Defi DF06501?DF06506, DF06601?DF06606, DF06701?DF06706, DF06801?DF06806,DF07004?DF07006, DF11501?DF11506,... Assembly instructions

Before handling (for installation personnel)
Propertiesforsafetywarning
Indicates attention needs to be paid. (Including warnings)
Indicates restricted actions. (PROHIBITED actions)
Indicates actions that need to be carried out. (MUST actions)
Prohibited
Must
Thank you very much for purchasing our product.
This product is an additional product for providing information to automobile users about engine conditions
and other important factors. Before installing and using the product, please read this manual and the
warranty card thoroughly. All sections are for customers and installation personnels. After installation,
please keep this manual and the warranty card for future reference. In the event that this product (or the
vehicle in which it is installed) is lent to or transferred to another person, please be sure this operation
manual and warranty card accompany the product.
Defi will not be held responsible for accidents or damages related to installation of this product.
When installing and operating this product, be sure to read the cautionary items in the operation manual for
the vehicle in which this product will be installed in addition to the manual of this product. Please obtain a
full understanding of the cautionary items and use the product accordingly. Before using the product,
please confirm all the components are included in the package.
Safety Warning 【Please read carefully.】
In this manual, the degree of hazard arising from actions such as improper operation is separated into the 3
levels "Danger," "Warning," and "Caution." In addition, instructions that must be followed for safe and
proper use of this product as well as practices that must be maintained are marked with a "Confirmation"
heading. Please read and become familiar with these sections.
Caution
Warning
Confirmation
Danger Indicates the imminent dangerous situation of death or serious injury if the product is
mishandled.
Indicates the possibility of death or serious injury if the product is mishandled.
Indicates a conceivable source of personal injury or damage to equipment if the product
is improperly operated.
Indicates an instruction that must be performed or practice that must be maintained.
Warning
disassemble/
modify
Caution
24V
Carefully consider the installation location and driver's operation of the product before installation. Do
not install the product where it interrupts driving and the safety deices of vehicle such as the airbag
system. Be sure not to install the unit where it could fall. Improper installation or operation could
cause the product to fall and damage the vehicle or cause serious danger by impeding driving.
Do not disassemble or modify this product. Such actions will not only void the warranty but also
damage or destroy the product.
Do not perform installation of this product immediately after the engine has been switched off. The
engine and exhaust system are extremely hot at this time and can cause burns if touched.
Ensure that the wiring of this product does not have an adverse impact on the other wiring of the vehicle. Any
controlling devices or other electronic components of the vehicle could be damaged.
Discontinue use of this product if the product doesn't operate or operates improperly. Continued use while the
condition exists could result in an accident or fire.
Please keep children and infants away from the installation area. Children may swallow small parts or be injured in other ways.
Do not install this product in the area where safety equipment such as airbags are mounted. This may cause more
injuries in the event of an accident.
Danger
Ensure that the vehicle will remain stationary and turn off the engine before installing this product. Failure to do so
could result in a fire, and could make the vehicle move during installation.
Remove the key from the ignition and disconnect the negative (-) battery terminal prior to installation of this product.
Failure to do so could result in a fire caused by an electrical short circuit.
Take care not to install this product in a way that interferes with safety equipment such as seat belts and air bag
systems or vehicle operation equipment such as engine controls, steering wheel or brake systems. Interference
with normal operation of the vehicle can result in an accident or fire.
Solder or use a solderless connector for wiring connections and make sure connections are insulated. In areas
where there could be tension or sudden impacts on the wiring, safeguard the wiring with corrugated tubing or other
shock absorbent material. Accidental shorts can cause fires.
When wiring power supply wire, to avoid the risk of electrical shock or fire, be sure to confirm that there is no
disconnection or breakage of wire. Poor connection can result in short-circuit, electrical shock, fire, or other hazards.
Discontinue use of this product if a blowout of the fuse has occurred. Continued use while the condition exists could
result in an accident, fire, or damage to the vehicle.
Use the fuse of regulated capacity when the fuse of the power wire is changed. Using a fuse that exceeds regulated
capacity may cause fire and may affect the accuracy.
Do not install the product at the wet places. It may result in a fire caused by an electrical short circuit.
This product is designed for use on 12V vehicles. Do not install this product on vehicles with 24V systems.
Insulate any unused wires. If any wires or connectors loosen during installation, please make sure
they are correctly reattached.
Do not drop any of the components of this product. It may result in damage to the product.
Do not apply excessive force on switches/terminals. It may result in damage to the product.
Do not use wires other than the provided wires.
Do not attach wires on the body of the vehicle or engine parts as this may result in damage to the product.
Install wires away from ignition and also radio signal frequency interference as this could cause the gauges to malfunction.
