DCS RGSC-305 User manual

1
LP/NATURAL CONVERSION KIT INSTRUCTIONS
RGSC-305 PROFESSIONAL RANGE
CKL-RGSC305 Natural to LP
CKN-RGSC305 LP to Natural
Before you begin, read these instructions completely and carefully.
PARTS INCLUDED
Main Burner Orifice (5)
Simmer Burner Orifice (5)
Valve Bypass Jet (5)
Bake Burner Orifice (1)
Broil Burner Orifice (1)
Conversion Sticker (1)
Valve Stem C-Clip (5)
TOOLS NEEDED
1/8" Flat-blade Screwdriver
Adjustable Wrench
7mm Nut Driver
4mm Nut Driver (included)
Phillips Screwdriver
Ratchet with 1-1/16" Hex Deep Socket
25/32" Socket
1/2” Deep Socket
Manometer
CAUTION:
Before proceeding with the conversion, shut off gas supply to the appliance prior
to disconnecting the electrical power.
WARNING
This conversion kit must be installed by a qualified service agency in accordance with the
manufacturer’s instructions. All applicable codes and requirements of the authority
having jurisdiction must be followed. If the information in these instructions is not
followed exactly, fire, explosion or production of carbon monoxide may result, causing
property damage, personal injury or loss of life. The qualified service agency is
responsible for the proper installation of this kit. The installation is not proper and
complete until the operation of the converted appliance is checked as specified in the
manufacturer’s instructions supplied with the kit.
STEP 1
GAS SUPPLY
Measure the incoming gas pressure to the regulator.
With the installation of this conversion kit, the range should operate on LP gas at 10" of water column pressure
and on natural gas at 5" of water column pressure.
The pressure regulator must be connected in series with the manifold of the range and must remain in
series with the supply line.
When checking the regulator, the inlet pressure must be at least 1" greater than the regulator output
setting.
– If the regulator is set for 10" of water column pressure, the inlet pressure must be at least 11".
For proper operation, the maximum inlet pressure to the regulator must be no more than 14" of water column
pressure for LP gas and 9" water column pressure for natural gas.

2
IMPORTANT:
Disconnect the range and the individual shut-off valve from the gas supply piping system
during any pressure testing of that system at test pressures greater than 1/2 psig. Isolate
the range from the gas supply piping system by closing the individual manual shut-off
valve to the range during any pressure testing of the gas supply piping system at test
pressures equal to or less than 1/2 psig.
STEP 2
REPLACE COOKTOP BURNER ORIFICES AND VALVE BYPASS JETS
To replace cooktop burner orifices:
1. Remove the grates from the cooktop.
2. Remove burner caps and brass port rings (refer to diagram below).
3. Unscrew the brass nuts using a 1-1/16” socket or adjustable wrench and lift the simmer rings from the
burner bases.
4. Unscrew the brass venturis from the burner bases using a 25/32” socket.
5. Lift each burner base and disconnect the push-on wire
terminal from the spark electrode. Place the burner
base assembly in a safe place.
6. Remove the black porcelain plates under each burner
base to allow access to the orifice holders below the
cooktop panel.
7. Unscrew the orifices using an appropriately sized
conventional socket or nut driver. Use a piece of sticky
tape inside the socket to prevent the loose orifice from
falling out.
Verify that the orifice sizes in the kit match the chart sizes and
replace the burner orifices. Both the main and simmer orifices
must be changed. Do not reassemble the burners at this time.
Locator Pin
Electrode
Main Orifice
Burner Ring
Locking Nut
Burner Base
Burner Head
(Brass)
Burner Ring
(Aluminum)
Burner Cap
Simmer Orifice
NOTE: Gas conversion should be done before pushing the range into the cabinet.
NATURAL GAS
LOCATION MAIN LOW
SIZE MARKING RATE SIZE MARKING RATE
CENTER 1.85mm 185 17.5K Btu/hr 0.57mm P 3400 Btu/hr
OUTER 1.78mm 178 16.0K Btu/hr 0.57mm P 3400 Btu/hr
LP GAS
LOCATION MAIN LOW
SIZE MARKING RATE SIZE MARKING RATE
CENTER 1.10mm 110 15.0K Btu/hr 0.37mm G 2900 Btu/hr
OUTER 1.10mm 110 15.0K Btu/hr 0.37mm G 2900 Btu/hr
Connection: 1/2" N.P.T. - minimum 5/8" dia. metal flex line.
4mm
7mm

