in operation, air pressure
keeps vent valve closed and lubricant is
directed through outlet to injectors. When air
to pump is shut off, vent valve opens and
supply line pressure vents back into
reservoir.
Safety unloader
Safety unloader () is provided at pump
outlet to prevent build-up of dangerously
high lubricant pressure in system. It is fac-
tory set to open at approximately
  psi to   psi ( to  bar).
WARNING
Safety unloader requires no adjustment
and should not be tampered with.
Failure to comply may result in death
or serious injury.


/ in NPTF
18
/ in NPTF
14
/ in NPTF
14
2)
7)
/ in NPTF
14
/ in NPTF
34
/ in NPTF
34
/ in NPTF
14
35
36
37 37
38
39
40
41
42
43
44
45
46
47 48
49 50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77 78
793)
80
81
82
835)
84
85
866)
87
88
896)
90
91
92 93
94 95
96
493)
48
52
41
50
514)
75
36
1)
49
37
8)
67
Fig. IPB 
) Torque  to  ft.lbf. (, to , Nm).
) Air exhaust port
) Torque  to  in.lbf. (, to , Nm).
) Torque  to  in.lbf. ( to  Nm).
) Assemble with Loctite # Blue
) Tighten to  to  ft.lbf. ( to  Nm).
) Vent valve ()
) Included in .


Service parts
Item Description Part number Quantity Item Description Part number Quantity
Lock washer    Screw  
 Hex head screw    Gasket (neoprene) ) 
 Plug button    Screw  
 Lock washer    Trip shoe )) 
 Nut    Trip rod )) 
 Cover    Gasket )) 
 Reservoir cap assembly    Gasket )) 
 Strainer    Packing (nitrile) )) 
 Reservoir (acrylic)    Trip rod packing nut )) 
 Tie rod    Bushing and plunger assembly  
 Base    O-ring (nitrile)  
 Adapter    O-ring (nitrile) )) 
 / external nipple    Pump check disc )) 
 Tee    Spring  
 Straight tube connector    Steel ball  
 Nylon tubing S   Check housing  
 Washer    Outlet body  
 Nut    Vent plug  
 Bracket    Gasket )) 
 Pipe plug    Outlet block  
 Gasket (nitrile)    Gasket  
 ° tube connector    Spring retainer  
 Nylon tubing    Spring  
 Safety unloader assembly )  Muffler cover  
 Valve body    Muffler  
 ° tube connector    Valve gasket (nitrile) )) 
 Vent valve    Valve slide, seat and gasket assembly )) 
 Closure plug    Valve guide plate )) 
 Cap screw    Spring  
 Washer    Steel ball ) 
 Support adapter    Valve seat bolt  
 Straight tube connector    Spring  
 Lock washer    Cover  
 Pump assembly    Toggle plate assembly )) 
 Tube gasket    Screw  
 Gasket    Base casting  
 Washer    Gasket ) 
 Packing (nitrile)    Packing nut  
 Air piston bolt    Washer  
 Gasket (nitrile coated fiber)    Packing (nitrile) ) 
 Trip sleeve ))   Packing cap  
 Air valve casting    Air cylinder  
 O-ring (nitrile) ))   Piston  
 Seat ))   Packing (nitrile) ) 
 Trip rod pin ))   Viton packing assembly  
 Valve cap gasket    Valve seat ) 
 Cap    Valve body  
 Trip rod collar ))   Needle ) 
) Recommended service parts inventory.
) Included in  repair kit.


Troubleshooting
Problem Cause Solution
Pump operates continuously. Pump has lost prime. Examine lubricant supply. Refill reservoir
if necessary.
Air pocket trapped in lubricant. Loosen vent plug one turn. Allow pump to
operate until trapped air is pumped out.
Close vent plug.
Pump continues to operate without discharging
lubricant.
Pump check () and steel ball ()
fouled.
Remove and clean checks and check seats.
Vent valve () fouled. Replace vent valve.
Foreign material prevents needle ()
from seating properly.
Clean or replace parts.
Pump fails to operate. Air system is leaking. Verify air supply is connected.
Verify air system is not leaking.
Injectors fail to cycle. Leak in supply line. Examine lines and connections.


skf.com | lincolnindustrial.com
® SKF and Lincoln are registered trademarks of the SKF Group.
© SKF Group 
The contents of this publication are the copyright of the publisher and may not be reproduced (even
extracts) unless prior written permission is granted. Every care has been taken to ensure the accuracy
of the information contained in this publication but no liability can be accepted for any loss or damage
whether direct, indirect or consequential arising out of the use of the information contained herein.
October  · Form  Version 
Warranty
The instructions do not contain any information on the warranty.
This can be found in the General Conditions of Sales, available at:
www.lincolnindustrial.com/technicalservice or www.skf.com/lubrication.
