DAYLIFF OSMOSIS Installation instructions

Installation & Operating ManualSMART REVERSE OSMOSISUNIT

SPECIFICATIONS
1.
1
3.
INSTALLATION 3 INDEX© Davis & Shirtliff Ltd 2020Contents herein are not warranted 4. OPERATION 6 5. MAINTENANCE 6 6. TROUBLE SHOOTING 8
2.
WARNINGS & SYMBOLS 2 7. TERMS OF WARRANTY 9

11. SPECIFICATIONSA five stage water treatment purifier suitable for treating water from clean municipal sources or borehole water for undersink installation that includes:• Output 1,800L/day, • Three stage sediment & carbon cartridge pre-treatment with easy to replace cartridges and LED replacement reminder.• Reverse osmosis purification using Hidrotek membranes with up to 50% recovery.• Post Carbon stage for water conditioning.• Supplied complete with 24VDC diaphragm pump• Compact tankless design for installation within minimal space.• Two outlet options – RO water and pre-treated water.• Operating Parameters: Chlorine level <0.2ppm, TDS<250ppm, Water 0Temperature 5-45 C.TECHNICAL SPECIFICATIONSFeed Water Quality: Municipal tap waterVoltage and Frequency: 100~240V, 50/60HzPowerInput:96WPurified Water Flow: 1.2L/MinCongratulations on selecting a Dayliff Smart Reverse Osmosis. They are manufactured to the highest standards and if installed and operated correctly will give many years of efcient and trouble free service. Careful reading of this Installation Manual is therefore important, though should there be any queries they should be referred to the equipment supplier.

2Feed Water Temperature: 5~45℃Feed-water TDS: ≤ 250ppmFeed-water Chlorine level: ≤ 0.2ppmRejection: 90~99%Feed-Water Pressure: 0.1~0.4 MpaWater Treatment Process Flow Diagram Technological ProcessFeed WaterT33 FilterRO FilterSpecial PumpDrain WaterSewer PipeGoose FaucetDC24V+DC24V-
IndicatorLight
MainControlPanelInlet Water Solenoid WaterRO WaterPP FilterGAC FilterCTO FilterPuried Water(Optional)DiagramFlush Water Solenoid WaterPumpLeakage DetectorLow Pressure SwitchHigh Pressure Switch

32. WARNINGS & SYMBOLSWash and replace cartridges regularly.WARNINGDo not disassemble parts randomly, it may cause leakage or damage.WARNINGDo not use power supply with disproportional rated voltage.WARNINGCAUTIONDo not store or explore in an environment of 0℃ or below.WARNINGHandle with care when discharging, moving and installing.WARNINGPlease turn off the feed water ball valve and cut off the source water to avoid the “water hammer phenomenon” which may lead to leakage or damage to housings and lters if go out in daytime or after the last use at night. WARNINGPlease cut off power and source water at once in case troubles occur and ask professional staff to repair.WARNINGPlease pull the power plug and cut off the feed water valve if long term storage. Professional staff are advised to replace cartridges.WARNINGIt is normal to hear vibration sound when system is producing water.WARNING

43. INSTALLATION Product and AccessoriesIncludes spun PP filter(PP), Granular carbon filter(GAC), block carbon filter(CTO), 2pcs x reverse osmosis membrane(RO), and post activated carbon filter(T-33). Water hammer is a pressure surge or wave caused when water in motion is forced to step or change direction suddenly.When resident in building close his valve suddenly, a pressure wave propagates in the pipeline of building.NOTEMain BodySix Filter Cartridges Includes faucet, 3-way ball valve, three pipes, instruction book, adapter and drain clamp.One Accessory BoxGooseFaucet3-wayBall Valve3 pipes(red, blue & white)Instruction BookAdapterDrain Clamp

5Functional Schematic DiagramRO water faucetPowerPuriedwater (optional)Leave at least 100mmspace at the back of products for bending pipesTap water faucetTap water pipe3-way ballvalveInlet water pipe(3/8" white pipe)RO water pipe(1/4" blue pipe)Drain water pipe(1/4" red pipe)Installation Ball Valve and Tee FittingsŸ Install Tee Fitting and 3-way ball Valve as per diagram.ŸWrap threads of 3-way ball Valve and Tee Fitting with Teflon tape.ŸConnect inlet water pipe (3/8” white) from unit to Feed Water Valve.ŸInstall 3-way ball valve to Tee fitting, and then connect to source water.

