Deep Sea Electronics Plc DSE9 Series User manual

Typical Wiring Diagrams
053-049
ISSUE 13
DSE9xxx Battery Charger Installation Instructions
D E E P S E A E L E C T R O N I C S
DANGER F DEATH : LIVE PARTS exist within the DSE9xxx enclosures. The enclosure
cover must not
be removed.
Installation
The DSE9xxx battery char ers are desi ned to be mounted within a control panel, on the panel DIN rail utilisin the inte ral mounts
or on a chassis utilisin the mountin holes. For dimension and mountin details, see overleaf.
The DSE9xxx battery char ers are fit-and-forget. It can be permanently connected to the supply and the load, with no requirement to
disable the char er durin times of heavy load (such as en ine crankin ) or when in parallel with a char in alternator.
Battery suitability
The char er is factory set by DSE to suit Lead Acid batteries. The DSE91xx & DSE92xx battery char ers can be adjusted at the time
of orderin to suit other battery types. The DSE947x MKII & DSE948x MKII battery char ers are confi ured usin the DSE
Confi uraiton Suite to suit other battery types.
Care should be taken to ensure the batteries connected to the char er are of the correct ‘technolo y’ to suit the settin of the
char er.
Indications
The DSE9xxx Battery Char ers feature an LED indicator(s) to show the battery char er Status.
(Refer to DSE publication: 057-085 DSE9xxx Series Operator Manual for further information)
Boost Mode
(Not applicable to DSE9150 12V 2A or DSE9155 30V 2A)
(DSE947x & DSE948x MKII Series Only. Boost feature is controlled automatically, no external connection needed.)
Boost mode is operated by connectin the BOOST terminals to ether (for instance with an external switch or timer circuit. This will
raise the battery char er floatin volta e by 0.8V DC.
Caution:- Boost mode is intended for equalisation of cells in lead acid batteries.
Dimensions and Mounting
DSE9150 12V 3A
Overall size 108mm x 101mm x 49mm
(4.25” x 3.98” x 1.91”)
Wei ht 0.16k
Mountin type DIN rail or chassis mountin
Din rail type EN 50022 35mm type only
Mountin holes Suitable for M4
Mountin hole centres 91mm x 89mm
(4.25” x 3.51”)
Input volta e (nominal) 110V-240V
Input volta e (absolute
ran e)
90V-250V
Char e failure relay
ratin
3A DC resistive, 30V maximum
Operatin Temperature
-30
°
C to 55
°
C
(-22°F to 131°F)
Dimensions in mm unless stated
Connection type Screw terminal, risin clamp, no
internal sprin
Min cable size 0.5mm² (AWG 20)
Max cable size 2.5mm² (AWG 14)
Recommended AC fuse
230V AC Input
110V AC Input
DSE9130 12V 5A char er
DSE9140 12V 10A char er
DSE9150 12V 3A char er
DSE9155 30V 2A char er
DSE9250 24V 3.7A char er
DSE9255 24V 5A char er
DSE9260 24V 10A char er
DSE9470 MKII 24V 10A char er
DSE9472 MKII 24V 5A char er
DSE9480 MKII 12V 10A char er
DSE9481 MKII 12V 5A char er
1.0A anti-sur e
2.0A anti-sur e
1.0A anti-sur e
1.0A anti-sur e
1.0A anti-sur e
2.0A anti-sur e
3.5A anti-sur e
3.5A anti-sur e
2.0A antisur e
2.0A anti-sur e
1.0A antisur e
2.0A anti-sur e
3.5A anti-sur e
1.5A anti-sur e
2.5A anti-sur e
2.5A anti-sur e
3.5A anti-sur e
6.3A anti-sur e
6.3A anti-sur e
3.5A anti-sur e
3.5A anti-sur e
2.5A anti-sur e
Boost not available on
DSE9150 12V 3A
DSE9155 30V 2A
CF not available on
DSE9150 12V 2A
DSE 947x & 948x MKII Battery Char ers
DSE 91xx & 92xx Series
Battery Char ers

N TE : DSE9000 series chargers are designed to be mounted with the base to a vertical surface with
the terminal strips at the bottom.
N TE : This document is intended as a ‘quick start’ guide only. For full operating instructions and
specifications, refer to DSE publication: 057-085 DSE9xxx Series perator Manual
Dimensions and Mounting
DSE9130 12V 5A DSE9250 24V 3.7A *
DSE9155 30V 2A DSE9255 24V 5A
* This model is no lon er available
Overall size 136mm x 140mm x 63mm
(5.37” x 5.53” x 2.5”)
Wei ht 0.5k
Mountin type DIN rail or chassis mountin
Din rail type EN 50022 35mm type only
Mountin holes Suitable for M4
Mountin hole
centres
119.36mm x 128.36mm
(4.7” x 5.05”)
Input volta e
(nominal)
DSE9250-001 24V 3.7A
DSE9250-002 24V 3.7A
DSE9130 12V 5A
DSE9255 24V 5A
110V-240V
110V-277V
110V-277V
110V-277V
Input volta e
(absolute ran e)
DSE9250-001 24V 3.7A
DSE9250-002 24V 3.7A
DSE9130 12V 5A
DSE9255 24V 5A
90V-265V
90V-305V
90V-305V
90V-305V
Char e failure
relay ratin
3A DC resistive, 30V maximum
Operatin
Temperature
-30
°
C to 55
°
C
(-22°F to 131°F)
Dimensions in mm unless stated
Dimensions and Mounting
DSE9140 12V 10A
DSE9260 24V 10A
Overall size 152mm x 188mm x 62mm
(6” x 7.4”x 2.44”)
Wei ht
DSE9140 12V 10A
DSE9260 24V 10A
0.75k
0.85k
Mountin type DIN rail or chassis mountin
Din rail type EN 50022 35mm type only
Mountin holes Suitable for M4
Mountin hole centres 142mm x 128mm
(5.59” x 5.0”)
Input volta e (nominal) 110V-277V
Input volta e
(absolute ran e)
90V-305V
Char e failure relay ratin 3A DC resistive 30V Maximum
Operatin Temperature -30
°
C to 55
°
C
(-22°F to 131°F)
Dimensions in mm unless stated
Deep Sea Electronics Plc.
Tel:[phone]
Fax: [phone]
Email: s[email protected]om
Web: www.deepseaplc.com
Deep Sea Electronics Inc.
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.deepseausa.com
Dimensions and Mounting
Intelligent Battery Chargers
DSE9481 MKII 12V 5A
DSE9472 MKII 24V 5A
DSE9480 MKII 12V 10A
DSE9470 MKII 24V 10A
Overall size 205mm x 135mm x 80mm
(8.1” x 5.3” x 3.1”)
Wei ht
DSE9470 MKII
DSE9472/80/81 MKII
0.78k
0.7k
Mountin type DIN rail or chassis mountin
Din rail type EN 50022 35mm type only
Mountin holes Suitable for M4
Mountin hole centres 190mm x 120mm
(7.5” x 4.7”)
Input volta e (nominal) 110V-277V
Input volta e
(absolute ran e)
95V-305V
Char e failure relay ratin 3A DC resistive
30V maximum
Operatin Temperature -30
°
C to 85
°
C with de-ratin
(-22°F to 185°F)
Optional Temperature
Sensor
NTC connections for PT1000
sensor only
Communications RS485
PC connection (USB) To enable PC Confi uration
Dimensions in mm unless stated
6in
2.44in
7.4 in