Do not place wires near the engine, exhaust pipe or turbine. It may result in damage or fusion of wires.
Make sure the waterproof processing is done when diverging wires in the engine compartment.
When installing the sensor, do not bend the wire near the sensor body.
Wear gloves to avoid burns when soldering and cuts when installing wires, sharp edges of parts.
Install sensors away from hot or wet places.
When using sunshade, put sunshade between products and windshield to avoid direct sun exposure .
Use the dried soft cloth for cleanup. Do not use the cleaner except for the neutral detergent. It result in the trouble.
Do not share single fuse with multiple gauges. Every gauge requires independent fuse for IGN and +B line.
Do not pull the wires out of connectors forcefully. The connectors may be broken and the
wires may be cut. When pulling out the wires, press the lock firmly and unclip the locks of
connectors.
Do not install gauges into the passenger side or center of the dashboard. It doesn't meet
vehicle safety standards.
http://www.defi-shop.com/
'12.07-2
A
Over90°
Confirmation
Be sure to follow all instructions in this manual to ensure safe installation and operation of the product.
When the negative (-) battery terminal is disconnected, equipment such as clocks and audio components having
internal memory may lose their memory data. Follow the operation manual of each component to reset data after
installation of this product.
Do not lay the gauge face down due to oil leakage. Angle "A" must be more than 90 degrees.
After installation is complete, return this operation manual, warranty card, and the package to
the customer along with the warranty.
The gauge pointer may not be in the proper position when you purchase the product. Normal
function will resume when power is connected.
Please confirm with the maintenance book on the car that the manufacturer issued when installing and detaching
genuine parts.
Before tapping wires, check the voltage of the existing wire. After tapping the wire, check the voltage of the tapped
wire again to confirm whether you have tapped into the proper place.
If car navigation system or car television is installed in vehicle, gauges and wires of this product need to be kept as
far away as possible from the wiring and installing positions of car navigation system or car television. Failure to do
so may result in interference of television display.
On no event will Nippon Seiki Co., Ltd. be liable to you for any damages or losses of genuine parts for your vehicle
while installing.
Confirmation
About Installation and Operation(for customer and installation personnel)
Warning
On no event will Nippon Seiki Co., Ltd. be liable to you for any damages arising out of the use or inability to use the
product, even if Nippon Seiki Co., Ltd. has been advised of the possibility of such damage.
Do not pull the wires out of connectors forcefully. The connectors may be broken and
the wires may be cut. When pulling out the wires, press the lock firmly and unclip the
locks of connectors.
Caution
This product cannot be linked to either the ADVANCE System or the Defi-Link System.
The information displayed on this product are for reference purposes only. Please drive according to the indication
of vehicle's originally equipped instruments.
This product uses high luminance LEDs. When several gauges are lined up, there might be color difference in the
LED production tolerance, but it is not malfunction.
Please check the installed product regularly. Durability might deteriorate according to use conditions, etc.
Please have this product installed by the retail store or dealer where it was purchased. Installation by the customer
will void the warranty.
Do not disassemble or modify this product. Such actions will not only void the warranty but also damage or destroy the product.
In order to ensure safe driving, check the information on the gauge only for short periods of time. Looking at the
display for long periods of time could distract adequate attention from the road and result in an accident.
Discontinue use of this product if the gauge doesn't operate, water gets into the unit, or smoke or a strange odor
comes from the unit. If such a condition occurs, contact the sales outlet or installation personnel as soon as
possible. Continued use while the condition exists could result in an accident or fire.
Do not operate during driving.
Fix the switch unit and other parts tightly to the vehicle to avoid that children swallow those.
[In case using screws]
Use screws commercially available as needed.
Buffer
Double
sided tape
Mounting bracket
(rear side)
Attaching position
of buffer
Holes for screws
(Φ4.4mm)
Bolt
Nut Washer
A
Over90°
■How to attach Mounting bracket set
1) Cut the double sided tape as shown in figure 1.
2) Insert convex part of the mounting bracket over the legs of the meter cup. Attach the mounting
bracket to the meter cup with the bolt, nut, and washer included in the kit as shown in figure 2.
3) Attach one piece of double sided tape and the buffer on the gauge as shown in figure 3. (Cut the
buffer into suitable length when installing Φ52(2 1/16”) series.)
4) Pass the power supply wire and the sensor wire through the hole of the meter cup and connect them
to the gauge.
5) Place the gauge in the meter cup making sure that the wires are not sandwiched.
6) Attach double sided tape on the back of the mounting bracket as shown in figure 4. Bend the
mounting bracket to conform to the structure of the location where you intend to attach it.
Confirmation
Use appropriate dashboard cleaning liquids (commercially available) to clean the area
where the double sided tape will be attached.
