DEELAT D1173519 User manual

User Manual
DEELAT ® Solar Powered Outdoor LED
Landscape Light - 5000 Lumens |D1173519
SOLAR POWERED OUTDOOR LED LANDSCAPE LIGHT
- 1 -
1. Solar panel: 50W
2. Li-ion battery: 461.76WH
3. LED: 5000 Lumens (60W)
4. Charge time in bright sunlight for full charge: Approximately 9 -10 hours.
5. Automatically turns on when it becomes dark. IR Sensor detects dim light.
6. Lighting time: Approximately 3 nights.
7. 1 Year Warranty
8. Install height: 20ft (6M)
9. Size: 36”x 9” (935 x 234 mm) *Diameter x Height
The internal battery is locked from
operation during shipment for safe
transport. Use the supplied key pin
to unlock the battery by moving
into the “on” position. To prepare for
transport, move to “off” position.
Use the supplied screws to attach
to your desired pole. Tighten until
secure.
— Solar Panel
— LED Light
— Pole Connection
— Switch



Characteristics
How to switch from Lock Mode to Operational Mode
Easy Install

User Manual
DEELAT ® Solar Powered Outdoor LED
Landscape Light - 5000 Lumens |D1173519
SOLAR POWERED OUTDOOR LED LANDSCAPE LIGHT
- 2 -
Function
During daylight hours, the
light is in charging mode.
It will not turn on when there
is sufcient sunlight present.
Use the remote control to select your desired function:
Constant Brightness Mode: select the desired level of brightness (10%,
30%, 60% or 100%).
Timer Mode: Select the number of hours
When selecting PIR security modes below, the light will remain in the
desired lower running brightness and only increase to full brightness if mo-
tion is detected within 26 feet (8M). It will remain in Full brightness for 30
seconds and if no motion is detected it will return to the lower brightness.
PIR security M1: 50% brightness for the rst 5 hours + 10% for the
remaining 7 hours.
PIR security M2: 40% brightness for the rst 5 hours + 10% brightness for
next 5 hours + 40% brightness for the next 2 hours.
*The default mode is constant brightness at 10% throughout the night.

User Manual
DEELAT ® Solar Powered Outdoor LED
Landscape Light - 5000 Lumens |D1173519
SOLAR POWERED OUTDOOR LED LANDSCAPE LIGHT
- 3 -
Remove the battery cover on the backside of the remote to expose the
timer switch to select between 1-4 hours and 5 -6 hours as indicated in the
image below.
1. Keep device away from re and oil to avoid explosion.
2. Severe shock to Solar powered light is to be avoided.
3. Do not dissemble the light without assistance from an expert/professional.
Remote Control
Warning
— Infrared transmitter
— On key
— Lighting mode: M1/M2
— Off key
— Brightness key
— Timer key
— Indicator light







