DeepSea Power & Light LED SeaLite LSL-1000 User manual

DEEPSEA
POWER & LIGHT
®
Operator’s Manual
T: 858-576-1261
F: 858-576-0219
4033 Rufn Road
San Diego, CA
92123- 1817 USA
www.deepsea.com
[email protected]
Original Instruction
®
PRELIMINARY
LED Sealite®
1000, 2000
REV 02/13/17

Specification Overview
* Specications subject to change without notice.
2
Operator’s Manual
LED SeaLite®
PRELIMINARY
LSL-1000 LSL-2000
Optical Specications
Typical Lumen Output
(Flood) 9,000
Efcacy 56 lm/w185 lm/w1
Lux
Wide2: 2,300 lx
Flood: 5,600 lx
Spot: 14,000 lx
Dual Beam: 9,400 lx
Color
Day Light White 5000 K ~ 6500 K
Warm White 2600 K ~ 3700 K
Selectable Dual Colors
Contact Sales for Color Options
CRI Day Light White: 70
Warm White: 80
Beam Angle (HPFW)
Wide2: 115°
Flood: 75°
Spot: 35°
Dual Beam: 45° ~ 75°
Environmental Specications
Depth Rating 6,000 m or 11,000 m Sapphire Port
3,000 m Acrylic Port
Thermal Protection Intelligent Thermal Rollback
Operational Temperature -10°C ~ 40°C [14°F ~ 104°F]3
Storage Temperature -40°C ~ 100°C [-40°F ~ 212°F]
Electrical Specications
Voltage 90~140 VAC 50/60 Hz
110~160 VDC 10~48 VDC1
Power 160W @ 120 VAC 60 Hz 106W @ 24 VDC
Dimming RS2324, RS4854, Phase/Triac RS2324, RS4854, 0~5V, 0~10V,
4~20mA
Mechanical Specications
Housing Hard Anodized 6013 Aluminum
Titanium
Port Standard: Sapphire
Optional: Acrylic
Outer Diameter 63.0 mm [2.48 in]
Overall Length
(Without Connector)
Flood: 88.5 mm [3.48]
Spot: 94.9 mm [3.73 in]
Weight in Air5Flood: 490 g
Spot: 510 g
Flood: 450 g
Spot: 470 g
Weight in Water5Flood: 240 g
Spot: 260 g
Flood: 200 g
Spot: 220 g
Connector6
Default SEACON MCBHMP
Please contact sales for more options.
1100% output available above 20 VDC. 50% output from 10~20 VDC due to input current limits.
2Wide beam angle only available on Acrylic port 3,000 m depth rating.
3For 120 VAC versions, thermal rollback may reduce light output in water temperatures
exceeding 25° C [77° F]. See Manual for additional information.
4For RS232 and RS485, see Manual.
5Nominal values are measured with MCBHMP connector, aluminum housing, and sapphire port
conguration.
6Ensure that ampacity ratings for interconnect system are suitable for your operating conditions.
See Manual for more information.

Specification Overview
* Specications subject to change without notice.3
LED SeaLite®
Operator’s Manual
Extended Endcap Option
1.69
42.9
1.00
25.4
1.59
40.3
1.00
25.4
4x 1/4"-20
OR
4x M6x1
3.73
94.9
5.01
127.3
2.48
63.0
3.10
78.7
1.60
40.6
1.59
40.3
SPOT
2.48
63.0
3.10
78.7
3.48
88.5
4.76
120.9
1.59
40.3
1.35
34.2
FLOOD
mm [inch]
Standard Endcap
Bracket
4.32
109.7
5.59
142.1
2.48
63.0
3.10
78.7
1.60
40.6
1.59
40.3
SPOT
2.48
63.0
3.10
78.7
4.07
103.3
5.34
135.7
1.59
40.3
1.35
34.2
FLOOD
mm [inch]
PRELIMINARY