Do not lay the gauge face down due to oil leakage. Angle "A" must be more than 90
degrees.
If the adherence of double sided tape is not enough, use commercial tapping screws.
(c)
(b)
(a)
■How to attach boost sensor
1) The rubber hose attached to the sensor should be as short as possible. Attach the sensor with bolts
(M6) in the engine compartment in an area where it will not be subject to excess heat or vibration.
2) Access to the air pressure intake may be obtained between the surge tank and the fuel regulator.
(A)Detach the vacuum hose from the surge tank side that has less pressure oscillations and connect
it to the point (a) or (b) of the three way joint.
(B)In order to connect the surge tank with three way joint, cut the required length of the hose from
the included rubber hose.
(C)Use the remaining rubber hose to connect the sensor to the three way joint.
To sensor wire
Rubber hose
Three-way joint
Fuel regulator
Surge tank
Attach with clamps.
(commercially available)
Sensor
*Be sure to be installed facing side the
hole down.
To avoid disconnection of rubber hose and air leak, attach hose clamps or use tie-wraps to secure the
adjacent hose in the engine compartment. Disconnected hose or air leak could cause damage to the engine.
Warning
The length of the included rubber hose is 0.5m. Please adjust appropriately.
The included three-way joint can be used only for the piping inner diameter of Φ4 between the surge
tank and fuel pressure regulator. In case of other than Φ4, use another joint that fits properly.
The sensor must be installed being the rubber hose connection side faced down.
For vehicles which have a solenoid valve between the surge tank and the fuel pressure regulator,
place a three-way joint closer to the surge tank side than to the solenoid side.
Confirmation
Main Features (for customer)
SI & Imperial SeriesSI & Imperial Series
TURBO (DF065, DF115 series)
■Components
■How to wire the power supply wire
■How to use the regular position bezel
1) Disconnect negative ( - ) battery cable.
Disconnect negative ( - ) battery cable.
2) Connect the power supply wire as shown below.
3) Connect each sensor. Refer to "How to attach sensor" sections. (Except the Volt gauge)
4) Connect the sensor wire.
5) Reconnect negative ( - ) battery cable.
White wire：+ILM(Illumination)
Black wire：GND (Ground)
To 12V wire when small lamp on
To ground or negative battery terminal
Orange wire：IGN (Ignition)
To 12V wire when ignition on
Red wire：+B (12V Battery)
To 12V battery wire
Sensor wire Sensor
Power supply wire
Installation（for customer and installation personnel）
Lineup (for customer)
Product Specifications（for customer and installation personnel）
PRESS. (DF066, 116 series)
■Components
【figure 1】【figure 3】【figure 2】
【figure 4】
WEAR
SAFETY GLASSES
IMPORTANT
■Stepping motor "STEP MASTER VS-2" provides smooth operation.
■Ignition ON initiates self-luminescence gauge.
■Illumination using high-brightness LEDs
■Lightning-like Opening / Closing mode
■Self-diagnostics function monitors both sensor disconnection and short-circuiting during startup.
a) Sensor disconnection check
This function reports any in-proper connections, broken or disconnected sensor or sensor
wire. The pointer will wave between 250 and 260 degrees.
b) Short-circuiting check
This function indicates any short circuit on the sensor or sensor wire.
The pointer will wave between 10 and 20 degrees.
■Full 270°sweep dial provides ultimate visibility.
■A mounting bracket and instrument case is provided with the product.
■The red triangle of the regular position bezel can be used as a warning indicator and others.
Operation manual (this sheet) and warranty card are included other than the parts listed above. Keep them at hand.
Gauge 1pc Boost sensor 1pc Sensor wire (2.5ｍ,8 1/5ft)
1pc
Light blue
3pins
Power supply wire
(1m, 3 1/3ft) 1pc
Three way joint
1pc
Mounting bracket set
Rubber hose (0.5m, 1 3/5ft)
1pc Meter cup 1pc Regular position bezel 1pc
Double sided
tape 1pc Buffer 1pc Mounting bracket 1pc M4 bolt, nut, washer 1pc
Operation manual (this sheet) and warranty card are included other than the parts listed above. Keep them at hand.
Mounting bracket set
Double sided
tape 1pc Buffer 1pc Mounting bracket 1pc M4 bolt, nut, washer 1pc
Gauge 1pc Pressure sensor
(1/8PT) 1pc Sensor wire (2.5m, 8 1/5ft) 1pc Power supply wire (1m, 3 1/3ft) 1pc
Meter cup 1pc Regular position
bezel 1pc
Red
3pins
Red triangle
(a)
(b)
+B 0.3A
IGN 0.3A
Fuse
Φ4mm x 3
Inside
diameter
Φ4mm
TURBO
PRESS.