3
TO REPLACE THE VALVE BYPASS JETS:
1. Remove the control knobs from the valve shafts and thermostat.
2. Remove the four mounting screws from the corners of the valve panel.
3. Pull the panel forward over the valve stems.
4. Disconnect the wiring terminals at the light switch. Unsnap the indicator lights from the back of the valve
panel, being careful not to allow the lenses to fall from the face of the panel.
5. Remove the C-clips that retain the valve switches and slide the switches off of the valve shafts.
6. Locate the valve bypass jet in the valve body. Using a flat blade screwdriver, unscrew the bypass jets and
remove from valves.
Verify that the valve bypass jet sizes in the kit match the chart sizes and replace the valve bypass jets. Screw the
jet into the valve body until fully seated. Do not re-install the valve panel at this time.
STEP 3
CONVERT THE PRESSURE REGULATOR
WARNING
Do not remove the pressure regulator from the range.
To access the regulator, remove the kick panel, located below the range door. To convert the regulator from
Natural gas to LP gas or from LP gas to Natural gas, reverse the slotted plug in the regulator. See diagram.
VALVE ORIFICE (SIMMER)
LOCATION NAT LP
SIZE MARKING RATE SIZE MARKING RATE
ALL 0.57mm 57 1700 Btu/hr 0.37mm 37 1500 Btu/hr
Valve
Orifice
VALVE
BYPASS JET
VALVE
SWITCH
(REMOVE)
VALVE
BYPASS JET
NAT
LP
Reverse
Plastic Plunger
Cap Screw
NAT LP

4
STEP 5
CHECK FOR LEAKS
WARNING
Check for leaks before attempting to light the burners or use the oven.
Check to be sure all controls are in the OFF position.
Turn on the gas supply at the shut-off valve.
Use a leak detector at all connections. If a leak is detected, tighten the connection and test again.
DO NOT USE A FLAME TO CHECK FOR GAS LEAKS.
STEP 4
REPLACE THE OVEN BAKE AND BROILER BURNER ORIFICES
To replace the bake burner orifice:
1. Open and remove the oven door (refer to range installation instructions). Remove racks.
2. Remove the two screws that retain the convection inlet spout to the convection baffle and remove spout.
3. Pull the oven bottom panel forward and remove from the oven.
4. Remove the retaining screw from the left end of the bake burner. Slide burner to the left, off of orifice and
out of burner box.
5. Using the 1/2” deep socket, remove the bake burner orifice.
6. Verify that the orifice size in the kit matches the chart size and replace the burner orifice.
7. Reinstall the bake burner on the orifice and fasten to burner box with screw.
Do not reassemble oven bottom at this time.
To replace the broiler burner orifice:
1.Remove the four black screws that fasten the door latch access panel to the front frame. Pull panel forward.
2. Remove the broiler orifice/air shutter cover located on the right side of the recessed area where the door
latch is located. Note the location of the insulation strip under the edge of the cover.
3. Locate the orifice elbow on the end of the broiler burner venturi. The orifice is fastened to the far side of
the elbow. Using the appropriately sized wrench, remove the orifice from the elbow.
4. Verify that the orifice size in the kit matches the chart size and replace the burner orifice.
Do not re-assemble air shutter cover or access panel at this time.
OVEN BURNER ORIFICES
LOCATION NATURAL LP
SIZE MARKING RATE SIZE MARKING RATE
BAKE #40 DMS 40 28.0K Btu/hr #53 DMS 53 25.0K Btu/hr
BROILER #50 DMS 50 15.0K Btu/hr #56 DMS 56 15.0K Btu/hr

5
STEP 6
RE-ASSEMBLE SURFACE BURNERS, CHECK OPERATION
Cooktop Section
Re-assemble the burners and valve panel in the reverse order shown in Step 2 above. Make sure the brass port
rings are properly engaged in the simmer rings.
Check for proper ignition:
Connect electrical power.
Push in one control knob and turn 90° to “HI” position.
The igniter will spark and the burner will light; the igniter will cease sparking when the burner is lit. (Note
that all burners will spark.)
The first test may require some time while air is flushed out of the gas line.
Turn knob to “OFF”.
Repeat the procedure for each burner.
Check Flame Quality
Check for proper burner flame characteristics (see diagram).
Burner flames should be blue and stable. Some yellow tipping may be normal on LP Gas. The flame should not
have excessive noise or exhibit lifting of the flame from the burner. Due to differences in gas characteristics and
burner usage (i.e. gas pressure, cleanliness, etc.), burners may perform differently.
Burner Operation
Two flames are used on all five burners.These dual flame burners have an upper ring of main burner ports that
produce the main flame for high heat cooking from the “HI” knob setting to the “LO”knob setting.
The bottom simmer flame is used for simmer heat cooking operations such as melting chocolate, holding food at
serving temperature and simmering. Both flames are lit when the knob is between “HI”and “LO”.Only the simmer
flame is lit when the knob is in the “SIM” position.
Burner Adjustment
There is no air shutter adjustment, etc. on this burner.
The only adjustment available is to clean the burners and clean or replace orifices.
Main Burner Ports
Simmer Flame
Simmer Ring
Burner Cap
High to Low
Flame
Simmer Flame

