Decor Star WPC05-TB User manual

1WPC05 Rev. B 04/2018Decor Star
Widespread Two Handles Lavatory Faucet
Model Number:
WPC05-TB
WPC05-TC
Features:
- Three Hole Installation
- Brass and Zinc Construction
- Drip Free 1/4 Turn Ceramic Cartridge
- Neoperl aerator
- Maximum ow rate 1.2 gpm at 60 psi
- Complies with:
EPA WaterSense
ANSI / ASME A112.18.1
IAPMO / UPC / cUPC
CA AB-1953
ADA
NSF 61-9
Max. Deck Thickness 1.75”
8” ~ 10”
6.125”
10”
2.375”
6.25”
2.56”2.56”
5” 3.75”
1” Hole Size 1.375” Hole Size 1/2” Connection
* Drawing not to scale. All Measurements are approximate*
Approx. 11” long

2WPC05 Rev. B 04/2018Decor Star
Thank you for purchasing Decor Star products. Please read the information below and keep this installation
guide for future reference. If you require assistance, please contact our customer service department at
1-800-879-1197, Monday - Friday 9AM - 5PM Paci c Time or by email at [email protected].
Limited Lifetime Warranty (For USA Only)
The manufacturer warrants this product to be leak and drip free during daily normal household use for as long
as it is owned by the original purchaser of this product. Please keep a copy of the original invoice as proof of
purchase.
Should a malfunction occur within the warranty period, Decor Star USA will, as its option, (1) repair or replace
the defective part(s) or product at no charge; (2) issue a refund of the purchase price paid for the product
(Valid within 30 days from the date of purchase); or (3) issue a credit to be applied against the purchase of a
new Decor Star product. Shipping/delivery charges may apply and are in Decor Star USA’s sole discretion.
This limited warranty shall not apply to goods which have been subject to accident, negligence, improper
installation, product abuse, product misuse, or use of cleaners containing abrasives, alcohol or other organic
solvents, whether performed by a contractor, service company, or yourself, are excluded from this warranty.
Our responsibility under this warranty is limited to only to replacement parts and no other costs. Decor Star
USA will not be responsible for labor charges and/or damage incurred by installation, repair or replacement,
nor for any indirect incidental or consequential damages, losses, injury or costs of any nature relating to this
faucet. Except as provided by law, this warranty is in lieu of and excludes all other warranties, conditions,
and guarantees, whether expressed or implied, statutory or otherwise, including without restriction those
merchantability of  tness for use.
This limited warranty is non-transferable. This limited warranty only applies to products purchased and
installed in the United States. This limited warranty covers the original consumer purchase only and does not
include business, commercial or industrial use of this product. To obtain service under the Limited Warranty,
please contact Decor Star USA at [email protected]. The Decor Star USA Customer Care Department
will determine whether to repair or replace your product, issue a refund, or issue a credit.

3WPC05 Rev. B 04/2018Decor Star
Important Points
• This installation guide is subject to change without notice, please contact us to request the most
updated version of this installation guide.
• This is a general installation guideline, actual installation may vary. Consult a professional installer
if necessary.
• Read and understand this instructions completely before installation.
• Please follow all local building and plumbing codes.
• Product drawings in this installation guide is for illustration purpose only. Actual product may vary
depends on model.
• Always take extra precautions and wear appropriate safety equipment when installing this
product.
• Wrap all threaded connections, except the aerator in the spout, with Te on (PTFE) tape. Always
wrap in a counterclockwise direction.
• When installing your new faucet,  rst hand tighten the water supply hoses then use a wrench to
give the compression nuts an additional (1/4) turn. Do not over tighten the compression nuts as it
will reduce the integrity of the sealed connection.
Maintenance Guide
Please follow the cleaning material manufacturer’s instructions. Damage caused by improper
treatment will not be covered by product warranty. In addition, pay attention to the following points:
• Regular cleaning can prevent mineral build up on faucet spout.
• Carefully read the cleaner product label to ensure the cleaner is safe for use on the material.
• Test the cleaner on a small area before using on the entire surface.
• Use a mild detergent such as liquid dishwashing soap and warm water for cleaning.
• Do not use abrasive / harsh chemical when cleaning the  xture as they will damage and dull the
 nish.
• When using spray cleaners, spray  rst onto a soft cloth or sponge. Never spray directly onto the
faucet as droplets can enter openings and gaps and cause damage.
• After cleaning, rinse thoroughly with clean water to remove any cleaner residue.
You may also need the following tools
1. Safety Glasses 5. Adjustable Wrench
2. Teon (PTFE) Tape 6. Screwdriver
3. Plumber’s Putty and Caulking
4. 1 3/8” Basin Wrench or
1 11/32” Shower Valve Socket Wrench

4WPC05 Rev. B 04/2018Decor Star
Installation
A. Shut o water supply at the valves.
Remove old faucet and clean the
mounting surface for installation of new
faucet.
D. Apply Teon (TPFE) tape on the
thread of the center spout brass pipe.
Use an adjustable wrench to tighten the
ttings. (NOTE: Do not overtighten the
connection.)
F. Insert hot and cold valves from under-
neath the mounting surface. Secure the
handle assemblies with the decorative
trims from top of the mounting surface.
E. Use a small hex wrench to loosen the
small setscrew on the handle. Lift up the
decorative trim handle and remove all
trim pieces.
G. Apply Teon (TPFE) plumbing tape
on both valve assemblies and shuto
valves. Attach water supply hoses with
1/2” ttings (not included) with an ad-
justable wrench. Also connect the water
hose between the handle assemblies
and the center spout. (NOTE: Do not
overtighten the connection.)
H. Use the aerator wrench to remove
the aerator. Turn on both hot and cold
handles and let the water run for about
1 minute to ush out any sediment or
debris inside the plumbing. Also check
for leaks at all connections.
I. Re-install the aerator once all con-
nections are checked. Keep the aerator
wrench for future use. The installation is
complete at this time.
B. Place spout with ange through the
center mounting hole on the mounting
surface.
C. Insert the C shaped rubber / metal
washer and locking nut on the center
spout. Use an adjustable wrench to se-
cure spout in place. (NOTE: Do not over
tighten the locking nut.)
ABC
DF
Hot
Cold
GH
E
I

5WPC05 Rev. B 04/2018Decor Star
02
03
04
12
11
05
06
07
08
09
10
01
13
14
15
16
17
18
19
20
21
22
24
25
23
26
01. Faucet Body
02. Aerator (52007211PL)
03. O-ring
04. Spout Decorative Trim
05. O-ring
06. C Shaped Rubber Washer
07. C shaped Metal Washer
08. Brass Pipe
09. Flow Valve (5d0005400PL0)
10. Locking Nut
11. Connecting Hose (52009319NC7)
12. Complete Handle Assembly
13. Setscrew (5T0F0149NT)
14. Handle
15. O-ring
16. Decorative Trim with Threads
17. Rubber Gasket
Parts
18. Decorative Base Plate
19. O-ring
20. Plastic Spacer
21. Screw
22. Cartridge (HOT 5Y01033NT7)
Cartridge (COLD 5Y01034NT7)
23. Rubber Washer
24. Metal Washer
25. Mounting Nut and Screws
26. Valve Body