TEMP.
EXT.T.
VOLT
Display Range
●The red triangle can be used as an warning indicator.
●To move the position of the red triangle, remove the bezel
once and then adjust the position and attach it again.
Confirmation
When several gauges are installed into a vehicle, use each power supply wire to connect gauges to
the vehicle independently. Do not join multiple power supply wires. Do not share single fuse with
multiple gauges. Every gauge requires independent fuse for IGN and +B line.
Manual
RacerGaugeΦ52and60mm
DF06501〜DF06506,DF06601〜DF06606,DF06701〜DF06706,DF06801〜DF06806,
DF07004〜DF07006,DF11501〜DF11506,DF11601〜DF11606,DF11701〜DF11706,
DF11801〜DF11806,DF11901〜DF11903
Φ52
DF06504
DF06604
DF06704
DF06804
DF07004
Φ52
DF06505
DF06605
DF06705
DF06805
DF07005
Φ52
DF06506
DF06606
DF06706
DF06806
DF07006
-100kPa〜+200kPa
0〜1000kPa
30〜150℃
200〜1100℃
10〜15V
Φ60
DF11504
DF11604
DF11704
DF11804
DF11901
Φ60
DF11505
DF11605
DF11705
DF11805
DF11902
Φ60
DF11506
DF11606
DF11706
DF11806
DF11903
Illumination color
Size(mm) Blue Red White
BOOST
PRESS.
TEMP.
E.G.T.
VOLT
Display Range
Φ52
DF06501
DF06601
DF06701
DF06801
DF07004
Φ52
DF06502
DF06602
DF06702
DF06802
DF07005
Φ52
DF06503
DF06603
DF06703
DF06803
DF07006
Φ60
DF11501
DF11601
DF11701
DF11801
DF11901
Φ60
DF11502
DF11602
DF11702
DF11802
DF11902
Φ60
DF11503
DF11603
DF11703
DF11803
DF11903
Illumination color
Size(mm) Blue Red White
-30inHg〜30PSI
0〜140PSI
100〜300°F
400〜2000°F
10〜15V
SI models
Imperial models
→
(provided with commercial parts)
■How to attach pressure sensor for oil pressure (Use a commercial sensor attachment.)
Engine
Engine
Sensor attachment
(commercially available)
O ring
Sensor To sensor wire
Thread size 1/8PT
Detach the original
element.
Wind Teflon tape.
Be sure not to twist.
The thread size of the pressure sensor is 1/8PT. Use a sensor attachment of 1/8PT. If the thread
size of the sensor attachment for the pressure sensor is 1/8NPT, use a conversion adapter available
from hardware stores.
Tighten the sensor into the sensor attachment and then connect it to the sensor wire.
Be sure the sensor wire is not twisted when installing the sensor. The sensor wire will be cut.
Oil spills by the installation work. Please replenish the engine with oil. The engine might overheat
when oil is too little.
To avoid oil leaks by installing of the sensors, use Teflon tape. Before driving, inspect oil blocks for
leaks. Leaks could cause a fire or damage the engine.
Do not install the sensor near oil pump. Do not install the sensor to pressure switch directly. Failure to
do so could damage the sensor because the pressure pulsation is too big and exceed three times
full-scale momentarily.
To avoid the damage of the sensor wire, please fix the waterproof connector on the vehicle body and
do not bend the sensor wire near the sensor.
Warning
Confirmation
■How to attach pressure sensor for fuel pressure (Use a commercial three-way joint and hose unions.)
*Cut the fuel feed pipe and
install hose unions.
*If the material used for the
inner surface of fuel feed
pipe is resin, a hose union
may not be fixed. Check the
material before cutting the
fuel feed pipe.
Be sure the sensor wire is not twisted when installing the sensor. The sensor wire will be cut.
Before cutting the fuel feed pipe, be certain to remove the gas cap to relieve any pressure built up in the
fuel tank.
When cutting the fuel feed pipe, be certain to discharge static electricity. Otherwise, there is a possibility
of the ignition in gasoline.
Wear glasses to protect eyes when cutting the fuel filter pipe.
To avoid fuel leaks during installation of the sensor, use Teflon tape. Attach hose connection and fuel
feed tubing with clamps. Inspect pipes and hose connections for leaks before driving.
To avoid the damage of the sensor wire, please fix the waterproof connector on the vehicle body and
do not bend the sensor wire near the sensor.
The sensor must be installed on the feed (high pressure) pipe side between the fuel tank and the
fuel pressure regulator.
*It is not possible to obtain accurate fuel pressure from the return (low pressure) side at the rear of the
fuel pressure regulator.