LED SeaLite®Operator’s Manual
4
Table of Contents
Specification Overview ...............................................................................................................2-3
Table of Contents............................................................................................................................ 4
General Notes & Warnings............................................................................................................. 5
Pre & Post Dive Inspection ............................................................................................................ 5
Troubleshooting.............................................................................................................................. 6
RMA Procedure for Repair............................................................................................................. 6
Limited Warranty............................................................................................................................. 6
Appendix A LSL-1000 Driver Characteristics ............................................................................... 7-8
Appendix B LSL-2000 Driver Characteristics ............................................................................. 9-10
Appendix C Dimming Curve......................................................................................................11-13
Appendix D Beam Patterns ........................................................................................................... 14
Appendix E SeaSense™Information ............................................................................................. 15
PRELIMINARY

LED SeaLite®
Operator’s Manual
5
Safety Symbols
In this operator’s manual and on the product, safety symbols are used to communicate important
safety information. This section is provided to improve understanding of these symbols.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to
avoid possible injury or death.
DANGER indicates a hazardous situation which, if not avoided, could result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could result in damage to the product or bodily harm.
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE indicates information that relates to the protection of property.
This symbol means read the operator’s manual carefully before using the equipment. The operator’s manual contains important information
on the safe and proper operation of the equipment.
This symbol means always wear safety glasses with side shields or goggles when handling or using this equipment to reduce the risk of
eye injury.
This symbol indicates the risk of electrical shock.
DANGER
!
WARNING
CAUTION
NOTICE
This symbol indicates a risk of exposure to high brightness.
UV and blue light can cause eye injury. Avoid exposure to eyes.
This symbol indicates high voltage.
This symbol indicates a potentially hot surface that may cause burns or ignition.
PRELIMINARY
General Notes & Warnings
The LED SeaLite®light is designed and built for years of
reliable service.
This light was thoroughly pressure tested prior to leaving
the factory to confirm the integrity of the complete
assembly. While there should be no reason to repair the
LED SeaLite, this light is designed to be completely field
serviceable. No soldered wire connections or specialized
tools are required. All o-rings use viton material and
have an extended shelf life.
The LED SeaLite can run at full power in air. This light
is equipped with thermal sensing circuitry which will
automatically roll back the light output and prevent it
from overheating. The light will return to full brightness
once it is submerged and allowed to cool.
WARNING
Modifying the light in any way may damage the light and
void the warranty.
Do not clean any part of the light with solvent or alcohol.
Soapy water is recommended.
Reconfiguring the pin-out of the light is potentially
dangerous to the operator and can cause significant
damage to the light. Any change to the pin-out should
be done only through consultation with the factory in
order to provide proper documentation and new pin-
out labeling. Failure to do so will result in the loss of
warranty coverage for the light.
DANGER
When the LED SeaLite is operated in air, the light may
reach temperatures in excess of 65° C (150° F). These
temperatures may cause burns if the light is handled
without personal protective equipment.
While operating in air, this light emits sufficient photonic
energy to ignite combustible materials. When light is
operating in air, take appropriate precautions.
Do not operate any high voltage electrical equipment in
or around water without using proper safety equipment
such as a Ground Fault Circuit Interrupter (GFCI) and an
isolation transformer, especially when divers are in the
water.