6
STEP 8
COMPLETE AND ADHERE CONVERSION LABEL TO THE REAR OF THE RANGE
Complete the required information on the Conversion Label. Adhere the label to the rear of the range next to
Rating Label. The Conversion Label MUST reflect the change on fuel.
STEP 7
CHECK OVEN OPERATION, RE-ASSEMBLE OVEN
Bake Burner
Push the“BAKE”mode select button. Turn the oven control knob to set a temperature. The bake igniter will begin
to glow. In approximately 45 seconds, the burner will light.
Check Flame Quality
Burner flames should be blue and stable. Some yellow tipping may be normal on LP gas. The flame should not
have excessive noise or exhibit lifting of the flame from the burner. If air shutter adjustment is needed for proper
operation,turn the unit off and allow it to cool. Remove the bake burner and adjust burner air shutter as required.
Infrared Broiler Burner
Push the“BROIL” mode select button. Turn the oven control knob to “BROIL”.The broil igniter will begin to glow.
In approximately 45 seconds, the burner will light.
Check Flame Quality
Burner flames should be a “blanket” approximately 1/8” thick across the surface of the burner screen. The flames
will be blue in color, and as the burner continues to run, the screen will begin to glow red-orange.
Reinstall the oven bottom panel and convection spout in the reverse order shown in Step 4. Reinstall oven door.
Reinstall orifice/air shutter cover and door latch access panel in reverse order shown in Step 4. Ensure insulation
strip is properly located under the edge of the cover.

7
CONVERSION STICKER SAMPLES
A. From Natural Gas to LP B. From LP to Natural Gas
THIS CONVERSION RATING LABEL RELATES TO THE FOLLOWING
DCS MODELS:
RGSC305
SUPPLY PRESSURE - MINIMUM 11" W.C.
MAXIMUM 14" W.C.
MANIFOLD PRESSURE - 10" W.C.
INPUT RATINGS - FRONT & REAR BURNERS - 14,000 BTU/HR
CENTER BURNER - 14,000 BTU/HR
BAKE BURNER - 26,000 BTU/HR
BROIL BURNER - 15,000 BTU/HR
CONVERSION KIT PART. CKL-RGSC305
THIS APPLIANCE HAS BEEN CONVERTED ON
FROM NATURAL GAS TO LP GAS WITH CONVERSION KIT
PART NO. CKL-RGSC305
Name and address of qualified installer or service organization
WHO ACCEPTS RESPONSIBILTITY FOR THE CORRECTNESS OF THE
CONVERSION
THIS CONVERSION RATING LABEL RELATES TO THE FOLLOWING
DCS MODELS:
RGSC305
SUPPLY PRESSURE - MINIMUM 6" W.C.
MAXIMUM 9" W.C.
MANIFOLD PRESSURE - 5" W.C.
INPUT RATINGS - FRONT & REAR BURNERS - 16,000 BTU/HR
CENTER BURNER - 17,500 BTU/HR
BAKE BURNER - 28,000 BTU/HR
BROIL BURNER - 15,000 BTU/HR
CONVERSION KIT PART. CKN-RGSC305
THIS APPLIANCE HAS BEEN CONVERTED ON
FROM LP GAS TO NATURAL GAS WITH CONVERSION KIT
PART NO. CKN-RGSC305
Name and address of qualified installer or service organization
WHO ACCEPTS RESPONSIBILTITY FOR THE CORRECTNESS OF THE
CONVERSION

P/N 17618 Rev. B 03/03
5800 Skylab Road, Huntington Beach, CA 92647
Tel: [phone] Fax: [phone]
Customer Service: [phone]
www.dcsappliances.com