The thread size of hose unions and the three-way joint need to be 1/8PT. Use hose unions and a
three-way joint of 1/8PT. If the thread size of the three-way joint is 1/8NPT, use a conversion adapter
available from hardware stores.
Tighten the sensor into the sensor attachment and then connect it to the sensor wire.
Warning
Confirmation
Use a commercial
conversion adapter in case
the inlet of the sensor
attachment is 1/8NPT.
Fuel pressure regulator
Three-way joint
(commercially available)
Fuel return pipe
(low pressure)
Hose union
(commercially
available)
Fuel feed pipe (high pressure)
Fix tightly with clamps.
(commercially available)
Wind Teflon tape.
Sensor
To sensor wire
↑
Thread size 1/8PT
Be sure not to twist.
Use a commercial
conversion adapter in case
the inlet of the three-way
joint is 1/8NPT.
■Power-supply voltage: 10V to 15V DC (12V vehicles only)
■Current consumption:+B line: MAX 120mA (Dark current 0mA)
IGN line: MAX 120mA
ILM line: MAX 2mA
■Temperature range (humidity is assumed to be 80% or lower) Unit: °C(°F)
Temperature range for storage Temperature range for operation
Gauge -30（-22）~ +80(176) -20(-4) ~ +60(140)
Boost sensor -30（-22）~ +100(212) -30（-22）~ +80(176)
Pressure sensor -30（-22）~ +140(284) -30（-22）~ +120(248)
Temperature sensor -30（-22）~ +150(302) -20（-4）~ +150(302)
Exhaust temperature sensor -30（-22）~ +130(266) -30（-22）~ +130(266)
*The upper temperature limit of sensor connectors is 105℃（221°F）.
*The sensing part of exhaust temp. sensor is not included in the temperature range above.
■Dial color: Black (invisible until the ignition is turned on)
■Illumination color: Blue, red, and white *The color cannot be switched.
■Dimensions: See reverse side.

Terms and Conditions (for customer)
Volt is displayed by connecting the power supply wire.
Use the tube fuse of repair part when the fuse of the power supply wire is changed. Using a
commercial fuse may affect the accuracy.
Confirmation
Repair Parts (for customer)
A. Limited Warranty
a. Our sole obligation to you after the sale of a product is to replace, without charge, the product or any
component thereof discovered to bee defective within a period of one (1) year from the purchasing
date(the "Warranty Period"). You accept sole responsibility for the proper assembly operation and
regular maintenance of the product. This limited warranty is void if any product is damaged by
accident, misuse, improper installation, or abuse, including tampering or damage in transit. Further,
this limited warranty is void if you sell or otherwise transfer a product to a third party, regardless of
whether the transfer takes place within the Warranty Period.
b. Out liability to you resulting from the sale of any product, including liability for any latent defects found
within the Warranty Period, shall not exceed the total purchase price paid for the product by you.
c. YOU UNDERSTAND AND AGREE THAT WE MAKE NO REPRESENTATIONS OR WARRANTIES OF
ANY KIND, EXPRESS OR IMPLIED ASTO ANYMATTER WHATSOEVER, INCLUDING THE
CONDITION OF THE PRODUCT OR ANY COMPONENT PARTS THEREOF, ITS
MERCHANTABILITYOR ITS FITNESS FOR ANY PARTICULAR PURPOSE ANDYOU ACCEPT IT,
"AS IS," "WHERE IS."
d. You also understand that we are not granting any express warranties, other than those stated herein.
These include only those warranties enumerated in paragraph A. a. There are no other express
warranties granted anywhere in these terms and conditions of sale, and you understand and agree to
this fact as part of the bargained for exchange of this sale. Nowhere else, except as stated in this
paragraph, in this contract is there intended, by either party, for there to be any express warranties
granted to you.
e. EXCEPT AS OTHERWISE PROVIDED HEREIN, WE SHALL NOT BE LIABLE FOR DAMAGES,
INCLUDING SPECIAL, INCIDENTALOR CONSEQUENTIAL DAMAGES WHETHER IN CONTRACT
OR IN TORTARISING OUT OF OR IN CONNECTION WITH THE PERFORMANCE OFANY
PRODUCT OR ANYCOMPONENT PART THEREOF OR ITS USE BY YOU,AND WE SHALL NOT
BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGESARISING OUT OF
OR IN CONNECTION WITH YOUR USE OF THE PRODUCT.
f. The warranty on this product is void if the product is modified, changed, adjusted or damaged. This
product is to be used only in the ways for which it is designed and marketed for, any deviations from
the intended uses will void the warranty and will excuse any possible liability of ours.