LED SeaLite®Operator’s Manual
6
All shipments should be sent to the address below:
DeepSea Power & Light
Attn: RMA ####
4033 Ruffin Road
San Diego, CA 92123-1817
U.S.A
Tel: [phone]
Fax: [phone]
Email: [email protected]
Limited Warranty
Seller warrants that the goods (except internal electronic
components) sold under this contract will be free from
defect in material and workmanship for a period of two
years from the date of shipment from the factory, if they
have been properly used. Internal electronic components
are warranted for 90 days from the date of shipment
from the factory, if they have been properly used. This
warranty will be limited to the repair or replacement of
parts and the necessary labor and services required
to repair the goods. IT IS EXPRESSLY AGREED
THAT THIS WARRANTY WILL BE IN LIEU OF ALL
WARRANTIES OF FITNESS AND IN LIEU OF THE
WARRANTY OF MERCHANTABILITY. This warranty
is the exclusive and only warranty to pass with the
goods under this contract. No agent, employee, or
representative of the Seller has any authority to bind
Seller to any information, representation, or warranty
concerning the goods sold under this contract, and
unless an affirmation, representation, or warranty
made by an agent, employee, or representative is
specifically included within this contract, it will not be
enforceable by Buyer. If notice of defect is given to
DeepSea Power & Light, Inc. within such 90 day or two-
year warranty period, the sole obligation of DeepSea
Power & Light, Inc. shall be to furnish new or repaired
parts free of charge in exchange for parts which have
been proved defective and does not include any other
costs such as the cost of removal of the defective part,
installation, labor, or consequential damages of any
kind, the exclusive remedy being to require DeepSea
Power & Light, Inc. to furnish such new parts. Under
no circumstances shall the Buyer be entitled to recover
any incidental damages as that term is defined in
Commercial Code §2715.
Pre & Post Dive Inspection
Check to make sure that the rear bulkhead connector,
mating connector, and all mounting hardware are secure
before deployment.
Check the following areas for previous damage, wear,
or corrosion: rear bulkhead connector, power cable, and
front port.
Rinse the LED SeaLite in fresh water after use.
After each deployment, carefully check to make sure the
light is operational and has not flooded. If it has flooded,
the light can become internally pressurized upon
surfacing and create a potential danger. Additionally,
if the power remains on when the light has partially
flooded, it is possible for electrolytic generation of an
explosive mixture of hydrogen and oxygen gases. Point
the light away from persons and valuable equipment and
make sure that the power is disconnected.
Troubleshooting
If the light stops working while underwater, assume that
it has flooded.
If it has been determined that the light is not flooded,
and if the light does not turn on during pre-deployment
checks, check the input power cable/inline connector to
make sure that correct voltage is being supplied and that
the correct pin-out is being used. If the light still does
not work, return it to DSPL using the RMA Procedure for
Repair below.
RMA Procedure for Repair
For warranty and non-warranty repairs, please contact
DeepSea Power & Light for an RMA number prior to
returning the item. Please have the light model number,
serial number, and any other pertinent information along
with a description of the problem on hand when calling,
or include them in a fax or e-mail.
When shipping the item, be sure that the freight is pre-
paid (CODs will not be accepted) and that the RMA
number is clearly printed on the outside of the box.
www.deepsea.com
[email protected]
T: 800-487-3775
F: 858-576-0219
PRELIMINARY

LED SeaLite®
Operator’s Manual
7
Appendix A
LSL-1000 Driver Characteristics
100
110
120
130
140
150
160
170
180
190
200
80 100 120 140 160 180 200
Input Power, W-rms
Input Voltage, V-rms
LSL-1000: Real Power vs. RMS Input Voltage
AC DC
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
80 100 120 140 160 180 200 220
Input Current, A-rms
Input Voltage, V-rms
LSL-1000: Peak RMS Current vs. RMS Input Voltage
AC DC
PRELIMINARY

LED SeaLite®Operator’s Manual
8
0.78
0.80
0.82
0.84
0.86
0.88
0.90
0.92
0.94
80 90 100 110 120 130 140 150 160
Power Factor
Input Voltage, VAC
LSL-1000: Power Factor vs. RMS Input Voltage
0%
50%
100%
0%
50%
100%
0%
50%
100%
-10°C -5°C 0°C 5°C 10°C 15°C 20°C 25°C 30°C 35°C 40°C
Light Output, %
Ambient Water Temperature
LSL-1000: Thermal Operating Limits
90VAC 120VAC 140VAC
PRELIMINARY

LED SeaLite®
Operator’s Manual
9
Appendix B
LSL-2000 Driver Characteristics
100%
50%
0%
50
60
70
80
90
100
110
120
10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48
Light Output Input Power, W
Input Voltage, VDC
LSL-2000: Input Power vs. DC Input Voltage
Low Input Range High Input Range
Low Output Range High Output Range
100%
50%
0%
0
1
2
3
4
5
6
7
10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48
Light Output Input Current, A
Input Voltage, VDC
LSL-2000: Input Current vs. DC Input Voltage
Low Input Range High Input Range
Low Output Range High Output Range
PRELIMINARY