6Installation for Goose FaucetŸSelect a convenient location near your sink to place the faucet.ŸDrill a hole 12mm in diameter in counter top.ŸPlace washers, plates, seals and nuts in order as per diagram and tighten on to counter.ŸAttach RO Water pipe (1/4” blue) to the bottom of faucet and connect tubing to unitInstallation for Drain ClampŸ Place drain clamp on drain pipe above the drain trap and tighten securely.ŸUsing the drain clamp as a guide, drill a 6mm hole, enough for the 1/4” tubing to pass through one side of the drain pipe. DO NOT drill through both sides.ŸConnect Drain tubing (1/4” red) from unit to Drain ClampDrain TubingCompression NutInsertDrain ClampFront PlateM6x35 ScrewDrain PipeM6 NutDrain ClampBack Plate

7First Use Instruction1. Connect RO system with adapter, then the power indicator light is on, buzzer rings three times, machine flushes for 90 seconds and indicator light is flashing in blue slowly.2. RO system begins making water and indicator light is flashing in blue slowly, system is in standby mode and indicator light keeps in blue when water tank is full.3. Machine stops making water and indicator light keeps in red, buzzer rings 30 times after being working continuously for 6 hours or water leakage is detected.Cartridges Replacement and ReminderRecommended Replacement Period for Cartridges Cartridges Replacement Please cut off the water, turn off the power, open RO water faucet and discharge water in pipeline before replacing cartridges.

8 1. Push side board according to arrow direction2. Lift up cartridge 30°, rotate anticlockwise then remove it.3. Install new cartridge by rotating clockwise according to specifications, then fix the side board.

49 Please reset cartridges after replacementNOTE6. TROUBLE SHOOTINGPROBLEMPOSSIBLE CAUSESOLUTION Increase feed water pressure Insufficient feed water pressure No power or power failure Water pump is out of service andsystem does not work Power-onHigh pressure switch is out of orderPump is blocked and adapter fuse burn-outReplace adapter and repair water pump Replace high pressure switch Replace RO membrane RO membrane is blocked Water pump pressure loss Water pump works but system does not work Repair water pumpFlush solenoid valve is damaged Replace flush solenoid valveConstantly running water in downtimeInlet water solenoid valve damagedReplace inlet water solenoid valve Cannot stop working when pressure tank is full or repetitivestartingCheck valve is damagedHigh pressure switch is damagedRepair or replace high pressure switchReplace C heck v alve

666107. TERMS OF WARRANTYIf equipment failure occurs in the normal course of service having been competently installed and when operating within its specified duty limits warranty will be provided as follows:-Ÿ Up to 1 year - The item will be replaced or repaired at no charge.Ÿ Over 1 year, less than two years - The item will be replaced or repaired at a cost to the customer of 50% of the Davis & Shirtliff market price.The warranty on equipment supplied or installed by others is conditional upon the defective unit being promptly returned free to a Davis & Shirtliff ofce and collected thereafter when repaired. No element of site repair is included in the warranty and any site attendance costs will be payable in full at standard charegeout rates. Also proof of purchase including the purchase invoice must be provided for a warranty claim to be considered.ŸIn lieu of any warranty, condition or liability implied by law, the liability of Dayliff in respect of any defect or failure of equipment supplied is limited to making good by replacement or repair (at the Company’s discretion) defects which under proper use appear therein and arise solely from faulty design, materials or workmanship within a specified period. This period commences immediately after the equipment has been delivered to the customer and at its termination all liability ceases. Also the warranty period will be assessed on the basis of the date that the Company is informed of the failure.ŸThe warranty applies solely to equipment supplied and no claim for consequential damages, however arising, will be entertained. Also the warranty specifically excluded defects caused by fair wear and tear, the effects of careless handling, lack of maintenance, faulty installation, incompetence on part of the equipment user, Acts of God or any other cause beyond the Company’s reasonable control. Also, any repair or attempt at repair carried out by any other party invalidates all warranties.i) General Liability ii) Standard Warranty