g. You accept sole responsibility for the proper assembly, operation and regular maintenance of the
product. This limited warranty is void if the product is damaged, changed, altered, or modified by
accident, misuse, improper installation , or abuse, including tampering or damage in transit or while in
use. YOU HAVE MADE AN INDEPENDENT INVESTIGATION OF THE PURCHASED
COMPONENTS AND HAVE RELIED SOLELY ONYOU OWN INVESTIGATION, BARGAININGAND
JUDGMENT IN REFERENCE THERETO. YOU ACKNOWLEDGE THAT YOU ARE NOT RELYING
ON OUR SKILL OR JUDGMENT TO SELECT OR FURNISH GOODS SUITABLE FOR ANY
PARTICULAR PURPOSE IN PURCHASING OUR PRODUCTS, YOU HAVE NOT RELIED OR
ACTED UPON ANY REPRESENTATIONS OR WARRANTIES ON OUR PART NOTSPECIFICALLY
SET FORTH HEREIN.
h. This limited warranty gives you specific legal rights. You may also have other rights which vary from
state to state. Some states do not enforce contractual limitations on how long an implied warranty
lasts, when an action may be brought, or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.
B. Modification Strictly Prohibited
You understand and agree that any modification whatsoever , of the product, is strictly prohibited. You
also agree not to modify the product in any manner regardless of whether such modification is
material or immaterial. You also acknowledge that any modification of the product will void your
limited warranty and bar you from any recovery or any remedy in a court of law or equity. Modification
is strictly forbidden unless expressly authorized by our prior written approval. You agree not to make
any modifications to the product and agree not to use any parts, components, or accessories in
connection with the installation and use of the product that are not authorized and approved by us.
C. Indemnity and Release
a. You understand and agree that many factors beyond our control affect the operational safety of the
product, including but not to limited to the installation of the product according to the instructions
provided with the product.
b. You also understand and agree that the installation of the product may involve the use of tools,
equipment and construction methods which may present safety hazards which are beyond our
control. You also understand and agree that the use of some of our products may create hazards and
lower your ability to control your vehicle.
c. You agree, as part of the bargained for exchange, to protect, indemnify, save harmless and release
us, our authorized agents, employees, officers, directors and shareholders from and against all
liabilities, obligations, claims, damages, penalties, causes of action, costs and expenses, imposed
upon or incurred by or asserted against us or any assignees of ours, by you or any third party by
reason of the occurrence or existence (or alleged occurrence or existence) of any use, installation,
assembly, possession or operation of the product, any loss, damage or destruction of the product as
of and after delivery(a "casualty occurrence"), and any other act or event relating to or caused by the
product, including but not limited to, consequential or of the terms and conditions hereof, or any and
all liability for property loss or damage, or any and all damage resulting from death or personal
injuries, including loss of services which any person may sustain on account of, arising out of, or in
connection with any use, maintenance, possession or operation of the product. In the event that any
action, suit or proceeding is brought against us or any of our authorized agents, employees, officers,
directors or shareholders by reason of any such occurrence, you will, upon our request and at your
expense, resist and defend such action, suit or proceeding or cause the same to be resisted and
defended by counsel designated and approved by us.
LIMITED PRODUCT WARRANTYAND LIMITED PRODUCT LIABILITY
TEMP. (DF067, 117 Series)
■Components
Gauge 1pc Temperature sensor
(1/8PT) 1pc Sensor wire (3m, 10ft) 1pc Power supply wire (1m, 3 1/3ft) 1pc
Meter cup 1pc Regular position
bezel 1pc
Red
2pins
■Components
Gauge 1pc Exhaust temperature
sensor 1pc Sensor wire (2.5ｍ,8 1/5ft) 1pc Power supply wire (1m, 3 1/3ft) 1pc
Meter cup 1pcFitting (1/8PT) 1pc Regular position
bezel 1pc
Black
2pins
EXT.T. (DF068, 118 series)
■How to attach Volt gauge
■Components
Gauge 1pc Power supply wire
(1m, 3 1/3ft) 1pc Meter cup 1pc Regular position
bezel 1pc
VOLT (DF070, 119 series)
Optional Parts (for customer)
Troubleshooting (for customer and installation personnel)
If operation of the product seems unusual, inspect the product to confirm that there is no malfunction.
If an operational problem has occurred, it could result in an accident.
※In addition to a general inspection of the product, use the following table to confirm proper operation of the unit.
Condition Possible Cause Corrective Action
Item Model Number
○Disconnection of sensor or sensor wire
○Connector is unhooked.
○Incorrect wiring
○A gauge lapses into the
disconnection check mode.
(Except VOLT gauge)
○Check the disconnection of connectors
and wires.
○Sensor or sensor wire has a short
circuit.
○Sensor or sensor wire is shorted to
the vehicle body.
○A gauge lapses into the short
circuit check mode. (Except
VOLT gauge)
○Look for the point of short circuit with the
following procedures.