LED SeaLite®Operator’s Manual
10
0%
50%
100%
0%
50%
100%
0%
50%
100%
-10°C -5°C 0°C 5°C 10°C 15°C 20°C 25°C 30°C 35°C 40°C
Light Output, %
Ambient Water Temperature
LSL-2000: Thermal Operating Limits
10VDC 20VDC 48VDC
PRELIMINARY

LED SeaLite®
Operator’s Manual
11
Appendix C
Dimming Curve
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
Light Output, %
LOUT Command Value
SeaSense™ Serial Dimming Curve
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
0°
10° 20° 30° 40° 50° 60° 70° 80° 90°
100° 110° 120° 130° 140° 150° 160° 170° 180°
Light Output, %
Phase Angle
LSL-1000 TRIAC Phase Dimming Curve
PRELIMINARY

LED SeaLite®Operator’s Manual
12
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
0.0V 0.5V 1.0V 1.5V 2.0V 2.5V 3.0V 3.5V 4.0V 4.5V 5.0V
Light Output, %
Dimming Voltage, V
LSL-2000 0~5V Analog Dimming Curve
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
0V 1V 2V 3V 4V 5V 6V 7V 8V 9V 10V
Light Output, %
Dimming Voltage, V
LSL-2000 0~10V Analog Dimming Curve
PRELIMINARY

LED SeaLite®
Operator’s Manual
13
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
0mA 2mA 4mA 6mA 8mA 10mA 12mA 14mA 16mA 18mA 20mA
Light Output, %
Dimming Control Current, mA
LSL-2000 4~20mA Analog Dimming Curve
PRELIMINARY

LED SeaLite®Operator’s Manual
14
Appendix D
Beam Patterns
Peak Lux: Peak Lux:
FWHP Angle: FWHP Angle:76
14400
34
LED SeaLite Daylight White Spot
LSL-1000-6KA-DW-035-PV-SUBMC3
LED SeaLite Daylight White Flood
LSL-1000-6KA-DW-075-PV-SUBMC3
5680
0.0%
10.0%
20.0%
30.0%
40.0%
50.0%
60.0%
70.0%
80.0%
90.0%
100.0%
-90 -85 -80 -75 -70
-65
-60
-55
-50
-45
-40
-35
-30
-25
-20
-15
-10
-5
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
Radial Lux Distribution Comparison
-90.0°
-80.0°
-70.0°
-60.0°
-50.0°
-40.0°
-30.0°
-20.0°
-10.0°
0.0°
10.0°
20.0°
30.0°
40.0°
50.0°
60.0°
70.0°
80.0°
90.0°
0% 25% 50% 75% 100%
Degrees
% Output
Angular Distribution
PRELIMINARY

LED SeaLite®
Operator’s Manual
15
Appendix E
SeaSense™Information
The DSPL SeaSense serial protocol is used to control enabled products in real-time over standard EIA-485
(RS-485) and EIA-232 (RS-232) industrial serial communications interfaces.
While the physical topology of these serial interfaces can differ signicantly, this protocol is designed to
operate equally well in each environment. The SeaSense protocol uses ASCII character commands, making
them human readable. Strict command string formatting and an optional check-sum eld offer robust, error-
tolerant communications in harsh environments and mixed-protocol network installations. DeepSea strongly
recommends host-side electrical isolation to the physical serial interfaces wherever serial interfaces are used
in subsea environments to limit risks to the host platform as dangerous voltages may be present in the LED
SeaLite.
The SeaSense protocol allows for an unparalleled exibility in the use and operation of the LED SeaLite. Using
the protocol, operators and system integrators can:
• Control the light output level and remap the dimming curve to t application requirements.
• Monitor system parameters and diagnostic information such as total run time, internal temperature, and
number of power cycles.
• Congure the serial interface by setting baud rates, device addresses, switching between EIA-232 or EIA-
485 serial interfaces, and enabling a termination resistor for EIA-485 operation.
• Control power usage by putting the device into a low power standby mode or limiting the maximum light
output level.
• Quickly switch between sixteen user preset states for light output and standby mode and congure the
power-on state to one of these user presets.
• Operate multiple units over a single serial interface and use group addresses (up to 32 per device) or send
global address to efciently control more than one device with a single command.
PRELIMINARY