【Step 1】Unplug the sensor from sensor wire.
<1> The gauge lapses into the
disconnection check mode.
→Short circuit of the sensor.
<2> The short circuit check mode
continues. →Go to【Step 2】
【Step 2】Unplug the sensor wire from the gauge.
<1> The gauge lapses into the
disconnection check mode.
→Sensor wire has a short circuit.
○Fuse on the power supply wire is
blown out.
○A gauge doesn't operate. ○Check the wiring.
○Do not share single fuse with multiple
gauges. Every gauge requires
independent fuse for IGN and +B line.
○Wiring of IGN wire or GND wire of
the power supply wire to the vehicle
is wrong.
○Fuse on the IGN wire of the power
supply wire is blown out.
○A gauge doesn't perform the
opening mode. ○Check the wiring.
○Replace the fuse of the power supply
wire.
○Wiring of constant battery+ wire of
the power supply wire to the vehicle
is wrong.
○Fuse on the constant battery+ wire of
the power supply wire is blown out.
○A gauge doesn't perform the
closing mode. ○Check the wiring.
○Replace the fuse of the power supply
wire.
○Wiring of ILM wire of the power
supply wire to the vehicle is wrong.
○Dimmer is not working. ○Check the wiring.
○Wrong wiring of the power supply wire
○Malfunctioning operation ○Check the wiring.
※If the problem is not solved after the remedies mentioned above are tried:
⇒Ask the installation personnel or the shop you purchased the gauge for inspection.
⇒Purchase new parts for replacing wear-out parts .
Warning
Fuse 0.3A (2pcs)
Mounting Bracket set for Φ60mmgauge
Power Supply wire
Boost Sensor
Boost Sensor wire
Pressure Sensor(1/8PT)
Pressure Sensor wire
Temp. Sensor(1/8PT)
Temp. Sensor wire
Exhaust Temp. Sensor
Exhaust Temp. Sensor wire
1/8PT Fitting for Exhaust Temp. Sensor
PDF06508G
PDF07809G
PDF06504H
PDF06503S
PDF06505H
PDF00703S
PDF06603H
PDF00903S
PDF05602H
PDF01103S
PDF06803H
PDF01105G
Mounting Bracket set for Φ52mmgauge PDF06507G
Item Model Number
Boost Sensor extension wire 1m(3 1/3ft.)
Pressure Sensor extension wire 1m(3 1/3ft.)
Pressure Sensor extension wire 2m(6 3/5ft.)
Temp. Sensor extension wire 1m(3 1/3ft.)
Temp. Sensor extension wire 2m(6 3/5ft.)
Exhaust Temp. Sensor extension wire 2m(6 3/5ft.)
PDF06002H
PDF06013H
PDF00707H
PDF06014H
PDF00906H
PDF01107H
Operation manual (this sheet) and warranty card are included other than the parts listed above. Keep them at hand.
Mounting bracket set
Double sided
tape 1pc Buffer 1pc Mounting bracket 1pc M4 bolt, nut, washer 1pc
Operation manual (this sheet) and warranty card are included other than the parts listed above. Keep them at hand.
Mounting bracket set
Double sided
tape 1pc Buffer 1pc Mounting bracket 1pc M4 bolt, nut, washer 1pc
Operation manual (this sheet) and warranty card are included other than the parts listed above. Keep them at hand.
Mounting bracket set
Double sided
tape 1pc Buffer 1pc Mounting bracket 1pc M4 bolt, nut, washer 1pc
→
(provided with
commercial parts)
Engine
Sensor attachment
(commercially available)
O ring Sensor
Detach the original element.
Wind Teflon tape.
Be sure not to twist.
■How to attach temperature sensor for oil temperature (Use a commercial sensor attachment.)
Do not put the sensor in the side hole.
The depth of the hole for the sensor
must be more than 30mm (1.2”). Thread size 1/8PT Engine
To sensor wire
The thread size of the temperature sensor is 1/8PT. Use a sensor attachment of 1/8PT. If the thread
size of the sensor attachment for the temperature sensor is not 1/8PT, and you use a conversion
adapter available from hardware store, note that the temperature is displayed lower than the actual
value.
The depth of the hole for the sensor must be more than 30mm (1.2”).
Tighten the sensor into the sensor attachment and then connect it to the sensor wire.
Be sure the sensor wire is not twisted when installing the sensor. The sensor wire will be cut.
Oil spills by the installation work. Please replenish the engine with oil. The engine might overheat
when oil is too little.
To avoid oil leaks by installing of the sensors, use Teflon tape. Before driving, inspect oil blocks for
leaks. Leaks could cause a fire or damage the engine.
To avoid the damage of the sensor wire, please fix the waterproof connector on the vehicle body and
do not bend the sensor wire near the sensor.
Warning
Confirmation
Radiator
Attach tightly with clamps.
(commercially available)
Wind Teflon tape.
Sensor →To sensor wire
Thread size 1/8PT
Be sure not to twist.
*Cut the upper hose and connect the
sensor attachment between hoses.
Upper hose
Sensor attachment
(commercially available)
Be sure the sensor wire is not twisted when installing the sensor. The sensor wire will be cut.
Coolant spills by the installation work. Please replenish the engine with coolant and bleed the air
from the system, or the engine might overheat.
To avoid water leaks during installation of the sensors, use Teflon tape. Attach the sensor
attachment and upper hose with clamps. Inspect hose connections for leaks before driving.
To avoid the damage of the sensor wire, please fix the waterproof connector on the vehicle body and
do not bend the sensor wire near the sensor.
The thread size of the temperature sensor is 1/8PT. Use a sensor attachment of 1/8PT. If the thread
size of the sensor attachment for the temperature sensor is not 1/8PT, and you use a conversion adapter
available from hardware store, note that the temperature is displayed lower than the actual value.
Tighten the sensor into the sensor attachment and then connect it to the sensor wire.
Confirmation
Warning
■How to attach temperature sensor for water temperature (Use a commercial sensor attachment.)
Thread size 1/8PT
Exhaust manifold
Make a threaded screw
hole (1/8PT).
Sensor wire
Fitting(b)
Bushing
Exhaust temperature sensor
Fitting(a)
The thread size of the fitting is 1/8PT. Make a threaded screw hole of 1/8PT.
Tighten the sensor into the sensor attachment and then connect it to the sensor wire.
Confirmation
To avoid personal injury, do not install the exhaust temperature sensor while the engine is hot.
When making a hole, make sure no chip remains in the exhaust pipe or turbine. It may result in
damage to the engine, exhaust pipe, or turbine.
Warning
1) Make a 1/8PT threaded screw hole in the exhaust manifold pipe. (Weld if the pipe wall thickness is not enough）
2) Dismantle the fitting. Do not crush the bushing inside the fitting.
3) Tighten the fitting(a) to the hole of the exhaust manifold.
4) Pierce the sensor through the fitting(b) and the busing.
5) Insert the edge of the sensor into the fitting(a) and position it at the center of the exhaust pipe.
6) Tighten the fitting(b).
■How to attach exhaust temperature sensor for exhaust temperature
Racer Gauge Φ52,Φ60 Operation Manual
■Issue First edition: September, 2011 Second edition: July, 2012
■ManufacturerNippon Seiki Co., Ltd.
■Contact Information Nippon Seiki Co., Ltd. Defi Business Division
【Address】190-1 Fujihashi 1-chome, Nagaoka-shi, Niigata 940-2141 JAPAN
【URL】http://www.defi-shop.com/
Patent pending PAT. 3624865 PAT. 3365604
Maintenance & Check/Warranty & Servicing
■Warranty card・Terms and conditions
This product is delivered with this operation manual and a warranty card. Please read terms and conditions in
this manual thoroughly and keep the warranty card in a safe place. Failure to show this warranty will void the
warranty.
■Warranty period
Limited one year warranty. The warranty period starts at the date of retail purchase by the original end-user
purchase. Please confirm the warranty card is provided with the information of retail store where purchased.
Please refer to Limited Warranty for details.
■Inspection
Please ask the shop you purchased the product for inspection if any defect in product is suspected. We don't
accept the order of fixing because Defiproducts require installation and wiring to the vehicle. In case you cannot
go to the shop you purchased because of move-out or closure of shop, please ask the nearest DefiDistributor
listed in the Defiwebsite.
For a repair/inspection service, take the warranty card and customer contact information with you.
■Label
The label sticked on the product is for the product traceability. Do not peel it off.
■Repairing
When a repair is necessary, we will return the inspection result report through the store to you. After receiving a
repair service request, we start repairing. Ask the store how much it costs and how long it takes to repair.
■Discarding the products
Please dispose products in accordance with disposal laws, state laws and local government. A recycle label on
the package indicates that the package is recyclable.
Except in the case of defects, we shall not be liable for any trouble including violation, accident or improper
wiring resulting from using this product.
The warranty does not cover any unauthorized repair performed or caused to be performed by the end user.
Such action can destroy or damage this product.
A
B
C
D
E
F
G
Φ52
58.3
51.8
15.2
67.9
61.9
15°
25°
Φ60
66.3
52.2
15.5
70.2
70.5
15°
32°
Gaugediameter
Gaugediameter
ΦA
C
B
Dimensions in mm (1mm=0.039in)
ΦE
F
G
D
